himbol Memory I User manual

Video Recording Monitor
Memory Ⅰ
Instruction Manual
Shenzhen ZO Video Technology Co., Ltd.

Packing list
Monitor*1
30cm HDMI Cable*1 Hot Shoe Mount*1
Tempered Screen Protector User Manual
TF Card SD card holder
Monitor*1 30cm HDMI Cable*1
Tempered Screen Protector*1
User Manual*1
TF Card*1
SD card holder*1
Hot Shoe Mount*1
User Manual

Buttons and Ports
1 2
3
4
5
6
7
7
8
9
10
1234
5678
9
Power ON/OFF Button
DC Input
NP-F Battery Plate
SD Card Slot
10 Heat Dissipation Port
1/4”-20 Thread Hole USB Upgrade Port
Custom Function Buttons HDMI Input 3.5mm Headphone Jack

1
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
7
2 3 4 5
1
2
3
4
5
6
7
User Interface
Resolution
Waveform Menu
Marker Menu
Focus Menu
Exposure Menu
Color Menu
Recording & Playback
Menu
System Settings
Playback Button
Audio Meter
REC Button
Zoom
SD Card
3D-LUT
Fan Status
Power Indication
6
3840*2160 30p LUT 7.6VDC

Scope Menu Marker Menu
User Interface
Focus Menu Exposure Menu
Color Menu Recording & Playback Menu
3840*2160 30p LUT 7.6VDC
Scope menu
Waveform
Opacity 50%
RGB-paral Histogram Vector
3840*2160 30p 7.6VDC
Marker menu
Safe area
Safe area
Color
Width
Ratio
Grip Anamorphic N ext
12 3
80%
96%
85% 90% 93%
7.6VDC
Focus menu
peaking Zoom
3840*2160 30p 7.6VDC
Exposure menu
Zebra
Zebra pattern
Maximum
Minimum
50%
50%
False color Monochrome
peaking
Color
Sensitivity 50%
3840*2160 30p 7.6VDC
Color menu
3D-LUT Gamma HDR ColorTemp
3840*2160 30p 7.6VDC
Recording and playback menu
Recording
Mode
Playback
Gamma curve
Value
HDR
2.2 2.4 2.6
User Trigger Timecode
File naming
ZO-A-SCE-001
3840*2160 30p
LUT
LUTLUT
LUTLUT
Recording Definition
LT HQ XQ

Function Instruction
1.Short press the power on/off button to turn on the monitor, long press
3 seconds to turn it off.
2.3D-LUT import method
Place the LUT file in the LUT folder on the SD card and insert the
SD card into the monitor
Click on the LUT file that needs to be loaded, then click Import and
wait for the file to be imported into the system
Click the LUT file, enter the file selection, select the desired LUT,
and click to confirm that the LUT is loaded successfully
Note: LUT file name only support English, do not allow any other
languages , special characters, spaces, otherwise it will fail to be
imported !
1
2
3
4
Click the Color Menu-3D-LUT, turn on , and then selecting
Custom, click the Import button and wait for the system to retrieve
the LUT file in the SD card that needs to be loaded
3840*2160 30p 7.6VDC
Color menu
3D-LUT Gamma HDR ColorTemp
LUT
LUT Selection
LUT file XXXXXXXXXX
HDR
Preset User
Import Delete
LUT

Function Instruction
1
2
3
4
This position represents the camera position, click up and down to adjust
Trigger/TimeCode camera synchronization recording function
This position represents the shooting site, click up and down to adjust
This position represents the number of cameras, it is not adjustable and
the digital number increases with the number of shootings
3.The Way to Customize the File Name
234
3840*2160 30p 7.6VDC
Recording and playback menu
Recording
Mode
Playback
User Trigger Timecode
File naming
ZO-A-SCE-001
1
LUT
Recording Definition
LT HQ XQ

Function Instruction
4.RGB Gain and Offset Control Functions
5.Formatting SD Cards
Setting
Function
System
RGB gain
R100%
G
B
Reset
100%
100%
RGB offset
R100%
G
B
Reset
100%
100%
RGB gain
RGB offset
3840*2160 30p 7.6VDC
Display
LUT
3840*2160 30p 7.6VDC
Display
Setting
Function
System
Scan Underscan
Backlight
Volume
SD card format
Fan status: Automatic Off Slow Fast
Normal
50%
50%
LUT

Notes
1.Correlation of Function States
2.SD Card Identification and Use Problems
3.The Abnormal Phenomenon of Using Recording and Playback
Zoom, Anamorphic, Waveform, these three functions can only be opened
one at a time. Such as when the Anamorphic function is open, has opened the
Zoom or Waveform will be forced to close
2.1 The SD card of this product does not support hot-swapping, if the SD card is
inserted and removed during use, causing abnormalities such as the card
cannot be recognized and the screen interface cannot be operated, please
restart the device
2.2 The SD card format used in this monitor is FAT32 and it is different from the
card format used in the camera,so can not be mixed
2.3 The newly purchased SD card has to formatting before normal use
2.4 Recommended card capacity is 32G-512G
Synchronous recording (Trigger/TimeCode)
3.3 Some of the cameras have been having TimeCode output, when
TimeCode mode ON, will trigger automatic recording
3.2 Trigger/TimeCode function is turned on
3.1 The camera needs to support HDMI Trigger/TimeCode

1
2
2
1
Technical Parameters
Interface:
Model No.:
Power Supply Method
Input Voltage
Screen Resolution
Memory Ⅰ
Weight
Unit Size
Please note:
Brightness
Contrast Ratio
Screen Size
DC In , HDMI input, 3.5mm Headphone out, SD card
slot, Type-C
NP-F / DC IN
DC 6.5V-16.8V
1920*1080
2000cd/m²
1200：1
5.5''TP
4096*2160P25/24/23.98
3840*2160P30/23.98/25/24/23.98
1920*1080p60/59.94/50/30/29.97/25/24/23.98
1920*1080i60/59.94/50
1280*720p60/59.94/50
MP4(A single file can't exceed 3.85G)
Recording file It is under "Video" folder of root directory in
SD card.
It is under "Lut" folder of root directory in
SD card, and the LUT files should not
exceed 50.
The LUT file to be imported
SD card updates
48kHz
283g
146.6*87.6*26.5mm
Power Consumption
<9W
Input Signal Formats
Video Recording Format
cube file（17*17*17和33*33*33）
LUT Format
Firmware Updates
Audio Frequency

Tel[phone]
URL:www.zeroone-video.com
Address:2C, 2nd Floor, Building 6, Longbi Industrial Park
No.27 Dafa Road, Bantian Street, Longgang District, Shenzhen
Shenzhen ZO Video Technology Co., Ltd.
