Home appliances CK60 User manual

CK60 / CKS70
60cm / 70cm Electric Cooktop
USER MANUAL

Dear Customer,
Congratulations on purchasing your new product from Home Appliances.
To register your Parts and Labour Warranty, some conditions apply, please refer to your warranty card for
more details and contact our Customer Care team on:
1800 444 357
Our Customer Care Centre is there to ensure you get the most out of your appliance. Should you want to
learn more about your product and how to use it to its best potential or tips on cleaning, please feel free
to call us on the above number.
It is important that you read through the following instruction manual thoroughly to become familiar with
the installation and operation of this appliance and ensure optimum performance.
We also carry a complete range of spare parts for all Home Appliance products. For all your spare parts
enquiries please contact our team at Pronto Parts on
1300 306 973
Again, thank you for choosing an appliance brought to you by Home Appliances and we look forward to
being of service to you.
Kind regards,
The Management
Home Appliances

NOTE: This User Instruction Manual contains important information, including safety &
installation points, which will enable you to get the most out of your appliance. Please
keep it in a safe place so that it is easily available for future reference; for you or any
person not familiar with the operation of the appliance.

Content
1. Foreword ........................................................................3
1.1 Safety Warnings .......................................................................... 3
1.2 Installation ................................................................................. 3
1.2.1 Electrical Shock Hazard .................................................. 3
1.2.2 Cut Hazard ................................................................... 3
1.2.3 Important safety instructions........................................... 3
1.3 Operation and maintenance .......................................................... 4
1.3.1 Electrical Shock Hazard .................................................. 4
1.3.2 Health Hazard ............................................................... 4
1.3.3 Hot Surface Hazard ........................................................ 4
1.3.4 Cut Hazard ................................................................... 4
1.3.5 Important safety instructions........................................... 5
2. Product Introductio n .......................................................... 7
2.1 Top View .................................................................................... 7
2.2 Control Panel .............................................................................. 7
2.3 Product Information ..................................................................... 7
2.4 Working Principle......................................................................... 7
2.5 Before using your New Ceramic Hob............................................... 8
2.6 Technical Specification ................................................................. 8
3. Operation of Product ......................................................... 8
3.1 Choosing the right Cookware......................................................... 8
3.2 How to use ................................................................................. 9
3.2.1 Start cooking ................................................................ 9
3.2.2 Finish cooking ............................................................... 9
4. Cooking Guidelines ............................................................ 9
4.1 Cooking Tips ............................................................................... 9
4.1.1 Simmering, cooking rice ................................................. 9
4.1.2 Searing steak .............................................................. 10
4.1.3 For stir-frying .............................................................. 10
5. Care and Cleaning ........................................................... 10
6. Hints and Tips ................................................................ 11
8. Installation.................................................................... 11
8.1 Selection of installation equipment............................................... 11
8.2 Before locating the fixing brackets ............................................... 12
8.3 Cautions................................................................................... 13
8.4 Connecting the hob to the mains power supply .............................. 13

3
1. Foreword
1.1 Safety Warnings
Your safety is important to us. Please read this information
before using your cooktop.
1.2 Installation
1.2.1 Electrical Shock Hazard
•Disconnect the appliance from the mains electricity supply
before carrying out any work or maintenance on it.
•Connection to a good earth wiring system is essential and
mandatory.
•Alterations to the domestic wiring system must only be made
by a qualified electrician.
•Failure to follow this advice may result in electrical shock or
death.
1.2.2 Cut Hazard
•Take care - panel edges are sharp.
•Failure to use caution could result in injury or cuts.
1.2.3 Important safety instructions
•Read these instructions carefully before installing or using
this appliance.
•No combustible material or products should be placed on this
appliance at any time.
•Please make this information available to the person
responsible for installing the appliance as it could reduce
your installation costs.
•In order to avoid a hazard, this appliance must be installed
according to these instructions for installation.
•This appliance is to be properly installed and earthed only by
a suitably qualified person.
•This appliance should be connected to a circuit which
incorporates an isolating switch providing full disconnection
from the power supply.

