sauermann E INSTRUMENTS E6000 Installation and operation manual

OPERATING & MAINTENANCE
MANUAL
E6000
Combustion Analyzer
Respect your environment: think before printing the full manual on paper

3K600000000EJ 032438 220519
TABLE OF CONTENTS
1.0 IMPORTANT INFORMATION 07
1.1 Information about this manual 07
1.2 Safety warnings 07
2.0 SAFETY 08
2.1 Intended use of the product 08
2.2 Improper use of the product 08
3.0 WORKING PRINCIPLE 09
3.1 General overview of the Analyzer 09
4.0 DESCRIPTION OF THE PRODUCT 11
4.1 Working principle 11
4.2 Measurement cells 11
4.3 CO dilution 11
4.4 Fuel types 12
4.5 Pressure sensor, piezoelectric, temperature compensated 12
4.6 Gas extraction pump 12
4.7 Simultaneous measurement of pressure, O2, pollutants 12
4.8 Smoke measurements 12
4.9 Temperature measurements 12
4.10 Auxiliary measurements 12
4.11 Bluetooth® connection 12
5.0 DESCRIPTION OF COMPONENTS 14
6.0 MAIN CONFIGURATIONS 17
7.0 TECHNICAL SPECIFICATIONS 18
7.1 Technical specifications 18
7.2 Measurement and Accuracy Ranges 20
8.0 USING THE FLUE GAS ANALYZER 21
8.1 Preliminary operations 21
8.2 Warnings 21
8.3 Analyzer power supply 22
8.3.1 Checking and replacing the batteries 22
8.3.2 Use with external power pack 22
8.4 QR Code generation 22
8.5 Connection diagram 23
8.5.1 Gas Sampling Probe 25
8.5.2 Condensate trap and fine dust filter 26
8.5.3 Connecting the gas sampling probe
(standard / average CO) and water trap assembly 26
8.5.4 Gas probe for industrial engines 26
8.5.5 Combustion air temperature sensor 27
8.5.6 Tc-K temperature measurement probe 27
8.5.7 Ionization current measurement probe 27

4K600000000EJ 032438 220519
TABLE OF CONTENTS
8.5.8 Draft measurement pressure gauge compliant
with UNI 10845 standard. 27
8.5.9 Pressure Test Kit 27
8.5.10 Burner pressure verification probe 27
8.5.11 Connection to PC 27
8.5.12 Connection to battery charger 28
9.0 POWER ON - OFF 29
9.1 Starting the device 29
10.0 CONFIGURATION 31
10.1 Configuration Menu 31
11.0 MEMORY 73
11.1 Memory Menu 73
11.1.1 Memory Organization 75
12.0 PRINT 88
12.1 Print Menu 88
13.0 MEASUREMENTS 99
13.1 Measurements Menu 99
14.0 COMBUSTION ANALYSIS 118
14.1 Combustion Analysis 118
14.1.1 Switching on the instrument and auto-calibration 118
14.1.2 Inserting the probe inside the stack 118
14.1.3 Simultaneous measurement of pressure, O2, pollutants 119
14.1.4 Flue Gas Analysis 119
14.1.5 End of Analysis 119
14.2 Combustion Analysis - Preliminary operations 121
14.3 Performing the Combustion Analysis - Manual mode 123
14.4 Performing the Combustion Analysis - UNI 10389 mode 125
14.5 Performing the Combustion Analysis - BImSchV mode 127
14.6 Performing the Combustion Analysis - Data logger mode 128
15.0 SENSORS 130
15.1 Sensors arrangement 130
15.2 Sensor types and relevant positioning 131
15.3 Gas sensors life 131
15.4 CxHy sensor for measurement of the unburnt hydrocarbons 132
15.4.1 Installing the CxHy sensor 132
16.0 MAINTENANCE 133
16.1 Routine maintenance 133
16.2 Preventive maintenance 133
16.3 Cleaning the sample probe 133
16.4 Maintaining the water trap / filter unit 134

