Hitachi DV 14DCL2 User manual

[DV 18DCL2]
International Sales Division
The Models DV 18DCL2 and DV 14DCL2 are cordless impact driver drills equipped with an 18 V and 14.4 V
lithium-ion battery, respectively. The Models DV 18DVC2 and DV 14DVC2 are cordless impact driver drills
equipped with an 18 V and 14.4 V Ni-Cd battery, respectively. Vigorous sales promotion and expanded market
share are anticipated with the introduction of the new Models DV 18DCL2, DV 18DVC2, DV 14DCL2 and D
V
14DVC2. The key features of the Models DV 18DCL2, DV 18DVC2, DV 14DCL2 and DV 14DVC2 are as follows:
(1) Improved overload durability
(2) 22-position torque adjustable clutch (Max. clutch torque: 6.0 N•m)
(3) Equipped with safe and secure lithium-ion battery or new Ni-Cd battery
We aim to expand our market share with the new Models DV 18DCL2, DV 18DVC2, DV 14DCL2 and DV
14DVC2.
LIST Nos.
DV 14DCL2: H866
DV 14DVC2: H868
DV 18DCL2: H867
DV 18DVC2: H869
Jun. 2010
PRODUCT NAME
Hitachi 14.4 V Cordless Impact Driver Drill
Models DV 14DCL2, DV 14DVC2
Hitachi 18 V Cordless Impact Driver Drill
Models DV 18DCL2, DV 18DVC2
• Tightening and loosening wood screws, self-tapping screws and machine screws
• Drilling into wood, plastic, mild steel and aluminum materials
• Drilling into brick and concrete blocks
MARKETING OBJECTIVE
APPLICATIONS
SELLING POINTS
[NEW FEATURES]
Improved overload durability
(improved cooling efficiency)
22-position torque adjustable clutch
Soft-grip handle
Safe and secure
lithium-ion battery (BCL 1415, BCL 1815),
or new Ni-Cd battery (BCC 1412, BCC 1812)
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT.
D

REMARK:
• For more information about HANDLING INSTRUCTIONS, visit our website at:
http://www.hitachi-koki.com/manual_view_export/
• Throughout this TECHNICAL DATA AND SERVICE MANUAL, a symbol(s) is(are) used in the place of
company name(s) and model name(s) of our competitor(s). The symbol(s) utilized here is(are) as follows:
Models DV 18DCL2 and DV 18DVC2
Competitors
Symbols Utilized
Company Name Model Name
R RYOBI CDI-1801
Models DV 14DCL2 and DV 14DVC2
Competitors
Symbols Utilized
Company Name Model Name
R RYOBI CHI-1442

CONTENTS
Page
SELLING POINTS -------------------------------------------------------------------------------------------------------------- 1
SPECIFICATIONS -------------------------------------------------------------------------------------------------------------- 3
1. Specifications --------------------------------------------------------------------------------------------------------------------------------- 3
COMPARISON WITH SIMILAR PRODUCTS---------------------------------------------------------------------------- 7
1. Comparison of Specifications --------------------------------------------------------------------------------- 7
2. Comparison of Drilling and Fastening Performance per Charge ----------------------------------- 11
PRECAUTIONS ON SALES PROMOTION ---------------------------------------------------------------------------- 13
1. Safety Instructions --------------------------------------------------------------------------------------------- 13
2. Inherent Drawbacks of Cordless Impact Driver Drills Requiring
Particular Attention during Sales Promotion ------------------------------------------------------------- 15
REPAIR GUIDE---------------------------------------------------------------------------------------------------------------- 17
1. Precautions on Disassembly and Reassembly --------------------------------------------------------- 17
2. Precautions on Disassembly and Reassembly of the Battery Charger --------------------------- 25
STANDARD REPAIR TIME (UNIT) SCHEDULES-------------------------------------------------------------------- 26
Assembly Diagram for DV 18DCL2
Assembly Diagram for DV 18DVC2
Assembly Diagram for DV 14DCL2
Assembly Diagram for DV 14DVC2

-1-
•1.76 N•m {18 kgf•cm} intermittent load test (14.4 V)
•2.06 N•m {21 kgf•cm} intermittent load test (18 V)
Improved overload durability (improved cooling efficiency)
The Models DV 18DCL2, DV 18DVC2, DV 14DCL2 and DV 14DVC2 ensure durability in continuous
operation, thanks to of a powerful motor and improved air ducts.
SELLING POINTS

