homelabs HME050392N User manual

Smokeless Grill - Basic
HME050392N
Thank you for selecting our quality appliance. Please be sure to read this user manual carefully before using. Any question, please contact the professional service for help.

In the event this product malfunctions or customer believes
it is defective, the customer should contact Customer Service
and retain the defective product pending further instructions.
Defective product should be clearly marked or stored where it
cannot be used again by mistake. Failure to retain the product
may impede hOme™’s ability to correct any legitimate problem
and may limit the extent to which hOme™may provide recourse.

Important Safety Instructions
Operating Instructions
Cleaning and Maintenance
Troubleshooting
Warranty
Manufacturing Info
Warning
Contact Us
6-8
9-12
13-14
14
15
15
15
15
TABLE OF CONTENTS

on bringing home your new appliance!
Congratulations
Don’t forget to register your product at homelabs.com/reg
for updates, coupons, and other relevant information.
Although greatly appreciated, product registration is not
required to activate any warranty.

6
When using electrical appliances, basic safety precautions should always be followed, including the
following:
• Read all Instructions.
• Do not touch hot surfaces.
• To protect against electric shock do not immerse cord, plugs in water or other liquid.
• Close supervision is necessary when any appliance is used by or near children.
• Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off
parts, and before cleaning the appliance.
• Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or
has been damaged in any manner. Return appliance to the nearest authorized service facility for
examination, repair or adjustment.
• The use of accessory attachments not recommended by the appliance manufacturer may cause
injuries.
• Do not use outdoors.
• Do not let cord hang over edge of table or counter, or touch hot surfaces.
• Do not place on or near a hot gas or electric burner, or in a heated oven.
• Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.
• To disconnect, turn power button to “off”, then remove plug from wall outlet.
• Do not use appliance for other than intended use.
• The product is not designed to be controlled by an external timer or a separate remote control
system.
• The grill is intended only for indoor home/private use or use in similar environments such as
kitchens in stores, ofces and other workplaces, or use by individual clients in hotels, motels and
other residential environments and Bed & Breakfast type rooms. Do not grill in closed rooms where
adequate ventilation is not maintained.
• This appliance can be used by children above 8 years and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have been given supervision or
instructions concerning use of the appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and maintenance should not be performed by children unless they are above 8 years and
are supervised by an adult responsible for their safety.
• Store the device and its plug out of the reach of children.
• Attention! Charcoal and other similar fuels must not be used with this appliance.
• The device may only be used when is properly assembled in accordance with the assembly
instructions.
• Do not use the accessories not recommended by the manufacturer, otherwise may cause injuries.
• Before use check if current and voltage are in compliance with the data on the rating plate.
• Use only properly earthed power supply source.
• When using the grill for the rst time, it may produce smoke and unpleasant odor. This is normal.
• Do not use the appliance if the cable or the plug is damaged.
• The appliance and it parts shouldn’t be repaired by the user. Otherwise the warranty becomes null
and void. If any damage is found during the warranty period, contact the retailer where the product
was purchased. After the warranty period contact a serviceman or a certied technician.
• Never use the grill near ammable materials such as wood, dry grass, shrubs etc. Keep the grill at a
safe distance from the above mentioned objects.
• Do not keep kitchen oil near the appliance.
• Pay attention not to allow the grill contact ammable materials such as paper, walls, towels,
chemicals etc.
Important Safety Instructions

7
• Do not move the appliance during use. Never carry the grill with hot oil or other hot liquids in the
tray. Wait until the grill gets cold.
• Do not touch the grill plate or other hot surfaces during or just after grilling. Be careful.
• Do not allow fat or other dirt to accumulate on the surface or inside the device.
• When roasting with oil / fat, do not let it ignite. Do not use water to extinguish the re. In case of
re, switch off the device, disconnect the grill from the power source and cut off the air supply with
a damp cloth or a re blanket.
• The appliance can be used according to the intended manner only. The manufacturer will not be held
responsible for any damage arising from misuse or improper use.
• Do not use the grill under the inuence of alcohol or when you are tired.
• Do not leave the grill switched on without supervision.
• Do not use the grill in high humidity environments.
• Do not use the appliance on boats or recreational vehicles.
• When disconnecting the cable from the socket, pull the plug out from the socket. Do not plug the
cable.
• Never carry the appliance by the power cord.
• Keep the grill in a dry place. Do not expose the device to sunlight.
• Failure to observe the above precautions may lead to death, serious injuries or damage to property.
SAVE THESE INSTRUCTIONS HOUSEHOLD USE ONLY
• A short power-supply cord is to be provided to reduce the risk resulting from becoming entangled in
or tripping over a longer cord.
• Longer detachable power-supply cords or extension cords are available and may be used if care is
exercised in their use.
• If a long detachable power-supply cord or extension cord is used:
• The marked electrical rating of the cord or extension cord should be at least as great as the
electrical rating of the appliance;
• If the appliance is of the grounded type, the extension cord should be a grounding 3-wire cord;
and
• The longer cord should be arranged so that it does not drape over the countertop or table top
where it can be pulled on by children or tripped over unintentionally.
Important Safety Instructions

