IEEE1394.b
Progressive Scan CCD Camera
KP-F140F
Specifications
Aegis Electronic Group
www.aegiselect.com

2 / 12
1. General
The KP-F140F is single CCD type camera which utilized the progressive scan CCD image sensor
with square pixel for SXGA format of 1 / 2-inch.
By adoption of an IEEE1394.b interface, high-speed connection of maximum of 800 Mbps can be
possible. Moreover, by daisy chain, construction of multiple camera system can be easily performed.
2. Principal features
1) High resolution
The 1/2-inch 1,450,000 pixels square lattice progressive scan CCD achieve a high resolution and
of 1360(H) x 1024(V) (SXGA).
2) IEEE1394.b interface
High-speed serial interface IEEE1394.b is supported and direct connection is possible to PC by
the diameter cable of thin as compared with parallel output. It is possible to be supplied power and
trigger by one cable, and connectable to a 4 sets/port by daisy chain.
3) IIDC1.31 correspondence
Based on uncompressed data protocol IIDC1394-based Digital Camera Specification Ver.1.31, a
maximum of 800Mbps high speed data transmit is available and suitable for image processing.
4) Various output formats
Various output formats are available, such as the high quality picture format and the high frame
rate for multiple connection picture format, according to the usage and the situation.
Ex. SXGA: 1360(H) x 1024(V) / Mono8nit / 15fps
VGA: 640(H) x 480(V) / Mono8bit / 30fps x 4 sets
5) A daisy chain
The KP-F140F have two IEE1394.b connectors, it can link together cameras. Since one PC and
the minimum number of cable can control the plural camera, simple system integration can be
realized.
6) CCD drive functions
･Auto electronic Shutter mode (AES)
Adjusted automatically from approx. 1/100,000 second to 10 second.
･Variable electronic shutter mode
Variable from approx. 1/100,000 second to 10 second.
7) External trigger
An external trigger signal input can be used to capture an image at desired timing for instant view
or processing. The software trigger via an IEEE1394 cable and our original system corresponding
to the hardware trigger can deal with all trigger signals.
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

3 / 12
3. Specifications
1) Imaging device : 1/2-inch progressive scan interline CCD
(with on-chip microlenses)
Total number of pixels : 1434(H) x 1050(V)
No. of effective pixels : 1392(H) x 1040(V)
Unit cell size : 4.65(H) x 4.65(V) µm (Square pixel)
2) Scanning system : Progressive scan
3) Sync system : Internal / external
4) Video signal output
Interface : IEEE1394.b (FireWire 800)
Protocol : IEEE1394-based Digital Camera Specification Version 1.31 compliant
Transfer rate : 800 / 400 / 200Mbps
Image format : MONO8 / MONO16
Image size : 1360(H) x 1024(V)
1280(H) x 960(V)
1024(H) x 768(V)
800(H) x 600(V)
640(H) x 480(V)
Frame rate : 15fps (Condition: Mono8, 1392(H) x 1024(V))
5) Camera remote : IEEE1394 control
6) Standard sensitivity : 2000 lx F8
7) Minimum illumination : 5 lx (F1.4, Max gain)
8) Gain : Auto / Manual (0dB to 18dB)
9) Electric shutter speed : Auto (AES) / Manual (VARIABLE)
From 1/100,000 second to 10 second
10) External trigger shutter : Mode Fixed shutter (Mode 0)
One trigger (Mode 1)
Reset control (Mode 14)
VD Sync (Mode 15)
Input Via IEEE1394 cable (Software trigger )
Our company original method (Hardware trigger)
11) Auto Exposure (ALC: Auto level control)
: Adjustable for video level
12) Gamma : OFF / LUT
13) Sharpness : Adjustable
14) Brightness : Adjustable
15) Time stamp : OFF / ON
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

4 / 12
16) Cycle timer sync : OFF / ON
17) HD reset : OFF / ON
18) Daisy chain : Possible, Even if there is no repeater.
Iftwoisconnected,theframeratebecomeshalf.
19) Lens mount : C mount (Flange-back adjustment)
20) Power supply : DC+8V to +30V (Via IEEE1394 cable)
21) Power consumption : Approx. 4.1W (DC+12V)
22) Ambient temperature
Operating : -10 ℃to +50 ℃/ 30 to 80 %RH
Note : If operated continuously, be sure to use at less than +40 ℃(104F)
for long term stable performance.
Storage : -20 ℃to +60 ℃/ 20 to 90 %RH
23) Vibration endurance : 68.65 m/s2or less
(10 to 200Hz, 30 minutes each on XYZ axes)
(Do not subject to strong vibration for long periods of time.)
24) Shock endurance : 490.3 m/s2 or less (vertical, horizontal, once each face)
25) External dimensions : 44(W) x 44(H) x 54(D) mm
(not including lens and protrusions)
26) Mass : Approx. 130g (without lens)
27) Supplied equipment : Camera
CD-ROM (Operation manual / Driver soft)
28) Optional accessories : IEEE1394 cable (with Locked mechanism)
Tripod adopter (TA-FD140)
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

