USE AND CARE GUIDE
Microwave Oven
THANK YOU
We appreciate the trust and condence you have placed in Vissani through the purchase of this microwave. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Vissani
Item # 000-000
Model #VSCMWE11S2SW-10
Questions, problems, missing parts? Before returning to the store,
call VISSANI Customer Serive
8 a.m -8 p.m., EST, Monday-Friday, 8 a.m.-6 p.m., EST, Saturday
1-855-VISSANI
HOMEDEPOT.COM

Table of Contents
Table of
Contents...................................................................2
Safety Information...................................................2
Precautions to Avoid Possible Exposure
to Excessive Microwave Energy ...............................2
California Proposition 65 Warning.............................2
General Warning .......................................................2
Grounding Instructions...............................................4
Installation Guide........................................................5
Product Diagram.........................................................5
Control Panel............................ ..................................6
Operation Instructions................................................7
Setting the Clock ............................................7
Timer.................................................................7
+30 Sec Function.................................................7
Microwave Cooking.............................................7
Weight Defrost ....................................................8
Time Defrost........................................................8
Auto Cook............................................................8
Express Cook.......................................................9
Multi-stage Cooking............................................9
Child Lock............................................................9
Cleaning And Care ............................................10
Product Warranty ...........................................11
Do not attempt to operate this oven with the
door open since open-door operation can result in
harmful exposure to microwave energy. It is
important not to defeat or tamper with the safety
interlocks.
□ Do not place any object between the oven front
face and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
□ Do not operate the oven if it is damaged. It is
very important that the oven door close properly
and that there is no damage to the
a) Door (including any dents),
b) Hinges and latches (broken or loosened),
c) Door seals and sealing surfaces.
The oven should not be adjusted or repaired by
anyone except qualied service personnel.
CALIFORNIA PROPOSITION 65 WARNING
General Warning
To reduce the risk of burns, electric shock,
fire, injury to persons or exposure to
excessive microwave energy:
□ Read all instructions before using the
appliance.
□ Read and follow the specic "PRECAUTIONS
TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY" on page 2.
This appliance must be grounded. Connect only
to properly grounded outlet. See "GROUNDING
INSTRUCTIONS " on page 4.
□ Do not operate the oven when empty.
Install or locate this appliance only in accordance
with the provided installation instructions.
□ Some products such as whole eggs and sealed
containers -for example, closed glass jars- are
able to explode and should not be heated in this
oven.
□ Use this appliance only for its intended use as
described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This type of
oven is specically designed to heat, cook, or dry
food. It is not designed for industrial or laboratory
use.
□ As with any appliance, close supervision is
necessary when used by children.
2HOMEDEPOT.COM Please contact 1-855-VISSANI
for further assistance
WARNING:
Precautions to Avoid Possible Exposure to
Excessive Microwave Energy
□
WARNING: Cancer and Reproductive
Harm-WWW.P65Warnings.ca.gov.
Safety Information

