TLL90S Digital Protractor
User Guide V2.0

2022 Aug 15
1
Features:
1) High accuracy up to ±0.005°, high resolution 0.001°
2) Dual and single axis angle measurement, LCD display will automatically
rotate to user friendly displaying angle.
3) Laser module installed for level alignment
4) Rechargeable
5) V Shape Aluminum metal case for easy to fit at the corner or pipe.
6) 2 Side Magnetic bases with milled surface
7) Audible alarming at settable angle range
8) Any angle measurement with gyro
9) USB / Bluetooth to pc connection (*need to order adapter)
10) PLC Modbus RS485 connection with 6P6C socket, connect up to 255
unit in one network

2022 Aug 15
2
Specifications
Gravity Measurement Accuracy: 0 to 20°: ±(0.005°)
20 to 70°: ±(0.01°)
70 to 90°: ±(0.005°)
*After Calibrated
Measuring range: Single axis: 360°, Dual axis: ±40°
Resolution: 0.001°
Gyro Measurement ±0.5°
Accuracy:
Gyro Measurement 0.1°
Resolution:
Gyro Rotation Speed: <90°/s
Display Response time: <0.3 second
Audio sound: 60dB @ 30cm
Zero offset drift angle per °C: 0.002°(typical)
Operating temperature: 0 to 50°C
Storage temperature: -10 to 60°C
Laser Power: CLASS 2
Laser Wavelength: 650nm
User Interface: Mono-color LCD with backlight
Supply Power: Rechargeable Li-Polymer 3.7V
Charger port: 5V 500mA Mini type-B USB port
Power Consumption: Standby: 10uA, Operation: 20mA.
Standby Battery Life: 4000 hours
Operating Battery Life: 30 hours
Dimensions (in mm): 93(L) x 66(W) x 28(H)
Magnetic Base: affix at 2 faces
Magnetic Force: N35
Weight: 120gram

2022 Aug 15
3
Laser use and care!
-For Class II, Class IIIA, Class IIIB, Class IV grade laser product has potentially hazard.
-Do not stare into the direct or reflected laser beam yourself, not even from a
distance.
-Do not allow children to use the laser product with or without supervision
Please follow and notice the warning sign on the laser product, if the text of the warning
label is not in your national language, stick the provided warning label in your national
language over it before operating.

2022 Aug 15
4
Button Functions
Button
Function Descriptions
Normal Mode
MENU Mode
This button turns the device ON.
Press and release will turn laser on/ off.
Long Press for 3 seconds will turn off.
Serves as the
escape key at
menu mode
When pressed, the current reading is set to
zero; subsequent measurements are relative
to this reading. The LCD will show
the icon to indicate the device is in zero
mode.
Press and hold for 3 seconds to enable or
disable sound. The icon on LCD will be
displaced accordingly. The buzzer alarming
could be set at different accuracy level. Refer
to section “Angle Alarming”.
Serves as the
upward key for
option selection
When pressed, the current value will freeze;
the unit icon flashes to indicate the
reading is on hold.
Press and hold for 3 seconds to switch the
measurement mode: Degree -> mm/M ->
Gradient %
Serves as the
downward key at
menu mode

2022 Aug 15
5
Press and hold for 3 seconds to enter MENU
mode, for set mode options.
Serves as the Set
key.
Any angle measurement start button. Refer to
section “Any Angle”
Press and hold for 3 seconds to enter MENU
mode, for set mode options.
Serves as the Set
key.
LCD Icons Representations
Battery status indication icons
These icons indicate the battery level. There are 3
levels representing empty, half and full.
In dual-axis mode, the LCD displays the direction of tilt
graphically. It will show as E bubble to display the
direction of tilt
Degree mode. Flash when unit is in HOLD mode
mm/M, the height of one end for 1m long plate.
Gradient % mode. Flash when unit is in HOLD mode

2022 Aug 15
6
Sound notification on.
Blank as off
Show this logo as relative value is showing. When the
Zero button is pressed, the unit reset current angle to
zero.
Direction of tilt icons, show the tilt angle direction
Dual-Axis Mode. Both the X and Y axis angle will be
showed. Dual axis mode measures inclination up to
±40 degree for each axis before it automatically
switch to single axis mode.
Single Axis Mode. Measure slope up to ±90 degree.
The triangle icon indicates the direction of tilt with
respect to the bottom right corner of the unit.

