SMARTFiber Pro
Fiber Optic Power Meter
for Wavelength 850/1300/
1310/1490/1550/1625
User Manual
Model No. 257835Pro

Introduction
Features
Product description
Accessories
Key definition
Specification
Instructions for operation
3-1 TEST MODE
3-2 RECORD MODE
3-3 BROWSE MODE
3-4 SET MODE
3-5 ZERO MODE
3-6 LIMIT MODE
Instructions for battery
Driver installation
Maintenance
Storage conditions
Warranty
03
04
05
06
07
08
09
10
13
18
20
21
24
28
28
44
44
44

Introduction
The Optical Power Meter is a high accuracy optical power
measurement tool. It tests dynamic range of optical power
from +3 to –60dBm with six calibrated wavelengths:
850nm, 1300nm, 1310nm, 1490nm, 1550nm and 1625nm.
With Hobbes Optical Power Meter, it displays a pass or fail
result according to the threshold the user has defined. It
also has the capability to identify modulate signals (270Hz,
1kHz, 2kHz) simultaneously by the power source for
identification purposes. For fast and easy operation in
testing the corresponding wavelengths, we recommend
the Hobbes optical light source (OPTIsource) as a
complete instrument in auto-identifying wavelength of
optical power source.
It utilizes an InGaAs detector for an improved sensitivity
and temperature stability. It also has the capacity to record
up to 1000 test data that is up-loadable to a PC via USB
connection for easy and convenient report purposes.
03

Features
• Portable, high accuracy and dynamic power meter
• Calibrated at 850nm, 1300nm, 1310nm, 1490nm, 1550nm
and 1625nm
• Relative and absolute power display
• With self-calibrated ZERO function
• Ideal for both multi-mode and single-mode optical fibers
• Identify modulate signals (270Hz, 1kHz, 2kHz) for
identification purposes
• Automatic wavelength switching
• Optional adapter to test both 2.5mm/1.25mm fiber cables
• Battery low indicator and auto power shut off
• 1000 data item storing and uploading
• Pass/fail indication by user-defined threshold
04

Product description
1. Replacement connector
2. LCD display
3. On/Off (cancel)
4. Mode (backlight)
5. (Wavelength)
6. dBm/W
7. Up
8. Down
9. Enter (save/edit)
10. Rubber cover
11. Battery holder
12. Stand
13. USB connector
13
12
11
1
3
5
7
9
2
4
6
8
10
05

Accessories
(Protective zipped bag
with PU foam inside)
(Portable strap)
(User manual)
(Driver installation CD)
SMARTFiber Pro
Fiber Optic Power Meter
for Wavelength 850/1300/
1310/1490/1550/1625
User Manual
Model No. 257835Pro
06
(USB 2.0 cable)
(SC and ST connector)

Key definition
Marking Name Function
On/Off
(cancel)
Power button
Cancel button
1. Press the button for a few
seconds to power the unit
“on” or “off”
2. When the power is on, press
the button to activate or
deactivate auto off function.
3. Cancel setting button, return
to test mode.
Mode
(backlight)
1.Mode button
2.Backlight button
1. 6 Selection modes: TEST
(default mode) RECO/BROW/
SET/ZERO/LIMIT Mode.
2. Press the button for a few
seconds to activate or
deactivate the backlight.
Wavelength
selection button
Wavelength selection for
850nm, 1300nm, 1310nm,
1490nm, 1550nm and
1625nm
dBm/W Unit
selection button
Optical power measurement
in dB, dBm, Watt.
Up
Down
Enter
(save/edit)
Increase
the number
Decrease
the number
Key operation
(execution)
Selection or execution
Decrease the number or
letters
Increase the number
or letters
07

Specifications
Sensor type: InGaAs
Wavelength: 850nm, 1300nm, 1310nm, 1490nm,
1550nm, 1625nm
Dynamic Range: +3 to –60dBm
Accuracy: ±0.15dB±1nW@1300nm/1310nm/1490nm/
1550nm, ±0.25dB±1nW@850nm/1625nm
Resolution: 0.01dBm
Unit: dBm, Watt, dB
Fiber connector: Replacement type for FC, ST, SC
Battery: AA battery x 4(1.5V)
Dimension: 202.8 x 107 x 64.5mm
Weight: Around 550g (without battery)
08

Instructions for operation
1.Turn on/off the unit
Turn the unit on:
Press and hold the “On/Off” button for a few seconds,
the unit will display all the screen contents on the LCD
until button is released. The unit then enters the TEST
MODE automatically.
When power is on, press “On/Off” button to activate/
deactivate auto power off function. (Note: auto off time
is 5 minutes)
When power is on, press “On/Off” button for a few seconds
to turn off the unit.
09

