Homeilight HM-LS02 User manual

LED Moving Head Beam 8 eyes Light
USER MANUAL
KEEP THIS MANUAL FOR FUTURE NEEDS

Thank you for your patronage. We are confident that our excellent
products and service can satisfy you. For your own safety, please read this
user manual carefully before installing the device.
In order to install, operate, and maintain the lighting safety correctly. We
suggest that the installation and operation should be done by the verified
technician and follow the instruction strictly.
ACAUTION! Keep this device away
from rain and moisture!
CAUTION!
Unplug mains lead before opening the housing.
Every person involved with the installation, operation and maintenance of
this device has to:
-be qualified
-follow carefully the instructions of this manual
1. INTRODUCTION
Thank you for having chosen this professional moving head.
You will see you have acquired a powerful and versatile device.
Unpack the device. Inside the carton box you should find:
1. One XLR power cable
2. One user manual
3. Two pcs omega

Please check carefully that there is no damage caused by transportation.
Should there be any, please consult your dealer and don’t install this
device.
2 Mounting and installation
2.1 Cautions: for added protection mount the fixyures in areas outside
walking paths ,seating areas,or in areas were the fixture might be reached
by unauthorized personnel.
Before mounting the fixture to any surface ,make sure that the installation
area can hold a minimum point load of 10 times the device’s weight.
Fixture installation must always be secured with a secondary safety
attachment ,such as an appropriate safety cable.
Never stand dirrctly below the device when mounting ,removing ,or
servicing the fixture, from a ceiling,or set on a flat level surface (see
illustration below).Be sure this fixture is kept at least 0.5m (1.5ft) away
from any flammable (decoration etc.)
Always use and install the supplied safety cable as a safe cable as safety
measure to prevent accdental damage and /or injury in the event the
clamp fails.
2.2 Mounting points:
Overhead mounting requires extensive experience , including amongst
others calculating working load limits, a fine knowledge of the
installation material being used ,and periodic safety inspection of all

installation material and the fixture. If you lack these qualifications ,
Do not attempt the installation yourself ,improper installation can result
in bodily injury.
Be sure to complete all rigging and installation procedures before
connecting the main power cord to the appropriate wall outlet.
2.3 Clamp mounting :
The LED moving head provides a unique mounting bracket assembly that
integrates the bottom of the base, the included ‘omega bracket’ and the
safety cable rigging point in one unit (see the illustrationbelow).When
mounting this fixture to truss be sure to sere to secure an appropritely
rated clamp to the included omega bracket using a M10 screw fitted
through the center hole of the ‘omega bracket’.As an added safety
measure be sure to attached at least one properly rated safety cable to the
fixture using on of the safety cable rigging point integrated in the base
assembly.

2.4 DMX-512 control connection
Connect the provided XLR cable to the female 3-pin XLR output of your
controller and the other side to the male 3-pin XLR input of the moving
head. You can chain multiple Moving head together through serial
linking. The cable needed should be two core, screened cable with XLR
input and output connectors. Please refer to the diagram below.
2.4 DMX-512 connection with DMX terminator
For installations where the DMX cable has to run a long distance or is in
an electrically noisy environment, such as in a discotheque, it is
recommended to use a DMX terminator. This helps in preventing
corruption of the digital control signal by electrical noise. The DMX
terminator is simply an XLR plug with a 120 resistor connected between
pins 2 and 3,which is then plugged into the output XLR socket of the last

fixture in the chain. Please see illustrations below.
3 TECHNICAL PARAMETERS
POWER SUPPLIE
Input power:AC100-240V 50/60 Hz
LED:8PCS 10W high power RGBW LED
DMX channel:13/46channels
Movement:Pan/Tilt:X axis540degree, Y1 axis 120degree, Y2
axis120degree
Control mode:DMX512/Master-Slave/Auto run
Display:Blue blueground LCD display
Beam angle:3degree
Pan/tilt speed:3 selectable for High, medium and low speed
WEIGHT&SIZE
N.W: 9kgs
G.W:11kgs
size: 32*41*28CM
Packing size:50*38*37CM

4 :MENU FUNCTION
1DMX
Address
DMX Address
=001
2DMX Mode DMX Mode .=DMX 13 Channel
.=DMX 46 Channel
3Run Mode Run Mode .=Master
.=Slave
4 Auto Play Internal Program .=001
.=002
.=003
.=004
.=005
.=006
.=007
.=008
5Sound Ctrl
Mode .=OFF
.=ON
6Reverse
Pan .=OFF
.=ON
7Reverse
Tilt1 .=OFF
.=ON
8Reverse
Tilt2 .=OFF
.=ON
9Reset
Motor .=OFF
.=ON
10 Special
Reset Default 1 .=OFF
.=ON
Calibration 2
Code
Code
=018
PAN
PAN
=+000
TILT1
TILT1
=+000
TILT2
TILT2
=+000

Dimmer
Dimmer
=000
Manual Control 3
PAN
PAN
=000
PAN-Fine
PAN-Fine
=000
X MoveSpeed
X MoveSpeed
=000
TILT1
TILT1
=000
TILT2
TILT2
=000
Y Move Speed
Y Move Speed
=000
Dimmer
Dimmer
=000
Strobe
Strobe
=000
Red1
Red1
=000
Green1
Green1
=000
Blue1
Blue1
=000
White1
White1
=000
Red2
Red2
=000
Green2
Green2
=000
Blue2
Blue2
=000
White2
White2
=000
Mic Sensitivity
4 .=000%-100%
ACC SETUP 5
Low speed
Middle Speed
Low Speed

