HOMCLOUD Speed 11S User manual

QUICK GUIDE
ORIGINALITY DESIGN SMART - AND BEAUTIFUL
CAMERA
Speed 11S

1
Please consult this checklist for all parts.
What's in the box
User manual
EU Power adapter
Wrench
Screws
BracketSpeed 11S

2
Reset
SD card slot
Speaker
Microphone
Antenna
Status light
Lens
Power
Microphone
Status light
DC 12V/1A
Capture sound for your video
Solid red light on: network is malfunctional
Blinking red light: wait for network connection (slowly blinking)
connecting the network (quickly blinking)
Solid blue light on: the camera is working correctly
Support local SD card storage (Max.128G)
Press and hold on for 5 seconds to reset the camera
Reset
SD card slot
Description
IR LED
Screw

3
Bracket Installation
Installation
2. Install the camera in the bracket and lock it with the screw
1. Fix the bracket on the wall
1
When ajusting your camera angle,
please lock this screw
(Optional)
0~90°
-75°~75°
2
After fixing your camera,
please lock this screw

4
Set up router
The router supports the 2.4GHz WiFi (doesn't support the 5GHz), and is
connected to the WiFi network.Please set the parameters of the router
before connecting the WiFi network, and record the SSID and password
of your WiFi.
Please keep network available
2.4GHz 5GHz
Connection

5
QR Code Configuration
Open the Homcloud App, click "My" >> "Home Management" >>
"Create a home", and you can customize the home name and related
settings (optional).
1
Click "Add Device" or "+", and then select “Speed 11S Security cam”
or any other "Smart Camera" icons to add camera.
2

6
QR Code Configuration
Power on and reset camera until the status indicator is flashing quickly
or a prompt tone is heard, and then click "Next". Then input your WiFi's
passwords and click "Next".
Click " " to change network.
3
Note:
1) Camera only supports 2.4GHz WiFi network.
2) The number of bits in the ssid and passwords of the router
should not exceed 24 digits.

7
QR Code Configuration
In this interface, you should scan the QR code in your phone with the
camera,when the camera comes out "dong dong dong". And you can
complete the configuration about 30s.
4

8
QR Code Configuration
When connecting, you should make sure your router,mobile,and camera
are as close as possible.When camera added successffully,click " "
you could also DIY the camera's name.
5
Icons
Enlarge the image full screen.
Turn on receiving audio.
Switch to Full HD resolution (SD is Standard Resolution).
Take a snapshot (it will be saved on your smartphone).
Activate smartphone microphone and speak through camera.
Record a part of a video (it will be saved on smartphone).
Play recorded video on SD card.
Access cloud recordings (extra service).

9
In "Smart Camera" interface,click " ",you can set the camera common
functions.
Settings
- Wifi standard: 2.4G ~ 2.4835 GHz wifi (IEEE802.11b/g/n)
- Channel bandwidth: Support 20/40MHz
- Wifi security: WPA-PSK/WPA2-PSK
- Max transmission power : <20 dbm
- Communication protocol: HTTP,DHCP,DNS,RTSP,TCP/IP
Wi-Fi standard
- Homcloud code: ME-WCS11SPT
- Model No: Speed 11S
- Power: DC 12V1A
- Resolution: 2Mp, 1920(H)*1080(V)
- IR Distance: 10m
- Adjust angle: -75°/+75°horizontal
- Waterproof grade: IP65
- Working temp: -20°C - 50°C
- View Angle: 110°
- Dimension: 180x75x100mm
- Detection movement max distance:9m
- Lens: 4mm, 110°