8
SAVE THESE INSTRUCTIONS
For Household Use Only
FCC Statement
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
MODIFICATION: Any changes or modications not expressly approved by the grantee of this device could
void the user’s authority to operate the device.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Important Safety Instructions

9
PARTS LIST
CONTROL PANEL
Operating Instructions
Glass lid
Nonstick griddle plate
Nonstick grill plate
Heating element with detachable power cord
Drip tray
Water tray
Base unit
Removable electric fan
Snap-off fan cover
Power indicator
Power button
Temperature down button
Temperature up button
Fan button
Fan indicator
3
4
5
6
1
3 4 5 61 2
2

10
Before rst use
• Unpack the grill and remove all packaging materials. Wipe the cooking surface and base with a clean,
damp cloth. Dry thoroughly. Do not use harsh or abrasive detergents to clean any part of the grill.
• Place the device on a stable, at and heat-insulating surface.
• Place the water tray in the bottom of the base and ll in enough clean water according to the MAX
and MIN ll line.
• Place the drip tray on the base unit. Align the arrows on the drip tray and the base. The appliance will
not operate if the drip tray is installed incorrectly.
• Place the heating element on the base unit.
• Place the grill or griddle plate on the top.
• You are recommended a “trial run” at a high temperature to eliminate any protective substance or oil
that may remained used for packing and shipping. Switch on the grill, set the temperature to 450°F.
Let the grill run for 20 minutes. A small amount of smoke and odor may be detected. This is normal.
• Before rst use, spread 2 teaspoons of vegetable oil with a soft cloth or folded paper towel over the
entire grill surface to condition the nonstick surface. Set temperature to 450°F. After the grill reaches
the set temperature for 6 minutes, turn off and cool the device completely. The grill is ready for use.
Warnings
• Make sure that the grill is assembled fully according to the assembly diagrams.
Use the grill
• Connect the cord to the grill rst, and then plug the power cord into power socket. The power
indicator ickers.
• Press the power button, the power indicator light will turn on.
• The temperature starts at 350°F (default setting). Press +or -button to set the temperature at 200°F,
250°F, 300°F, 350°F, 400°F or 450°F. The fan will run automatically. You can turn off the fan by
pressing the fan button. The fan should be kept running during the whole grilling process.
• The default temperature system is in Fahrenheit. To switch between Celsius and Fahrenheit system,
press and hold both the + and -buttons for a few seconds.
• After grilling, press the power button to shut down the appliance. Then the fan will power off
automatically. Unplug the power cord from the outlet and allow the appliance to cool down
completely. Then disassemble the appliance for cleaning.
Note:
• Use a meat thermometer to make sure the food is roasted at a safe temperature. The fan should be
kept running throughout the grilling to prevent grease accumulating.
• You may adjust the cooking temperature during the cooking process. To keep food warm, set the
temperature at 200°F.
• Before starting to grill, always connect the power cable to the device rst, then plug the cord to the
outlet. After grilling, always remove the plug from the outlet rst, then disconnect the cable from the
device.
• Do not block the holes in the drip tray with food particles, otherwise fat will not drain into the water
tray.
Operating Instructions

11
Cooking Guide
Tips:
• Be careful not to transfer germs from raw meat to cooked meat. Use separate utensils and platters
for raw and cooked meat.
• Always marinade in a tightly covered nonmetal dish and turn the food occasionally. Be sure to
refrigerate all meats while marinating.
• If leftover wet marinade is to be used as a sauce with the cooked food, be sure to place it in a small
pan and heat to a rolling boil before serving to eliminate bacterial growth.
• Similar to a stove top frying pan, grease from high-fat foods, such as bacon or sausage, may splatter
on the countertop. Protect the countertop as necessary.
• Before grilling, partially cook bone-in chicken, ribs, and uncooked smoked or fresh sausages for best
results. If not partially cooked, these meats may become overbrowned on the outside before the
center is done.
• To prevent scratching the coating, use only nonmetallic utensils. Do not cut food on the grill plate
using sharp utensils, such as forks or knives, that can scratch the cooking surface.
• Do not use steel wool or other metal pads. They could leave coarse scratches. Always rinse
thoroughly and dry immediately with a soft towel.
Set the cooking temperature by referring to below Grill Temperature Chart and Griddle Temperature Chart.
Grill Temperature Chart Griddle Temperature Chart
Food Temperature Food Temperature
Chicken breast, boneless 350°F Bacon 350°F
Chops: Lamb, Pork, Veal 350°F Eggs 300°F
Fish 350°F French Toast 350°F
Hamburgers 450°F Grill Cheese Sandwiches 350°F
Shrimp 350°F Hash Browns 350°F
Spare ribs 350°F Pancakes 350°F
Steak 450°F Sausages 350°F
Operating Instructions

