Home appliances RSR6 User manual

RSR6

Information and advice
CAUTION:Accessibie parts may become hot when used with cooking appliances.
must
light a flame
Attention ! Observe the warning in the instruction sheet concerning the
operation of the appliance when air is discharged from the room
has been used.
oil splashing and
becoming a fire hazard.

˄metal grill with grease filter optional˅

Information
We recommend that after
installation the bottom of
the hood should be no less
than 650mm and no more
than 750mm above the
stove's heating elements
and burners.
We recommend that after
installation the bottom of
the hood should be no less
than 650mm and no more
than 750mm above the
stove's heating elements
and burners.
2
3
B
A
Vertical discharge
Vertical is the most common.
If you select this venting direction, you only need
to open the ducting knockout A.Remove the
ducting knockout by inserting a Flat head
screwdriver under one end and prying it up. Then
snip or break the attachment points by tin snips.
You must make sure that the ducting knockout B is
not removed.
B
A
Horizontal discharge
Assuming that the range hood is located against an
outside wall, horizontal discharge is preferred
provided that there are no obstructions such as, wall
joints, or where openings are difficult to make.
If you select this venting direction, you only need to
open the ducting knockout B.
Same with removing the ducting knockout A, you must
make sure that the ducting knockout A is not removed.
Sufficient air
is needed for
proper
combustion
and
exhausting
of gases
through the
fule
(chimney) of
fuel burning
equipment to
prevent back
drafting.

to

*3/8"nut driver

holes, in case the front and back
of hood moves, so that the user is
safe.
fastened enough.

Security
hole Security
hole
ss
and back of hood moves, so that the user is safe.

in the

Information
There is a
fire risk if
cleaning is
not carried
out in
accordance
with the
instructions.
14
·It is recommendable to clean the metallic filter every three
months by carrying out the following instructions:
-Remove the metallic filter from the cooker hood and wash it
in a solution of water and neutral liquid detergent, leaving to
soak
-Rinse thoroughly with warm water and leave to dry.
-The metallic filter may also be washed in the dishwasher.
The metallic filter may alter in colour after several washes.
This is not cause for customer complaint nor replacement of
metallic filter.

The manufacturer shall decline all responsibility if the foregoing
recommendations and instruction regarding installation, maintenance and use are
not observed and respected when using the cooker hood.