-2-
22-position torque adjustable clutch (Max. clutch torque: 6.0 N•m)
The 22-position torque adjustable clutch ensures fine torque adjustment for better operability.
Clutch dial position Tightening torque
1 1.0 ± 0.5 N•m {10 ± 5 kgf•cm }
4 1.7 ± 0.6 N•m {17 ± 6 kgf•cm }
10 3.1 ± 0.7 N•m {31 ± 7 kgf•cm }
13 3.8 ± 0.8 N•m {38 ± 8 kgf•cm }
19 5.3 ± 0.9 N•m {53 ± 9 kgf•cm }
22 6.0 ± 1.0 N•m {60 ± 10 kgf•cm }
* There may be some differences in operation depending on shapes of screws and the
workpieces used.
Conduct a test before actual driving.
Soft-grip handle
The handle is widely covered with soft-touch elastomer (rubber-like soft resin). It is slip-resistant and
securely fits in the palm of a hand even if the gripping hand sweats.
Safe and secure lithium-ion batteries (Types BCL 1815 and BCL 1415)
The new 1.5 Ah Types BCL 1815 and BCL 1415 Lithium-ion Batteries were developed for light-duty work.
Both batteries are equipped with an overdischarge protection circuit, overload protection circuit, overheat
protection circuit and voltage monitoring circuit for each cell to prevent reduced battery service life due to
overdischarge (overuse) or overcharge (excessive charging). These protection circuits make it possible to
safely use the batteries.
Precautions on using the Types BCL 1815 and BCL 1415 Lithium-ion Batteries
The Types BCL 1815 and BCL 1415 Lithium-ion Batteries are both equipped with a protective function that
automatically stops output to prolong battery service life. The motor may stop automatically in any of cases
(1), (2) and (3) below, even if the switch is held down during operation. This is due to activation of the
protective function. The batteries are not faulty.
Protective function Source of trouble Corrective action
(1) Overdischarge
protection circuit
Drop in battery voltage to about:
12 V/BCL 1815
8 V/BCL 1415
Charge the battery immediately.
(2) Overload
protection circuit Heavy-duty work Release the switch and eliminate
the cause of the overload problem.
(3) Overheat
protection circuit
Continuous operation
or heavy-duty work
Remove the battery from the tool
and allow it to cool down.
New Ni-Cd batteries (Types BCC 1412 and BCC 1812)
The new 1.2 Ah Ni-Cd Batteries Types BCC 1412 and BCC 1812 were developed for light-duty work.
These batteries—the lowest-level Ni-Cd models of 14.4 V and 18 V batteries—are consequently easier to
purchase than other Ni-Cd batteries.

-3-
1. Specifications
Model
Item DV 18DCL2
Capacity
Screw driving Machine screw ------------ 6 mm (1/4")
Wood screw --------------- 8 mm dia. x 75 mm (#20 x 3")
Drilling Brick ------------------------ 13 mm (1/2") [Depth 30 mm (1-1/4")]
Metal ------- Mild steel --- 13 mm (1/2") [Thickness 1.6 mm (1/16")]
Aluminum -- 13 mm (1/2") [Thickness 1.6 mm (1/16")]
Wood ----------------------- 38 mm (1-1/2") [Thickness 18 mm (11/16")]
Keyless chuck
(13VLRS-N)
Mount type ----------------------Screw-on (UNF 1/2" to 20)
Diameter-------------------------2.0 to 13 mm (5/64" to 1/2")
Rotation speed
(No-load) Low: 0 to 400 min-1, High: 0 to 1,500 min-1
Torque
Slip torque-----------------------1 to 6.0 N•m (10 to 60 kgf•cm, 9 to 52 in-lbs.) [22 stages]
Max. torque ---------------------Low: 43 N•m (439 kgf•cm, 382 in-lbs.)
High: 12 N•m (122 kgf•cm, 106 in-lbs.)
Type of motor Fan-cooled DC magnet motor
Type of switch Trigger switch with pushing button for forward and reverse rotation changeover
(with brake)
Enclosure
Body -----------------------------Glassfiber-reinforced polyamide resin (black)
and thermoplastic elastomer (green)
Battery --------------------------Glassfiber-reinforced polyamide resin (black)
Charger -------------------------ABS resin (black)
Battery
(Type BCL 1815)
Sealed cylindrical lithium-ion storage battery
Nominal voltage ----------------DC 18 V
Nominal life ---------------------Charging/discharging: Approx. 800 times
Nominal capacity ---------------1.5 Ah
Charger
(Model UC 18YKL)
Overcharge protection system:
(1) Battery voltage detection (∆V system)
Battery temperature detection (dT/dt system) for Ni-Cd, Ni-MH battery
(2) Battery surface temperature detection (by thermostat or thermistor)
(3) 240 minute timer
(4) Stop current detection (Li-ion batteries)
Power input: 50 W
Charging time: Approx. 60 minutes [for Type BCL 1815 Battery at 20°C (68°F)]
Operable ambient temperature range: 0°C to 40°C (32°F to 104°F)
The maximum allowable temperature of the Type BCL 1815 Battery is 50°C (122°F).
Indication method of battery charging function
Net Main body unit (including battery) ------------------------------------------- 1.6 kg (3.5 lbs.)
Charger unit (UC 18YKL, including cord) ----------------------------------- 0.4 kg (0.9 lb.)
Weight
Gross DV 18DCL2 (2LCKK) - -------------------------------------------------------- 4.1 kg (8.9 lbs.)
Standard
accessories 2LCKK
Charger (UC 18YKL) ---------------------------------------------------------- 1
Battery (BCL 1815) ------------------------------------------------------------ 2
Phillips (plus) driver bit (No. 2) ----------------------------------------------- 1
Case ---------------------------------------------------------------------------- 1
SPECIFICATIONS

