Hitachi LC57F User manual

NTSC/ATSC LC57F R/C: CLU-4351UG2
LCD REAR PROJECTION TELEVISION
55VS69
62VS69

106
CONTROL PANEL and JACKS
LC57F chassis
Model: 55VS69,62VS69
(1) FRONT PANEL
(2) REAR PANEL
5,6 4< ('(&+2&(/(& 7 5,4< (
1(3$ 6 2<= 5,5
&$<7,21
5,6 .2)(/(& 75,& 6+ 2&.
'212723(1
LC57F

TABLE OF CONTENTS
FINAL WIRING DIAGRAM
TABLE OF CONTENTS
TABLE OF CONTENTS
LC57F
107
Model: 55VS69,62VS69

TABLE OF CONTENTS
FINAL WIRING DIAGRAM
TABLE OF CONTENTS
TABLE OF CONTENTS
LC57F
108
Model: 55VS69,62VS69

TABLE OF CONTENTSTABLE OF CONTENTS
FINAL WIRING DIAGRAM
TABLE OF CONTENTS
TABLE OF CONTENTS
LC57F
109
Model: 55VS69,62VS69

TABLE OF CONTENTS
FINAL WIRING DIAGRAM
TABLE OF CONTENTS
TABLE OF CONTENTS
LC57F
110
Model: 55VS69,62VS69

LAMP ASSY, REAR BOARD,EXHAUST FAN
ԘLamp Door P#PH37491 ԜScrew T2B 4*12 P#MJ03634(2 pcs.)
ԙLamp Assy P#UX25951 ԝLamp Guide P#PH37481
ԚScrews M3M 4*16P#MJ03462(5 pcs.) ԞScrew T1T 4*18 P#MJ03587(2 pcs.)
T1T 4*16 P#MJ03587(10 pcs.)
ԟExhaust Fan P#GS01262
ԛRear Board P#PH37742
TABLE OF CONTENTS
LC57F
111
QUICK DISASSEMBLE GUIDE

CHASSIS ASSY, CONTROLBLOCK, OPTICAL ENGINE
ԘScrew T2B 3*12 P#MJ03551(3 pcs.) ԜScrew T2B 4*25 P#MJ03639(2 pcs.)
ԙScrew M3M 4*18 P#MJ03462(3 pcs.) ԜScrew M3M 4*16 P#MJ03462(2 pcs.)
ԚChassis Assy P#UE25851ԝOptical Engine
55VS69 P#UE25845
ԛControl Block Assy P#UE25871 62VS69 P#UE25846
112
LC57F

SCREEN FRAME ASSY, MIRROR COVER ASSY
ԘScrew T1T 4*25 P#MJ03589(6 pcs.)
ԙScrew T2V 4*16 P#MJ03442(17 pcs.)
ԚScrew T1T 4*25 P#MJ03589(6 pcs.)
ԛScrew T1T 4*25 P#MJ03589(4 pcs.)
113
LC57F
n
n
Lower Cabinet Assembly, P# AQD52461
CH 4

MIRROR COVER, MIRROR, SCREEN FRAME, SCREEN ASSY
ԘScrew T2V 4*16 P#MJ03442(17 pcs.)ԜMirror Cover
55VS69 P#QD51712
ԙScrew T1T 4*18 P#MJ03587(6 pcs.)) 62VS69 P#QD52431
ԚScrew T1T 4*18 P#MJ03587(4 pcs.)) ԝScrew T1T 4*18 P#MJ03587(14 pcs.))
ԛMirror50VS69 P#KS20791ԞScreen Assy
55VS69 P#KS20792 55VS69 P#UX26142
62VS69 P#KS20783 62VS69 P#UX26143
ԟScreen Frame
55VS69 P#UX26162
62VS69 P#UX26163
114
LC57F

CONTROL BLOCK, POWER PWB, DIGITAL MODULE, SIGNAL PWB, DIGITAL MODULE FAN
ԘControl Block P#UE25871(Includes Control PWB P#JT25541) ԞPower PWB AssyP#JT24994
ԙChassis Assy P#UE25851 ԟScrew T2B 3*16 P#MJ03459(3 pcs.)
ԚScrew T2B 3*16 P#MJ03459(2 pcs.) ԠDigital core Assy P#UE24613
ԛScrew T2B 3*12 P#MJ03551(4 pcs.) ԡSignal PWB Assy P#JT25531
ԜAntenna Switch Box P#HP00774 ŋScrew T2B 3*20 P#MJ03555(4 pcs.)
ԝScrew T2B 3*16 P#MJ03459(2 pcs.) ŌDigital Module Fan P#GS01092
115
LC57F

BALLAST, DRIVE PWB
ԘScrew T2B 3*12 P#MJ03458(2 Pcs.) ԜPanel Duct P#NJ22861
Panel Duct 2 P#NJ22871
ԙPowerUnit(Ballast) P#HA01641 Panel Filter P#MN09462
ԚBallast PWB ShieldP#MD09891 ԝScrew M3M 3*8 P#MJ03593(4 pcs)
ԛScrew T3E 3*12 P#MJ03458(4 pcs) ԞDrive Cover P#MD09821
ԟDrive PWB Assy P#JP50081
116
LC57F

PBS FAN, LAMP FAN
ԘScrew T3E 3*12 P#MJ03651(2 pcs)
ԙPBS Fan P#GS01182
ԚScrew T3E 3*12 P#MJ03651(2 pcs)
ԛLamp Fan P#GS01262
Cushion P#MN07012(4 pcs)
117
LC57F