□ To reduce the risk of fire in the oven cavity:
1. Do not overheat the liquid. Carefully attend to the
appliance when paper, plastic, or other combustible
materials are placed inside the oven to facilitate
cooking.
2. Remove wire twist-ties from paper or plastic bags
before placing bag in oven.
3. If materials inside the oven should ignite, keep
oven door closed, turn oven off using the circuit
breaker panel, and call emergency services.
□ Do not use the cavity for storage purposes. Do
not leave paper products, cooking utensils or food in
the cavity when not in use.
□ Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing to
be boiling due to surface tension of the liquid. Visible
bubbling or boiling when the container is removed from
the microwave oven is not always present. This could
result in very hot liquids suddenly boiling over when a
spoon or other utensil is inserted into the liquid.
□ To reduce the risk of injury to person:
1. Do not overheat the liquid.
2. Stir the liquid both before and halfway through
heating it.
3. Do not use straight-sided containers with narrow
necks.
4. After heating, allow the container to stand in the
microwave oven for a short time before removing the
container.
5. Use extreme care when inserting a spoon or other
utensil into the container.
□ Do not heat oil or fat for deep-frying. It is difcult
to control the temperature of oil in microwave oven.
□ Do not cover or block any openings on the
appliance.
□ Do not operate this appliance if it has a damaged
cord or a plug, if it is not working properly or if it has
been damaged or dropped.
□ Do not immerse cord or plug in water. Keep cord
away from heated surface. Do not let cord hang over
edge of table or counter.
□ This appliance should be serviced only by
qualied service personnel. Contact nearest authorized
service facility for examination, repair, or adjustment.
□ When cleaning surfaces of door and oven that
comes together on closing the door, use only mild,
non-abrasive soaps, or detergents applied with a
sponge or soft cloth.
□ Oversized food or oversized metal utensils
should not be inserted in a microwave/toaster
oven as they may create a re or risk of
electric shock.
□ Do not store or use this appliance
outdoors. Do not use this product near water,
for example, near a kitchen sink, in a wet
basement, near a swimming pool, or similar
locations.
□ Do not clean with metal scouring pads.
Pieces can burn off the pad and touch
electrical parts involving a risk of electric
shock.
□ Do not use paper products when appliance
is operated in the toaster mode.
□ Do not store any materials, other than
manufacturer’s recommended accessories, in
this oven when not in use.
□ Do not cover turntables, pans or any other
part of the oven with metal foil. This will
cause overheating of the oven.
□ This equipment has been tested and found
to comply with Part 18 of the FCC Rules.
Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
3HOMEDEPOT.COM Please contact 1-855-VISSANI
for further assistance
CAUTION: Changes or modifications not approved
by the party responsible for compliance could
void the user's authority to operate the product.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation.
Safety Information (Continued)

If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
1.Reorient or relocate the receiving antenna.
2.Increase the separation between the equipment
and receiver.
3.Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
4.Consult the dealer or an experienced radio/TV
technician for help.
This appliance must be grounded. In the event of
an electrical short circuit, grounding reduces risk of
electric shock by providing an escape wire for the
electric current. This appliance is equipped with a
cord having a grounding wire with a grounding
plug. The plug must be plugged into an outlet that
is properly installed and grounded.
Consult a qualied electrician or serviceman if the
grounding instructions are not completely
understood, or if doubt exists as to whether the
appliance is properly grounded. If it is necessary to
use an extension cord, use only a 3-wire extension
cord that has a 3-blade grounding plug and a 3-slot
receptacle that will accept the plug on the
appliance. The marked rating of the extension cord
shall be equal to or greater than the electrical rating
of the appliance.
3-Pronged Plug
Ground Plug
3-Prong Receptacle
Electrical Requirements
The electrical requirements are a 120 volt 60
Hz, AC only, 20 amp. It is recommended that
a separate circuit serving only the oven be
provided. The oven is equipped with a
3-prong grounding plug. It must be plugged
into a wall outlet properly installed and
ground.
Power Cord
□ A short power supply cord is provided to
reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
□ Longer cord sets or extension cords are
available and may be used if care is
exercised in their use.
□ If long cord or extension cord is used:
a) The marked electrical rating of the cord
set or extension cord should be at least as
great as the electrical rating of the
appliance.
b) The extension cord must be a
grounding-type 3-wire cord, and the longer
cord should be arranged so that it will not
drape over the countertop or tabletop
where it can be pulled on by children or
tripped over accidentally.
4HOMEDEPOT.COM Please contact 1-855-VISSANI
for further assistance
IMPORTANT:Important Grounding Instructions
Safety Information (Continued)