-4-
Model
Item DV 18DVC2
Capacity
Screw driving Machine screw ------------ 6 mm (1/4")
Wood screw --------------- 8 mm dia. x 75 mm (#20 x 3")
Drilling Brick ------------------------ 13 mm (1/2") [Depth 30 mm (1-1/4")]
Metal ------- Mild steel --- 13 mm (1/2") [Thickness 1.6 mm (1/16")]
Aluminum -- 13 mm (1/2") [Thickness 1.6 mm (1/16")]
Wood ----------------------- 38 mm (1-1/2") [Thickness 18 mm (11/16")]
Keyless chuck
(13VLRS-N)
Mount type ----------------------Screw-on (UNF 1/2" to 20)
Diameter-------------------------2.0 to 13 mm (5/64" to 1/2")
Rotation speed
(No-load) Low: 0 to 400 min-1, High: 0 to 1,500 min-1
Torque
Slip torque ----------------------1 to 6.0 N•m (10 to 60 kgf•cm, 9 to 52 in-lbs.) [22 stages]
Max. torque ---------------------Low: 43 N•m (439 kgf•cm, 382 in-lbs.)
High: 12 N•m (122 kgf•cm, 106 in-lbs.)
Type of motor Fan-cooled DC magnet motor
Type of switch Trigger switch with pushing button for forward and reverse rotation changeover
(with brake)
Enclosure
Body -----------------------------Glassfiber-reinforced polyamide resin (black)
and thermoplastic elastomer (green)
Battery --------------------------Glassfiber-reinforced polyamide resin (black)
Charger -------------------------ABS resin (black)
Battery
(Type BCC 1812)
Sealed cylindrical nickel-cadmium storage battery
Nominal voltage ----------------DC 18 V
Nominal life ---------------------Charging/discharging: Approx. 300 times
Nominal capacity --------------1.2 Ah
Charger
(Models UC 18YK/
UC 18SF for Ni-Cd
battery only)
• Overcharge prevention circuit (UC 18YK only):
A thermostat monitors the battery surface temperature and upon detecting a rise in
temperature that occurs at the end of charging, the unit turns off automatically to prevent
the battery from overcharge.
• Power input: UC 18YK: 50 W, UC 18SF: 24 W
• Indication method: Pilot lamp indicator of battery charging
Function (UC 18YK):On------During charging
Off ------Charging completed
Function (UC 18SF):On------When inserting a battery
Off ------Disconnecting a battery
Net
Main body unit (including battery) ------------------------------------------- 1.9 kg (4.2 lbs.)
Charger unit (UC 18YK, including cord) ------------------------------------ 0.35 kg (0.8 lb.)
Charger unit (UC 18SF, including cord) ----------------------------------------- 0.6 kg (1.3 lbs.)
Weight
Gross DV 18DVC2 (2SLKK) --------------------------------------------------------- 4.7 kg (10.4 lbs.)
DV 18DVC2 (3SLSK) --------------------------------------------------------- 5.6 kg (12.3 lbs.)
2SLKK
Charger (UC 18YK) ----------------------------------------------------------- 1
Battery (BCC 1812) ------------------------------------------------------------------ 2
Phillips (plus) driver bit (No. 2) ----------------------------------------------- 1
Case ----------------------------------------------------------------------------- 1
Standard
accessories
3SLSK
Charger (UC 18SF) ----------------------------------------------------------- 1
Battery (BCC 1812) ----------------------------------------------------------- 3
Phillips (plus) driver bit (No. 2) ----------------------------------------------- 1
Case ---------------------------------------------------------------------------- 1

-5-
Model
Item DV 14DCL2
Capacity
Screw driving Machine screw----------- 6 mm (1/4")
Wood screw ------------- 8 mm dia. x 50 mm (#20 x 2")
Drilling Brick ---------------------- 13 mm (1/2") [Depth 30 mm (1-1/4")]
Metal ------ Mild steel --- 13 mm (1/2") [Thickness 1.6 mm (1/16")]
Aluminum -- 13 mm (1/2") [Thickness 1.6 mm (1/16")]
Wood --------------------- 32 mm (1-1/4") [Thickness 18 mm (11/16")]
Keyless chuck
(13VLRS-N)
Mount type ----------------------Screw-on (UNF 1/2" to 20)
Diameter-------------------------2.0 to 13 mm (5/64" to 1/2")
Rotation speed
(No-load) Low: 0 to 400 min-1, High: 0 to 1,500 min-1
Torque
Slip torque ----------------------1 to 6.0 N•m (10 to 60 kgf•cm, 9 to 52 in-lbs.) [22 stages]
Max. torque ---------------------Low: 37 N•m (378 kgf•cm, 328 in-lbs.)
High: 10 N•m (102 kgf•cm, 89 in-lbs.)
Type of motor Fan-cooled DC magnet motor
Type of switch Trigger switch with pushing button for forward and reverse rotation changeover
(with brake)
Enclosure
Body -----------------------------Glassfiber-reinforced polyamide resin (black)
and thermoplastic elastomer (green)
Battery --------------------------Glassfiber-reinforced polyamide resin (black)
Charger -------------------------ABS resin (black)
Battery
(Type BCL 1415)
Sealed cylindrical lithium-ion storage battery
Nominal voltage ----------------DC 14.4 V
Nominal life ---------------------Charging/discharging: Approx. 800 times
Nominal capacity ---------------1.5 Ah
Charger
(Model UC 18YKL)
Overcharge protection system:
(1) Battery voltage detection (∆V system)
Battery temperature detection (dT/dt system) for Ni-Cd, Ni-MH battery
(2) Battery surface temperature detection (by thermostat or thermistor)
(3) 240 minute timer
(4) Stop current detection (Li-ion batteries)
Power input: 50 W
Charging time: Approx. 60 minutes [for Type BCL 1415 Battery at 20°C (68°F)]
Operable ambient temperature range: 0°C to 40°C (32°F to 104°F)
The maximum allowable temperature of the Type BCL 1415 Battery is 50°C (122°F).
Indication method of battery charging function
Net Main body unit (including battery) ------------------------------------------- 1.5 kg (3.3 lbs.)
Charger unit (UC 18YKL, including cord) ----------------------------------- 0.4 kg (0.9 lb.)
Weight
Gross DV 14DCL2 (2LCKK) - -------------------------------------------------------- 4.0 kg (8.7 lbs.)
Standard
accessories 2LCKK
Charger (UC 18YKL) ---------------------------------------------------------- 1
Battery (BCL 1415) ------------------------------------------------------------ 2
Phillips (plus) driver bit (No. 2) ----------------------------------------------- 1
Case ---------------------------------------------------------------------------- 1