REPLACEMENT PARTS LIST
PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to safety. Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
Capacitors: Resistors: Semiconductors:
AL: Aluminum Electrolytic CF: Carbon Film TR: Transistor
CD: Ceramic Disc CC: Carbon Composition DI: Diode
EL: Electrolitic MF: Metal Oxide ZD: Zener Diode
PF: Polyester Film VR: Variable Resistor VA: Varistor
PP: Polypropylene WW: Wire Wound TH: Termistor
PL: Plastic FR: Fuse Resistor IC: Integrated Circuit
TA: Tantalum MG: Metal Grazed
PR: Paper
TM: Trimmer
MC: Mylar
ABBREVIATIONS
TABLE OF CONTENTS 158
SYMBOL PART No. DESCRIPTION
LC57F
SYMBOL PART No. DESCRIPTION
LC57F
CT02 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) 0
JP08503 SUBDIGITAL PWB CT03 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V 0
CT04 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) 0
CAPACITORS CT05 AA01173R CCC1R0K50-B-32CT 1UF/50V-B-3225 0
CM01 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CT06 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CM02 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CT07 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V 0
CM03 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CT08 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CM04 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CT09 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CM06 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CT10 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CM07 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) 0 CT11 AA01802R CCC103K50-B-16CT MCH18 0
CM08 AA01123R CCC105K10-B-16CT 0 CT12 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CM09 AA01802R CCC103K50-B-16CT MCH18 0 CT13 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0
CM11 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CT14 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
CM12 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CT15 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CP04 AA00699R CAP.CHIP-CERAMIC 10UFK 16V B 3 0 CT16 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CP05 AA00724R CAP.CHIP-CERAMIC 3216B 1UF 50V 0 CT17 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CP20 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0 CT22 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CP21 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CT23 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0
CP22 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CT24 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) 0
CP23 AA00969R CAP.CHIP2125-B-22UF6.3V 0 CT25 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CP24 AA00969R CAP.CHIP2125-B-22UF6.3V 0 CT26 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
CP25 0893126R CAP 1608CHIP 100PFJCH 50V TAPE 0 CT27 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
CP26 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 CT28 0893123R CAP 1608CHIP 56PFJCH 50V TAPE 0
CP27 0893193R CAP 1608CHIP 10000PFKB 25V TAPE 0 CT29 0893124R CAP 1608CHIP 68PFJCH 50V TAPE 0
CP63 AA01123R CCC105K10-B-16CT 0 CT30 0893115R CAP 1608CHIP 15PFJCH 50V TAPE 0
CP64 0893193R CAP 1608CHIP 10000PFKB 25V TAPE 0 CT31 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CP65 0893126R CAP 1608CHIP 100PFJCH 50V TAPE 0 CT32 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
CP66 AA00969R CAP.CHIP2125-B-22UF6.3V 0 CT33 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CPG1 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CT34 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CPG2 0893135R CAP 1608CHIP 470PFJCH 50V TAPE 0 CT35 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CPS1 0893126R CAP 1608CHIP 100PFJCH 50V TAPE 0 CT36 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
CPS2 0893213R CAP1608CHIP 2200PFKB 50V TAPE 0 CT39 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
CPS3 AA00955R CAP.CHIP-CERAMIC 2125 B 4.7UF 0 CT40 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
CPS4 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CT41 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CPS5 AA00955R CAP.CHIP-CERAMIC 2125 B 4.7UF 0 CT42 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CR01 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CT43 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
CR02 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 CT44 0893123R CAP 1608CHIP 56PFJCH 50V TAPE 0
CR03 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 CT45 0893125R CAP 1608CHIP 82PFJCH 50V TAPE 0
CR08 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CT46 0893125R CAP 1608CHIP 82PFJCH 50V TAPE 0
CT01 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V 0 CT47 0893115R CAP 1608CHIP 15PFJCH 50V TAPE 0
LC57F

PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to safety. Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
159
SYMBOL PART No. DESCRIPTION
LC57F
SYMBOL PART No. DESCRIPTION
LC57F
CT48 0893106R CAP 1608CHIP 4PFCCK 50V TAPE 0 CTF1 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT49 0893121R CAP 1608CHIP 39PFJCH 50V TAPE 0 CTF2 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT51 0893125R CAP 1608CHIP 82PFJCH 50V TAPE 0 CTF3 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT52 0893119R CAP 1608CHIP 33PFJCH 50V TAPE 0 CTF4 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) 0
CT53 0893106R CAP 1608CHIP 4PFCCK 50V TAPE 0 CTF5 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT54 0893124R CAP 1608CHIP 68PFJCH 50V TAPE 0 CTF6 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0
CT58 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0 CTF7 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT60 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTG0 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT61 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0 CTG1 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT62 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTG2 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT63 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTG3 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) 0
CT64 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTG4 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT65 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTG5 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT66 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0 CTG6 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT67 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTG7 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT68 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTG8 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT69 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTG9 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT70 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTH0 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT71 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 CTH1 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT72 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) 0 CTH2 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT73 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) 0 CTH3 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT74 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 CTH4 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT75 0893126R CAP 1608CHIP 100PFJCH 50V TAPE 0 CTH5 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CT76 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTH6 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V 0
CT77 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTH9 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT78 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) 0 CTJ2 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CT79 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTJ3 AA00969R CAP.CHIP2125-B-22UF6.3V 0
CT80 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTJ4 AA00969R CAP.CHIP2125-B-22UF6.3V 0
CT81 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0 CTJ5 0893122R CAP 1608CHIP 47PFJCH 50V TAPE 0
CT83 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTJ6 0893123R CAP 1608CHIP 56PFJCH 50V TAPE 0
CT84 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTJ7 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
CT85 0893113R CAP 1608CHIP 10PFCCH 50V TAPE 0 CTJ8 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT86 0893113R CAP 1608CHIP 10PFCCH 50V TAPE 0 CTJ9 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT87 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTK0 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT88 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTK2 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT89 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTK3 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT90 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTK4 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CT91 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTK6 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT92 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTK7 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT93 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTK8 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CT94 AA01216R CAP.CHIP-CERAMIC 1005B 1UF 6.3 0 CTM0 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT95 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTM1 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT96 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTM2 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CT97 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTM3 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT98 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTM4 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CT99 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTM5 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CTA0 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) 0 CTM6 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CTA1 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) 0 CTM7 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) 0
CTA2 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTM8 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0
CTA3 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 CTN0 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CTA4 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTN1 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CTA6 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTN2 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0
CTA7 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTN5 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
CTA8 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTN6 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
CTA9 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTN7 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
CTC0 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CTN8 0893124R CAP 1608CHIP 68PFJCH 50V TAPE 0
CTC1 AA00931R CAP. CERAMIC 2012 (1UF 10V) 0 CTP0 0893123R CAP 1608CHIP 56PFJCH 50V TAPE 0
CTC2 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CTP1 0893107R CAP 1608CHIP 5PFCCH 50V TAPE 0
CTC3 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0 CTP2 0893123R CAP 1608CHIP 56PFJCH 50V TAPE 0
CTC4 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 CTP3 0893107R CAP 1608CHIP 5PFCCH 50V TAPE 0
CTC5 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CV08 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
CTC6 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CV09 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0
CTC7 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CV10 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0
CTC8 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CV11 0893008R CAP.CHIP-CERAMIC 100000PF 16V 0
CTC9 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CV12 AA00955R CAP.CHIP-CERAMIC 2125 B 4.7UF 0
CTE0 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0 CV13 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0
CTE1 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0 CV14 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0
CTE2 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CV15 0893217R CAP 1608CHIP 4700PFKB 50V TAPE 0
CTE4 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 CV16 0893217R CAP 1608CHIP 4700PFKB 50V TAPE 0
CTE5 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0 CW01 AA01123R CCC105K10-B-16CT 0
CTE6 AA01231R 0.1UF 16V 1005-B CERAMIC CAPAC 0 CW02 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0
CTE7 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 CW03 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CTE8 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 CW08 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CTE9 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0 CW09 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
CTF0 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0 CW11 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0
LC57F

PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to safety. Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
160
SYMBOL PART No. DESCRIPTION
LC57F
SYMBOL PART No. DESCRIPTION
LC57F
CW12 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT03 BA00162R CHIP COIL 56NK16CT-HK1608 0
CW14 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT04 BA00862R 2520 CHIP COIL 2.2UH 0
CW15 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT05 BA00192R CHIP COIL 47NJ16CT-HK1608 0
CW16 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0 LT06 BA01227R HK2125 TYPE CHIP INDUCTOR 150N 0
CW17 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0 LT07 BA00162R CHIP COIL 56NK16CT-HK1608 0
CW18 AA00969R CAP.CHIP2125-B-22UF6.3V 0 LT08 BA01234R HK2125 TYPE CHIP INDUCTOR 470N 0
CW19 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0 LT09 BA00189R CHIP COIL 33NJ16CT-HK1608 0
CW20 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT10 BA01234R HK2125 TYPE CHIP INDUCTOR 470N 0
CW21 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT11 BA01225R HK2125 TYPE CHIP INDUCTOR 100N 0
CW22 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT12 BA00191R COIL HCC39NJ16CT-HK1608 0
CW23 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT14 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
CW24 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT15 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
CW25 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT16 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
CW26 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT17 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
CW27 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT18 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
CX01 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V 0 LT19 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
CX02 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V 0 LT20 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
CX03 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT21 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
CX04 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT22 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
CX05 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 LT23 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
CXJ1 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V 0 LT24 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
CXJ2 0893126R CAP 1608CHIP 100PFJCH 50V TAPE 0 LT25 BA02252R 7E06NG TYPE POWER INDUCTOR 6.8 0
CXJ3 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 LT26 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
CXJ4 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V 0 LT27 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
LT28 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
DIODES LT29 BM10348R CHIP FERRITE BEAD BLM18PG121SN 0
DP01 CC00781R DIODE.CHIP RB160L-40(TE25) 0 LT30 BA00189R CHIP COIL 33NJ16CT-HK1608 0
DPS1 CC02211R RSX201L-30 0 LT31 BA01225R HK2125 TYPE CHIP INDUCTOR 100N 0
DPS2 CC01641R DIODE HSU119 0 LT32 BA00191R COIL HCC39NJ16CT-HK1608 0
DT01 CC01131R ZENER.CHIP MAZS3000H 0 LX01 BA00889R LBC2518 CHIP COIL 22UH 0
LX02 BA00889R LBC2518 CHIP COIL 22UH 0
MODULES
HM01 CZ01241 GP1FM514TZ0F IR Reciver 0 TRANSISTORS
QM04 CA02091R SRC1204EF_PF 0
INTEGRATED CIRCUITS (IC's) QP08 CA02091R SRC1204EF_PF 0
IM01 CK37218R MONO IC TK11150CSCL 0 QT01 CA02171R TRS.CHIP 2SC4082T106P 0
IM02 CK50961R SN74CB3T3306DCUR 0 QT02 CA02171R TRS.CHIP 2SC4082T106P 0
IM03 CK38326R IC SN74LVC1G32DCKR 0 QT03 CA02171R TRS.CHIP 2SC4082T106P 0
IP02 CK38851R MAX5026EUT-T 0 QW01 CA02171R TRS.CHIP 2SC4082T106P 0
IP05 CK52131R ANALOG MONOLITHIC IC(VT221H) 0 QW02 CA02091R SRC1204EF_PF 0
IP12 CK51331R TK11100CS 0 QX01 1323293R TRS.CHIP 2SC4617 TL (R/S) 0
IPG1 CK33543R ANALOG MONOLITHIC IC(PST9227N 0 QX02 1323293R TRS.CHIP 2SC4617 TL (R/S) 0
IPS1 CK52141R ANALOG MONOLITHIC IC(SC4517AI 0 QX03 1323293R TRS.CHIP 2SC4617 TL (R/S) 0
IR01 CK50051R MAX4788EXS-T 0 QX04 CA02091R SRC1204EF_PF 0
IT01 CK37218R MONO IC TK11150CSCL 0 QX05 CA02091R SRC1204EF_PF 0
IT02 CK37605R IC TK11250CM 0 QX06 CA02091R SRC1204EF_PF 0
IT04 CK37218R MONO IC TK11150CSCL 0
IT05 CK51131R UPC2711TB 0 RESISTORS
IT06 CK51151R UPC3221GV 0 RM01 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
IT07 CK51141R UPC3220GR 0 RM02 AQ00519R CHIP RESISTOR 47OHM 0
IT08 CK51121U THEATER313 0 RM03 0790051R RES.CHIP 1/16W 10K OHM 0
IT09 CK37211R MONO IC TK11118CSCL 0 RM05 0790051R RES.CHIP 1/16W 10K OHM 0
IT13 CK50071R TPS62040DGQR 0 RM06 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
IV04 CK51591R WM8521H9GED/RV 0 RM13 0196025R RES.-1608CHIP 1/16W 20-J 0
IW01 CK37218R MONO IC TK11150CSCL 0 RM14 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
IW02 CK08271R DIGITAL MONOLITHIC IC (SN74LVC244PW) 0 RM15 0790051R RES.CHIP 1/16W 10K OHM 0
IW03 CK08271R DIGITAL MONOLITHIC IC (SN74LVC244PW) 0 RM16 0790051R RES.CHIP 1/16W 10K OHM 0
IW04 CK38327R DIGITAL MONOLITHIC IC (SN74LVC1G86DCKR) 0 RM17 0790046R RES.CHIP 1/16W 4.7K OHM 0
IW05 CK51161R PI5C32X245BEX 0 RM18 0790059R RES.CHIP 1/16W 47K OHM 0
IW06 CK38378R DIGITAL MONO IC SI-3012KM 0 RM19 0790015R RES.CHIP 1/16W 22 OHM 0
IW07 CK38326R IC SN74LVC1G32DCKR 0 RM20 0790015R RES.CHIP 1/16W 22 OHM 0
IW08 CK38917R DIGITAL MONOLITHIC IC (SN74LVC32APWR) 0 RM21 0790015R RES.CHIP 1/16W 22 OHM 0
IW09 CK36321R SN74LVC125APW 0 RM22 0790015R RES.CHIP 1/16W 22 OHM 0
IW10 CK08271R DIGITAL MONOLITHIC IC (SN74LVC244PW) 0 RP05 AQ00255R RES.CHIP 1/16W 200K OHM TAPE 0
IW11 CK08271R DIGITAL MONOLITHIC IC (SN74LVC244PW) 0 RP06 AQ00217R RES.CHIP 1/16W 7.5K OHM TAPE 0
IW12 CK08271R DIGITAL MONOLITHIC IC (SN74LVC244PW) 0 RP18 AQ00528R CHIP RESISTOR 220OHM 0
IXJ1 CK51331R TK11100CS 0 RP19 AQ00528R CHIP RESISTOR 220OHM 0
RP20 0790051R RES.CHIP 1/16W 10K OHM 0
COILS RP21 0790037R RES.CHIP 1/16W 1.0K OHM 0
LM02 BA00892R LBC2518 CHIP COIL 47UH 0 RP22 AQ00223R RES.CHIP 1/16W 12K OHM TAPE 0
LP01 BA00577R SMD CHIP COIL SLF6028T-470MR59 0 RP23 AQ00243R RES.CHIP 1/16W 68K OHM TAPE 0
LP04 BA02261R 7E08L TYPE POWER INDUCTOR 1.8U 0 RP24 AQ00237R RES.CHIP 1/16W 43K OHM TAPE 0
LPS1 BA02251R 7E06NG TYPE POWER INDUCTOR 4.7 0 RP25 0790064R RES.CHIP 1/16W 100K OHM 0
LT01 BA00161R COIL HCC47NK16CT-HK1608 0 RP26 AQ00247R RES.CHIP 1/16W 100K OHM TAPE 0
LT02 BA01227R HK2125 TYPE CHIP INDUCTOR 150N 0 RP27 AQ00227R RES.CHIP 1/16W 18K OHM TAPE 0
LC57F

PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to safety. Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
SYMBOL PART No. DESCRIPTION
LC57F
SYMBOL PART No. DESCRIPTION
LC57F
RP28 0790051R RES.CHIP 1/16W 10K OHM 0RV16 AQ00185R RES.CHIP 1/16W 470 OHM TAPE 0
RP75 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RV17 AQ00185R RES.CHIP 1/16W 470 OHM TAPE 0
RP76 AQ00245R RES.CHIP 1/16W 82K OHM TAPE 0 RW01 AQ00519R CHIP RESISTOR 47OHM 0
RP77 AQ00233R RES.CHIP 1/16W 30K OHM TAPE 0 RW02 AQ00519R CHIP RESISTOR 47OHM 0
RP78 0790051R RES.CHIP 1/16W 10K OHM 0 RW03 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
RP80 0790024R RES.CHIP 1/16W 100 OHM 0 RW04 AQ00519R CHIP RESISTOR 47OHM 0
RP81 0790047R RES.CHIP 1/16W 5.6K OHM 0 RW05 0790019R RES.CHIP 1/16W 47 OHM 0
RPC1 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RW06 0790019R RES.CHIP 1/16W 47 OHM 0
RPE1 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RW07 AQ00519R CHIP RESISTOR 47OHM 0
RPG3 0790046R RES.CHIP 1/16W 4.7K OHM 0 RW08 AQ00519R CHIP RESISTOR 47OHM 0
RPS1 0790037R RES.CHIP 1/16W 1.0K OHM 0 RW09 AQ00519R CHIP RESISTOR 47OHM 0
RPS2 0790051R RES.CHIP 1/16W 10K OHM 0 RW10 0790019R RES.CHIP 1/16W 47 OHM 0
RPS3 AQ00236R RES.CHIP 1/16W 39K OHM TAPE 0 RW11 0790019R RES.CHIP 1/16W 47 OHM 0
RPS4 AQ00223R RES.CHIP 1/16W 12K OHM TAPE 0 RW12 AQ00519R CHIP RESISTOR 47OHM 0
RPX1 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RW13 AQ00519R CHIP RESISTOR 47OHM 0
RPX2 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RW14 0790019R RES.CHIP 1/16W 47 OHM 0
RR06 0790019R RES.CHIP 1/16W 47 OHM 0 RW15 0790019R RES.CHIP 1/16W 47 OHM 0
RR07 0790019R RES.CHIP 1/16W 47 OHM 0 RW16 AQ00519R CHIP RESISTOR 47OHM 0
RR10 AQ11519R RES CHIP 1/32 823J 3210 0 RW17 0790019R RES.CHIP 1/16W 47 OHM 0
RR11 0790061R RES.CHIP 1/16W 56K OHM 0 RW18 0790019R RES.CHIP 1/16W 47 OHM 0
RT01 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RW19 AQ00519R CHIP RESISTOR 47OHM 0
RT02 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RW20 0790051R RES.CHIP 1/16W 10K OHM 0
RT04 0790052R RES.CHIP 1/16W 12K OHM 0 RW22 0790051R RES.CHIP 1/16W 10K OHM 0
RT05 0790052R RES.CHIP 1/16W 12K OHM 0 RW23 0790051R RES.CHIP 1/16W 10K OHM 0
RT07 0790037R RES.CHIP 1/16W 1.0K OHM 0 RW24 0790064R RES.CHIP 1/16W 100K OHM 0
RT08 AQ00164R CHIP RESITOR 1/16W 75OHM TAPE 0 RW25 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
RT09 0790043R RES.CHIP 1/16W 2.7K OHM 0 RW26 0790051R RES.CHIP 1/16W 10K OHM 0
RT10 AQ00258R RES.CHIP 1/16W 270K OHM TAPE 0 RW27 0790051R RES.CHIP 1/16W 10K OHM 0
RT11 AQ00247R RES.CHIP 1/16W 100K OHM TAPE 0 RW29 0195250R RES 2125 CHIP JAMPER WIRE 0
RT12 AQ00229R RES.CHIP 1/16W 22K OHM TAPE 0 RW31 AQ00243R RES.CHIP 1/16W 68K OHM TAPE 0
RT14 0790046R RES.CHIP 1/16W 4.7K OHM 0 RW32 AQ00247R RES.CHIP 1/16W 100K OHM TAPE 0
RT15 0790037R RES.CHIP 1/16W 1.0K OHM 0 RW33 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
RT16 0790046R RES.CHIP 1/16W 4.7K OHM 0 RW34 AQ00231R RES.CHIP 1/16W 24K OHM TAPE 0
RT17 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RW35 AQ00258R RES.CHIP 1/16W 270K OHM TAPE 0
RT18 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RW36 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
RT19 0790024R RES.CHIP 1/16W 100 OHM 0 RW37 0790019R RES.CHIP 1/16W 47 OHM 0