Make sure that all the packing materials are
removed from the inside of the door.
This microwave oven must be placed on a at,
stable surface.
For correct operation, the oven must have
sufcient airow. Allow minimum 8 in.(20.32cm) of
free space necessary above the top surface of the
oven and 2 in. (5.08cm) at both sides. Do not cover
or block any openings on the appliance. Do not
remove feet.
Only use the appliance on a countertop over 3 ft.
(91.6cm) above the oor.
Do not place the oven where heat, moisture, or
high humidity is generated, or near combustible
materials.
8 inch
2 inch
2 inch
Make sure that the power cord is undamaged
and does not run under the oven or over any
hot or sharp surface.
The socket must be readily accessible so the
microwave oven can be easily unplugged in an
emergency.
Part No.
1
2
3
4
5
6
7
Description Quantity
Safety Interlock
System
Observation Window
Roller Ring
Plastic Shaft
Control Panel
Wave Guide Cover
Glass Turntable
1
1
1
1
1
1
1
NOTE: Hardware not shown to actual size.
5HOMEDEPOT.COM Please contact 1-855-VISSANI
for further assistance
Installation

Control Panel Operation
AUTO COOK
Use to set the automatic
sensor cook programs (See
Page 8).
TIMER
The TIMER function can be
used alone, even in the
process of cooking.
POWER LEVEL
Use to set microwave power
levels.
CLOCK
Press to set the clock function
TIME DEFROST
Press to set defrosting time.
TIME COOK
Use for multi-stage cooking. It
enables cooking at multiple
power/time settings.
WEIGHT DEFROST
Touch to set the weight of the
food to be defrosted.
Number Pad 1-6
Express cooking, press 1-6 to
automatically begin cooking
between 1 and 6 minute
increments.
STOP/CLEAR/LOCK
Press to clear all previous
settings before cooking starts.
Press once to pause current
cooking program or press
twice to cancel the program.
Or press and hold 3 seconds
for child lock.
START/+30 SEC
Press to start a cooking
program. It is also used to set
quick start function or to
increase cooking time during
cooking.
6HOMEDEPOT.COM Please contact 1-855-VISSANI
for further assistance

Operation Instruction
1. Setting The Clock
This is 12 and 24 hour clock, and you can
select which by pressing CLOCK pad. During
cooking, the current time can be seen by
touching CLOCK pad.
EXAMPLE: How to set the oven clock time at
8:30.
1) In standby mode, touch CLOCK pad once
to select 12 hour clock.
2) Use the number pads to enter the time
(touch number pads 8,3,0 in order to enter
8:30).
3) Press START/+30SEC to conrm.
2. Setting The Kitchen Timer
In standby state or during cooking, touch
TIMER pad to set kitchen timer.
Example: How to set 30 minutes timer.
1. Touch TIMER pad once.
2. Use the number pads to enter time. The
longest time is 99 minutes 99 seconds.
3. Touch START/+ 30 SEC pad.
3. Start/ Add 30 Sec
1) Touch once and cooking will start at full
power level immediately for 30 seconds.
Touching this button repeatedly will add 30
seconds each time.
2) During the time cook and time defrost, you
can add 30 seconds for each push.
This function will not work for auto cooking
menus and defrost program.
4. Cooking Program
1) Touch the TIME COOK pad.
2) Touch the number pad to enter desired
cooking time.
The maximum number can be entered is 99
min. 99 sec.
3) Touch the POWER LEVEL pad.
4) Use the number pads to enter the power
level as shown in the table below.
Touch START/+30 SEC pad to start.
7HOMEDEPOT.COM Please contact 1-855-VISSANI
for further assistance
Power Level Chart:
Power Level Display
100% P100
90% P-90
80% P-80
70% P-70
60% P-60
50% P-50
40% P-40
30% P-30
20% P-20
10% P-10
NOTE:
The TIMER function can be used in any
cooking process. You can check the
countdown time by pressing TIMER pad, but
if STOP/CLEAR pad is pressed when the
display shows the time, the function is
cancelled.
DisplayPower Level