-6-
Model
Item DV 14DVC2
Capacity
Screw driving Machine screw----------- 6 mm (1/4")
Wood screw ------------- 8 mm dia. x 50 mm (#20 x 2")
Drilling Brick ---------------------- 13 mm (1/2") [Depth 30 mm (1-1/4")]
Metal ------ Mild steel --- 13 mm (1/2") [Thickness 1.6 mm (1/16")]
Aluminum -- 13 mm (1/2") [Thickness 1.6 mm (1/16")]
Wood --------------------- 32 mm (1-1/4") [Thickness 18 mm (11/16")]
Keyless chuck
(13VLRS-N)
Mount type ----------------------Screw-on (UNF 1/2" to 20)
Diameter-------------------------2.0 to 13 mm (5/64" to 1/2")
Rotation speed
(No-load) Low: 0 to 400 min-1, High: 0 to 1,500 min-1
Torque
Slip torque ----------------------1 to 6.0 N•m (10 to 60 kgf•cm, 9 to 52 in-lbs.) [22 stages]
Max. torque ---------------------Low: 37 N•m (378 kgf•cm, 328 in-lbs.)
High: 10 N•m (102 kgf•cm, 89 in-lbs.)
Type of motor Fan-cooled DC magnet motor
Type of switch Trigger switch with pushing button for forward and reverse rotation changeover
(with brake)
Enclosure
Body -----------------------------Glassfiber-reinforced polyamide resin (black)
and thermoplastic elastomer (green)
Battery --------------------------Glassfiber-reinforced polyamide resin (black)
Charger -------------------------ABS resin (black)
Battery
(Type BCC 1412)
Sealed cylindrical nickel-cadmium storage battery
Nominal voltage ----------------DC 14.4 V
Nominal life ---------------------Charging/discharging: Approx. 300 times
Nominal capacity ---------------1.2 Ah
Charger
(Model UC 18YK for
Ni-Cd battery only)
• Overcharge prevention circuit:
A thermostat monitors the battery surface temperature and, upon detecting a rise in
temperature that occurs at the end of charging, the unit turns off automatically to prevent
the battery from overcharge.
• Input capacity: 50 W
• Indication method: Pilot lamp indicator of battery charging
Function: On-------------------When inserting a battery
Off ------------------Charging completed
Net Main body unit (including battery) ------------------------------------------- 1.8 kg (4.0 lbs.)
Charger unit (UC 18YK, including cord) ------------------------------------ 0.35 kg (0.8 lb.)
Weight
Gross DV 14DVC2 (2SKK) ----------------------------------------------------------- 4.4 kg (9.8 lbs.)
Standard
accessories 2SKK
Charger (UC 18YK) ----------------------------------------------------------- 1
Battery (BCC 1412) ------------------------------------------------------------------ 2
Phillips (plus) driver bit (No. 2) ---------------------------------------------------- 1
Case -------------------------------------------------------------------------------------- 1

-7-
1. Comparison of Specifications (Superior specifications: )
HITACHI
Maker
Model
Item DV 18DVC2 DV 18DVC
R
Machine screw
6 mm (1/4”) 6 mm (1/4”) Not indicated
Screw
driving Wood screw 8 mm dia. x 75 mm
(#20 x 3”)
8 mm dia. x 75 mm
(#20 x 3”) Not indicated
Brick 13 mm (1/2”) 13 mm (1/2”) 13 mm (1/2”)
Mild steel 13 mm (1/2”) 13 mm (1/2”) 13 mm (1/2”)
Aluminum 13 mm (1/2”) 13 mm (1/2”) Not indicated
Max. capacity
Drilling
Soft wood 38 mm (1-1/2”) 38 mm (1-1/2”) 38 mm (1-1/2”)
Low 0 to 400 min-1 0 to 400 min-1 0 to 400 min-1 Rotation
speed High 0 to 1,500 min-1 0 to 1,500 min-1 0 to 1,400 min-1
Low 0 to 5,600 min-1 0 to 5,600 min-1 0 to 5,200 min-1
Impact rate High 0 to 21,000 min-1 0 to 21,000 min-1 0 to 18,200 min-1
1.0 to 6.0 N•m
(10 to 60 kgf•cm)
(9 to 52 in-lbs.)
1.0 to 6.0 N•m
(10 to 60 kgf•cm)
(9 to 52 in-lbs.)
Not indicated
Slip torque
22 positions 22 positions 24 positions
Max. torque
43 N•m
(439 kgf•cm)
(382 in-lbs.)
43 N•m
(439 kgf•cm)
(382 in-lbs.)
35 N•m
(357 kgf•cm)
(310 in-lbs.)
Type Double sleeve Double sleeve Double sleeve Drill
chuck Capacity 13 mm (1/2”) 13 mm (1/2”) 13 mm (1/2”)
Type Variable speed Variable speed Variable speed
Switch Electric brake Equipped Equipped Equipped
Automatic spindle lock None None None
Reversing switch Push-button Push-button Push-button
Handle shape T-type T-type T-type
Soft-grip handle Equipped Equipped Equipped
Hook None Equipped None
Strap None Equipped None
Nominal
capacity 1.2 Ah 1.4 Ah 1.5 Ah
Nominal voltage
18 V 18 V 18 V
Battery
Charging time* 50 min. (UC 18YK)
180 min. (UC 18SF)
30 min.
(UC 18YG) 60 min.
Overall length 234 mm (9-7/32”) 235 mm (9-1/4”) 264 mm
(10-25/64”)
Overall height 245 mm (9-21/32”) 244 mm (9-19/32”) 260 mm
(10-15/64”)
Dimensions
Overall width 78 mm (3-5/64”) 78 mm (3-5/64”) 72 mm (2-7/8”)
Weight 1.9 kg (4.2 lbs.) 2.3 kg (5.1 lbs.) 2.5 kg (5.5 lbs.)
*: Charging time varies depending on the type of charger used.
COMPARISON WITH SIMILAR PRODUCTS