2. Backlight function
When power is on, press “Mode” button for a few seconds
to activate/deactivate LCD backlight.
3. Mode selection
When Power is on, press “Mode” button to enter the mode
selection menu. 6 Selection Modes: TEST MODE, RECORD
MODE, BROWSE MODE, SET MODE, ZERO MODE, and
LIMIT MODE.
Press the “Mode” button to switch between mode options
and press the “Enter” to select the corresponding mode.
3-1 TEST MODE
TEST Mode is set by default when powering the unit on. In
TEST MODE, the meter receives fiber power source, tests
and displays power value, and a pass/fail indicator by user-
defined threshold.
10

Note:
During the power value -dBm rate measuring.
1. Current Wavelength
2. Power Value
3. TEST mode
4. Battery Status
How to measure in db power value
Step 1: First, set power reference value (REF):
(Press and hold “dBm/W” button for a few seconds to set
the current power values as power reference value)
1
2
3
4
11

Step 2: Formula and Example are as follow:
Formula:
The current value (in dBm) –REF = the current value (in dB)
Example:
REF= –46.97dBm, the current value (in dB)= –13.79
Then the current value (in dBm) = (–46.97dBm) + (–13.79dB)
= –60.76dBm
Switch power measure of three types to power value.
Press “dBm/W” button to switch power measure (dB, dBm,
or Watt)
Change wavelength
Press “button” to change wavelength at 850nm, 1300nm,
1310nm, 1490nm, 1550nm and 1625nm.
Reference value setting
Press “dBm/W” button for a few seconds to set the current
power values as power reference value (in dBm measure)
12

Saving data in TEST MODE
Step 1: Press “Enter” button for a few seconds to save the
current test result.
Step 2: User can press “Up” and “Down” button for setting
the fiber ID. Otherwise, the unit prepares the fiber ID
according to 1 step increment. The fiber ID is from 1 to 999.
3-2 RECORD MODE
By using SMARTFiber Pro RECORD MODE function, user can
test the stability of LD light source in a period of time. In
RECORD MODE, the unit tests and restores fiber power value
automatically in a period of time. The recording test result
from record mode is only viewable in SMARTFiber Pro
application after recording data upload to the PC, it is not
available in browse mode. Once the record set up is finished,
device will test and record power value in set up test time.
The default test time is 15 minutes, and default sample
frequency is 5 seconds.
13

14
RECORD MODE Selection
Press “Mode” button to select the RECO mode, and then
press Enter button to enter the mode.
In wavelength selection submenu, pressing “Up” and “Down”
button will change wavelength. After selection, pressing the
“On/Off” button will cancel the operation and return to
previous menu.

Set auto test time parameter
Pressing the “Enter”buttons to increase or decrease the
value parameter and sample frequency parameter, 15/ 30/
60/ 120/ 180/ 240/ 300 minutes is available (default is 15
minutes). Press “On/Off” button to cancel the operation,
and return to previous menu.
00 15
00 15
TIME
TIME
Auto off
R
Note:
The 0015 stands for 15 minutes. It is test parameter.
15

Set sample frequency parameter
Press the “Up” and “Down” buttons to increase or decrease
the value, 5/10/15/20/30/60 seconds is available, default
is 5 seconds, then press “On/Off” button to cancel the
operation, and return to previous menu.
0005
0005
SAMP
SAMP
Auto off
R
Note:
The 0005 stands for 5 seconds. It is sample frequency
parameter. After setting, press “Enter” button to start
the auto test. Then press the “On/Off” button to stop
the auto test.
16

Note:
LCD displays the remaining time. It is 00 hour, 14 minutes,
23 seconds.
1. Hour (Counting down automatically)
2. Minutes and Seconds (Counting down automatically)
3. Testing automatically
4. RECORD Mode
1
2
3
4
17

Note:
LCD displays current wavelength, fiber ID, power value.
1. Current wavelength
2. Fiber ID or the number of Records
3. Power value in dBm
4. BROWSE Mode
1
2
3
4
3-3 BROWSE MODE
In the mode, user can browse fiber ID, power value
and wavelength.
18

Note:
The deleted record item can not be browsed.
Step 1: Press “Mode” button to select the BROWSE mode,
and then press “Enter” button to enter the mode.
Step 2: Press the “Up” and “Down” button to change the
test results forward or backward.
Step 3: Pressing and Holding the “Enter” button a few
seconds will delete the current record.
19

3-4 SET MODE
In SET MODE, user can set identification number for each
fiber cable in order to identify the cable test result. Cable
name is only viewable in SMARTFiber Pro application, it is
not available in BROWSE MODE.
For example:
When saving the test results in TEST mode, user can set the
fiber ID and the cable name to be displayed when test result
data are uploaded to a PC.
Step 1: Press “Mode” button and select the SET mode. Then
press “Enter” button to enter the mode. Cable naming can be
set up to 4 characters: from 0 to 9, then to A to Z sequences.
Step 2: Press “Up” and “Down” button to increase/decrease
each character number.
Step 3: Press “Enter” button to begin next character setting.
Step 4: Press “Enter” button for a few seconds to save the
setting. When cable naming is incomplete, the corresponding
field will flash to indicate missing field.
Step 5: Press “On/Off” buttons to return to previous menu.