5:Function Mode
5.1 DMX address setting
With this function, you can adjust the desired DMX-address via the
Control Board.
Select via the encoder.
Press the encoder, adjust the DMX address by turning the encoder.
Press the encoder to confirm.
Press the Mode/Esc-button in order return to the main menu.
Set DMX address
Display the DMX 512 value of each channel
With this function you can display the DMX 512 value of each channel.
The display automatically
shows the channel with a value changing.
5.2 DMX Mode
The LED moving head have 8CH and 21CH, can receive the International
DMX signal.
5.3 Run Mode
In the【Run】mode，you can chose【Master】mode and【Slave】mode.
5.4:Auto Play
With this function, you can run the 8 Inside program with master mode.
5.5 sound
[Music control]With this function, you can run sound-controlled.
5.6 Pan Reverse

With this function you can reverse the Pan-movement.
5.7 Tilt 1 Reverse
With this function you can reverse the Tilt 1-movement.
5.8 Tilt 2 Reverse
With this function you can reverse the Tilt 2-movement.
5.9:Reset
With this function, you can reset the device via the Control Board.You
can select the different reset function by turning the encoder.
5.10:Special Setting
5.10.1 [Factory Reset]
With this function, you can select restore factory set for ON or OFF, the
default is OFF.
5.10.2[Calibrate values]
With this function, you can calibrate and adjust the effect wheels to their
correct positions. The password of calibrate values is 018.
5.10.3 [Manual Control]
With this function, user can control the function by manual.
5.10.4 [Mic Sensitivity ]
With this function, Mic Sensitivitycan from 000% to 100%
5.10.5 [ACC SET UP]
Pan/tilt speed:3 selectable for High, medium and low speed
6: DMX CHANNELS
6.1 13 channel definition table

Channel DMX Value Function
1 000 - 255 X
2 000 - 255 Y1
3 000 - 255 Y2
4 000-255 Dimmer(0-100%)
5
000-9 Shutter closed
010-250 Strobe effect slow to fast
251-255 Shutter open
6 000-255 R(ALL)
7 000-255 G(ALL)
8 000-255 B(ALL)
9 000-255 W(ALL)
10
000-007 Empty
008-017 R1,2,3,4
018-027 R5,6,7,8
028-037 G1,2,3,4
038-047 G5,6,7,8
048-057 B1,2,3,4
058-067 B5,6,7,8
068-077 W1,2,3,4
078-087 W5,6,7,8
088-097 R(ALL)
098-107 G(ALL)
108-117 B(ALL)
118-127 W(ALL)
128-255 MacroColorLine(Slow from slow to fast)
11
000-007 Empty
008-037 LED Auto Play 1
038-067 LED Auto Play 2
068-097 LED Auto Play 3
098-127 LED Auto Play 4
128-157 LED Auto Play 5
158-187 LED Auto Play 6
188-217 LED Auto Play 7
218-247 LED Auto Play 8
248-255 LED Sound Control MODE
12 000-255 LED Auto Play Speed(Slow to Fast)
13
000-007 Empty
008-033 X/Y auto run 1
034-059 X/Y auto run 2
060-085 X/Y auto run 3
086-111 X/Y auto run 4
112-137 X/Y auto run 5

138-163 X/Y auto run 6
164-189 X/Y auto run 7
190-240 X/Y auto run 8
241-255 X/Y sound
6.2 46 channel definition table
Channel DMX Value Function
1 000 - 255 X
2 000 - 255 X Fine
3 000 - 255 X Motor Speed
4 000 - 255 Y1
5 000 - 255 Y1 Fine
6 000 - 255 Y2
7 000 - 255 Y2 Fine
8 000 - 255 Y Motor Speed
9 000-255 Dimmer(0-100%)
10
000-9 Shutter closed
010-250 Strobe effect slow to fast
251-255 Shutter open
11 000-255 Red1
12 000-255 Green1
13 000-255 Blue1
14 000-255 White1
15 000-255 Red2
16 000-255 Green2
17 000-255 Blue2
18 000-255 White2
19 000-255 Red3
20 000-255 Green3
21 000-255 Blue3
22 000-255 White3
23 000-255 Red4
24 000-255 Green4
25 000-255 Blue4
26 000-255 White4
27 000-255 Red5
28 000-255 Green5

29 000-255 Blue5
30 000-255 White5
31 000-255 Red6
32 000-255 Green6
33 000-255 Blue6
34 000-255 White6
35 000-255 Red7
36 000-255 Green7
37 000-255 Blue7
38 000-255 White7
39 000-255 Red8
40 000-255 Green8
41 000-255 Blue8
42 000-255 White8
43
000-007 Empty
008-017 R1,2,3,4
018-027 R5,6,7,8
028-037 G1,2,3,4
038-047 G5,6,7,8
048-057 B1,2,3,4
058-067 B5,6,7,8
068-077 W1,2,3,4
078-087 W5,6,7,8
088-097 R(ALL)
098-107 G(ALL)
108-117 B(ALL)
118-127 W(ALL)
128-255 MacroColorLine(Slow from slow to fast)
44
000-007 Empty
008-037 LED Auto Play 1
038-067 LED Auto Play 2
068-097 LED Auto Play 3
098-127 LED Auto Play 4
128-157 LED Auto Play 5
158-187 LED Auto Play 6
188-217 LED Auto Play 7
218-247 LED Auto Play 8
248-255 LED Sound Control MODE
45 000-255 LED Auto Play Speed(Slow to Fast)
46
000-007 Empty
008-033 X/Y auto run 1
034-059 X/Y auto run 2
060-085 X/Y auto run 3

086-111 X/Y auto run 4
112-137 X/Y auto run 5
138-163 X/Y auto run 6
164-189 X/Y auto run 7
190-240 X/Y auto run 8
241-255 X/Y sound