RT20 0790024R RES.CHIP 1/16W 100 OHM 0 RW38 0790019R RES.CHIP 1/16W 47 OHM 0
RT21 0790052R RES.CHIP 1/16W 12K OHM 0 RW40 0790051R RES.CHIP 1/16W 10K OHM 0
RT22 AQ00212R RES.CHIP 1/16W 4.7K OHM TAPE 0 RW41 0790051R RES.CHIP 1/16W 10K OHM 0
RT23 AQ00244R RES.CHIP 1/16W 75K OHM TAPE 0 RW42 0790051R RES.CHIP 1/16W 10K OHM 0
RT24 0790046R RES.CHIP 1/16W 4.7K OHM 0 RW43 AZ01031R THERMISTOR NANOSMDC050F13.2 0
RT25 0790046R RES.CHIP 1/16W 4.7K OHM 0 RW44 0790019R RES.CHIP 1/16W 47 OHM 0
RT26 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RW45 0790019R RES.CHIP 1/16W 47 OHM 0
RT27 0790024R RES.CHIP 1/16W 100 OHM 0 RW47 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
RT28 0790024R RES.CHIP 1/16W 100 OHM 0 RW48 0790051R RES.CHIP 1/16W 10K OHM 0
RT30 AQ00175R RES.CHIP 1/16W 200 OHM TAPE 0 RW49 0790051R RES.CHIP 1/16W 10K OHM 0
RT31 AQ00175R RES.CHIP 1/16W 200 OHM TAPE 0 RW50 0790051R RES.CHIP 1/16W 10K OHM 0
RT32 0790037R RES.CHIP 1/16W 1.0K OHM 0 RW51 0790051R RES.CHIP 1/16W 10K OHM 0
RT33 0790028R RES.CHIP 1/16W 220 OHM 0 RW52 0790051R RES.CHIP 1/16W 10K OHM 0
RT34 0790028R RES.CHIP 1/16W 220 OHM 0 RW54 0790064R RES.CHIP 1/16W 100K OHM 0
RT36 0790037R RES.CHIP 1/16W 1.0K OHM 0 RW55 0790051R RES.CHIP 1/16W 10K OHM 0
RT37 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RW58 AQ00519R CHIP RESISTOR 47OHM 0
RT40 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RW59 AQ00519R CHIP RESISTOR 47OHM 0
RT42 AQ00175R RES.CHIP 1/16W 200 OHM TAPE 0 RW60 0790019R RES.CHIP 1/16W 47 OHM 0
RT43 AQ00175R RES.CHIP 1/16W 200 OHM TAPE 0 RW61 0790019R RES.CHIP 1/16W 47 OHM 0
RT44 0790019R RES.CHIP 1/16W 47 OHM 0 RW62 0790019R RES.CHIP 1/16W 47 OHM 0
RT45 0790019R RES.CHIP 1/16W 47 OHM 0 RW63 0790051R RES.CHIP 1/16W 10K OHM 0
RT46 0790011R RES.CHIP 1/16W 10 OHM 0 RW64 0790051R RES.CHIP 1/16W 10K OHM 0
RT47 0790011R RES.CHIP 1/16W 10 OHM 0 RW65 0790051R RES.CHIP 1/16W 10K OHM 0
RT48 0790011R RES.CHIP 1/16W 10 OHM 0 RW66 0790051R RES.CHIP 1/16W 10K OHM 0
RT49 AQ00511R CHIP RESISTOR 10OHM 0 RW67 0790051R RES.CHIP 1/16W 10K OHM 0
RT50 AQ00511R CHIP RESISTOR 10OHM 0 RW68 0790051R RES.CHIP 1/16W 10K OHM 0
RT56 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RW73 0790064R RES.CHIP 1/16W 100K OHM 0
RT57 0790035R RES.CHIP 1/16W 680 OHM 0 RX01 0790016R RES.CHIP 1/16W 27 OHM 0
RT64 0790051R RES.CHIP 1/16W 10K OHM 0 RX02 0790024R RES.CHIP 1/16W 100 OHM 0
RT65 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RX03 0790024R RES.CHIP 1/16W 100 OHM 0
RT66 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0 RX04 0790031R RES.CHIP 1/16W 330 OHM 0
RT69 0790051R RES.CHIP 1/16W 10K OHM 0 RX05 0790031R RES.CHIP 1/16W 330 OHM 0
RT70 0790051R RES.CHIP 1/16W 10K OHM 0 RX06 0790031R RES.CHIP 1/16W 330 OHM 0
RT71 AQ00261R RES.CHIP 1/16W 330K OHM TAPE 0 RX07 0790051R RES.CHIP 1/16W 10K OHM 0
RT72 AQ00258R RES.CHIP 1/16W 270K OHM TAPE 0 RX08 0790051R RES.CHIP 1/16W 10K OHM 0
RT73 0790043R RES.CHIP 1/16W 2.7K OHM 0 RX09 0790051R RES.CHIP 1/16W 10K OHM 0
RT74 0790043R RES.CHIP 1/16W 2.7K OHM 0 RXJ1 AQ00241R RES.CHIP 1/16W 56K OHM TAPE 0
RV14 0790051R RES.CHIP 1/16W 10K OHM 0 RXJ2 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
RV15 0790051R RES.CHIP 1/16W 10K OHM 0 RXJ3 AQ00261R RES.CHIP 1/16W 330K OHM TAPE 0
161
LC57F

