Home Decorators Collection 23RT04823112 User manual

SKU # 1009 537 859
Model # 23RT04823112
Thank you!
We appreciate the trust and confidence you have placed in Home Accents
through the purchase of this 5ft Icicle Shimmer TWINKLING LED DEER.
We strive to continually create quality products designed to enhance your
home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing HomeAccents!
1-855-HDHoliday (1-855-434-6543)
HOMEACCENTSHOLIDAY.COM
ASSEMBLY INSTRUCTIONS
5ft Icicle Shimmer TWINKLING LED DEER
USEANDCAREGUIDE
PLANNING ASSEMBLY
Carefully remove all the parts from the box and place them on the ground. Many parts
are connected by the lighting string that runs throughout the item. Take special care not
to pull, cut or damage the lighting string. Read the entire manual prior to assembly and
identify all the parts included in the package against the parts list. It is recommended to
assemble parts of the product while laying flat on the ground versus standing the item
up to assemble the parts. If any parts are missing or damaged do not attempt assembly
but contact our customer service center or return to place of purchase with purchase
receipt.
Assembly of this product may require more than one person.
1-855-HDHoliday (1-855-434-6543)
Pre-Operation
CAUTION:Grasp the plug to insert or remove from the power source.
Do not unplug by pulling on cord.
CAUTION:The lighting string on this product is rated at 7.2 Watts (0.06
Amps). Do not overload. Do not connect to another lighting string, decorative outfit or
other electrical products. Before you use or re-use this product inspect it carefully.
Discard or return to place of purchase with purchase receipt if the product has cuts,
damage, frayed wire insulation on cords, cracks in the socket enclosures, loose
connections, exposed copper wire or other obvious damage.
CareandCleaning
a. Carefully remove the product from wherever it is placed. This helps to avoid any
undue strain or stress on the product connections, and wires. If the product is placed
somewhere other than the ground it should be well secured, flat and stable.
b. Carefully disassemble the unit taking caution not to cut any electrical wires.
c. Wipe the unit with a damp cloth and allow the unit to dry before storing.
d. Store the product neatly in a cool, dry location protected from sunlight.
Troubleshooting
a. Ensure that the ground or surface that the item sits on is flat and level
b. Be sure to plug the item correctly to a wall outlet or a UL Listed Power Cord
c. Ensure all parts are assembled properly per the Instruction Manual
d. If the item does not light check for loose or broken bulbs and connections
e. Do not plug into other electrical items
f. If the item has multiple Light String Cords be sure to plug in all cords
g. Check for Broken or Burned Out Fuse In Plug
Guarantee
What is Covered
The product is intended for residential seasonal use for 90 days per year. This
product is covered by a 90 days limited guarantee due to defects in material and
workmanship. Return the product with purchase receipts to the location of purchase
for refund within 90 days of purchase.
What is Not Covered
This warranty does not cover commercial use, normal wear and tear, products not used in
accordance with directions provided on or with the product, burn out of bulbs or LEDS,
batteries, products that have been subjected to unauthorized repair and/or modification
and damage caused by shipping and improper handling, alterations, misuse, in store
display models or accidents. Questions, problems, missing parts? Before returning to the
store, call HomeAccents Holiday Customer Service 8 a.m.-6 p.m., EST, Monday-Friday
1-855-HDHoliday (1-855-434-6543)
Diagram of Parts
Parts List
Locater Name Qty.
A Antler 2
B Ear 2
C Head/Neck 1
D Body 1
E Tail 1
F Front Leg 2
G Hind Leg 2
H Bow 1
Hardware List
Locater Name Qty.
I Spare Fuse 2
J Spare Bulb 6
K Plastic Tie 15
L Ground Stake 4
A A
B B
C
D
E
F F G G
H
I
J
K
L
A
SSEMBLY
1 Assembling the Legs to the Body
Insert the connecting rods on the Front and Hind Legs (F,G) into the
connecting holes on the underside of the Body (D) .
2 Securing the Legs to the Body
Fasten the Body (D) and Legs (F,G) together with the Plastic Ties (K) over
the metal wire where the parts meet. The Legs come with metal bars attached
to stabilize the Deer. Insert the hooked end of the metal bars into the metal nut
on the opposite Leg.
3 Assembling the Head/Neck to Body
Insert the connecting rods at the bottom of the Head/Neck (C) into the
connecting holes on the top front of the Body (D) and fasten together
at the connecting loops with Plastic Ties (K).
4 Assembling the Antlers to Head/Neck
Insert the connecting rods on both Antlers (A) into the matching connecting
holes at the top of Head /Neck (C).
5
Assembling the Ears to Head/Neck
Insert the connecting rods on both Ears (B) into the matching connecting
holes at the top of Head /Neck (C). [Note: The Ears go to the outside of
the Antlers]
6
Assembling the Tail to Body
Insert the connecting rod on the Tail (E) into the connecting hole at the rear
of Body (D).
7 Assembling the Bow to the Body
Insert the wire ties on the back side of the Bow (H) through the holes of
the Body material then twist the wires together around the metal frame
or material to secure.
8 AssemblingtheGroundStakes
Insert the Ground Stakes (L) over the metal frame at each hoof of the Deer then
firmly into the ground.
D
F
F G G
D
F G
K
C
D
K
A A
C
B
B
C
E
D
H
L
