Hiland Premium Series User manual

OWNER’S MANUAL
WA ING
Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-775-1330, 7 a.m. - 4 p.m., PST, Monday – Friday. Or email us
at [e-mail].
MODEL #FTB-51161B
ATTACH YOUR RECEIPT HERE
Serial Number
Page 1 of 6

WARNINGS:
OWNER'S MANUAL
•The metal may become very hot during and after use. Do not touch the metal or try to move
the unit while hot.
•Keep children away from the unit while in use until the fire is extinguished and the metal has
cooled.
•Do not use on a wooden surface, or on grass, near walls or flammable articles, or under
overhead coverings. Keep at least 2 feet away from all other articles during use.
•This fire bowl is intended for outdoor use only. Do not use on wooden decks.
•This fire bowl is intended to burn wood logs only. Do not burn coal, leaves, or other
combustible materials in the fire bowl.
•Do not overload the fire bowl with wood logs.
•Not for use by children. Keep children and pets away from the fire bowl.
•The fire bowl is hot. Use with caution. Do not touch the hot fire bowl with bare hands.
•Never leave the burning fire bowl unattended, and always extinguish the fire completely
before leaving the fire bowl.
•Do not use near flammable or combustible objects or materials.
•When the fire bowl is in use, the handle on the mesh screen can reach extreme temperatures
that can cause serious injury to an unprotected hand. Use a poker or an appropriate heat
resistant glove or pad when handling.
•Check local fire regulations and municipal by-laws for safe use.
•Fuels used in wood or charcoal burning appliances,and the products of combustion of such
fuels,contain chemicals known to the state of California to cause cancer and birth defects or
other productive harm.
Page 2 of 6

FIRE PIT PARTS LIST
HARDWARE LIST
NO. PARTS QTY
J M6*12 Bolt 4
K M6*18 Bolt 8
Tools required :Screw driver(not included)
OWNER'S MANUAL
M6 Nut
L9
No. PARTS Qty
A Lift Handle 1
B Screen 1
C Log Grate 1
D Fire Bowl 1
E Slate Top 1
F Corner Posts with
Side Panel 2
G Side Panel 2
H Poker 1
I
Cover 1
Page 3 of 6

Page 4 of 6
FIG 1
FIG 2
FIG 5
FIG 4
FIG 3

Assembly Steps:
Step 1: Place Slate Top (E) upside down on a protected flat surface. Then
attach one Corner Posts with Side Panel (F) to Slate Top (E) by using M6x12
Bolt (J) screw. Hand tighten bolts,But do not fully tighten. Repeat for
another Corner Posts with Side Panel (F) . (See FIG 1)
Step 2: Attach one Side Panel (G) between two Corner Posts with Side Panel
(F) by using 4 M6 x18 Bolts (K) and Nuts (L). Hand tighten bolts,But do not fully
tighten. Repeat for another Side Panel (G). (See FIG 2)
Step 3: Check alignment and make any necessary adjustments.Tighten all bolts
with screw driver.
Step 4: Assemble the Screen (B) by using Lift Handle (A) and M6 Nut (L).
(See FIG 3)
Step 5: Turn the assembled table top to upright position, put Fire Bowl (D) onto the
Slate Top (E) and place Log Grate(C) into Fire Bowl (D). (See FIG 4), Finally put
the screen (B) on the fire bowl. (See FIG 5),
Your fire pit is ready for use now. Once fire pit has cooled after use ,use
cover to protect against rain and dust .
Page 5 of 6

AZ Patio Heater, LLC (“Vendor”) warrants to the original retail purchaser of this heater to no other
person, that if this heater is assembled and operated in accordance with the printed instructions
accompanying it, then for a period of one year from the date of purchase, all parts in such heater
shall be free from defects in manufacturing and workmanship. Vendor may require reasonable
proof of your date of purchase from an authorized retailer or distributor. Therefore, you should
retain your sales slip or invoice. This limited Warranty shall be limited to the repair or replacement
of parts, which prove defective under normal use and service and which the vendor shall
determine in its reasonable discretion upon examination to be defective. Before returning any
parts, you should contact Vendors customer service department using the contact information
listed below. If Vendor confirms, after examination a defect covered by this limited warranty in any
returned part, and if Vendor approves the claim, Vendor will replace such defective part without
charge. If you return defective parts, Transportation charges must be prepaid by you. Vendor will
return replacement parts to the original retail purchaser, Freight or postage prepaid.
The limited Warranty does not cover any failures or operating difficulties due to accident, abuse,
misuse, alteration, misapplication, improper installation or improper maintenance or service by
you or third party. The failure to perform normal and routine maintenance on the product,
shipping, damage, abnormal adjustment to the burner, damage or repairs related to insects, birds,
or animals of any kind, and damage due to weather conditions as set out in this owner’s manual.
In addition, the Limited Warranty does not cover damage to the finish such as scratches, dents,
discoloration, rust or weather damage, after purchase. Please protect your investment.
The limited Warranty is in lieu of all other warranties offered by any retail company. Vendor
disclaims all warranties for products that are purchased from sellers other than authorized
retailers or distributors. AFTER THE PERIOD OF THE 1 YEAR WARRANTY, VENDOR
DISCLAIMS ANY AND IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. FURTHER, VENDOR SHALL HAVE NO LIABILITY WHATSOEVER TO
PURCHASER OR ANY THIRD PARYY FOR ANY SPECIAL, INDIRECT, PUNITIVE,
INCIDENTAL, OR CONSEQUENTAL DAMAGES. Vendor assumes no responsibility for any
defects caused by third parties. This limited warranty gives the purchaser specific legal rights; a
purchaser may have other rights depending upon where he or she lives. Some jurisdictions do not
allow the exclusion or limitation of special, incidental or consequential damages, or limitations on
how long a warranty lasts, so the above exclusion and limitations may not apply to you.
Vendor does not authorize any person or company to assume for it any other obligation or
liability in connection with the sale, installation, use, removal, return, or replacement of its
equipment, and no such representations are binding on vendor.
For warranty service, please contact [email protected] or call us toll free at
888‐775‐1330.