5K600000000EJ 032438 220519
TABLE OF CONTENTS
16.5 Replacing the particulate filter 134
16.6 Replacing the gas sensors 135
16.7 Replacing the battery pack 140
16.8 Replacing the printer paper roll 141
16.9 Firmware Update 142
17.0 TROUBLESHOOTING 143
17.1 Troubleshooting guide 143
18.0 SPARE PARTS AND SERVICING 145
18.1 Spare parts 145
18.2 Accessories 146
18.3 Service Centers 147
ANNEX A - Data management with “E INSTRUMENTS QR CODE APP” 148
ANNEX B - Analysis report examples 150
ANNEX C - Coefficients of the fuels and Formulas 153
ANNEX D - Optional measures list 154
ANNEX E - Declaration of Conformity 157
E INSTRUMENTS by SAUERMANN - ALL RIGHTS RESERVED -
Total or partial reproduction of this document by any means (including photocopying
or storage on any electronic medium) and transmittal of same to third parties in any
manner, even electronically, is strictly prohibited unless explicitly authorized in writing
by E INSTRUMENTS by SAUERMANN.

6K600000000EJ 032438 220519

7K600000000EJ 032438 220519
1.1 Information about this manual
 This manual describes the operation and the characteristics and the maintenance of the Combustion Analyzer
E6000.
 Read this operation and maintenance manual before using the device. The operator must be familiar with the
manual and follow the instructions carefully.
 This use and maintenance manual is subject to change due to technical improvements - the manufacturer
assumes no responsibility for any mistakes or misprints.
1.2 Danger levels and other symbols
WARNING
Information on LCD
Ensure correct disposal
Keyboard with preformed keys
with main control functions.
1.0 IMPORTANT INFORMATION
Symbol Meaning Comments
Read information carefully and prepare
safety appropriate action!
To prevent any danger from personnel or other
goods. Ignoring of this manual may cause
danger to personnel, the plant or the
environment and may lead to liability loss.
The magnets in the back of the instrument can damage credit cards, hard driver, mechanical
watches, pacemakers, defibrillators and other devices proven sensitive to magnetic fields.
It is recommended to keep the instrument at a distance of at least 9.84 inches (25cm) away
from these devices.
Dispose of the battery pack at the end of its
working life only at the dedicated collecting bin.
The customer takes care, at his own cost, that
at the end of its working life the product is
collected separately and it gets correctly
recycled.
07/08/14
10:00
Service
Information
Esc
@sauermanngroup.com
sales.instruments
www.e-inst.com
Phone: [phone]
Langhorne, PA 19047 USA
850 Town Center Drive
by Sauermann
E Instruments

8K600000000EJ 032438 220519
2.0 SAFETY
2.1 Intended purpose
This chapter describes the areas of application for which the E6000 is intended.
Using the E6000 in other application areas is at the risk of the operator and the manufacturer assumes no
responsibility and liability for loss, damage or costs which could be a result. It is mandatory to read and pay
attention to the operating/maintenance manual.
All products of the series E6000 are handheld measuring devices in professional flue gas analysis and emissions
monitoring for boilers, engines, burners, furnaces, heaters and other combustion equipment.
Additional functions of the measuring instrument:
 Flue gas analysis according 1. BImSchV or qA-mean value (selectable)
 Calculating of stack heat loss and efficiency
 CO- and NO environment measurement
 Store Smoke value, calculating mean value
 Measuring differential pressure
 Draft measurement
2.2 Improper use of the product
The use of E6000 in application areas other than those specified in Section 2.1 "Intended use of the product" is to
be considered at the operator’s risk and the manufacturer assumes no responsibility for the loss damage or costs
that may result. It is compulsory to read and pay attention to the instructions in this use and maintenance manual.
E6000 should not be used:
 For continuous measurements > 1h without completing a fresh auto-zero cycle.
 As safety alarm instrument or control device.