4
•Failure to install the appliance correctly could invalidate any
warranty or liability claims.
1.3 Operation and maintenance
1.3.1 Electrical Shock Hazard
•Do not cook on a broken or cracked cooktop. If the cooktop
surface should break or crack, switch the appliance off
immediately at the mains power supply (wall switch) and
contact a qualified technician.
•Switch the cooktop off at the wall before cleaning or
maintenance.
•Failure to follow this advice may result in electrical shock or
death.
1.3.2 Health Hazard
•This appliance complies with electromagnetic safety
standards.
•However, persons with cardiac pacemakers or other
electrical implants (such as insulin pumps) must consult with
their doctor or implant manufacturer before using this
appliance to make sure that their implants will not be
affected by the electromagnetic field.
•Failure to follow this advice may result in death.
1.3.3 Hot Surface Hazard
•During use, accessible parts of this appliance will become hot
enough to cause burns.
•Do not let your body, clothing or any item other than suitable
cookware contact the Ceramic glass until the surface is cool.
•Metallic objects such as knives, forks, spoons and lids should
not be placed on the hob surface since they can get hot
•Keep children away.
•Handles of saucepans may be hot to touch. Check saucepan
handles do not overhang other cooking zones that are on.
Keep handles out of reach of children.
•Failure to follow this advice could result in burns and scalds.
1.3.4 Cut Hazard
•The razor-sharp blade of a cooktop scraper is exposed when
the safety cover is retracted. Use with extreme care and

5
always store safely and out of reach of children.
•Failure to use caution could result in injury or cuts.
1.3.5 Important safety instructions
•Never leave the appliance unattended when in use. Boilover
causes smoking and greasy spillovers that may ignite.
•Never use your appliance as a work or storage surface.
•Never leave any objects or utensils on the appliance.
•Do not place or leave any magnetisable objects (e.g. credit
cards, memory cards) or electronic devices (e.g. computers,
MP3 players) near the appliance, as they may be affected by
its electromagnetic field.
•Never use your appliance for warming or heating the room.
•After use, always turn off the cooking zones and the cooktop
as described in this manual (i.e. by using the touch controls).
Do not rely on the pan detection feature to turn off the
cooking zones when you remove the pans.
•Do not allow children to play with the appliance or sit, stand,
or climb on it.
•Do not store items of interest to children in cabinets above
the appliance. Children climbing on the cooktop could be
seriously injured.
•Do not leave children alone or unattended in the area where
the appliance is in use.
•Children or persons with a disability which limits their ability
to use the appliance should have a responsible and
competent person to instruct them in its use. The instructor
should be satisfied that they can use the appliance without
danger to themselves or their surroundings.
•Do not repair or replace any part of the appliance unless
specifically recommended in the manual. All other servicing
should be done by a qualified technician.
•Do not use a steam cleaner to clean your cooktop.
•Do not place or drop heavy objects on your cooktop.
•Do not stand on your cooktop.
•Do not use pans with jagged edges or drag pans across the
Ceramic glass surface as this can scratch the glass.
•Do not use scourers or any other harsh abrasive cleaning
agents to clean your cooktop, as these can scratch the

6
Ceramic glass.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
•This appliance is intended to be used in household and
similar applications such as: -staff kitchen areas in shops,
offices and other working environments; -farm houses; -by
clients in hotels, motels and other residential type
environments; -bed and breakfast type environments.
•WARNING: The appliance and its accessible parts become
hot during use.
•Care should be taken to avoid touching heating elements.
•Children less than 8 years of age shall be kept away unless
continuously supervised.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
•Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision
.
•WARNING: Unattended cooking on a hob with fat or oil can
be dangerous and may result in fire. NEVER try to extinguish
a fire with water, but switch off the appliance and then cover
flame e.g. with a lid or a fire blanket.
•WARNING: Danger of fire: do not store items on the
cooking surfaces.
•Warning: If the surface is cracked, switch off the appliance
to avoid the possibility of electric shock, for hob surfaces of
glass-ceramic or similar material which protect live parts
•A steam cleaner is not to be used.
•The appliance is not intended to be operated by means of an
external timer or separate remote-control system.
Congratulations on the purchase of your new Ceramic Hob.
We recommend that you spend some time to read this Instruction / Installation Manual in order to fully

7
understand how to install correctly and operate it. For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for
future reference.
2. Product Introduction
2.1 Top View
2.2 Control Panel
2.3 Product Information
The microcomputer ceramic cooker hob can meet different kinds of cuisine demands because of resistance
wire heating, micro-computerized control and multi-power selection, really the optimal choice for modern
families.
The ceramic cooker hob centers on customers and adopts personalized design. The hob has safe and
reliable performances, making your life comfortable and enabling to fully enjoy the pleasure from life.
2.4 Working Principle
This ceramic cooker hob directly employs resistance wire heating, and adjust the output power by the
1. Max. 1200 W zone
2. Max. 1800 W zone
3. Max. 1200 W zone
4. Max. 1800W zone
5. Glass plate
7. Control panel
1. Hot hob warning indicators
2. Power regulating controls