2022 Aug 15
7
Battery Charging
It has a built in Lithium Ion rechargeable battery. A standard charger is supplied that the
input voltage is 110V to 240V AC, 50/60Hz, and the output is 5V DC, 500mA. The
charger operating procedure is list below:
1) Plug the Charger into AC socket, the RED indicator on the charger should turned
ON,
2) Plug the USB charging cable to the Charger,
3) Insert the other end of the USB cable to the unit,
4) The battery icon on the LCD blinks to indicate charging in process. Upon charging
complete, the icon stops blinking.
5) The charging time is approx. 3 hours.
The unit could also be charged by connecting the USB cable to the unit and a computer’s
USB port. This has the same effect when charging the unit with the provided adaptor.
Note: When the unit is turned OFF, and plug in the USB charge cable, the LCD will no
show anything, it is NORMAL. Once the unit is turned ON, the battery icon should flash
indicating the unit is in charging mode.
Relative/ Absolute Measurement
Relative Measurement
LCD Icon:
Absolute Measurement
LCD Icon: Blank
Relative and Absolute Mode Switching:

2022 Aug 15
8
1 Press and release the “ZERO” key to set the relative measurement zero point
2 Press and release the “ZERO” key to cancel the relative zero point and back to
absolute measurement mode.
Hold Function
Holding Mode:
LCD Icon blinking:
Holding function:
1. Press and release the “HOLD” key to activate holding function, digit will freeze.
2. Press and release the “HOLD” key to cancel the holding function.
Menu Mode
Press and hold for 3s enter Menu Mode.
Inside Menu mode, user can use “Up”and “Down”button to select the menu setting item,
and then press “Angle/Set” button to confirm

2022 Aug 15
9
POWER:
Auto Power Off
For no movement in 30 minutes, the unit will power off.
Or we can set to never sleep mode at below instruction.
Power auto off setting:
1. Press and hold “SET”/ “ANGLE” key and enter MENU mode
2. Select “POWER” by “ZERO” and “HOLD” key, press “SET” key to enter Power
mode
3. Scroll “NEVER” or “30MIN” by “ON/OFF” and “HOLD” key
4. Press “SET” key to confirm NEVER or 30MIN (30 minutes) sleep
FACTORY SET:
Restore Factory Setting
When you find that the unit is abnormal, you can restore the unit to factory setting.
All calibration setting will be restored to factory setting.
*Not suggest restore to factory setting in normal status, for accuracy drift, please follow
Calibration. After factory set, please redo calibration to ensure the accuracy.
Restore to factory setting:
1. Press and hold “SET”/ “ANGLE” key and enter MENU mode
2. Select “FACTORY SET” by “ZERO” and “HOLD” key, press “SET” key to enter
FACTORY SET mode
3. Scroll “YES” or “NO” by “ZERO” and “HOLD” key
4. Press “SET” key to confirm

2022 Aug 15
10
ALARM:
Angle Alarming
Alarming Mode:
LCD Icon:
Alarming Angle setting:
1. Press and hold “SET”/ “ANGLE” key and enter MENU mode
2. Select “ALARM” by “ZERO” and “HOLD” key, press “SET”or “ANGLE” key to
enter Alarm Setting
Press and hold “ZERO” and “HOLD” key for fast scrolling the digit.
3. Press “SET”or “ANGLE” to enter setting value
SINGLE AXIS
Vertical / Single axis mode alarming angle (Degree)
DUAL AXIS X
Horizontal/ Dual axis mode X axis alarming angle (Degree)
DUAL AXIS Y
Horizontal/ Dual axis mode Y axis alarming angle (Degree)
RANGE
The range (Degree)that will trigger the audible alarming
For example: SINGLE. set to 20.000
RANGE set to 01.000
While the unit is in +19° to +21°or -19 °to -21°, the unit will
alarm
TRIGGER AREA
INSIDE or OUTSIDE to set the alarm will alarm in of range
or out of range

2022 Aug 15
11
LEVEL CAL.
Calibration
Calibrate the unit, once you found that there is accuracy drift on the unit. You can verify
the accuracy at below step:
At Step1, you measured X and Y value, X1 and Y1
At Step2, you measured X2 and Y2, in theory X1=-X2, Y1=-Y2.
If the error is too large, you can enter calibration mode to eliminate the error
Accuracy drift is causing by large ambient temperature change (5 to 10 Degree Celsius)
or the unit has been dropped.
Calibration Procedure:
Step 1: Press and hold the “Angle/Set” key enter Menu mode. Select “LEVEL CAL.”
mode, press “SET”. Place the unit on a flat table (no need perfect level table)
LCD display “DUAL AXIS CALIBRATION”, press “SET” and buzzer will beep; wait until
the beep sound stop. While the buzzer is beeping keep the unit stable.