9K600000000EJ 032438 220519
3.1 General overview of the Analyzer
E6000 is a portable analyzer for flue gas and emissions.
The instrument is equipped with:
 Pneumatic circuit which can accommodate up to 6 sensors in the FLEX-sensors series.
 Intuitive user interface: the instrument can be used without the support of the user manual.
 Wide (55x95 mm) and bright TFT color display which delivers great readability thanks to the zoom function
and an efficient backlight.
 Single rechargeable 'Li-Ion' battery pack, used to power both the unit and the thermal printer.
 Thermal printer integrated in the instrument.
 Connectivity with a computer through the USB connection and/or Bluetooth ®. Once the special software
provided with the instrument is used, this allows for the storage of combustion analysis as well as the
configuration of the main parameters.
 Connectivity with a smartphone through Bluetooth®. Once the specific APP “E-Inst. App” available on Google
play-store is installed on the device, the user can start remote analysis of combustion and/or view real-time
data of the analysis in progress.
Main functions:
- Combustion analysis in manual or automatic mode (UNI 10389-1 or BImSchV or according to the data logger
function, user-defined mode).
- The analyzer is pre-installed with 12 commonly used fuel parameters (such as natural gas, #4 oil, diesel
wood, coal, propane, & LPG)
- The user can load and save parameters for 32 additional fuels if the fuels chemical are known.
- Monitoring of pollutants (emissions).
- Memory capable of storing up to 2,000 full analysis.
- Storing of acquired data and their averaging.
Measurable gases:
- CO, CO2, CxHy referenced to methane
- O2
- CO (ambient monitoring)
- CO / H2
- CO (low, medium, high)
- NO (low, medium)
- NO2 (low, medium)
- SO2 (low, medium)
- NOx
- H2S
- H2
Measurements:
- Ambient CO (with the internal sensor)
- Draft in the stack.
- Smoke (with the use of the external manual pump).
- Gas pressure in the piping, pressure in the burning chamber and check of the pressure switches, using the
measurement range up to 80 WC (200hPa).
- Combustion air measurement
- Auxiliary temperatures
- Air speed for air or flue gas leaving the stack with the use of Pitot tube
- Ionization current measurement (with external auxiliary probe)
3.0 WORKING PRINCIPLE

10 K600000000EJ 032438 220519
Maintenance:
- Sensors can be replaced by the user without having to ship the instrument to the service center, because the
spare sensors delivered are pre-calibrated.
- The instrument requires annual calibration, as required by the standard UNI 10389-1, to be carried out at any
authorized service center.
Certificate of calibration
The instrument is accompanied with a calibration certificate compliant with standard EN 17025.