-8-
(Superior specifications: )
HITACHI
Maker
Model
Item DV 18DCL2 DV 18DCL
R
Machine screw
6 mm (1/4”) 6 mm (1/4”) Not indicated
Screw
driving Wood screw 8 mm dia. x 75 mm
(#20 x 3”)
8 mm dia. x 75 mm
(#20 x 3”) Not indicated
Brick 13 mm (1/2”) 13 mm (1/2”) 13 mm (1/2”)
Mild steel 13 mm (1/2”) 13 mm (1/2”) 13 mm (1/2”)
Aluminum 13 mm (1/2”) 13 mm (1/2”) Not indicated
Max. capacity
Drilling
Soft wood 38 mm (1-1/2”) 38 mm (1-1/2”) 38 mm (1-1/2”)
Low 0 to 400 min-1 0 to 400 min-1 0 to 400 min-1 Rotation
speed High 0 to 1,500 min-1 0 to 1,500 min-1 0 to 1,400 min-1
Low 0 to 5,600 min-1 0 to 5,600 min-1 0 to 5,200 min-1
Impact rate High 0 to 21,000 min-1 0 to 21,000 min-1 0 to 18,200 min-1
1.0 to 6.0 N•m
(10 to 60 kgf•cm)
(9 to 52 in-lbs.)
1.0 to 6.0 N•m
(10 to 60 kgf•cm)
(9 to 52 in-lbs.)
Not indicated
Slip torque
22 positions 22 positions 24 positions
Max. torque
43 N•m
(439 kgf•cm)
(382 in-lbs.)
43 N•m
(439 kgf•cm)
(382 in-lbs.)
35 N•m
(357 kgf•cm)
(310 in-lbs.)
Type Double sleeve Double sleeve Double sleeve Drill
chuck Capacity 13 mm (1/2”) 13 mm (1/2”) 13 mm (1/2”)
Type Variable speed Variable speed Variable speed
Switch Electric brake Equipped Equipped Equipped
Automatic spindle lock None None None
Reversing switch Push-button Push-button Push-button
Handle shape T-type T-type T-type
Soft-grip handle Equipped Equipped Equipped
Hook None Equipped None
Strap None Equipped None
Nominal
capacity 1.5 Ah 1.5 Ah 1.5 Ah
Nominal voltage
18 V 18 V 18 V
Battery
Charging time* 60 min.
(UC 18YKL)
40 min.
(UC 18YGL2) 60 min.
Overall length 234 mm (9-7/32”) 235 mm (9-1/4”) 264 mm
(10-25/64”)
Overall height 237 mm (9-21/64”) 236 mm (9-19/64”) 260 mm
(10-15/64”)
Dimensions
Overall width 81 mm (3-3/16”) 81 mm (3-3/16”) 72 mm (2-7/8”)
Weight 1.6 kg (3.5 lbs.) 1.8 kg (4.0 lbs.) 2.5 kg (5.5 lbs.)
*: Charging time varies depending on the type of charger used.

-9-
(Superior specifications: )
HITACHI
Maker
Model
Item DV 14DVC2 DV 14DVC
R
Machine screw
6 mm (1/4”) 6 mm (1/4”) Not indicated
Screw
driving Wood screw 8 mm dia. x 50 mm
(#20 x 2”)
8 mm dia. x 50 mm
(#20 x 2”) Not indicated
Brick 13 mm (1/2”) 13 mm (1/2”) 13 mm (1/2”)
Mild steel 13 mm (1/2”) 13 mm (1/2”) 13 mm (1/2”)
Aluminum 13 mm (1/2”) 13 mm (1/2”) Not indicated
Max. capacity
Drilling
Soft wood 32 mm (1-1/4”) 32 mm (1-1/4”) 32 mm (1-1/4”)
Low 0 to 400 min-1 0 to 400 min-1 0 to 400 min-1 Rotation
speed High 0 to 1,500 min-1 0 to 1,500 min-1 0 to 1,400 min-1
Low 0 to 5,600 min-1 0 to 5,600 min-1 0 to 5,200 min-1
Impact rate High 0 to 21,000 min-1 0 to 21,000 min-1 0 to 18,200 min-1
1.0 to 6.0 N•m
(10 to 60 kgf•cm)
(9 to 52 in-lbs.)
1.0 to 6.0 N•m
(10 to 60 kgf•cm)
(9 to 52 in-lbs.)
Not indicated
Slip torque
22 positions 22 positions 24 positions
Max. torque
37 N•m
(378 kgf•cm)
(328 in-lbs.)
37 N•m
(378 kgf•cm)
(328 in-lbs.)
34 N•m
(347 kgf•cm)
(301 in-lbs.)
Type Double sleeve Double sleeve Single sleeveDrill
chuck Capacity 13 mm (1/2”) 13 mm (1/2”) 13 mm (1/2”)
Type Variable speed Variable speed Variable speed
Switch Electric brake Equipped Equipped Equipped
Automatic spindle lock None None Equipped
Reversing switch Push-button Push-button Push-button
Handle shape T-type T-type T-type
Soft-grip handle Equipped Equipped Equipped
Hook None Equipped None
Strap None Equipped Equipped
Nominal
capacity 1.2 Ah 1.4 Ah 1.7 Ah
Nominal voltage
14.4 V 14.4 V 14.4 V
Battery
Charging time* 50 min.
(UC 18YK)
30 min.
(UC 18YG) 60 min.
Overall length 234 mm (9-7/32”) 235 mm (9-1/4”) 258 mm
(10-5/32”)
Overall height 240 mm (9-29/64”) 239 mm (9-25/64”) 270 mm
(10-5/8”)
Dimensions
Overall width 78 mm (3-5/64”) 78 mm (3-5/64”) 72 mm (2-7/8”)
Weight 1.8 kg (4.0 lbs.) 2.1 kg (4.6 lbs.) 2.3 kg (5.1 lbs.)
*: Charging time varies depending on the type of charger used.