12
During the cooking, you can use a thermostat to check the internal meat temperature by referring to
below Cooking Chart. The cooking time depends upon the thickness and desired degree of doneness of
food. Foods can be grilled at maximum temperature. However you may wish to reduce the temperature
for certain items. Low temperatures will keep foods warm once cooked.
Cooking Chart
Food Item Temperature
Fish 155°F
Shrimp 155°F
Chicken Drumsticks 176°F
Chicken Wings 176°F
Steak 140°F–165°F
Pork Chops 160°F
Burgers 160°F
Sausages 160°F
Operating Instructions

13
Cleaning and Maintenance
• Cleaning and maintenance must be carried out after the grill cools down.
• Before cleaning or maintenance, pull the plug out of the power socket rst and then pull the
detachable cord from the appliance.
• Never wash any of the parts in a self-cleaning oven. High temperature will damage the parts.
• Do not clean the fan. The water tray drip tray, griddle plate and grill plate can be cleaned in
dishwasher, while the rest parts can only be cleaned by hands.
• Never immerse the appliance, power cord or the plug in water or other liquids. Improper
maintenance may cause re, property damage, serious injuries or death.
• Do not clean the grill with oven cleaning agents, abrasive cleaners, or cleaning agents contain acid or
non-organic alcohol.
• Do not clean the grill with a metal scraper. Metallic parts may detach from the scraper and cause a
short circuit between the electric parts.
• Do not put the hot plate in cold water. Always wait until the device cools down completely before
cleaning.
• Do not soak the grill plate or the griddle plate. This could damage the non-stick coating.
• Clean the grill timely to avoid accumulating fat.
• Dry all parts completely after cleaning.
Clean the housing
• Before cleaning the housing, take the fan out rst.
• Clean the housing with a soft cloth and mild detergent.
• Rinse the housing with clean water and dry completely.
Clean the heating element
• Wipe the heating element with a moist cloth. Do not scratch the heating element.
• Do not immerse the heating element in water.
• Use a dry cloth to dry the heating element.
• After cleaning, reassemble the grill according to the assembly instructions.

14
Troubleshooting
PROBLEMS SOLUTIONS
The power indicator does not
light on.
Check if the power cord is connected to the appliance and the
power socket securely.
The fan indicator lights on but
the working sound can not be
heard.
The fan cover maybe open. Disconnect the plug from the outlet
and close the fan over.
Cleaning and Maintenance
Remove the fan
Turn over the appliance Slide out the fan cover Take out fan
ATTENTION:
• Make sure the fan is assembled well and the fan cover is closed before use.
• Do not use the grill without fan. Fat will accumulate inside the grill and affect the operation of the grill.

15
hOme™offers a limited two-year warranty (“warranty period”) on all of our products purchased new
and unused from hOme Technologies, LLC or an authorized reseller, with an original proof of purchase
and where a defect has arisen, wholly or substantially, as a result of faulty manufacture, parts or
workmanship during the warranty period. The warranty does not apply where damage is caused by
other factors, including without limitation: (a) normal wear and tear; (b) abuse, mishandling, accident,
or failure to follow operating instructions; (c) exposure to liquid or inltration of foreign particles; (d)
servicing or modications of the product other than by hOme™ ; (e) commercial or non-household use.
The hOme™ warranty covers all costs related to restoring the proven defective product through
repair or replacement of any defective part and necessary labor so that it conforms to its original
specications. A replacement product may be provided instead of repairing a defective product. hOme™
’s exclusive obligation under this warranty is limited to such repair or replacement.
A receipt indicating the purchase date is required for any claim, so please keep all receipts in a safe
place. We recommend that you register your product on our website, homelabs.com/reg. Although
greatly appreciated, the product registration is not required to activate any warranty and product
registration does not eliminate the need for the original proof of purchase. The warranty becomes
void if attempts at repair are made by non-authorized third parties and/or if spare parts, other than
those provided by hOme™ , are used. You may also arrange for service after the warranty expires at an
additional cost.
These are our general terms for warranty service, but we always urge our customers to reach out to
us with any issue, regardless of warranty terms. If you have an issue with a hOme™ product, please
contact us at 1-800-898-3002, and we will do our best to resolve it for you.
This warranty gives you specic legal rights, and you may have other legal rights which vary from state
to state, country to country or province to province. The customer may assert any such rights at their
sole discretion.
HME050392N
Warranty
Manufacturing Info
This manual is to be used with all items with the model number
SKU# : HME050392N
Rated voltage/Frequency/Power: 120V / 60Hz / 1500W
Keep all plastic bags away from children.
Warning
Contact Us
homelabs.com/chat
Mon–Fri 10AM–5PM EST
1-(800)-898-3002
Mon–Fri 10AM–5PM EST
[email protected]
Respond within twelve hours
CHAT W ITH US CALL U S EMAIL U S

© 2016 hOme Technologies, LLC
37 East 18 Street, 7th Floor
New York, NY 10003
For household
Use Only
1-800-898-3002
[email protected]
homelabs.com/help
All rights reserved, hOme®. Printed in China.