11 K600000000EJ 032438 220519
4.1 Working principle
The gas sample is taken in through the gas probe, by a diaphragm suction pump inside the instrument.
The measuring probe has a sliding positioning cone that allows the probe to be inserted in holes with a diameter
of 11 mm (0.43”) to 16 mm (0.65”) and to adjust the immersion depth. It is recommended to have the gas
sampling point roughly in the center of the flue/stack.
The gas sample is cleaned of humidity and impurities by a condensate trap and filter positioned along the rubber
hose that connects the probe to the analyzer.
The gas is then analyzed in its components by electrochemical and infrared sensors.
The electrochemical cell guarantees high precision results in a time interval of up to about 60 minutes during
which the instrument can be considered very stable. When measurement is going to take a long time, we suggest
auto-zeroing the instrument again and flushing the inside of the pneumatic circuit for three minutes with clean air.
During the zero calibrating phase, the instrument aspirates clean air from the environment and detects the cells’
drifts from zero (20.95% for the O2 cell), then compares them with the programmed values and compensates
them. The pressure sensor autozero must, in all cases, be done manually prior to measuring pressure.
The values measured and calculated by the microprocessor are viewed on the LCD display which is backlit to
ensure easy reading even when lighting is poor.
4.2 Measurement cells
The instrument takes advantage of pre-calibrated FLEX-series gas sensors for the measurement of Oxygen (O2),
Carbon Monoxide (CO - Hydrogen compensated measurement, Nitrogen Oxide (NO), Nitrogen Dioxide (NO2),
Sulphur Dioxide (SO2) and hydrogen sulphide (H2S).
The sensors do not need particular maintenance yet they have to be replaced periodically when exhausted.
Measurement of the oxygen (%O2) is carried out with an electrochemical cell that loses sensitivity over time
because it is constantly exposed to 20.9% Oxygen in ambient air.
The toxic gases (CO, SO2, NO, NO2) are measured with electrochemical sensors that are not subject to natural
deterioration being intrinsically lacking of oxidation processes.
The measurement cells are electrochemical cells made up of an anode, a cathode, and an electrolytic solution,
which depends on the type of gas to be analyzed. The gas penetrates the cell through a selective diffusion
membrane and generates an electric current proportional to the absorbed gas. Such current is measured,
digitalized, temperature-compensated, processed by the microprocessor, and displayed.
The gas shall not be at such a pressure to damage or destroy the sensors; for this reason the suction pump is
continuously adjusted, in order to ensure an appropriate flow to the sensors. The maximum estimated allowed
pressure is ±40 WC gauge (±100hPa).
The response times of the measurement cells used in the analyzer are:
O2 =20 sec. at 90% of the measured value
CO(H2)=50 sec. at 90% of the measured value
CO =50 sec. at 90% of the measured value
NO = 40 sec. at 90% of the measured value
NO2=50 sec. at 90% of the measured value
SO2=50 sec. at 90% of the measured value
H2S=50 sec. at 90% of the measured value
H2=90 sec. al 90% of the measured value
It is therefore suggested to wait 5 minutes (anyway not less than 3 minutes) in order to get reliable
analysis data.
If sensors of toxic gases are submitted to concentrations higher than 50% of their measurement range for more
than 10 minutes continuously, they can show up to ±2% drift as well as a longer time to return to zero. In this
case, before turning off the analyzer, it is advisable to wait for the measured value be lower than 20ppm by in
taking clean air. If there is an automatic calibration solenoid, the device performs an automatic cleaning cycle and
it turns off when the sensors return to a value close to zero.
The auto-zero solenoid valve allows the operator to turn the instrument on with the probe inserted in the flue. Up to
4 alarm set points are programmable with visual and acoustic signals for the relevant measurement parameters.
The UNI 10389-1 standard provides that the instrument must be calibrated by a certified laboratory that is
authorized to issue annual calibration certificates. Exhausted cells can be easily replaced by the user without
depriving himself of the instrument and without complicated calibration procedures with certified mixtures as they
are pre-calibrated before being supplied.
E Instruments certifies the accuracy of the measurements only upon a calibration certificate issued by its
laboratory or other approved laboratory.
4.3 CO dilution
One of the characteristics of the electrochemical sensor for the measurement of CO is the need to require very
long self-calibration time in case it has been in contact with high gas concentration (greater than the full scale) for
a long time. The CO sensor is therefore protected in this instrument by an automatic dilution system that allows to
extend the measuring range of the sensor without overloading the sensor itself.
The dilution system allows to have the CO sensor efficient any time and ready to perform properly even in case
4.0 DESCRIPTION OF THE PRODUCT

