Hitachi CST258PC User manual

TECHNICAL SPECIFICATIONS
Power Consumption.........................11W
Mains Voltage................220V/240V 50Hz
Fuse.....................................T3.15A Type
December 1998
SM00016
CST258PC
CST258PS
CST32APC
CST32APS
CST32BPW
SERVICE MANUAL
CAUTION:
Before servicing this chassis, it is important that the service technician read the
“Safety Precautions” and “Product Safety Notices” in this service manual.
Data contained within this
Service manual is subject to
alteration for improvement.

ASSEMBLY SUPPLEMENT
The following pages are extracted
from the Customer Assembly Guide to
assist Service Engineers.





        
      

 

       
 !
       

" #     
$%&'$%     

      
     
   
     (
     
      
       

      

$%&'$%
       
)*+
, &
 -     
     

. %       #
  .//0 1'     

2 3      
     "0 &' 
,.0 1'      

4       



      
 
    







 $%&'$%' 
      
     
   

        

       
   

5

        
!.06 $
       
   

 $        
       7 

       
    )*
!
      
!809!:
;
" )*
        
       
    )* -
 )*   
       $%&'$%

, <
 1      
      
=


%        ! 



R
S
AUDIO LINE INAUDIO LINE IN
SURROUND
OUTPUT
INPUT
C
L
DC.18V.200mA
2 x 6W16
....
....
Speaker Console
Assembly Guide
CST32APC/PS

notes on safety
This equipment has been designed and manufactured to meet international safety standards, but like any electrical equipment, care must
be taken if you are to obtain the best results and safety is to be assured.
Please read these assembly instructions before you attempt to use the equipment.
Do ensure that all electrical equipment (including the mains plug, extension leads and interconnections between pieces of equipment) are properly
made in accordance with the manufacturers instructions. Switch off and withdraw the mains plug when making or changing connections.
Do consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.
Do be careful with any glass panels or doors on equipment.
Do not continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in any way - switch off,
withdraw the mains plug and consult your dealer.
Do not place water filled vessels on top of your TV’s cabinet.
Do not remove any fixed cover as this may expose dangerous voltages.
Do not leave equipment switched on when it is unattended unless it is specifically stated that it is designed for unattended operation or
has a standby mode. Switch off using the switch on the equipment and make sure that your family know how to do this. Special
arrangements may need to be made for infirm or handicapped people.
Do not obstruct the ventilation of the equipment, for example with curtains or soft furnishings. Overheating will cause damage and shorten
the life of the equipment.
Do not use makeshift stands and NEVER fix legs with wood screws - to ensure complete safety always fix the manufacturers approved
stand or legs with the fixings according to the instructions.
Do not allow electrical equipment to be exposed to rain or moisture.
NEVER let anyone especially children push anything into holes, slots or any other opening in the case - this could result in a fatal shock.
NEVER guess or take chances with electrical equipment of any kind - it is better to be safe than sorry.

pagepage
assembly guide contents
Console parts .....................................................................................................................1
Step 1: speaker box assembly.............................................................................................2
Step 2: side panel preparation ...........................................................................................3
Step 3: console preparation ...............................................................................................4
Step 4: fixing your TV to the console .................................................................................5
Step 5: securing the speaker to the console .....................................................................6
Step 6: assembly of glass door...........................................................................................7
Sound option 1.....................................................................................................................8
Sound option 2 ...................................................................................................................9
Step 7: surround speaker connection (free standing unit) ................................................10
Step 8: surround speaker connection (wall mounted unit) ................................................11
Sound mode and technical data ........................................................................................12
Guarantee ..........................................................................................................................13
title

X2
X5
X2
X2
X2
X2
X2
X2
X20
X1
X1
X2
A
X10
X4
X2
X2
X2
X2
X9
B
C
G
F
E
D
HIJ
KLM
N
OQ
T
S
X8
R
X2
P
11
U
console parts
NOTE: For the construction of this
console you will also require a
Phillips screwdriver (not supplied).
If any parts are missing please consult
your dealer immediately.

C
1c1c
1b1b
1a1a B
1d1d
C
A
T
I
22
Magnetic
end
Insert door catch ‘A’ onto the underside of
the speaker box and fix with screws ‘B’.
To ensure the plug is
secure, a distance of
4mm is required from the rear
face of the speaker to the head of
the screw...
...to aid with
measurement,
place component
‘I’ alongside screw
‘T’ and adjust the
screw so that the head is flush with the
centre of ‘I’.
a. Insert bushes ‘C’ into the speaker grille.
b. Push fit the speaker grille onto the front of
the speaker box assembly.
Speaker box is now prepared for
later stages
DO NOT connect plug to mains at this
stage - ensure that plug socket is
secure to speaker
Step 1: speaker box assembly
a. Insert screws ‘T’. The screw heads are to be used to support the 4 point plug socket.
b. Fit the 4 point plug socket onto the back of the speaker box as illustrated.

