Honeywell HDS18SS User manual

18” Stainless Steel Dishwasher
User Manual
Read and save these instructions before use
HDS18SS

CONTENTS
1Important Safety Instructions
1.1 Proper installation
1.2 Basic precautions before use
2Installation Introduction
3Features of Your New Dishwasher
3.1 Components
3.2 Filter System
3.3 Smart Wash System
4Operating Instructions
4.1 Start/Cancel
4.2 Wash Cycle Selections
4.3 Delay
4.4 Display Window
4.5 Status Indicators
4.6 Options
4.7 Status Window
4.8 Error Indication
4.9 Cycle Chart
5 User Maintenance
5.1 Cleaning the Exterior
5.2 Cleaning the Interior
5.3 Cleaning the Filters
6 Troubleshooting
6.1 Error Codes
7 Technical Information
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

1
1 IMPORTANT SAFETY INSTRUCTION
Please install your dishwasher properly by following the installation guide.
• Water supply inlet temperature should be between 120°F and 149°F.
• Dispose of discarded appliances and packing materials properly.
• The dishwasher must be properly grounded, or it can result in a risk of electric
shock. PERMANENTLY CONNECTED and CORD-CONNECTED are both allowed.
• If there is any damage to the Dishwasher, please contact to your Dealer, do not
to attempt to repair or replace any parts by yourself.
• Read all instructions before using the dishwasher.
• The manual does not cover every possible condition and situation that may
occur.
• Use the dishwasher only for its intended function as described in this manual.
• When loading items to be washed, arrange sharp items and knives so that
they are not likely to damage the door seal and tub. Load these items with the
handles upright in order to reduce the risk of personal injury.
• Do not wash plastic items unless they are marked dishwasher safe. If they are
not marked, check with the manufacturer for recommendations. Items that are
not dishwasher safe may melt and create a potential fire hazard.
• If the dishwasher drains into a food disposer, make sure the disposer is
completely empty before running the dishwasher.
• Do not tamper with controls.
• Do not operate your dishwasher unless all enclosure panels are properly placed.
• Do not touch the heating element during or immediately after use, especially if
the sanitize option has been selected.
• To reduce the risk of injury, do not allow children to play in or on a dishwasher.
1.1 Proper Installation
1.2 Basic Precautions Before Use
WARNING: For your safety, please follow the information in this manual to minimize
the risk of fire, explosion, electric shock and to help prevent property damage or
personal injury.

2
• Do not let children hit, sit or stand on door or racks of the dishwasher.
• Under certain conditions, hydrogen gas may be produced in a hot water system
that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE.
If the hot water system has not been used for such a period, before using the
dishwasher, turn on all hot water faucets and let water flow for several minutes.
This will release any accumulated hydrogen gas. Hydrogen gas is flammable. Do
not smoke or use an open flame during this time.
• Do not store or use combustible materials, gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
• Use only detergents or rinse agents recommended for use in a dishwasher and
keep them out of the reach of children.
• Keep young children and infants away from dishwasher while it is operating.
• Do not use the dishwasher if it has a damaged power line or plug, and do not
plug the dishwasher into a damaged outlet. Failure to observe these instructions
may result in electrical shock.
• Remove the door to the washing compartment when removing an old
dishwasher from service or discarding it.
SAVE THESE INSTRUCTIONS

3
2 INSTALLATION INTRODUCTION
IMPORTANT Observe all governing codes and ordinances.
NOTE TO INSTALLER Be sure to leave these instructions for the consumer’s and
local inspector’s use.
NOTE TO CONSUMER Keep these instructions with your Owner’s Manual for future
reference.
SKILL LEVEL Installation of this dishwasher requires basic mechanical and
electrical skills. Proper installation is the responsibility of the installer. Product
failure due to improper installation is not covered under the Appliance Warranty.
COMPLETION TIME 1 to 3 Hours. New installations require more time than
replacement installations.
IMPORTANT The dishwasher MUST be installed to allow for future removal from
the enclosure if service is required. If you received a damaged dishwasher, you
should immediately contact your dealer or builder.
FOR YOUR SAFETY Read and observe all CAUTIONS and WARNINGS shown
throughout these instructions. While performing installations described in this
booklet, gloves, safety glasses or goggles should be worn.
WARNING To reduce the risk of electrical shock, fire, or injury to persons, the
installer must ensure that the dishwasher is completely enclosed at the time of
installation.
READ CAREFULLY. KEEP THESE INSTRUCTIONS. If you have an installation
problem, contact your dealer or installer. You are responsible for providing adequate
electrical, exhausting and other connecting facilities.
BEFORE YOU BEGIN Read these instructions completely and carefully.

