Installation Instructions for HMI HOYME ADP-1102-S5A
Interlocks 24Vac Combustion Air Control Damper
To 120Vac Safet Control Circuit
INST LL TION OF THIS D PTOR SH LL BE
IN CCORD NCE WITH REQUIREMENTS OF
THE UTHORITIES H VING JURISDICTION.
Refer also to HMI HOYME Installation Instructions:
‘Combustion ir Control, Series HOM’.
ADP-1102-S5A
4” x 5” x 2 1/2”
101 x 127 x 64 mm
This daptor, with two relays, senses a line
voltage stat, proves a 24Vac damper to be open
and then sends a signal back to line stat circuit for
firing. For 250mVdc – 100Vdc refer to Installation
Instruction for DP- 0MV2-S5 .
I.D.: ADP- 1102 – S5A; Includes-
- Relay: DPDT Coil-120Vac Contacts-24Vac
- Relay: SPDT Coil-24Vac Contacts-120Vac,
5 mps
- TEST/RUN manual Switch.
- For one appliance, use one daptor and one
Damper, Series HOM, Type-SF1.
- For two appliances, use two daptors and
one damper, Series HOM, Type-SF1.
- daptors may be mounted on side of
appliance control box. Leads must be
suitably cabled and fastened. Refer to local
electric codes.
-Use an approved 24Vac transformer of
adequate capacity (10 V min.) if required.
- Supply for the transformer primary shall be
taken from the line voltage supply for the
appliance. Refer to applicable codes.
- lways conduct a thorough checkout after
installation is complete.
- ffix attached wiring diagram label adjacent
to appliance wiring diagram label.
1. Turn temperature control to lowest setting.
2. Turn off electrical power to heating
appliance.
3. Disconnect line voltage burner lead form
terminal B1 on line voltage control. See wiring
Diagram.
4. Connect daptor BL CK lead to terminal B1
on line voltage control. ( Sensor)
5. Using screw-on wire connector, join daptor
RED lead to burner wire normally connected to
terminal B1 of line voltage control. (Signal)
6. Connect daptor WHITE lead to terminal B2
of line voltage control.
7. Connect damper wires BL CK (1), RED (2),
BROWN (3) and BLUE (5) to daptor terminals
1, 2, 3 and 4 respectively. Note: daptor c/w
‘TEST/RUN’ manual switch. When using two
daptors for two appliances connected to one
damper, daptor terminals 1,2, 3 and 4 may be
connected to like terminals of the other daptor.
8. Connect 24Vac continuous supply to daptor
terminals 3 and 5.
9. Turn on electrical power supply. Damper will
close. Note: ‘TEST/RUN’ manual switch shall be
in the ‘RUN’ position.
10. Turn temperature control to call for heat.
Damper will open and heating appliance will
operate normally.

1207-ch 2 Printed in Canada
For more information, please contact HMI HOYME Manufacturing Inc. @ 1-800-661-7382
www.ho me.com
Note: Where a low limit may allow operation of the
burner or fuel valve when thermostat is not calling for
heat, damper shall be used only in conjunction with
daptor as shown.
Note: This marking is also on label to be
affixed adjacent to appliance wiring diagram.
dditional wire shall be of the same size as originally
used when completing electric circuits.
TYPICAL SCHEMATIC WIRING DIAGRAM FOR
COMBUSTION AIR CONTROL DAMPER INTER-
LOCKED TO LINE VOLTAGE SAFETY CONTROL
CIRCUIT USING ADAPTOR ADP-1102-S5A