33
2a2a 2b2b
2c2c 2d2d
BB
EEFF
DD
BB
F
F
Step 2: side panel preparation
a. Use screws ‘B’ to fix bracket ‘E’ to the side pillar.
b. Use screws ‘B’ to fix the side pillar and bracket to
the side panel as illustrated.
c. Repeat these steps to assemble the side panels for
the other side of the console.
Insert the metal cam fixings ‘F’ into
the slotted side of the side panels.
Use a screw driver to
insert dowel ‘D’ into the
the pillar.
Repeat this step to the
other pillar.
Ensure that the long slot of the of the cam fixing ‘F’ is
pointing towards the hole on the edge of the side panel.
Fit the pillar to
the assembled
side pillar and
side panel as
illustrated.
Turn the cam fixing, ‘F’
clockwise to lock the
pillar in place.
Now repeat this process to assemble
the panels for the other side of the
console.

3a3a
44
3b3b GG
I
,,,
,,,


yyy
yyy
zzz
zzz
{{{|||
,,,
,,,


yyy
yyy
zz
zz
{{{||
{|
|
|
,yz
,,

yyzzz
{{|||
,

H
G

Step 3 : console preparation
a. Use 12 screws,‘G’ to fix the base of the console to the side
panels, as illustrated. Use the allen key ‘U’ to tighten the
screws.
b. Push fit the glide feet ‘H’ in place.
a. Turn the console over, onto its feet, and slide the back panel
into place.
b. IMPORTANT - Before fixing the top panel in place, make
sure that it is facing the correct way up!
The side with large recessed holes must be on the
underside.
Once you are sure that the top panel is fitted correctly, use 4
screws,‘G’ to fix the top panel to the side panels, as illustrated.
Use the allen key, ‘U’ to tighten the screws.
c. Fit both components ‘I’ in place.
IMPORTANT
These holes have a recess
on one side. The top panel
must be fitted so that the
recess is on the underside.

4c4c
KK
X4 X2
each side
4b4b
JX2
55
4d4d
C
G
G
4a4a
I
+
The TV is heavy - seek assistance when placing
the TV onto the console.
Secure the TV to the console with 2 screws ‘J’.
a. Insert dowels ‘K’ into the highest positioned
holes found in the side panels, (2 per side).
b. Insert 4 dowels ‘K’ into the speaker shelf
and place the shelf into the cabinet (you may
have to tilt the shelf at an angle to allow it to
pass through the front pillars). Rest the shelf
on the dowels in the side panels.
a. Secure the shelf to the side panels with
screws ‘G’.
Use the allen key ‘U’ to tighten the screws.
b. Insert 2 bushes ‘C’ into the base panel
as illustrated.
Step 4: fixing your TV to the console

5b5b
5c5c 5d5d
66
K
5a5a
SS
Step 5: securing the speaker to the console
At the back of the console, under the top shelf, insert a dowel ‘K’,
as illustrated. This is to prevent the speaker box from being
inserted too far into the console at the next stage.
Slide the speaker box into the console,
between the dowels on the shelf.
Check that the speaker box
locates correctly with the dowel
that was inserted at step 5a.
From underneath, secure
the speaker to the
supporting shelf with 2
screws ‘S’. The TV console unit is now
ready for the attachment of
the glass doors.

R
6a6a 6b6b
77
6c6c
M
R
N
O
L
+
+M
R
Q
P
L
+
+
a.
b.
Step 6: assembly of glass door
DO NOT overtighten
screws
GLASS
DO NOT overtighten
screws
GLASS
Attachment of left hand side door fittings. Attachment of right hand side door fittings.
DO NOT overtighten
screws
GLASS
Fit the left hand door first, as illustrated.
a. Insert the bottom hinge (already fixed to the door) into
the bush, in the base panel.
b. Insert the top hinge into the bush, in the speaker grille,
then slide the glass door into the hinge and tighten
screws ‘R’.
NB When the door in closed, screws ‘R’ should be
concealed, on the inside of the cabinet.
Repeat this procedure,
to fit the right hand
side door.
The left hand door is
now ready to be fitted
to the console
The right hand door is
now ready to be fitted
to the console

INPUT
C
S
R
L
C
S
R
L
SC
RL
AUDIO LINE IN
SURROUND
2 x 6W 16
OUTPUT
INPUT
88
sound option 1: console speaker with
surround speaker option
black plug black plug
green plug
blue plug
red plug
white plug
green plug
blue plug
red plug
white plug
Connection from rear of TV... ...to rear of speaker console
Surround speaker connections from speaker box console
Surround speakers.
(As supplied with your
speaker console.)
2. ONLY use surround speakers with impedance,
as stated on your console speaker box.
1. THESE connectors must only be connected
to the sockets on the speaker box and NOT the
TV’s sockets.
IMPORTANT...
For connection of leads to speakers see
page 10 - ‘Surround Speaker Connection’
magnification of speaker box sockets