-10-
(Superior specifications: )
HITACHIMaker
Model
Item DV 14DCL2 DV 14DCL
R
Machine screw
6 mm (1/4”) 6 mm (1/4”) Not indicated
Screw
driving Wood screw 8 mm dia. x 50 mm
(#20 x 2”)
8 mm dia. x 50 mm
(#20 x 2”) Not indicated
Brick 13 mm (1/2”) 13 mm (1/2”) 13 mm (1/2”)
Mild steel 13 mm (1/2”) 13 mm (1/2”) 13 mm (1/2”)
Aluminum 13 mm (1/2”) 13 mm (1/2”) Not indicated
Max. capacity
Drilling
Soft wood 32 mm (1-1/4”) 32 mm (1-1/4”) 32 mm (1-1/4”)
Low 0 to 400 min-1 0 to 400 min-1 0 to 400 min-1 Rotation
speed High 0 to 1,500 min-1 0 to 1,500 min-1 0 to 1,400 min-1
Low 0 to 5,600 min-1 0 to 5,600 min-1 0 to 5,200 min-1
Impact rate High 0 to 21,000 min-1 0 to 21,000 min-1 0 to 18,200 min-1
1.0 to 6.0 N•m
(10 to 60 kgf•cm)
(9 to 52 in-lbs.)
1.0 to 6.0 N•m
(10 to 60 kgf•cm)
(9 to 52 in-lbs.)
Not indicated
Slip torque
22 positions 22 positions 24 positions
Max. torque
37 N•m
(378 kgf•cm)
(328 in-lbs.)
37 N•m
(378 kgf•cm)
(328 in-lbs.)
34 N•m
(347 kgf•cm)
(301 in-lbs.)
Type Double sleeve Double sleeve Single sleeveDrill
chuck Capacity 13 mm (1/2”) 13 mm (1/2”) 13 mm (1/2”)
Type Variable speed Variable speed Variable speed
Switch Electric brake Equipped Equipped Equipped
Automatic spindle lock None None Equipped
Reversing switch Push-button Push-button Push-button
Handle shape T-type T-type T-type
Soft-grip handle Equipped Equipped Equipped
Hook None Equipped None
Strap None Equipped Equipped
Nominal
capacity 1.5 Ah 1.5 Ah 1.7 Ah
Nominal voltage
14.4 V 14.4 V 14.4 V
Battery
Charging time* 60 min.
(UC 18YKL)
40 min.
(UC 18YGL2) 60 min.
Overall length 234 mm (9-7/32”) 235 mm (9-1/4”) 258 mm
(10-5/32”)
Overall height 233 mm (9-11/64”) 232 mm (9-9/64”) 270 mm
(10-5/8”)
Dimensions
Overall width 81 mm (3-3/16”) 78 mm (3-5/64”) 72 mm (2-7/8”)
Weight 1.5 kg (3.3 lbs.) 1.8 kg (4.0 lbs.) 2.3 kg (5.1 lbs.)
*: Charging time varies depending on the type of charger used.

-11-
A
merican
p
ine
L75
ø
6
Coach bolt
(with predrilled holes
4 mm in dia.)
30 mm
Concrete drill bit
ø
10
Mortar
SPCC T1.6
Metal borin
g
ø
8
T1.6
2. Comparison of Drilling and Fastening Performance per Charge
Working Capacity
Type of Work Maker Model 0 *200 *400 *600 *800 *1,000
0 50 100 150 200 250
Drilling
Speed
(sec./pc.)
DV 18DVC2 31 11.1
DV 18DVC 37 11.3
DV 18DCL2 40 10.9
HITACHI
DV 18DCL 46 11.1
<Forward rotation, high
s
p
eed, im
p
act drillin
g
>R38 10.1
DV 18DVC2 109 3.1
DV 18DVC 127 3.6
DV 18DCL2 136 3.1
HITACHI
DV 18DCL 141 3.1
<High speed, drilling> R117 3.1
DV 18DVC2 72 7.0
DV 18DVC 84 7.1
DV 18DCL2 80 6.6
HITACHI
DV 18DCL 80 6.7
<High speed, 15 kg thrust> R75 7.5
DV 18DVC2 77 5.1
DV 18DVC 89 5.4
DV 18DCL2 101 5.0
HITACHI
DV 18DCL 100 5.1
<Low speed, drilling> R78 5.1
DV 18DVC2 752* 0.5
DV 18DVC 933* 0.5
DV 18DCL2 931* 0.5
HITACHI
DV 18DCL 946* 0.5
<High speed, maximum clutch>
R920* 0.5
[Working Capacity]
Without *: Number of holes or fasteners per charge
With *: Number of machine screws fastened per charge
As actually measured values listed in the table above may vary depending on sharpness of the drill bit,
workpiece hardness (particularly in wood materials), moisture content of wood, charging condition,
operator skill, and other factors, this data should only be used as a comparative guide.
A
merican
p
ine
T18
Wood borin
g
ø
24
Machine screw M6
Steel plate
S10C
L12