12 K600000000EJ 032438 220519
of very high concentration of CO. The dilution system also allows to extend the measurement range of the CO
sensor as follows:
- up to 100,000 ppm for a CO sensor with 8000 ppm full scale
- up to 250,000 ppm for a CO sensor with 20,000 ppm full scale
In this way in addition to better manage the wearing of the sensor, it is also possible to continue sampling,
without any work interruption.
4.4 Fuel types
The device is provided with the technical data of the most common types of fuels stored in its memory. By using
the PC configuration program, available as an option, it is possible to add fuels and their coefficients in order to
define up to a maximum of 32 combustibles, other than the default ones.
For more details see Annex C.
4.5 Pressure sensor, piezoelectric, temperature compensated
The instrument is internally provided with a piezoresistive differential pressure sensor, temperature compensated,
for measuring pressure or draft.
This sensor is differential type thus, thanks to the second measurement port, can be used for measuring the draft
(depressure) in the stack, for the leak test of the pipes, for differential pressure measurement, for measuring the
velocity of the flue gas using a Pitot tube, for flow measurement, and possibly for other measurements (pressure
of gas in the piping, pressure loss across a filter, etc.).
The measurement range is –4.14 WC .. +80.295 WC (-10.00 hPa .. +200.00 hPa).
Any potential drift of the sensor are nulled thanks to the autozeroing system which in this instrument can NOT be
operated with the flue gas probe inserted in the stack.
WARNING
ANY PRESSURE APPLIED TO THE SENSOR GREATER THAN ±120,442 WC (300 hPa) MAY
CAUSE A PERMANENT DEFORMATION OF THE MEMBRANE, THUS DAMAGING
IRREVERSIBLY THE SENSOR ITSELF.
4.6 Gas extraction pump
The sample pump located inside the instrument is a DC-motor-driven diaphragm pump, powered by the
instrument, and is such as to obtain optimal flow of the sampled gas being analyzed; an internal sensor that
measures the flow allows to:
- Keep the flow rate of the pump constant
- Check the efficiency of the pump
- Check the degree of clogging of the filters
4.7 Simultaneous measurement of pressure, O2, pollutants
The instrument, to obtain boiler’s perfect combustion parameters, allow to measure simultaneously the pressure
in the burner, levels of O2 , the pollutants levels and all the calculated parameters necessary to gain the correct
performance value.
See section 14.1.3.
4.8 Smoke measurements
It is possible to enter the smoke values measured according to a smoke comparison chart. The instrument will
calculate the average and print the results in the analysis report.
An external pump, available as an option, must be used to perform this measurement.
4.9 Temperature measurements
E 6000 can measure several types of temperatures taking advantage of dedicated probes.
4.10 Auxiliary measurements
This analyzer also features a connection to optional external sensors for draft measurement according to the
UNI10845 standard as well as for the measurement of the ionization current in the boilers.

13 K600000000EJ 032438 220519
4.11 Bluetooth® connection
The E6000 analyzer is internally equipped with a Bluetooth® module, which allows the communication with the
following remote devices:
- Remote Bluetooth® printer
- Smartphone or tablet with installed the OS Google Android v.4.1 (Jelly Bean) or later and the proper APP
‘E-Inst. App (available on Google Play Store) installed.
- PCs running Microsoft Windows 7 or later and Bluetooth® interface upon installation of the specific software
‘SmartFlue’ supplied together with the instrument.
The maximum transmission range in open field is 109 Yards / 100 meters (Class 1 Bluetooth® module), provided
that also the communication companion is equipped with a Class1 Bluetooth® interface.
This solution allows greater freedom of movement for the operator who is no longer bound directly to the
instrument for acquisition and analysis, with significant advantages for many applications.

14 K600000000EJ 032438 220519
5.0 DESCRIPTION OF COMPONENTS
LEGEND:
A
B
C
P
O
Q
Q Q
E
D
G
L M
I
F
N
H
A keypad
Adhesive polyester keypad with preformed keys featuring main control functions.
KEYS FUNCTION
Activates the context
keys shown on the
display
Access to the Memory
menu
Access to the Printing
menu
Access to the
Configuration menu
Performs the analysis of
the combustion
Access to the
Measurements menu
KEYS FUNCTION
Turns the device On /
Off
Exits the current screen
Select and/or Modify
Confirm settings
+Backlight turn-off.