5 / 12
4. Video format
A. Fixed format
Frame Rate
Format Mode Image Size Color Coding 30 15 7.5 3.75 1.875
5 640 x 480 YMONO8 ○○○○○ 0
6 640 x 480 YMONO16 ○○○○○
2 800 x 600 YMONO 8 －○○
5 1024 x 768 YMONO 8 －○○○○
6 800 x 600 YMONO 16 －○○○
1
7 1024 x 768 YMONO 16 －○○○○
2 1280 x 960 YMONO 8 －○○○○ 2
6 1280 x 960 YMONO 16 －○(*) ○○○
B. Free format (Format7)
Format Mode Image Size Color Coding Packet Size [Byte]
1360 x 1024 YMONO 8 8192 (*) 6144 (*) 4096 20487 0
1360 x 1024 YMONO 16 8192 (*) 6144 (*) 4096 2048
(*): required S800 data rate
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

6 / 12
5. Rear panel and pin assignment
①
①POWER/STATUS LED
②
③
②IEEE1394b connector
1
2
3
4
5
6
7
8
9
TPB-
TPB+
TPA-
TPA+
TPA(R)
VG
I/O
VP
TPB(R)
SERIAL DATA
SHIELD GND
SHIELD GND
POWER GND
POWER +12V
*Programmable I/O
③IEEE1394b connector
REAR PANEL
Green Yellow
Power ON
LED
light on light off
Transmission blink off blink on
blink offTransmission pause blink on
*Programmable I/O In Out
Trigger ○ ○
VD ○ ○
×Strobe (Flash) ○
Signal connection to IEEE 1394.b(PORT1/PORT2)
LED status
Viewer Soft Setting(PORT1/PORT2)
1234
56789
1234
56789
PORT 1 PORT 2
POWER/STATUS
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

7 / 12
6. Timing chart
a) Digital Out
(*1) 0.27～3930.51μs 0.96μs/step
(*2) 0.96～3931.2μs 0.96μs/step
(*3) Shutter Time – Strobe delay
（when duration time is set to 0）
Shutter time Shutter time
(Camera setting value)
Data Output
Shutter time
(Camera setting
value)
Strobe output
(Hi
g
h active)
Strobe delay (*1)
Strobe duration1 (*2)
Strobe duration2 (*3)
VD Output
(
Low active
)
3.2 ms (1280 x 960, Mono8, 15fps)
9H
DATA
VD
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

8 / 12
b) Fixed shutter mode
c) One-trigger mode
Trigger input
(High active)
High
Low
Shutter time Shutter time
(Camera setting value)
Data Output
More than 10μs More than T1 (*1)
Strobe output
(Hi
g
h active)
Trigger delay
(*3) Strobe delay (*4)
Strobe duration1 (*5)
Strobe duration2 (*6)
Output delay
(*2)
Port1/Port2
Output
(High active)
VD output
(Low active)
Port1/Port2(Trigger) input signal width
[sec]
rate frameSelf
1
T1 (*1) =(*2) 0.2～3931.4μs 0.96μs step
(*3) 0.4～3931.6μs 0.96μs step
(*4) 0.96～3931.2μs 0.96μs step
(*5) Shutter Time – Strobe delay
（when duration time is set to 0）
Trigger input
(High active)
High
Low
Shutter time Shutter time
(Integration time)
Data Output
More than 10μs
More than T1 (*1)
27μs
Strobe output
(High active)
Trigger delay
(*3) Strobe delay (*4)
Strobe duration1 (*5)
Strobe duration2 (*6)
VD output
(Low active)
Port1/Port2
Output
(
Hi
g
h active
)
Port1/Port2 (Trigger) input signal width
Output delay
(*2)
[sec]
rate frameSelf
1
T1 (*1) =(*2) 0.18～3930.42μs 0.96μs/step
(*3) 0.22～3930.46μs 0.96μs/step
(*4) 0.27～3930.51μs 0.96μs/step
(*5) 0.96～3931.2μs 0.96μs/step
(*6) Shutter Time – Strobe delay
（when duration time is set to 0）
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