162
PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to safety. Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
LC57F
SYMBOL PART No. DESCRIPTION
LC57F
SYMBOL PART No. DESCRIPTION
LC57F
C056 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
TEST POINTS C057 AA01123R CCC105K10-B-16CT 0
TPP1 EA00001R CHECKER CHIP 3216 TAPING 0 C058 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
C059 0800326R CAP.-ELECTRO. 100UF-M 16V 0
CRYSTALS & FILTERS C060 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
XP01 BK10323R CERAMIC FILTER NFM2012P13C105F 0 C061 0800326R CAP.-ELECTRO. 100UF-M 16V 0
XP04 BK10324R CERAMIC FILTER NFM2012P13C105BT1 0 C062 0800326R CAP.-ELECTRO. 100UF-M 16V 0
XP05 0195250R RES 2125 CHIP JUMPER WIRE 0 C064 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
XP06 0195250R RES 2125 CHIP JUMPER WIRE 0 C065 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
XPS1 BK10323R CERAMIC FILTER NFM2012P13C105F 0 C066 0893213R CAP1608CHIP 2200PFKB 50V TAPE 0
XT01 BG01624U SAW FILTER(X6875D) 0 C301 0800351R CAP.-ELECTRO. 470UF-M 6.3V 0
XT02 BN00261 BGS TRAP MKTGA47M2CAHP00B05 0 C302 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
XT03 BG01625U SAW FILTER(X6888D) 0 C304 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
XT04 BL01491R OSC25R14X10T 0 C307 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
XT05 BK10324R CERAMIC FILTER NFM2012P13C105BT1 0 C308 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
XT06 BK00281R CHIP CERAMIC FILTER SC16-050 0 C310 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
XT07 BK00281R CHIP CERAMIC FILTER SC16-050 0 C311 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
XX05 BK00191R CHIP CERAMIC FILTER NFL21SP506X1C3D 0 C312 0800353R CAP.-ELECTRO.470UF-M 16V 0
XX06 BK00191R CHIP CERAMIC FILTER NFL21SP506X1C3D 0 C313 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
XX07 BK00193R CHIP CERAMIC FILTER NFL21SP107X1C3D 0 C314 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
C315 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
CONNECTORS, JACKS C316 0800326R CAP.-ELECTRO. 100UF-M 16V 0
JSD1 EY01821R SD MEMORY CARD SOCKET 54768-0977 0 C317 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
JT01 EQ00791 JACK 0 C318 0800326R CAP.-ELECTRO. 100UF-M 16V 0
PFAN EA02132R 3P SMT PH CONNE. POST -LF- 0 C319 0800326R CAP.-ELECTRO. 100UF-M 16V 0
PSA EA00507R 30P FPC CONNECTOR 52559-3092 0 C320 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
PSM EA02221U 0.5 PITCH 240P B TO B CONN. SH 0 C321 0800351R CAP.-ELECTRO. 470UF-M 6.3V 0
PSP1 EY02002 JACK SCAA1A4700 PC CARD 0 C323 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0
PSP2 EY01991 JACK SCAB1A8100 0 C400 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
PTS ED04512U 2.54MM PITCH 120P B TO B PLUG 0 C401 0800352R CAP.-ELECTRO.470UF 10V 0
C402 AA01123R CCC105K10-B-16CT 0
MISCELLANEOUS C403 AA01123R CCC105K10-B-16CT 0
A JP08503 LC57 SUB DIGITAL PWB ASY 0 C404 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
UT01 HJ00541 ENV56N01D5F (TUNER) 0 C406 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
NW01~4 MJ03878 SCRW M3M_2*10PN+SM 0 C407 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
C408 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
C409 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
JT25531 SIGNAL PWB C410 0800352R CAP.-ELECTRO.470UF 10V 0
C411 AA01123R CCC105K10-B-16CT 0
CAPACITORS C412 AA01123R CCC105K10-B-16CT 0
C004 AA01123R CCC105K10-B-16CT 0 C413 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
C006 AA01123R CCC105K10-B-16CT 0 C414 AA01123R CCC105K10-B-16CT 0
C007 0800326R CAP.-ELECTRO. 100UF-M 16V 0 C415 AA01123R CCC105K10-B-16CT 0
C008 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 C416 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
C010 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 C418 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
C012 0800303R CAP.-ELECTRO. 22UF-M 50V 0 C419 0800352R CAP.-ELECTRO.470UF 10V 0
C013 0893213R CAP1608CHIP 2200PFKB 50V TAPE 0 C420 AA01123R CCC105K10-B-16CT 0
C014 0284623R CAP.-ELECTRO. 1UF-SME(BP) 50V 0 C421 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
C017 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 C422 AA01123R CCC105K10-B-16CT 0
C018 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0 C423 0800303R CAP.-ELECTRO. 22UF-M 50V 0
C019 0800326R CAP.-ELECTRO. 100UF-M 16V 0 C424 AA01123R CCC105K10-B-16CT 0
C020 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0 C425 AA01123R CCC105K10-B-16CT 0
C021 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0 C426 AA01123R CCC105K10-B-16CT 0
C022 AA01145R CAP.CHIP-CERAMIC 1608B0.15UF/1 0 C427 AA01123R CCC105K10-B-16CT 0
C023 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 C428 AA01123R CCC105K10-B-16CT 0
C025 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0 C429 AA01123R CCC105K10-B-16CT 0
C026 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 C430 AA01123R CCC105K10-B-16CT 0
C027 0893205R CAP 1608CHIP 560PFKB 50V TAPE 0 C431 AA01123R CCC105K10-B-16CT 0
C028 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0 C432 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0
C029 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 C433 0800352R CAP.-ELECTRO.470UF 10V 0
C033 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0 C434 0800352R CAP.-ELECTRO.470UF 10V 0
C038 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 C435 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V 0
C040 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 C436 0800326R CAP.-ELECTRO. 100UF-M 16V 0
C044 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 C437 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
C045 0800326R CAP.-ELECTRO. 100UF-M 16V 0 C438 AA01123R CCC105K10-B-16CT 0
C046 AA01123R CCC105K10-B-16CT 0 C439 AA01123R CCC105K10-B-16CT 0
C047 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0 C440 AA01123R CCC105K10-B-16CT 0
C048 0800326R CAP.-ELECTRO. 100UF-M 16V 0 C441 AA01123R CCC105K10-B-16CT 0
C049 0893122R CAP 1608CHIP 47PFJCH 50V TAPE 0 C443 0893205R CAP 1608CHIP 560PFKB 50V TAPE 0
C050 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 C447 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
C051 0893122R CAP 1608CHIP 47PFJCH 50V TAPE 0 C448 0800326R CAP.-ELECTRO. 100UF-M 16V 0
C052 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 C453 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
C053 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 C454 0800326R CAP.-ELECTRO. 100UF-M 16V 0
C054 0893122R CAP 1608CHIP 47PFJCH 50V TAPE 0 C500 AA01123R CCC105K10-B-16CT 0
C055 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 C501 AA01123R CCC105K10-B-16CT 0

PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to safety. Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
LC57F
SYMBOL PART No. DESCRIPTION
LC57F
SYMBOL PART No. DESCRIPTION
LC57F
C502 AA01123R CCC105K10-B-16CT 0 D302 2348293M DIODE MTZ-J33CTA 0
C503 AA01123R CCC105K10-B-16CT 0 D500 2348031M DIO-MTZ-J2.7ATA 0
C504 AA01123R CCC105K10-B-16CT 0 D501 2348031M DIO-MTZ-J2.7ATA 0
C505 AA01123R CCC105K10-B-16CT 0 D502 CC01921R SDS142WKF_PF 0
C506 AA01123R CCC105K10-B-16CT 0 D503 CC01921R SDS142WKF_PF 0
C507 AA01123R CCC105K10-B-16CT 0 DA05 CC01922R SDS142WMF 0
C508 AA01123R CCC105K10-B-16CT 0 DA11 CC01921R SDS142WKF_PF 0
C509 AA01123R CCC105K10-B-16CT 0 DA12 CC01921R SDS142WKF_PF 0
C510 AA01123R CCC105K10-B-16CT 0 DA13 CC01921R SDS142WKF_PF 0
C511 AA01123R CCC105K10-B-16CT 0 DA14 CC01921R SDS142WKF_PF 0
C512 AA01123R CCC105K10-B-16CT 0 DA15 CC01922R SDS142WMF 0
C513 AA01123R CCC105K10-B-16CT 0 DA16 2344041M DIODE 1SS254TA/1SS270TA 0
C514 AA01123R CCC105K10-B-16CT 0 DA17 2344041M DIODE 1SS254TA/1SS270TA 0
C515 AA01123R CCC105K10-B-16CT 0 DJ07 CC01911R SDS142WAF_PF 0
C518 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 DJ08 2344041M DIODE 1SS254TA/1SS270TA 0
C519 0800326R CAP.-ELECTRO. 100UF-M 16V 0 DJ09 2344041M DIODE 1SS254TA/1SS270TA 0
C522 0800303R CAP.-ELECTRO. 22UF-M 50V 0 DJ10 CC01921R SDS142WKF_PF 0
C523 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V 0 DJ11 2348282M DIODE MTZ-J30B TAPE 0
C524 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V 0 DJ14 2344041M DIODE 1SS254TA/1SS270TA 0
C526 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V 0 DP01 2342062 DIODE D3SBA60-4103 0
C527 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V 0
C590 0800352R CAP.-ELECTRO.470UF 10V 0 PROTECTORS
C591 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 FE01 2721351 FUSE HOLDER 0
C592 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 FP01 FN00474 FUSE 51MS 060 L-U 125V 6A 0
C593 0800353R CAP.-ELECTRO.470UF-M 16V 0
CA17 0800326R CAP.-ELECTRO. 100UF-M 16V 0 INTEGRATED CIRCUITS (IC's)
CA34 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0 I001 CK50991U M306H3MC-067FP 0
CA35 AA00936R CERAMIC CAP. 2125-X5R 4.7UF 10V 0 I002 CK51111R BD37A41FVM 0
CA36 AA00936R CERAMIC CAP. 2125-X5R 4.7UF 10V 0 I004 CK37216R MONO IC TK11133CSCL 0
CA46 0800279R CAP.-ELECTORO. 1.0UF-M(SMG) 50V 0 I005 CK50951R SN74CB3T3125PWR 0
CA47 0800279R CAP.-ELECTORO. 1.0UF-M(SMG) 50V 0 I301 CP05163S IC SI-3090F(LF1111) 0
CA48 0800279R CAP.-ELECTORO. 1.0UF-M(SMG) 50V 0 I302 CK37605R IC TK11250CM 0
CA49 0800279R CAP.-ELECTORO. 1.0UF-M(SMG) 50V 0 I401 CK39882U MM1630CQ 0
CA50 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 I501 CK39891R MM1631XJBE 0
CA51 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 I591 CP05163S IC SI-3090F(LF1111) 0
CA52 0800318R CAP.-ELECTRO. 47UF-M 25V 0 IA02 2004752 TA8200AHQ 0
CA53 0800318R CAP.-ELECTRO. 47UF-M 25V 0
CA54 0800328R CAP. ELECTRO. 100UF-M 35V 0 JUMPER WIRES
CA55 0880194R CAP.-POLYESTER 0.1UF-J 50V 0 KA01 2784381M 0.60MM TAPED JUMP.WIRE 0
CA56 0880194R CAP.-POLYESTER 0.1UF-J 50V 0 KA02 2784381M 0.60MM TAPED JUMP.WIRE 0
CA57 0880194R CAP.-POLYESTER 0.1UF-J 50V 0 KF04 2784381M 0.60MM TAPED JUMP.WIRE 0
CA59 AL01152S CAP.ELECTROLYTIC 470UF-M(YXF)3 0 KF14 2784381M 0.60MM TAPED JUMP.WIRE 0
CA60 0284824F CAP.-ELECTRO. 2200UF 35V 0 KP02 2784381M 0.60MM TAPED JUMP.WIRE 0
CA61 0284824F CAP.-ELECTRO. 2200UF 35V 0 KP03 2784381M 0.60MM TAPED JUMP.WIRE 0
CA64 258616 CAP.-ELECTRO 2.2UF-M 50V 0 KP04 2784381M 0.60MM TAPED JUMP.WIRE 0
CA65 258616 CAP.-ELECTRO 2.2UF-M 50V 0 KP05 2784381M 0.60MM TAPED JUMP.WIRE 0
CA66 0800319R CAP.-ELECTRO. 47UF-M 35V 0 KP08 2784381M 0.60MM TAPED JUMP.WIRE 0
CA67 0800328R CAP. ELECTRO. 100UF-M 35V 0 KP09 2784381M 0.60MM TAPED JUMP.WIRE 0
CA68 0800279R CAP.-ELECTORO. 1.0UF-M(SMG) 50V 0 KP10 2784381M 0.60MM TAPED JUMP.WIRE 0
CA69 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 KP11 2784381M 0.60MM TAPED JUMP.WIRE 0
CA93 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V 0 KP12 2784381M 0.60MM TAPED JUMP.WIRE 0
CA94 0800326R CAP.-ELECTRO. 100UF-M 16V 0 KP13 2784381M 0.60MM TAPED JUMP.WIRE 0
CA95 0800359R CAP.-ELECTRO. 1000UF-M 10V 0 KPD1 2784381M 0.60MM TAPED JUMP.WIRE 0
CA96 AA00936R CERAMIC CAP. 2125-X5R 4.7UF 10V 0 KPD2 2784381M 0.60MM TAPED JUMP.WIRE 0
CA97 AA00936R CERAMIC CAP. 2125-X5R 4.7UF 10V 0 KPD3 2784381M 0.60MM TAPED JUMP.WIRE 0
CA98 0893193R CAP 1608CHIP 10000PFKB 25V TAPE 0 KPD4 2784381M 0.60MM TAPED JUMP.WIRE 0
CJ00 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0
CJ01 AA00991R CERAMIC CAPACITOR(0.1UF 50V-B) 0 COILS
CJ02 AL01105R CAP.ELECTROLYTIC 1000UF-M(YXF) 0 L002 BH00697R FILTER COIL 100UH 0
CJ04 0800326R CAP.-ELECTRO. 100UF-M 16V 0 L003 BH00697R FILTER COIL 100UH 0
CJ05 0893222R CAP 1608CHIP10000PFKB 50V TAPE 0 L005 BH00697R FILTER COIL 100UH 0
CJ09 AL01105R CAP.ELECTROLYTIC 1000UF-M(YXF) 0 L006 BH00697R FILTER COIL 100UH 0
CJ10 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 L007 BH00697R FILTER COIL 100UH 0
CJ11 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 L400 BH00697R FILTER COIL 100UH 0
CJ12 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 L401 2123781R FILTER COIL 100UH(EL0607) 0
CJ30 0800288R CAP.-ELECTRO. 4.7UF-M(SMG) 50V 0 L402 BH00697R FILTER COIL 100UH 0
CP01 AJ00167F CAP.CERAMIC CS12-F2GA472MYNS 0 L403 BH00697R FILTER COIL 100UH 0
CP02 AJ00167F CAP.CERAMIC CS12-F2GA472MYNS 0 L500 BH00697R FILTER COIL 100UH 0
CP03 AL02762 CAP.ELEC. 680UF 200V MXC SERIES 0 LA01 BH00697R FILTER COIL 100UH 0
CP04 AL02762 CAP.ELEC. 680UF 200V MXC SERIES 0 LJ00 2125797N FILT.COIL(LHL08 10UH) 0
LJ01 2125797N FILT.COIL(LHL08 10UH) 0
DIODES LJ02 2125803N FILT.COIL(LHL08 27UH) 0
D005 2344041M DIODE 1SS254TA/1SS270TA 0 LJ03 2125803N FILT.COIL(LHL08 27UH) 0
D013 2348123M ZENER MTZJ-6.2C TA 0
D301 2348212M ZENER DIODE MTZ-J15B 0
163
!
!
!
!