15 K600000000EJ 032438 220519
B Display
Date, time and battery status.
Selected menu.
Parameters relative to the selected menu.
Context keys. In the various menus the functions vary depending on
the type of operation being carried out.
Combustion analysis
Backlight
The backlight can be turned off with the simultaneous pressure on keys + .
The backlight is turned on when any key is pressed, except ' ' key.
Printer
The thermal printer can print on either non-fading polyester paper or regular thermal paper. Thermal
polyester cannot be altered and it is resistant to light, to temperature, to humidity and to water.
The print menu is accessed by pressing the relative key and, besides enabling read-out printing, the menu
also allows you to modify print settings and to advance the paper manually so as to facilitate paper roll
replacement.
C
USB connector (type B)
Used to connect the instrument to a personal computer running Microsoft Windows 7 or later upon
installation of the specific software ‘SmartFlue’, supplied with the instrument.
D
Connector for the connection of auxiliary probes.
Serial connector, Mini Din 8-pin, for connection of an external probe such as:
- Probe for measurement of the ionization current
- Micromanometer
'T2' Connector
E
TFT 272 x 480 pixel backlit color display with 21 characters available and 8 lines. Allows the user to view the
measured parameters in the most comfortable format; a Zoom function displays the measured values in
magnified form.
CAUTION: If the instrument is exposed to extremely high or extremely low temperatures, the quality of
the display may be temporarily impaired. Display appearance may be improved by acting on the contrast
key.

16 K600000000EJ 032438 220519
input for the connection of the branch of the gas sampling probe with the condensation separating and
anti-dust filter assembly.
M
Pressure negative input (P-): used for measuring draft according to the standard UNI10845; it connects to
the second hose (with the larger pneumatic connector) of the sample probe for simultaneous measurement
of draft and combustion analysis.
Pneumatic connector 'IN'
L
'P+' pneumatic connector
Positive input (P+): used for measuring the pressure in general as well as for the leakage test.
N
Inputs ‘P+’ and ‘P-’ are respectively the positive and negative inputs of the internal
differential pressure sensor, piezoresistive, temperature compensated; therefore these can
be simultaneously used to measure the differential pressure.
Used to connect the Tc-K plug of the combustion air temperature probe.
'T1' Connector
F
Used to connect the Tc-K male connector of the gas temperature probe.
Gas outlet
G
'AUX' Connector
H
Input for optional external probes.
'P-' Pneumatic connector
I
Cover to access battery compartment.
O
Cover to access cell compartment.
P
Magnets.
Q
Instrument data label.
R

17 K600000000EJ 032438 220519
6.0 MAIN CONFIGURATIONS
1This model identifies custom configurations different to standard ones.
E6000-5DS E6000-5DC E6000-5SC E6000-5SH E6000-
6DSH
E6000-
6DSC
O2 SENSOR      
CO+H2 SENSOR      
CO+H2 SENSOR low range
CO SENSOR
CO SENSOR 0 .. 100.000 ppm
CO SENSOR 0 .. 20000 ppm
NO SENSOR      
NO SENSOR 5000 ppm
NO SENSOR low range
NO2 SENSOR    
NO2 SENSOR low range
SO2 SENSOR     
SO2 SENSOR low range
CxHy SENSOR   
H2S SENSOR 500 ppm  
EXPANDABLE TO 6SENSORS      
CO DILUTION      
BLUETOOTH      
CALIBRATION
CERTIFICATE      
QUICK GUIDE      
GAS SAMPLE PROBE 300mm      
CONDENSATE TRAP      
MEASURE KIT FOR DIFFERENTIAL
PRESSURE      
BATTERY CHARGER      
ADAPTER CABLE
USB type A / USB type B      
PC SOFTWARE      
HARD CASE      
ROLL OF PAPER
PRINTER      