Operation (Continued)
5. Setting Time Defrost
1) Touch the TIME DEFROST pad.
2) Enter desired defrosting time by touching
the correct number pads. The longest time
you can set is 99 min. 99 sec.
3) Touch the START/+30 SEC pad.
6. Setting Weight Defrost
1) In standby mode, touch the WEIGHT
DEFROST pad to defrost food by weight.
2) Enter food using the number pad, and
touch START/+30 SEC pad to start.
Maximum weight is 64oz.
7. AUTO Cooking Program
For the following foods or cooking operation, you do not need to input cooking power and
time. It is sufcient to indicate the type of food that you want to cook as well as the weight
or servings of this food.
1. In standby mode, press the corresponding menu button once.
2. Press the button repeatedly to enter food weight or servings.
3. The oven starts cooking automatically 3 seconds later.
8HOMEDEPOT.COM Please contact 1-855-VISSANI
for further assistance
Auto Program Food Chart
Time
1 Pot (8oz/serving)
2 Pot
6 oz
2-pc
4:00
2:00
7:00
2:20
1:20
0:40
POTATO
Weight/Serving
Menu
POPCORN
PIZZA
3.5oz
BEVERAGE
1-pc (200ml/serving)
3-pc 3:20
2:20
3:20
2:50
FROZEN
DINNER
9 oz
18 oz 9:00
5:00
REHEAT
21 oz
18 oz
14 oz
11 oz
7 oz
28 oz
25 oz
1:20
4:20
3:50
1:50
11 oz 1:10
16 oz 1:40
NOTE:
During defrosting program, the system
will pause and sound beeps to remind
user to turn food over, and then touch
START/+30SEC pad to resume.
NOTE:
During defrosting program, the system
will pause and sound beeps to remind
user to turn food over, and then touch
START/+30SEC pad to resume.

9HOMEDEPOT.COM Please contact 1-855-VISSANI
for further assistance
8. Express Cook
Cooking will start immediately after touching
the number pad (1-6). For example. if you
want to set the express cooking time to 6
minutes.
1) Touch the 6 pad.
2) 6:00 minutes displays.
3) Cooking automatically starts and runs for 6
minutes.
Touch Number Pad Time Minutes
1 Minute
2 Minutes
1
4
3
2
6
5
6 Minutes
5 Minutes
4 Minutes
3 Minutes
9. Multi-stages Cooking
Some recipes require different stages of
cooking at different temperatures.
SET STAGE 1:
1) Place food into oven and close it. Touch
TIME COOK pad.
2) Use the number pads to set a cooking
time.
3) Touch the POWER LEVEL pad.
4) Use the number pads to enter the power
level.
SET STAGE 2:
5) Touch TIME COOK pad.
6) Use the number pads to set a cooking
time.
7) Touch the POWER LEVEL pad.
8) Use the number pads to enter the (lower)
power level.
9) Touch START/+30 SEC to start.
10. Child Lock
The child lock prevents unsupervised
operation by children.
To set, in standby mode, press and hold
STOP/CLEAR for 3 seconds. "Loc" is
indicated on the display.
To cancel, press and hold STOP/CLEAR for 3
seconds. "Loc" indication disappears.
Operation (Continued)

Care and Cleaning
10 HOMEDEPOT.COM Please contact 1-855-VISSANI
for further assistance
1. Turn off the oven and unplug the power cord from the wall when cleaning.
2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to
oven walls, wipe with a damp cloth. Mild detergents may be used if the oven gets very
dirty. Avoid using spray or other harsh cleaners. They may stain, streak or dull the door
surface.
3.The outside of the oven should be cleaned with a damp cloth. To prevent damage to
the operating parts inside the oven, water should not be allowed to seep into the
ventilation openings.
4. Wipe the door and window on both sides, the door seals and adjacent parts
frequently with a damp cloth to remove any spills or spatters. Do not use abrasive
cleaner.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When
cleaning the control panel, leave oven door open to prevent oven from accidentally
turning on.
6. If steam accumulates inside or around the outside of the oven door, wipe with a soft
cloth. This may occur when the microwave oven is operated under high humidity
condition. This is normal.
7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in
warm sudsy water or in a dishwasher.
8. The roller ring and oven oor should be cleaned regularly to avoid excessive noise.
Simply wipe the bottom surface of the oven with mild detergent. The roller ring may be
washed in mild, soapy water or in a dishwasher. When removing the roller ring, be sure
to replace it in the proper position.
9. Remove odors from your oven by combining a cup of water with the juice and skin of
one lemon in a microwaveable bowl. Microwave for 5 minutes. Wipe thoroughly and dry
with a soft cloth.
10. If the light bulb burns out, please contact customer service to have it replaced.
11. The oven should be cleaned regularly and any food deposits should be removed.
Failure to maintain the oven in a clean condition could lead to deterioration of surface
that could adversely affect the life of the unit and could possibly result in a hazardous
situation.
12. Please do not dispose of this appliance into the municipal waste bin; it should be
disposed to the particular disposal center provided by the municipalities.

