BWI Eagle AIR-EAGLE XLT Manual

PRODUCT INFORMATION
BULLETIN
105 Bonnie Drive
Butler, PA 16002
724-283-4681
724-283-5939 (fax)
www.bwieagle.com
AIR-EAGLE®XLT
900MHz RF Receiver
MODEL 441-20800-AC
DESCRIPTION
The AIR-EAGLE XLTis an RF system designed for medium to long range
wireless remote control of electricalapparatus in avariety of industrial
applications. Systems can consist of any number of receivers and
handheld or contact input transmitters working together.This receiver is
equipped with 8 independent relays that are capable ofswitching 5 amps
@ 120VAC or 30VDC. The relays are user programmable for momentary
or toggle/latching operation and can be directly interfaced withthe
customer's equipment or P.L.C. Seven user selectable frequencies allow
multiple systems to be used inthe same area. Capable of receiving
remote signals transmitted from up to 2500 feet away (with the handheld
transmitter) or up to 2 miles away (withthe contact input transmitter),the
Air-Eagle XLT utilizes spread-spectrum technology and provides the
utmost security and reliability even in the noisiest RF environments.
SERIES FEATURE
The “441” Series features repeating capability. Transmitters can be set
up to send “repeat signal packets”, and any transmitter or receiver
within its range will repeat the signal packet to help propagate
communication over widespread areas.
INSTALLATION
DISCONNECT AC Power from all equipment before installation.
1. Mount the AIR-EAGLE XLT RECEIVER in a convenient location.
2. Install relay wiring to terminal strip.
3. Install antenna onto antennaconnector located onthe right side on
the enclosure.
4. Connect supplied power input cable to your external power source.
TERMINAL STRIP WIRING
1
N/O Relay #1
10
N/O Relay #4
19
N/O Relay #7
2
C Relay #1
11
C Relay #4
20
C Relay #7
3
N/C Relay #1
12
N/C Relay #4
21
N/C Relay #7
4
N/O Relay #2
13
N/O Relay #5
22
N/O Relay #8
5
C Relay #2
14
C Relay #5
23
C Relay #8
6
N/C Relay #2
15
N/C Relay #5
24
N/C Relay #8
7
N/O Relay #3
16
N/O Relay #6
8
C Relay #3
17
C Relay #6
9
N/C Relay #3
18
N/C Relay #6
AC POWER INPUT
Terminal #1
100-250 VAC
Terminal #2
100-250 VAC
DIMENSIONS
APPROVALS
United States (FCC)
MCQ-XB900HP
Canada (IC)
1846A-XB900HP

AIR-EAGLE®XLT
900MHz RF Receiver
MODEL 441-20800-AC
RELAY & FREQUENCY SET-UP
This unit is shipped from the factory with the SEL1 switches in the open
positions. All eight relays will operate in a maintained momentary manner,
and unit is receivingcommands on frequency one. If you wish to change
these default settings, follow the instructions on the table below.
1) Remove power from unit
2) Remove top cover.
3) Select desired relay operation and/or networkfrequency using table
below.
4) Reattach cover and apply power.
5) Programming is now complete.
RELAY CONFIGURATION
SEL1
SWITCH
NUMBER
OPEN
CLOSED
SW1
Relays #1 thru #8 maintained
momentary (default)
Relays #1 thru #8
toggle/latch
SW2
Not used on this model
Maintained Momentary –Relay mimics button or input –when
depressed or closed, relay will be energized; when released, relay de-
energizes
Toggle Latch –Relay changes (and holds) its state each time the
corresponding button or input is depressed or closed.
SW3
Vibrating Feedback OFF
(default)
Vibrating Feedback ON
SW4
Not used on this model
FREQUENCY SET-UP
SEL1
(SW5-7)
Network
Frequency
SW5
SW6
SW7
1 (default)
OPEN
OPEN
OPEN
2
CLOSED
OPEN
OPEN
3
OPEN
CLOSED
OPEN
4
CLOSED
CLOSED
OPEN
5
OPEN
OPEN
CLOSED
6
CLOSED
OPEN
CLOSED
7
OPEN
CLOSED
CLOSED
GENERAL OPERATION
Relays #1 thru #8 energize or de-energize based on specific
commands from a handheld or contact input transmitter.
