Belson Outdoors PLS6NB-P User manual

Model # PLS6NB-P Instructions Sheet
www.belson.com
ECONO-MIZER BENCH
627 Amersale Drive
Naperville, IL 60563
Phone: [phone]
Fax: [phone]
[email protected]

FP - FASTENER PACK
( 1 ) - ONE FASTENER PACK
A - BENCH END
( 3 ) - BENCH END
B - BENCH
( 3 ) - THREE BENCH BOARDS
www.belson.com
BEFORE ASSEMBLY, PLEASE MAKE SURE ALL COMPONENTS ARE INCLUDED.

www.belson.com
1 - #3 PHILLIPS DRIVE BIT
ALSO NEEDED FOR THIS ASSEMBLY WILL BE THE FOLLOWING MATERIALS:
18 - #12 X 2 1/2” FLAT HEAD PHILLIPS SCREW
BEFORE ASSEMBLY, PLEASE MAKE SURE ALL FASTENERS ARE INCLUDED.

#12 X 2 1/2” FLAT HEAD
PHILLIPS SCREW
www.belson.com
STEP #1:
PLACE ( 1 ) ONE BENCH END IN POSITION AS SHOWN ABOVE BEING SURE TO ALIGN THE PRE-DRILLED
HOLES TO THE PILOT HOLES IN THE BENCH BOARDS. AFTER THE HOLES ARE PROPERLY ALIGNED, FASTEN
WITH ( 1 ) ONE #12 X 2 1/2” FLAT HEAD PHILLIPS SCREW PER HOLE TO SECURE.
NOTE: DO NOT TIGHTEN SCREW COMPLETELY. THIS WILL BE DONE IN A LATER STEP.

#12 X 2 1/2” FLAT HEAD
PHILLIPS SCREW
www.belson.com
STEP #2:
REPEAT STEP #1 FOR THE REMAINING ( 2 ) TWO BENCH ENDS IN THE POSITIONS SHOWN ABOVE BEING
SURE TO ALIGN THE PILOT HOLES TO THE PRE-DRILLED HOLES IN THE BENCH BOARDS. AFTER THE
HOLES ARE PROPERLY ALIGNED, FASTEN WITH ( 1 ) ONE #12 X 2 1/2” FLAT HEAD PHILLIPS SCREW PER
HOLE TO SECURE.
NOTE: DO NOT TIGHTEN SCREWS COMPLETELY. THIS WILL BE DONE IN A LATER STEP.

www.belson.com
STEP 3:
REPEAT STEPS #1 AND #2 TO FASTEN THE REMAINING ( 2 ) TWO BENCH BOARDS IN POSITION AS
SHOWN ABOVE. BE SURE TO ALIGN THE PRE-DRILLED HOLES TO THE PILOT HOLES IN THE BENCH ENDS.
AFTER THE HOLES ARE PROPERLY ALIGNED, FASTEN WITH ( 1 ) ONE #12 X 1/2” FLAT HEAD PHILLIPS
SCREW PER HOLE TO SECURE.
NOTE: BE SURE TO TIGHTEN ALL SCREWS COMPLETELY AFTER THIS STEP.
#12 X 2 1/2” FLAT HEAD
PHILLIPS SCREW