Warranty
11 HOMEDEPOT.COM Please contact 1-855-VISSANI
for further assistance
This warranty applies to microwave ovens under the brand name Vissani sold by The Home Depot, in
the U.S (“Vissani Products”). This warranty is in lieu of any other warranty and expressly applies to the
individual product only. Vissani products are warranted to be free from any defects in material and
workmanship resulting from noncompliance with the legal standards for one year from the date of the
consumers’ first purchase. In addition, the magnetrons (parts only) of Vissani Products are warranted
to be free from defects in material and workmanship for a period of eight years from the date of the
consumers’ first purchase. Nevertheless, the consumer is responsible for all labor and transportation
expenses related to the diagnosis and replacement of the magnetron after the initial one-year warranty
expires. In the event the unit requires replacement or refund under the terms of this warranty, the
consumer is responsible for all transportation expenses to return the unit to our factory prior to
receiving a replacement unit or refund.
Please save your receipt as proof of purchase is required to make a warranty claim. If a covered defect
occurs during the one-year warranty period, we agree, at our own discretion, to repair, replace, or pay
the consumer the reasonable cost of repairing or replacing the defective item. The warranty can not be
transferred through resale, including the resale through a 3rd party unauthorized retailer and is only
bestowed upon the original consumer who purchases from an authorized retailer. This warranty does
not cover, and excludes, damage or defects caused by: Consumer misuse Abuse Neglect including the
failure to clean and/or provide adequate regular maintenance as outlined in the user manual,
Commercial use, Subjecting the product to any voltage outside the specified range, Loss of parts,The
affixing of any attachments not provided with the product, Loss or damage caused by acts of God,
including but not limited to fire, explosion, smoke, water escape, changes that are not reasonably
foreseeable in the level of underground water table, glass breakage, windstorm, hail, lightning, falling
trees, aircraft, vehicles, flood, and earthquakes. Use in a manner not intended and outlined in the user
manual. Failure of the consumer to take timely action to minimize loss or damage or failure of the
consumer to give us timely notice of the defect.
Any subsequent damages caused by the above listed exclusions will not be covered and any claims
determined to meet the above exclusions will be denied. All liability is limited to the purchase price and
does not include any: Retail offered extended warranties, Tax, Other charges (including postage to send
required materials), Incidental and/or consequential damages associated with the product in question.
Every implied warranty, including any statutory warranty of merchantability or fitness for a particular
purpose is disclaimed except to the extent prohibited by law, in which case such warranty is limited to
the duration of this written warranty. This warranty gives you specific legal rights. You may have other
legal rights that vary depending on where you live. Some states do not allow limitations on implied
warranties or special, incidental, or consequential damage, so the above limitations may not apply to
you.
If you have a claim under this warranty, please call our Customer Service number: 1-855-VISSANI.
For faster service, please have the model number, serial number, and receipt ready for the operator to
assist you.
Model Number Part& Labor Type of ServiceMagnetron (Parts Only)
VSCMWE11S2W-10 Carry InEight YearsOne Year

Questions, problems, missing parts? Before returning to the store,
call VISSANI Customer Serive
8 a.m -8 p.m., EST, Monday-Friday, 8a.m.-6 p.m., EST, Saturday
1-855-VISSANI
HOMEDEPOT.COM
Retain this manual for future use.
