HOMCOM 821-016 User manual

ASSEMBLY INSTRUCTION
INcjd045_UK
821-016
READ AND SAVE THIS INSTRUCTION FOR FUTURE USE
This owner's manual will provide you with valuable information necessary for the
proper care and maintenance of your new dehumidifier. Please take a few moments
to read the instructions thoroughly and familiarize yourself with all the operational
aspects of this dehumidifier.
Pictures inside are for reference only, details shall be in accordance with final
product.

2
Safety Instructions
Use this dehumidifier only in the specified temperature and humidity conditions; because the
low temperature humidity is small, there is no need for dehumidification.
Don't block the front air inlet and the air outlet of the dehumidifier; do not insert any foreign
objects into the air outlet, as this will lead to damage.
Dehumidifier should be placed on a level surface; otherwise the water will overflow.
When this dehumidifier is not being used for an extended period of time, please make sure
that the water tank is drained.
Remove the dehumidifier water box, do not tilt, to avoid water poured out
Please don’t store the transformer in moist places; it shall be kept in dry and well ventilated
place.
After each use, please shutdown the dehumidifier and unplug it to end the operation.
Appliances not accessible to general public.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
If the power supply cord is damaged it must be replaced by the
manufacture or a qualified service agent.

3
Intended of use
This Dehumidifier can be used in wardrobe, bookcase, storage box, rest room, kitchen and similar
small space, which has an area of about 20m2 and reduces the level of humidity in the air, only for
household use.
The ideal environment for use:
1. Temperature: 15℃-35℃
2. Humidity: > 45%
Product diagram
Note: This is only for reference; it can be different from different models.All rights reserved.
Operation
1. Use AC power supply. Install the water tank in to the dehumidifier; plug the DC plug into the DC
port of the appliance and the adaptor in to the socket outlet. The power light will turn on (blue) and
the fan will continuously run.
2. If the red indicator lights on, please check, if the water tank is in correct position.
3. This dehumidifier will stop the dehumidification automatically, if the water reaches the level and the
red indicator will turn on, which means the water tank is full. Please cut off the power supply, before
you take out the tank. Remove the black drain cover of the water tank and discard the collected water.
Then replace it.
4. Wipe and dry the water tank and the dehumidifier.

4
Technical data
1. Adapter: 9V DC, 2.5Amp.
2. Power: 22W。
3. Portable water tank Capacity: 500ml。
4. Water level sensor: the indicator will turn on in red, when the water tank is full and the appliance
will shut down automatically.
5. Dehumidifying Capability: 220ml/24 hours （CSQ 1307 with 200ml/24 hours)。
7. Area for dehumidifying: < 20m2。
8. Size: 154x218x130mm。
9. Operating environment: Temperature: 15℃-35℃relative Humidity: > 45%。
Trouble shooting
Cleaning and maintenance
Before cleaning and maintenance please pull out the plug out of the socket outlet. Wipe the shell of
the appliance with a soft damp cloth; never use abrasive agent and resolvent, as these will damage
this appliance.
Problem Possible Cause Solution
After connecting, the red
indicator lights up
The water tank is full Empty the water tank and
replace it in correct position
The float gets jammed Press the float and replace the
water tank
The dehumidifier
doesn’t work
The power supply is cut off Check if the adaptor is plugged
in
DC switch is OFF Turn the switch on
The air outlet is blocked Maintain the minimum
clearance at least 10cm
around
the dehumidifier when the unit
is operating
Correct Disposal of this product
This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To
return your used device, please use the return and collection systems or
contact the retailer where the product was purchased. They can take this
product for environmental safe recycling.