4
3 FEATURES OF YOUR NEW DISHWASHER
3.1 Components
Lock
Upper Basket
Upper Spry Arm
Cutlery Basket
Lower Basket
Heating Element
Rinse Aid Dispenser
Cup Shelf

5
3.2 Filter System
Your dishwasher has a multiple Filter System. In the System there are three mesh
filters. It can separate soiled water and clean water in different chambers.
The multiple filter system helps your dishwasher to get better performance with less
water and less energy.
3.3 Smart Wash System
Your dishwasher has Smart Wash System. When a partial load of lightly soiled
dishes is placed in the unit, a wash cycle similar to a short wash will automatically be
performed. When a full load of heavily soiled dishes is placed in the unit, a heavy wash
cycle will automatically be performed. it can determine the type of cycle required to
clean the dishes and will clean more efficiently every time.
How Your Dishwasher Cleans
Your dishwasher cleans by spraying a mixture of hot water and detergent through the
spray arms against soiled surfaces.
The dishwasher fills with water covering the filter area. Water is then pumped through
the multiple filter and spray arms. Separated soil particles go down the drain as the
water is pumped out and replaced with clean water.
The number of water fills will vary with the cycle being used.

6
Getting Started
01 Load the dishwasher. (See Dish Preparation and Loading sections)
02 Add detergent. (See Filling the Detergent Dispenser)
03 Add rinse aid. (See Filling the Rinse Aid Dispenser)
04 Select desired CYCLE. (See Cycle Chart)
05 Select desired OPTIONS (See Control Panel). The indicator light above the pad will
glow when selected.
06 Run the hot water faucet nearest the dishwasher until the water is hot, then turn it
off.
07 To start, press Start/Cancel. (See Control Panel) Then close door.
NOTE This model is embedded operation, all buttons can only be operated in the
open state.
Wash Cycle Selections
Cycle times are approximate and will vary with the options selected. Hot water is
necessary to activate the detergent and melt fatty food soils. An automatic sensor
will check the incoming water temperature. If it is not at the appropriate temperature
the timer will delay the cycle to allow automatic water heating during the main wash.
When the HI-TEMP wash is selected an even higher temperature will be assured to
handle heavier soil loads.

7
4 OPERATING INSTRUCTIONS
Control Panel
4.1 Start/Cancel
Open the door to select the desired cycle and options, touch the Start/Cancel button
and close the door within 4 seconds to start the cycle or begin the delay countdown.
To cancel and reset the program during the cycle, open the door, and touch Start/
Cancel for 3 seconds. Close the door and dishwasher will start a 60 second drain.
4.2 Wash Cycle Selections
PROGRAM BUTTONS Touch to select the program, corresponding indicator will be
lightened.
HEAVY This cycle is for hard-to-clean, heavily soiled dishes, pots, pans, and dishes.
NORMAL This is standard program. It is for regularly soiled dinner dishes or
silverware.
ECO It is suitable to clean normally soiled tableware and it is the most effcient
program in terms of it’s combined energy and water consumption for that type of
tableware.
GLASS For lightly soiled loads, such as glasses, crystal and fine china.
RAPID A shorter wash for lightly soiled loads that do not need drying.
RINSE Use for rinsing dishes, glasses and silverware that will not be washed right
away.
4.3 Delay
To delay the start of a selected cycle, press the Delay Start pad until the desired delay
time shows in the LED display. You can delay the start for 1 to 24 hours. To cancel the
delay start option before the delay period is over, press the Start/Cancel pad for 3-5
seconds.
4.4 Display Window
This displays the remained hours and minutes of the running cycle, delay hours and
error codes etc.
Start/Cancel
Wash Cycle Selections
Delay Display Window
Status Indicators
Options