164
LC57F
PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to safety. Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
SYMBOL PART No. DESCRIPTION
LC57F
SYMBOL PART No. DESCRIPTION
LC57F
R030 0790042R RES.CHIP 1/16W 2.2K OHM 0
TRANSISTORS R032 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
Q002 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R033 0790046R RES.CHIP 1/16W 4.7K OHM 0
Q003 CA02091R SRC1204EF_PF 0 R034 0790028R RES.CHIP 1/16W 220 OHM 0
Q005 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R035 0790051R RES.CHIP 1/16W 10K OHM 0
Q006 CA02091R SRC1204EF_PF 0 R037 0790051R RES.CHIP 1/16W 10K OHM 0
Q008 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R038 0790055R RES.CHIP 1/16W 22K OHM 0
Q009 CA02091R SRC1204EF_PF 0 R039 0790052R RES.CHIP 1/16W 12K OHM 0
Q011 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R040 0790064R RES.CHIP 1/16W 100K OHM 0
Q012 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R042 0790059R RES.CHIP 1/16W 47K OHM 0
Q013 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R043 0790046R RES.CHIP 1/16W 4.7K OHM 0
Q014 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R044 0790064R RES.CHIP 1/16W 100K OHM 0
Q015 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R046 0790046R RES.CHIP 1/16W 4.7K OHM 0
Q017 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R047 0790047R RES.CHIP 1/16W 5.6K OHM 0
Q018 CA02091R SRC1204EF_PF 0 R048 0790047R RES.CHIP 1/16W 5.6K OHM 0
Q021 CA02092R SRC1202EF 0 R049 0790056R RES.CHIP 1/16W 27K OHM 0
Q025 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R052 0790051R RES.CHIP 1/16W 10K OHM 0
Q026 CA02091R SRC1204EF_PF 0 R053 0790059R RES.CHIP 1/16W 47K OHM 0
Q027 CA02091R SRC1204EF_PF 0 R055 0790024R RES.CHIP 1/16W 100 OHM 0
Q029 CA02091R SRC1204EF_PF 0 R056 0790038R RES.CHIP 1/16W 1.2K OHM 0
Q030 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R057 0790052R RES.CHIP 1/16W 12K OHM 0
Q301 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R058 0790037R RES.CHIP 1/16W 1.0K OHM 0
Q400 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R060 0790051R RES.CHIP 1/16W 10K OHM 0
Q401 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R067 0790037R RES.CHIP 1/16W 1.0K OHM 0
Q402 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R068 0790046R RES.CHIP 1/16W 4.7K OHM 0
Q403 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R069 0790037R RES.CHIP 1/16W 1.0K OHM 0
Q407 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R070 0790033R RES.CHIP 1/16W 470 OHM 0
Q408 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R071 0790051R RES.CHIP 1/16W 10K OHM 0
Q409 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R074 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
Q410 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R075 0790051R RES.CHIP 1/16W 10K OHM 0
Q500 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R076 0790051R RES.CHIP 1/16W 10K OHM 0
Q501 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R077 0790037R RES.CHIP 1/16W 1.0K OHM 0
Q502 CA00461R TRS.CHIP 2SD2114K 20V TAPE 0 R078 0790024R RES.CHIP 1/16W 100 OHM 0
Q503 CA00461R TRS.CHIP 2SD2114K 20V TAPE 0 R079 0790024R RES.CHIP 1/16W 100 OHM 0
Q504 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R080 0790024R RES.CHIP 1/16W 100 OHM 0
Q505 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R081 0790024R RES.CHIP 1/16W 100 OHM 0
QA01 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R082 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
QA02 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R083 0790051R RES.CHIP 1/16W 10K OHM 0
QA03 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R085 0790059R RES.CHIP 1/16W 47K OHM 0
QA04 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R086 0790037R RES.CHIP 1/16W 1.0K OHM 0
QA05 CA00461R TRS.CHIP 2SD2114K 20V TAPE 0 R091 0790024R RES.CHIP 1/16W 100 OHM 0
QA06 CA00461R TRS.CHIP 2SD2114K 20V TAPE 0 R092 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
QA07 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R102 0790037R RES.CHIP 1/16W 1.0K OHM 0
QA08 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R103 0790037R RES.CHIP 1/16W 1.0K OHM 0
QA13 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R104 0790037R RES.CHIP 1/16W 1.0K OHM 0
QA14 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R108 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608 0
QA15 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R110 0790037R RES.CHIP 1/16W 1.0K OHM 0
QA18 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R111 0790051R RES.CHIP 1/16W 10K OHM 0
QA19 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R112 0790037R RES.CHIP 1/16W 1.0K OHM 0
QA20 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R113 0790037R RES.CHIP 1/16W 1.0K OHM 0
QA21 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R114 0790051R RES.CHIP 1/16W 10K OHM 0
QA22 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R115 0790051R RES.CHIP 1/16W 10K OHM 0
QJ00 CA02091R SRC1204EF_PF 0 R116 0790051R RES.CHIP 1/16W 10K OHM 0
QJ01 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R119 0790024R RES.CHIP 1/16W 100 OHM 0
QJ02 CA02132R TRS.CHIP 2SA1980UFG_PF 0 R120 0790024R RES.CHIP 1/16W 100 OHM 0
QJ03 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R121 0790024R RES.CHIP 1/16W 100 OHM 0
QJ04 CA02142R TRS.CHIP 2SC5343UFG_PF 0 R122 0790037R RES.CHIP 1/16W 1.0K OHM 0
R123 0790037R RES.CHIP 1/16W 1.0K OHM 0
RESISTORS R124 0790037R RES.CHIP 1/16W 1.0K OHM 0
R002 0790024R RES.CHIP 1/16W 100 OHM 0 R125 0790037R RES.CHIP 1/16W 1.0K OHM 0
R006 0790046R RES.CHIP 1/16W 4.7K OHM 0 R126 0790037R RES.CHIP 1/16W 1.0K OHM 0
R009 0790058R RES.CHIP 1/16W 39K OHM 0 R127 0790037R RES.CHIP 1/16W 1.0K OHM 0
R010 0790059R RES.CHIP 1/16W 47K OHM 0 R128 0790037R RES.CHIP 1/16W 1.0K OHM 0
R011 0790051R RES.CHIP 1/16W 10K OHM 0 R129 0790037R RES.CHIP 1/16W 1.0K OHM 0
R014 0790059R RES.CHIP 1/16W 47K OHM 0 R130 0790024R RES.CHIP 1/16W 100 OHM 0
R015 0790051R RES.CHIP 1/16W 10K OHM 0 R131 0790024R RES.CHIP 1/16W 100 OHM 0
R017 0790024R RES.CHIP 1/16W 100 OHM 0 R132 0790024R RES.CHIP 1/16W 100 OHM 0
R019 0790044R RES.CHIP 1/16W 3.3K OHM 0 R133 0790024R RES.CHIP 1/16W 100 OHM 0
R020 0790051R RES.CHIP 1/16W 10K OHM 0 R134 0790024R RES.CHIP 1/16W 100 OHM 0
R021 0790055R RES.CHIP 1/16W 22K OHM 0 R135 0790024R RES.CHIP 1/16W 100 OHM 0
R023 0790037R RES.CHIP 1/16W 1.0K OHM 0 R136 0790024R RES.CHIP 1/16W 100 OHM 0
R024 0790024R RES.CHIP 1/16W 100 OHM 0 R137 0790024R RES.CHIP 1/16W 100 OHM 0
R027 0790057R RES.CHIP 1/16W 33K OHM 0 R138 0790037R RES.CHIP 1/16W 1.0K OHM 0
R028 0790051R RES.CHIP 1/16W 10K OHM 0 R139 0790051R RES.CHIP 1/16W 10K OHM 0
R029 0790059R RES.CHIP 1/16W 47K OHM 0 R140 0196060R RES 1608 CHIP 1/16W 510J TAPE 0