-12-
30 mm
Concrete drill bit
ø
8
Mortar
A
merican
p
ine
T18
Wood borin
g
ø
18
SPCC T1.6
Metal borin
g
ø
6.5
T1.6
A
merican
p
ine
L40
ø
4.8
Coach bolt
(with predrilled holes
4 mm in dia.)
Machine screw M6
Steel plate
S10C
L12
Working Capacity
Type of Work Maker Model 0 *200 *400 *600 *800 *1,000
0 50 100 150 200 250
Drilling
Speed
(sec./pc.)
DV 14DVC2 38 9.5
DV 14DVC 38 9.4
DV 14DCL2 45 9.8
HITACHI
DV 14DCL 44 9.2
<Forward rotation, high
s
p
eed, im
p
act drillin
g
>R46 9.1
DV 14DVC2 129 3.2
DV 14DVC 161 3.4
DV 14DCL2 155 3.2
HITACHI
DV 14DCL 176 3.2
<High speed, drilling> R188 3.4
DV 14DVC2 69 6.2
DV 14DVC 81 6.3
DV 14DCL2 79 6.2
HITACHI
DV 14DCL 79 6.3
<High speed, 15 kg thrust> R91 7.5
DV 14DVC2 112 3.4
DV 14DVC 121 3.5
DV 14DCL2 144 3.2
HITACHI
DV 14DCL 140 3.2
<Low speed, drilling> R145 3.7
DV 14DVC2 610* 0.5
DV 14DVC 679* 0.5
DV 14DCL2 717* 0.5
HITACHI
DV 14DCL 744* 0.5
<High speed, maximum clutch>
R650* 0.5
[Working Capacity]
Without *: Number of holes or fasteners per charge
With *: Number of machine screws fastened per charge
As actually measured values listed in the table above may vary depending on sharpness of the drill bit,
workpiece hardness (particularly in wood materials), moisture content of wood, charging condition,
operator skill, and other factors, this data should only be used as a comparative guide.

-13-
1. Safety Instructions
In the interest of promoting the safest and most efficient use of the Models DV 18DCL2, DV 18DVC2,
DV 14DCL2 and DV 14DVC2 Cordless Impact Driver Drills by all of our customers, it is very important
when concluding a sale that the salesperson carefully ensure that the buyer seriously recognizes the
importance of the Handling Instructions, and fully understands the precautions listed on the Caution Plate
and Nameplate attached to each tool.
A. Handling instructions
Salespersons must be thoroughly familiar with the Handling Instructions in order to give pertinent advice to
the customer. In particular, they must have a thorough understanding of the precautions on using cordless
tools that differ from those of ordinary electric power tools.
(1) Before use, ensure that the unit is fully charged.
New units are not fully charged. Even if the units were fully charged at the factory, long periods of
inactivity, such as during shipment, cause the storage battery to lose its charge. Customers must be
instructed to fully charge the unit prior to use.
(2) Connect the charger to an AC power outlet only.
Use of any other power source (e.g., DC outlet, fuel powered generator) will cause the charger to
overheat and burn out.
(3) Do not use any voltage-increasing equipment (e.g., transformer) between the power source and
the charger.
Using the charger with voltage higher than that indicated on the unit will result in malfunction.
(4) Conduct battery charging at an ambient temperature range of 10°C to 40°C (50°F to 104°F).
Special temperature-sensitive devices are employed in the charger to permit rapid charging. Ensure
that customers are instructed to use the charger at the indicated ambient temperature range. At
temperatures below 10°C (50°F) the thermostat will not function properly, and the storage battery may
be overcharged. At temperatures above 40°C (104°F), the storage battery cannot be sufficiently
charged. The optimum temperature range is 20°C to 25°C (68°F to 77°F).
(5) The battery charger should not be used continuously.
Charging more than three storage batteries in succession at high ambient temperature will cause the
temperature of coils on the transformer to rise, running the risk of the temperature fuse inserted inside
the transformer inadvertently melting. After charging one battery, please wait at least 15 minutes before
charging the next battery.
(6) Do not insert foreign objects into the air vents on the charger.
The charger case is equipped with air vents to protect internal electronic components against
overheating. Caution the customer not to drop or insert such foreign matter as metallic or flammable
objects into the air vents. This could cause electric shock, fire, or other serious hazards.
PRECAUTIONS ON SALES PROMOTION

-14-
(7) Do not attempt to disassemble the storage battery or the charger.
Special devices such as a thermostat are built into the storage battery and charger to permit rapid
charging. Incorrect parts replacement and/or wiring will cause malfunctions that could result in fire or
other hazards. Instruct the customer to bring these units to an authorized service center in the event
repair or replacement is necessary.
(8) Disposal of the storage battery
Ensure that all customers understand that the storage batteries should be returned to the Hitachi power
tool sales outlet or authorized service center when no longer capable of being recharged or repaired. If
thrown into a fire, the batteries may explode.
B. Caution plates
(1) The following cautions are listed on the nameplate attached to the main body of each tool.
[For the USA and Canada]
Warning
•To reduce the risk of injury, user must read Instruction Manual.
AVERTISSEMENT
•Afin de réduire le risque de blessures, I’utilisateur doit lire le mode d’emploi.
(2) The following cautions are listed on the nameplate attached to each storage battery.
[For Europe]
[For the USA and Canada]
(3) The following cautions are listed on the nameplate attached to the Model UC 18YK Charger.
[For the USA and Canada]