BUTTON OR
INPUT
ACTIVATED
RELAY OPERATION
"1"
Relay #1 energizes,maintained momentary
"2"
Relay #2 energizes, maintained momentary
"3"
Relay #3 energizes, maintained momentary
"4"
Relay #4 energizes, maintained momentary
“5”
Relay #5 energizes, maintained momentary
“6”
Relay #6 energizes, maintained momentary
“7”
Relay #7 energizes, maintained momentary
“8”
Relay #8 energizes, maintained momentary
SPECIFICATIONS
Power Input
100-250 VAC, 5 W, 50/60 Hz
Fuse Protected
1 amp
Relay Contacts
SPDT 5 amp @ 120VACor 30VDC per
channel
Receiver Range
Up to 2500 feet when using handheld
transmitter / Up to 2 miles when using
stationary transmitter & external high gain
antennas
Note: Max range figures are estimates, based on free-air terrain with limited sources of
interference. Actual range will vary based on transmitting power, orientation of transmitter and
receiver, height of transmitting antenna, height of receiving antenna, weather conditions,
interference sources in the area, and terrain between receiver and transmitter, including, but not
limited to, indoor and outdoor structures such as walls, metal objects, trees, buildings, hills, and
mountains.
Receiver Frequency
900 MHz Spread Spectrum
RF Networks
Seven Independent Frequencies
Enclosure
Hinged fiberglass with window / NEMA 3,
3R, 4, 12, 13
Operating Temp
-40oF to +185oF
Weight
Approx 3.83 lbs.
ACCESSORIES
Standard Antenna (Included):
900MHz TNC “Rubber Duck” Antenna
49-1103
High Gain Antennas –
Used to help achieve max range in both non line of sight and line
of sight applications. - Contact BWI Eagle for recommendations
900MHz Thru-Hole Mount Omni Directional Antenna
49-2101
900MHz Magnet Mount Omni Directional Antenna
49-2102
900MHz Omni Directional Antenna
49-3101
900MHz Yagi Antenna
49-3102
High Quality Coax Cables –
Used to connect external high gain antennas to control unit
Flex Coax Cable w/Connectors –Available
in 5’,15’,25’,30’,40’,60’,80’,100’ Lengths
49-4000-XX
(XX = # of Feet)
Bulkhead Extensions –
Used to provide an external antenna connection whenmounting
control unit inside another enclosure
TNC Male to TNCBulkhead Cable Assembly
- Available in 2’, 4’, 7’ Lengths
49-5004-X-ISO
(X = # of Feet)
LIMITED WARRANTY STATEMENT
BWI Eagle Inc. warrants the Air-Eagle XLT Remote Control System, if properly
used and installed, will be free from defects in material and workmanship for a
period of 1 year after date of purchase. Saidwarranty to include the repair or
replacement of defective equipment. This warranty doesnotcoverdamage
dueto external causes, including accident, problems with electrical power,
usage not in accordance with product instructions, misuse, neglect, alteration,
repair, improper installation, or improper testing. This limitedwarranty, andany
implied warranties that may exist under state law, apply only to the original
purchaser of the equipment, and last only for as long as such purchaser
continues to own the equipment. This warranty replaces all other warranties,
express or implied including, butnot limitedto, theimplied warranties or
merchantability and fitness for a particular purpose. BWI Eagle makesno
express warranties beyond those stated here. BWI disclaims without limitation,
implied warranties of merchantability and fitness for a particular purpose. Some
jurisdictions do not allow the exclusion of implied warranties so this limitation
may not apply to you. To obtain warranty service, contact BWI Eagle for a
return material authorization. When returning equipment to BWI Eagle, the
customer assumes the risk of damage or loss during shipping and is
responsible for the shipping costs incurred.
DOCUMENT DATE: 03/04/2021 / PRODUCT REV. 5