8
4.5 Status Indicators
• Rinse Deterfent needs to be refilled.
• Program end.
• Water failure, faucet is not open.
4.6 Options
HEATING DRY When the “Heating Dry” function is selected, the heater will work
during the drying processs.
The Heating Dry option is not available with “Rinse” cycles.
SANITIZE When the”Sanitize”function is selected, the temperature of water will be
maintained at 69°C(156.2°F) max. The max temperature may not be reached if the
incoming water temperature is not correct. Certified residential dishwashers are not
intended for licensed food establishments.
The Sanitize option is available with “Heavy” “ Nomal” and “ECO” cycles.
HI TEMP When the “Hi Temp Wash” function is selected, the temperature of the water
will be maintained at 60°C (140°F) max.
The Hi Temp option is available with “Heavy” “Normal” “ECO” and “Glass” cycles.
ENERGY SAVE When the “Energy Save” function is selcted, energy consumption will
be reduced during washing process.
The Energy Save option is available with “Heavy” and “Normal” cyles.
4.7 Status Window
H:01-H:24 If the Delay Start option is selected, the number of delay start hours
shows in the Status Window.
2:15-0:00 After the machine works, the remaining time of the cycle that have been
selected will be showed in the Status Window.
4.8 Error Indication
In certain situations which are critical to the machines function and safe operation,
the control shall shut down and indicate an error code (See Error Codes on page 18).
If Error codes are displayed, contact the dealer or servicer. They will be able to provide
assistance in trouble shooting the problem and or locate an authorized service
technician if needed.
NOTE The remaining time could suddenly increase or drop several minutes. This
means the Smart Sensor has checked the soil level and determined if additional water
fills are needed or if water fills can be deleted.

9
Heavy Wash
Program Water (L)Cycle Description Cycle Time (min)
Glass
Normal Wash
Rapid
ECO
Rinse
Pre Wash
Main Wash (60°C)
Rinse(65°C)
Rinse (with Sani 69°C)
Drying
Pre Wash
Main Wash
19.7
15.5
9.5~18.5
12.5
15.5
6.7
155
95
105~135
60
105
20
Pre Wash
Main Wash (50-55°C)
Rinse(58-60°C)
Rinse (with Sani 69°C)
Drying
Pre Wash
Main Wash (50-55°C)
Rinse(58-60°C)
Rinse (with Sani 69°C)
Drying
Pre Wash
Main Wash (48-50°C)
Rinse(50-55°C)
Drying
Pre Wash
Main Wash (48-50°C)
Rinse(50-55°C)
4.9 Cycle Chart

10
5 USER MAINTENANCE
Keeping your dishwasher clean improves its performance, reduces unnecessary
repairs, and lengthens its life.
5.1 Cleaning the Exterior
It’s best to clean spills on the outside of your dishwasher as they occur. Use a soft,
damp cloth on the control panel to gently wipe away spills and dust. Do not use
benzene, wax, thinner, chlorine bleach, or alcohol. These materials may discolor the
inner walls and cause stains. Do not clean the dishwasher by sprinkling water over it
and avoid letting water come into contact with any of the electrical parts.
NOTE If your dishwasher has a stainless steel door panel, you can clean it with a
stainless steel cleaner for home appliances or a similar product using a clean, soft
cloth.
5.2 Cleaning the Interior
Clean the interior of your dishwasher periodically to remove any dirt or food particles.
Wipe the inside of the dishwasher and the inner part of the door with a wet dishcloth.
We recommend fi lling the detergent dispenser with dish detergent, and then running
the dishwasher empty periodically using either the Normal or Express 60 cycle with
the sanitize option. This will keep your dishwasher clean.
If white spots and odor are still present in your dishwasher, run the Normal cycle with
the dishwasher empty and without detergent until it fl ushes. Then, interrupt the cycle
and put an 8 ounce cup of white vinegar into the lower basket. Close the dishwasher
and let the cycle finish.
CAUTION Do not remove the tub front seal. (The long rubber seal enclosing
the opening of the dishwasher.)
Do not touch the heating element during or immediarely after use.
5.3 Cleaning the Filters
01 Turn off the dishwasher.

11
02 Rotate the filter insert counterclockwise to unfasten and detach the filter insert.
03 Remove the fine filter. (flat rectangle)
04 Remove any dirt or other remains from the filters, and then rinse them under
running water.
05 Reassemble the filters in the reverse order of the dissasembly, replace the filter
insert, and rotate clockwise to the close arrow.
CAUTION If the filter is not closed properly, its preformance will be decreased.