-15-
2. Inherent Drawbacks of Cordless Impact Driver Drills Requiring
Particular Attention during Sales Promotion
The cordless impact driver drill offers many advantages; it can be used in places where no power source is
available, the absence of a cord allows easy use, etc. However, any cordless tool has certain inherent
drawbacks. Salespersons must be thoroughly familiar with these drawbacks in order to properly advise the
customer in the most efficient use of the tool.
A. Suggestions and precautions on efficient use of the tool
(1) Use the cordless impact driver drill for comparatively light work.
The motor output of battery driven cordless impact driver drills is rather low compared with conventional
electric power tools. Accordingly, they are not suitable for the continuous drilling of many holes in
succession, or for drilling into particularly hard material that imposes a heavy load. Salespersons should
recommend conventional electric power tools for such heavy work.
(2) Large-diameter holes should be drilled at low speed.
Instruct the customer that drilling large-diameter holes or performing other work that requires
particularly strong torque should be done at low speed. Because there is less torque at high speed,
attempting such work at high speed will not improve working efficiency.
(3) Do not insert a foreign object into body vent holes.
The body of this tool has vent holes for improved cooling efficiency. As a fan is built into the motor, a
foreign object inserted through a vent hole may cause failure. Please instruct customers to never insert
a foreign object into the vent holes.
(4) Use at thrust of 100 to 150 N (10 to 15 kgf, 22 to 23 lbs.)
The drilling speed of this unit does not accelerate even if the tool is pressed strongly against the
workpiece as when using a typical AC impact drill. Such operation will damage the drill bit, resulting in
not only poor working efficiency but also motor burnout.
(5) Avoid “locking” of the motor
Locking of the motor will generate an overload current that could result in motor burnout and/or rapid
battery deterioration. Salespersons should advise the customer to immediately release the switch and
stop operation if the motor becomes locked. (A jammed drill bit can be disengaged from the workpiece
material by setting the switch to reverse rotation, or by manually turning the main body of the tool.)
(6) Variation in amount of work possible per charge
Although the nominal chargeable capacity of the storage batteries used with the Models DV 18DCL2,
DV 18DVC2, DV 14DCL2 and DV 14DVC2 is 1.2 Ah or 1.5 Ah, the actual capacity may vary within 10%
of that value depending on ambient temperature during use and charging, and the number of times the
batteries have been recharged. It should be noted that other factors that may affect the amount of work
possible per charge are the working conditions (e.g., ambient temperature, type and moisture content of
the workpiece, sharpness of the drill bit) and the operational skill of the user.

-16-
(7) Precautions on the use of HSS drill bits
For example, although the Model DV 18DCL2 is designed for drilling capacities of 38 mm (1-1/2") in
wood, and 13 mm (1/2") in aluminum and mild steel, this capability is not as efficient as conventional
electric power tools. In particular, when drilling through aluminum material with a 13 mm (1/2") drill bit,
the drill tends to become locked when the drill bit penetrates a material. For this reason, the customer
should be cautioned to reduce the thrust on the main body of the drill when drilling completely through a
material to avoid locking the tool. Repeated locking of the drill causes excessive current to flow from the
battery, thereby not only reducing the amount of work possible per charge, but also running the risk of
motor burnout.
(8) Securely tighten the sleeve of the keyless chuck.
The keyless chuck may slip during operation when using a cylindrically shaped drill bit shank,
depending on the surface conditions, materials, and other factors. Please instruct customers to
retighten the keyless chuck more securely if the keyless chuck slips during operation. The holding force
of the keyless chuck increases as you increase the tightening force of the keyless chuck.
(9) Avoid continuous use.
Although the Models DV 18DCL2, DV 18DVC2, DV 14DCL2 and DV 14DVC2 can withstand continuous
operation under certain conditions, operating conditions differ depending on the workpiece material and
sharpness of the drill bit in use. Please instruct customers to avoid continuous use of the Models DV
18DCL2, DV 18DVC2, DV 14DCL2 and DV 14DVC2, and generally take about a 15 minute break
following a single charge operation.

-17-
Be sure to remove the storage batteries from the main body before servicing. Inadvertent triggering of the
switch with the storage battery connected imposes the danger of the motor accidently turning.
1. Precautions on Disassembly and Reassembly
[Bold] numbers in the descriptions below correspond to item numbers in the Parts List and exploded
assembly diagrams for the Models DV 18DCL2, DV 18DVC2, DV 14DCL2 and DV 14DVC2.
1. Removal of Housing (A).(B) Set
First, align the drill mark " " on the Clutch Dial [4] with the triangle mark on Housing (A).(B) Set [33].
Remove the eight Tapping Screw (W/Flange) D3 x 16 (Black) [38] from the main body. Gently open
Housings (A) and (B) while holding the battery loading sections.
2. Removal of internal parts
After removal of Housing (B), all internal parts (assembled or separated) can be taken out as a single unit.
Lift the entire contents from Housing (A) while holding the Motor [36] and Clutch Dial [4].
3. Removal of the Drill Chuck 13VLRS-N (See Fig. 1.)
(a) Turn the Motor [36] counterclockwise (when viewed from the rear) and remove it from the Rear Case
[22]. Remove the Shift Knob [37] from the Shift Arm [24]. Be careful not to remove the Shift Arm [24]
from the Rear Case [22] in this operation.
(b) Attach the motor spacer to the assembly of the Drill Chuck 13VLRS-N [2], Clutch Dial [4], Front Case
[15] and Rear Case [22],and then mount the assembly on special repair tool J-348 clamped in the vise
as illustrated in Fig. 1. In this operation, confirm that the pinions press-fitted in the special repair tool J-
342 and Planet Gear (A) Set [27] are properly engaged.
(c) Secure the Slide Ring Gear [25] to the Front Case [15] side with the Shift Arm [24].
(d) Turn the sleeve of the Drill Chuck 13VLRS-N [2] counterclockwise (when viewed from the front) to fully
open the jaws of the Drill Chuck 13VLRS-N [2]. Turn Flat Hd. Screw (A) (Left Hand) M6 x 25 [1]
clockwise and remove it. (Note that the special screw is left-hand threaded.)
(e) Fit the hexagonal bar wrench M10 into the Drill Chuck 13VLRS-N [2] as illustrated in Fig. 1, and then
turn the wrench counterclockwise to remove the Drill Chuck 13VLRS-N [2].
REPAIR GUIDE
Disassembl
y