2022 Aug 15
12
Step 2: Then rotate the unit 180 degree with the other side against the same place.
Press the Set button again and wait for the beep finished.
Step 3: LCD display “SINGLE AXIS CALIBRATION”. Place the unit horizontal like the
picture “STEP 3” and then press “SET”, wait until the beep sound stop.
Step 4: Then rotate the unit 180 degree at the same place. Press the “ZERO” button
again and wait for the beep finished.

2022 Aug 15
13
Step 5: LCD display “SINGLE AXIS CALIBRATION”, mention that the ON/OFF Key at
upper side, hold on a flat wall. And then press “SET” Key. Wait for the “Beep” sound stop.
Step 6: Then rotate the unit 180 degree with the other side against the same place of
wall (ON/OFF Key at upper side). Press the Set button again and wait for the beep
finished. Now, the LCD should go back to the selection menu. The calibration is done, by
selecting “Back” to go back for normal operation
GYRO ANY ANGLE measurement:
Any angle measurement is using gyro technique.
You can measure the angle between two faces, not only in earth gravity direction.
1) Press Angle key at the first face, and then rotate slowly and must keep the rotation
axis to another testing face
2) It will then show the angle once you do not move the unit.

2022 Aug 15
14
The rotation axis:
Any Angle Measurement Method:
Example: Measure angle between two walls is 88.2°

2022 Aug 15
15
GYRO CAL.
Calibrate Gyro
1) Press and hold the “Angle/Set” key enter Menu mode. Select “GYRO CAL.” mode,
press “SET”
2) Place the unit on a flat table (no need perfect level table) and then press set

2022 Aug 15
16
3) Flip 360 degree in clockwise and then press set
Please rotate slowly to increase the accuracy
4) Place unit at flat table and then press set

2022 Aug 15
17
5) Flip 360 degree counter clockwise and then press set
Please rotate slowly to increase the accuracy

2022 Aug 15
18
COMMUNICATION
Data Communication
PORT SELECTION:
PORT: Select USB port or RS485 port as communication port.
RS485 PORT:
RS485 is 6P6C socket
Pin1&2 is power DC 6 to 9V
Pin 3 is RS485 A
Pin 4 is RS485 B
Pin 5&6 is ground.
USB port:
It is not standard USB protocol, but serial port
Pin 1 is VBUS to provide 5VDC
Pin 2 is D-, RS232 TX transmission pin in cmos 3.3V level
Pin 3 is D+, RS232 RX transmission pin in cmos 3.3V level
Pin 4 is not connected
Pin 5 is GND ground
** can order a RS232 adapter to convert to USB serial port and connect to computer.

2022 Aug 15
19
TX Mode:
There is 2 communication mode, one is Auto Mode, which can send the data
automatically for each sampling, and send in ASCII RS232 user setting baud rate.
1) Communication is in ASCII format for AUTO MODE:
Mode
ASCII format
Dual axis Degree mode
“DUAL X:-00.000* DUAL Y:+00.000*\r”
Single axis Degree mode
“SING:-00.000*\r”
GYRO mode
“GYRO:-00.000*\r”
Single axis mm/M mode
“SING:-000.00mm/M\r”
Single axis % gradient mode
“SING:-00.000%*\r”
3) REPLY MODE, will use Modbus format to ask and reply:
Communication is in RTU MODBUS format for REPLY MODE:
Can connect up to 255 TLL90 in the same RS485 network
Modbus protocol of communication
Sent to read (16 bit) (example to modify display mode)
Hex
Dec
Purpose
0x01
1
Address of device
0x03
3
Function read
0x00
0
High Byte of register address (100 Display mode)
0x66
102
Low Byte of register address (100 Display mode)
0x00
0
High Byte of number of register to read (Always 0)
0x02
2
Low Byte of number of 16 bit register to read
0x24
36
Low Byte of CRC
0x14
20
High Byte of CRC