9 / 12
d) Rest control
Note: Special function of reset control Trigger
The camera shifts to the output of a normal mode (continuous output) when Trigger signal passes about 1/3 seconds in the state of
High. (The image is output by inputting the Trigger at the VD cycle for this period.)
It returns to the Trigger mode if Trigger signal becomes Low. However, after becoming Low Trigger, the period of 1 second becomes
a Trigger signal input prohibition period.
Trigger
High
Low
Shutter time
Shutter time
(integration time)
Data output
More than 10μs
Readout pulse
(High active)
1～250ms
1/3s approx.
VD output
(Low active)
Trigger input
(High active)
Shutter time
Readout pulse
(High active)
Strobe output
(High active)
High
Low
Shutter time
(integration time)
Data output 9H
More than 10μs
93
μ
s
More than T1 (*1)
5H
1～250ms
VD output
(Low active)
Trigger
delay (*3)
Strobe delay (*4)
Strobe duration1 (*5)
Strobe duration2 (*6)
Output delay
(*2)
Port1/Port2
Output
(High active)
Port1/Port2 (Trigger) input signal width
[sec]
rate frameSelf
1
T1 (*1) =(*2) 0.19～3930.43μs 0.96μs/step
(*3) 0.22～3930.46μs 0.96μs/step
(*4) 0.28～3930.52μs 0.96μs/step
(*5) 0.96～3931.2μs 0.96μs/step
(*6) Shutter Time – Strobe delay
（when duration time is set to 0）
More than 10
μ
s
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

10 / 12
e) VD sync
VD input
(Low
active)
more than 1/self frame rate [sec]
more than 10µs
3.2 ms : 1280 x 960, Mono8, 15fps
DATA
VD output
(Low active)
0.34 µs
9H
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

11 / 12
7. External View
ＰＬＡＴＥ，ＲＡＴＥＤ
Ｕ１２５
±１
１１.５
±１
（５.７）
２－Ｍ３（ＤＥＰＴＨ：３）
１１.５
±１
（５.７）
２－Ｍ３（ＤＥＰＴＨ：３）
２５
±１
ＣＯＬＯＲ：ＢＬＡＣＫ
Ｓ
Ｅ
Ｅ
Ｍ
Ａ
Ｎ
Ｕ
Ａ
Ｌ
Ａ
Ｐ
Ｅ
Ｒ
Ｃ
Ｅ
Ｖ
Ｏ
Ｉ
Ｒ
Ｍ
Ａ
Ｎ
Ｕ
Ｅ
Ｌ
３４
±１
２－Ｍ２（ＤＥＰＴＨ：３）
ＣＯＬＯＲ：ＢＬＡＣＫ
Ａ
（６）
５４
±１.５
ＶＩＥＷ “Ｂ”
４４
±１.５
４４
±１.５
ＶＩＥＷ “Ａ”
ＣＯＬＯＲ：ＢＬＡＣＫ
・ＵＮＩＴ ： ｍｍ
・ＭＡＳＳ ： ＡＰＰＲＯＸ １３０ ｇ
Ｂ
ＰＯＷＥＲ/ＳＴＡＴＵＳ
ＰＯＲＴ ２ＰＯＲＴ １
２２
±１
２２
±１
３４
±１
２－Ｍ２（ＤＥＰＴＨ：３）
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

12 / 12
Warranty and service:
1) The guarantee period is one year after the data purchase. However, the defects due to
erroneous use or intentional act are excluded.
2) As the defect after expiration of the guarantee period, where product repair is possible,
repair will be performed at charge.
3) The present Warranty pertains only to the camera unit. Secondary malfunctions
attributable to camera failure as well as expenses incurred by disassembly and
reassembly of the related system, are beyond the scope of this Warranty.
4) Compensation for loss of business, loss or damage to software, database and other
contingent losses are beyond the scope of this Warranty.
5) Hitachi Kokusai Electric Inc. is not liable for the losses caused when the equipment is
used in a system, use for business trades, production process, medical fields, crime
prevention applications, etc.
6) The parts used in the equipment have their respective lives. The lives of such parts will
be shortened under the environments of high temperature or high humidity. When the
stable operation is required for a long time, it is recommended to perform periodical
maintenance and inspection every year or every two years.
7) The
Notice:
These specifications are sub
j
ect to change without prior notice due to product
improvement. Confirm the most recent specifications at time of order.
Hitachi Kokusai Electric certifies this product complies with the standard warranty
conditions of Hitachi Kokusai Electric, and that quality control is implemented to the
extent required to comply with these conditions.
Aegis Electronic Group
www.aegiselect.com