RL
SCR L
AUDIO LINE OUT
OUTPUT
S
2 X 12W 8
SC
RL
AUDIO LINE IN
SURROUND
2 x 6W 16
OUTPUT
INPUT
R
R
L
L
SC
AUDIO LINE OUT 2 X 12W 8
INPUT
R
C
L
R
C
L
99
AUDIOLINE INAUDIOLINE IN
SURROUNDSURROUND
2 x 6W 162 x 6W 16
infra-red speaker connections (not supplied)
sound option 2: console speaker with infra-red
surround speaker option
Connection from rear of TV... ...to rear of speaker console
black plug
green plug
blue plug
red plug
white plug
black plug
blue plug
red plug
white plug
green plug
Connect infra-red leads to TV ‘S’ socket and output socket of speaker box
Infra-red signal sent to
speakers for output of sound
(refer to instructions supplied
with infra-red unit)
Rear view of TV and
console
Magnified
view of model
C32WD2TN
Magnified view of speaker box
sockets
NOTE: In this option socket
‘S’ of the speaker box
console and green plugs
are not used.
Magnified view
of models
C32W35TN and
C32W40TN

7a7a
7b7b 1Press down on switch to allow entry into connector - repeat for other switch
and insert leads into appropriate speaker connectors -
grey with black stripe into black connector
plain grey into red connector
1
1010
black
red
plain grey
grey with black stripe
Step 7: surround speaker connection
free-standing unit
Remove connector cover from speaker housing to expose connection switches.
Replace connector cover after lead connection is complete.
Speaker connection lead

1111
Step 8: surround speaker connection
wall mounted unit
Remove the connection cover from the speaker housing to expose the
connector sockets. Connect the leads as shown on the previous page,
then secure the connection cover to an interior wall as illustrated.
Place speaker housing back
onto secured connector cover.
Speaker and sound direction can
now be angled for individual
needs.

Mains Voltage....................................................................................................................................................................................220 - 240V AC 50Hz
Power Consumption................................................................................................................................................................11 W
Dimensions (console only) ................................................................................................................................................890 x 440 x 475 (mm)
Power Output..................................................................................................................................................................................20 W through Sub Woofer
12 W through Centre
2 x 6 W through Surround
External Speaker Impedance...........................................................................................................................................2 x 16 Surround
1212
( W x D x H )
sound mode
technical data
When all the equipment is connected, it is recommended that the 'Normal'
'Speaker Set Up’ mode is selected, in order to achieve the best possible audio performance.
For more information regarding the various speaker modes,
refer to 'Speaker Set Up' in the main Users Guide.

1313
Your Guarantee of Excellence
ThankYou for purchasing this Hitachi Speaker Console
In the unlikely event that this product should develop a fault, we undertake to replace or repair any part of
the product which fails due to a manufacturing defect within 12 months of the date of purchase provided that:
i) The product has been installed and used only in accordance with the instructions supplied with the product
ii) The product has not been repaired , maintained or modified by any person other than an Hitachi authorised engineer
iii) The product serial number has not been removed or altered
This Guarantee does not apply to product aquired secondhand or for commercial or communal use.
Any parts replaced under this Guarantee shall become the property of
Hitachi Home Electronics (Europe) Ltd.
Please note that evidence of the date of purchase will be required before any service
 under this Guarantee is carried out.
This Guarantee does not affect your statutory rights - in all cases of diffuculty please consult your Hitachi dealer
guarantee

International Sales Division
THE HITACHI ATAGO BUILDING
Nº15 - 12 Nishi Shinbashi, 2 - Chome
Minato-Ku, Tokyo105, Japan
Tel. [phone]
ac
h
, d
...all around the world
HITACHI HOME ELECTRONICS ( EUROPE) Ltd, Hitachi House, Station Road, Hayes, Middlesex, UNITED KINGDOM, UB3 4DR, Tel: [phone]
HITACHI SALES EUROPA GmbH, Am Seestern18, 40547 Dusseldorf, DEUTSCHLAND, Tel: [phone]
HITACHI SALES ITALIANA SPA, ViaGulli n.39,20147 Milano, ITALIA, Tel: 0039 - 2 - 48768
HITACHI FRANCE (RADIO-TV-ELETRO-MENAGER) S.A., 4 Allee des Sorbiers,
Parc d’activite du Chene, BP 45, 69671 Bron cedex, FRANCE,
Tel: [phone]
HITACHI SALES IBERICA, S.A., Gran Via Carlos Tercero. 101,1-1, Barcelona 08028,
ESPAÑA, Tel: [phone]
HITACHI HOME ELECTRONICS (HELAS) S.A, 91 Falirou St117-41 Athens, GREECE,
Tel: [phone]
HITACHI HOME ELECTRONICS (NORDIC) AB, Haukadalsgatan 10, Box 77, 164 94 Kista,
SVERIGA, Tel: [phone]
HITACHI HOME ELECTRONICS NORWAY, Brugata 14, N-0186 Oslo, NORGE, Tel: [phone]
ITEM N.V./S.A.(INTERNATIONAL TRADE FOR ELECTRONIC MATERIAL & MEDIN.V./S.A.),UCO Tower Bellevue, 17-9050 Gent, BELGIQUE (for BENELUX) Tel: [phone]
X831712