18 K600000000EJ 032438 220519
7.0 TECHNICAL SPECIFICATIONS
7.1 Technical features
Power supply: Li-Ion battery pack with internal protection circuit, rechargeable.
Battery charger: External 5Vdc 2A battery charger with female A-type USB connector +
connection to the device with the same serial communication cable
supplied.
Charging time: 5 hours to charge from 0% to 90% (6 hours for 100%). The device can
also be charged by connecting it to the PC, the device must be turned off,
the charging time depends on the output current from the PC and may be
more than 12 hours.
Instrument working time: 12 hours of non-stop operation (excluding printing).
——————————————————————————————————————————————————
Display: 4.3” TFT 272x480 pixels graphic color with backlight
——————————————————————————————————————————————————
Connectivity:
Communication port: USB connector type B.
Bluetooth®: Class 1. Communication distance <109 yards (100 meters, in open field)
——————————————————————————————————————————————————
Autozero: Perform the automatic autozero cycle with the probe NOT INSERTED into
the stack.
Dilution: Widens the CO sensor measurement range up to 100,000 ppm (10.00%).
Programmable as simple protection of the CO sensor with the intervention
level set by the user.
Pre-set triggering threshold at 2500 ppm.
——————————————————————————————————————————————————
Gas measurement sensors: Up to 6 configurable sensors: electrochemical, NDIR (single cell) and
pellistor.
Programmed fuels: 12 factory pre-set plus 32 user-programmable.
——————————————————————————————————————————————————
Self-diagnosis: All the functions and internal functions are checked and anomalies
signalled.
Temperature measurement: Double K thermocouple input with mini connector (ASTM E 1684-96 ) to
measure differential temperature (supply and return)
Measurement of ambient temp.: Via internal sensor or T2 thermocouple input with remote probe.
——————————————————————————————————————————————————
Printer: Thermal integrated with easy loading paper and sensor for the presence of
paper
Printer powered: By the analyzer batteries.
Printer autonomy: Up to 40 analysis reports with the batteries fully charged.
——————————————————————————————————————————————————
Internal data memory: 2000 complete data analyses, time and name of the customer can be
stored.
User data: 8 programmable user names.
Print header: 6 lines x 24 characters user-customized.
——————————————————————————————————————————————————
Suction pump: 0.22 gal/m (1 l/m) heads at the flue up to 54.2 WC (135mbar).
Measurement of flow: Internal sensor to measure the flow of the pump.
Condensate trap: Outside the instrument.
Line filter: With replaceable cartridge, 99% efficient with 20um particles (inside the
condensate trap).

19 K600000000EJ 032438 220519
Smoke: Using an external hand pump; it is possible to enter and print the smoke
index.
Leak test: Gas pipes tested for leaks with separate printout of the result, by means of
the attachment AACKT02, according to UNI 7129 (new systems) and UNI
11137: 2012 (existing systems), with automatic calculation of pipe volume.
Condensing boiler efficiency: Automatic recognition of the condensing boiler, with calculation and
printout of efficiency (>100%) on the LHV (Lower Heating Value) in
accordance with UNI10389-1.
Environmental gases: Measurement and separate printout of the ambient CO values.
Draft test: By using the internal sensor connected to the port P-, resolution 0,1 Pa,
accuracy 0,5 Pa.
Draft test must be carried out only by means of the AACDP02 external
accessory in compliance with UNI 10845 standard.
——————————————————————————————————————————————————
Operating temperature: 23°F to 113° F (-5 °C to +45 °C)
Storage temperature: -4°F to 122°F (-20 °C to +50 °C)
Humidity limit: 20% .. 80% RH
IP rating: IP42
Air pressure: Atmospheric
Outer dimensions: Analyzer Only : 3.5 x 12.2 x 2.4” (9 x 31 x 6 cm) (H x W x D)
Weight: Analyzer Only : ~2 lbs. (~ 1 Kg)
—————————————————————————————————————————–————————-

