Hitech ZOpid User manual

DIGITAL WIRELESS CAMERA
USER MANUAL
NOTE REGARDING FCC COMPLIANCE
Users are not permitted to make changes or modify the device in any way.
Changes or modifications not authorized by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:(1) This device many not cause harmful
interference,and (2) This device must accept any interference received,
including interference that may cause undesired operation.
FCC Notice to Users
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and the receiver.
●Connect equipment to an outlet on a circuit different from that to which the
receiver is connected.
●Consult the dealer or an experienced radio/TV technician for help.
1

a.POWER ON:
Connect Camera to an A/C outlet using the included A/C adapter.
NOTE: Camera also works with a built-in rechargeable battery, or by
connecting it to a computer's USB port using a USB cable.
In Power Off Mode, press and hold ON/OFF button for 3 seconds.
Power-indicator LED lights-up indicating the camera is ON.
b.POWER OFF
To turn off the Camera press and hold ON/OFF button for 3 seconds, the
Power-indicator LED turns OFF indicating the Camera is OFF.
c.BATTERY STATUS
When the Camera is not connected to an A/C adapter or computer's USB
port, it automatically operates on built-in rechargeable battery. When the
battery voltage falls below 3.6V the Power Indicator LED turns RED from
GREEN, indicating the battery needs to be charged.
d.NIGHT-VISION(IR)OPERATION:
The camera is equipped with eight(8) Infrared LEDS for night-vision
operation. In low light situation the Infrared LEDS turn-on automatically, to
activate night-vision.
NOTE: The night-vision picture is always black & white and not that sharp.
This camera has up to 10 feet night-vision range
e.CAMERA STAND / MOUNTING BRACKET:
Screw the stand to the camera screw hole. Use a coin to tighten the screw on the back.
2
Coin

● Turn Monitor ON
● Press"OK/MENU"button on the monitor to display Main Menu.
● Use "UP"or "DOWN"button to highlight "Multi Camera" Option and press
"OK/MENU" button to complete the selection.
● From "Multi Camera" Menu highlight "Register Camera" using "UP" or
"DOWN" button and press "OK/MENU"button to complete the selection
● From "Register Camera" Menu highlight one of the available(not used) camera
number you want to assign to this new camera and press "OK/MENU" button to
complete the selection.
NOTE:Camera numbers which have already been allocated (used to register existing
cameras) have "thumbs up" sign next to the camera number.
● Use "UP" or "DOWN" button to select "Yes" and press "OK/MENU"
button to complete the selection;the screen will display "register camera
#" where # is the camera number you selected.
● Press and quickly release ON/OFF button on the CAMERA to complete pairing
process - IMPORTANT: Camera must be powered ON and this step must be
completed while the monitor screen displays "register camera #".
● If pairing is successful, the screen will display "Camera # Registered",where # is
the camera number you selected in previous step. "Thumbs up" sign will appear
next to the camera #.
NOTE:If the pairing/registration process is not successful, repeat this process again.
● Press "ESC" button twice to exit from the Menus and view the camera.
Coverage:Hi-Tech Trading (USA),Inc.("HiTT") warrants this product
("Product") against defects in materials and workmanship under normal
consumer use for 1 year from the date of purchase. HiTT, at its option, will
at no charge repair, replace or refund the purchase price of this Product
should it not conform to this warranty. This limited warranty is a consumer's
exclusive remedy, extends only to the first consumer purchaser, is not
transferable and is valid only on Products purchased by consumers in the
United States or Canada.
Limited 1 Year Warranty
3
Camera Selection
Register Camera
Multi Camera
Settings
Camera 1
Camera 2
Camera 3
Camera 4
Camera 5
Camera 6
Camera 7
Camera 8
Register Camera Register Camera
Register Camera 1?
Yes No
f.REGISTER/PAIR NEW CAMERA WITH THE MONITOR:
● Turn camera power ON
IMPORTANT:Make sure all other cameras are powered OFF during pairing
process.

Exclusions:
Normal Wear and Tear:Periodic maintenance, repair and replacement of
parts due to normal wear and tear are excluded from coverage.
Batteries:Only batteries whose fully charged capacity falls below 80% of
their rated capacity and batteries that leak are covered by this limited
warranty.
Miscellaneous:This warranty does NOT cover defects or damage that
result from:(a) improper operation, storage, misuse or abuse, accident or
neglect, such as physical damage(cracks,scratches,ets.) To the surface of
the Product resulting from misuse;(b) contact with liquid, water, rain,
extreme humidity or heavy perspiration, sand, dirt or the bike, extreme heat,
or food;(c) use of the Product for commercial purposes or subjecting the
Product to abnormal usage or conditions;(d) service, installation, alteration,
or modification in any way by someone other than HiTT and,(e) other acts
which are not the fault of HiTT.Obtaining Service:To obtain service or
information, please send email to .You will receive
instructions on how to ship the Product, at your expense, to a HiTT Service
Center. To obtain service, you must include a copy of your receipt.
[e-mail]
ZOpid and the stylized logo are registered in the US Patent &Trademark
Office.All other product or service names are the property of their
respective owners.
©2009 Hi-Tech Trading(USA),Inc.
The information contained in this User Manual is believed to be correct at the
time of printing. HiTT reserves the right to change or modify any information
or specifications without notice. The contents of this User Manual are
provided "as is." Except as required by applicable law, no warranties of any
kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fintness for a particular purpose, are made
in relation to the accuracy, reliability, or contents of this guide.
Hi-Tech Trading (USA),Inc.
P.O.Box 179
Woodbury,New York 11797
Email:
Web:
[e-mail]
www.hittusa.com
4