20 K600000000EJ 032438 220519
7.2 Measurement and Accuracy Ranges
* Please contact E Instruments for details regarding if this CO2 NDIR sensor is recommended for your application.
MEASUREMENT SENSOR RANGE RESOLUTION ACCURACY
O2Electrochemical sensor 0 .. 25.0% vol 0.1% vol ±0,2% vol
CO
with H2 compensation Electrochemical sensor 0 .. 8000 ppm 1 ppm ±10 ppm 0 .. 200 ppm
±5% measured value 201 .. 2000 ppm
±10% measured value 2001 .. 8000 ppm
diluted Electrochemical sensor 10.00% vol 0.01% vol ±20% measured value
CO Low range
with H2 compensation Electrochemical sensor 0 .. 1000 ppm 0.1 ppm ±2 ppm 0 .. 40.0 ppm
±5% measured value 40.1 .. 1000.0 ppm
diluted Electrochemical sensor 6250 ppm 10 ppm ±20% measured value
CO Mid range Electrochemical sensor 0 .. 20000 ppm 1 ppm ±100 ppm 0 .. 2000 ppm ±5% measured value 2001 .. 4000 ppm
±10% measured value 4001 .. 20000 ppm
diluted Electrochemical sensor 25% vol 0.01% vol ±20% measured value
CO Hi range Electrochemical sensor 0 .. 10.00% vol 0.01% vol ±0.1% vol 0 .. 2.00 %
±5% measured value 2.01 .. 10.00 %
NO Electrochemical sensor 0 .. 5000 ppm 1 ppm ±5 ppm 0 .. 100 ppm
±5% measured value 101 .. 5000 ppm
NO Low range Electrochemical sensor 0 .. 500 ppm 0.1 ppm ±2 ppm 0 .. 40.0 ppm
±5% measured value 40.1 .. 500.0 ppm
NOx Calculated
SO2Electrochemical sensor 0 .. 5000 ppm 1 ppm ±5 ppm 0 .. 100 ppm
±5% measured value 101 .. 5000 ppm
SO2 Low range Electrochemical sensor 0 .. 500 ppm 0.1 ppm ±2 ppm 0 .. 40.0 ppm
±5% measured value 40.1 .. 500.0 ppm
NO2Electrochemical sensor 0 .. 1000 ppm 1 ppm ±5 ppm 0 .. 100 ppm
±5% measured value 101 .. 1000 ppm
NO2 Low range Electrochemical sensor 0 .. 500 ppm 0.1 ppm ±2 ppm 0 .. 40.0 ppm
±5% measured value 40.1 .. 500.0 ppm
CxHy Pellistor sensor 0 .. 5.00% vol 0.01% vol ±0.25% vol
CO2Calculated 0 .. 99.9% vol 0.1% vol
CO2*NDIR sensor 0 .. 20.0% vol 0.1% vol ±0.3% vol 0.00 .. 6.00 %
±5% measured value 6.01 .. 20.0 %
CO2*NDIR sensor 0 .. 50.0% vol 0.1% ±1% vol 0.00 .. 10.00 %
±2% vol 10.01 .. 50.0 %
PI**
(CO/CO2 ratio) Calculated 0.01%
H2SElectrochemical sensor 0 .. 500 ppm 0.1 ppm ±5 ppm 0 .. 100.0 ppm
±5% measured value 100.1 .. 500.0 ppm
H2Electrochemical sensor 0 .. 2000 ppm 1 ppm ±10 ppm 0 .. 100.0 ppm
±10% measured value 100 ... 2000.0 ppm
Air temperature TcK sensor -20.0 .. 1250.0 °C 0.1 °C ±0.5 °C 0 .. 100 °C
±0.5% measured value 101 .. 1250 °C
Flue gas temperature TcK sensor -20.0 .. 1250,0 °C 0.1 °C ±0.5 °C 0 .. 100 °C
±0.5% measured value 101 .. 1250 °C
Pressure
(draft & differential) Piezoelectric sensor -10.00 .. +200.00 hPa
0.01 hPa ±1% measured value -10.00 .. -2.01 hPa
±0.02 hPa -2.00 .. +2.00 hPa
±1% measured value +2.01 .. +200.00 hPa
Differential temperature Calculated 0 .. 1250.0 °C 0.1 °C
Air index Calculated 0.00 .. 9.50 0.01
Excess air Calculated 0 .. 850 % 1 %
Stack loss Calculated 0.0 .. 100.0 % 0.1 %
Efficiency Calculated 0.0 .. 100.0 % 0.1 %
Efficiency
(condensing) Calculated 0.0 .. 120.0 % 0.1 %
Smoke index External instrument 0 .. 9
** The Poison Index ratio (P.I.) is a reliable indicator of a boiler or burner good operation. It only takes a simple flue gas test to determine
whether or not a service is needed to fix the system.