12
Cleaning the Nozzles
If your dishwasher does not seem to be cleaning adequately or the nozzles seem
clogged, you can clean each of the nozzles. When removing the nozzles, take care as
they may break.
Lower Nozzle
01 Check whether the nozzle holes are clogged by food particles.
02 If cleaning is needed, remove the nozzle by pulling it upwads.
03 Clean the nozzle, and then push it back into place.
04 Check whether the nozzle is engaged correctly by rotating it by hand.

13
6 TROUBLESHOOTING
Dishwasher won’t start
Dishwasher beeps at the
end of cycle
Rinse Aid light on
Dishwasher operates
too long
Dishes are
not clean enough
Dishes are
not drying enough
Possible CauseProblem Solution
Before Calling for Service
Door may not be closed properly
Power supply or power line is not
connected
Delay Start option has been
selected
Child Lock activated
The dishwasher is connected to
cold water
The cycle time will vary due to the
soil
The Sanitize option is selected
Water pressure is temporarily low
The inlet water is low
Dishes are loaded too close
together
Improper use of detergent
The selected cycle is not suitable
for food soil condition
Spray arms are blocked by items
Detergent dispenser is empty
Improper loading of dishes
The cycle you chose did not
include drying
Check the dishwasher, make sure
it is connected to the hot water
supply
When heavy soil is detected the
Auto, Normal, Heavy Wash cycle
will automatically increase the
cycle time
When Sanitize option is selected,
the cycle time will increase to meet
the sanitized temperature request
Use dishwasher when water
pressure is normal
Make sure dishwasher is
connected to hot water supply, try
not to use dishwasher when hot
water is being used elsewhere
Load dishes again as the manual
introduced
Add detergent depending on the
water hardness and the cycle
chosen, use fresh detergent
Choose another cycle for longer
washing time
Make sure the spray arm is rotated
fluently
Fill Rinse Aid Dispenser or increase
amount of Rinse Aid
Load the dishes again as indicated
Choose the proper cycle with
drying
It indicates the wash cycle finished,
the dishwasher will beep
The Rinse Aid level is low Add Rinse Aid
Shut the door completely, make
sure it is latched
Check and connect the power
supply, refer to this manual to reset
Deactivate the Child Lock, refer to
Child Lock section in this manual

14
Possible CauseProblem Solution
Spots and filming
on dishes
Etching
Detergent dispenser
will not shut
Dishwasher leaks
Dishwasher does not
drain properly
Stained tub interior
Detergent left in
dispenser cup
Water remains
in the dishwasher
Black or gray
marks on dishes
Suds in the tub
Water hardness is too high
Improper loading of dishes
Old or damp powder Rinse Aid
is used
Rinse Dispenser empty
Using too much detergent
The inlet water temperature
exceeds 150°F
Improper orientation of the
detergent cover
Excessive suds caused by using
improper detergent
Dishwasher is not level
Drain is clogged
Drain hose is bent
Coffee and tea soil
Reddish stain
Detergent may be too old
Spray arm is blocked
Previous cycle has not finished or
has been interrupted
Aluminum utensils have rubbed
against dishes
Improper detergent is used
For extremely hard water, install a
water softener
Load the dishes again as indicated
Use fresh Rinse Aid
Add Rinse Aid to the Dispenser
Use less detergent if you have soft
water etching
Lower the inlet water temperature
Add detergent and rinse aid as
indicated by this manual
Make sure to use only the
automatic dishwasher detergent
Level the dishwasher (see manual)
Check the air gap if you have
Make sure the disposer is empty if
the dishwasher is connected to the
disposer
Make sure the drain hose is
properly connected to the sink
Using a spot cleaner to remove the
soil
Some tomato based food will
cause this, use of the rinse only
cycle right after loading this will
decrease the staining
Use fresh detergent
Load the dishes making sure the
spray arms aren’t blocked
Select the proper cycle as
introduced by the manual
Choose a higher cycle
Make sure the inlet water is no less
than 120°F
Make sure to use only the
automatic dishwasher detergent

15
Possible CauseProblem Solution
Noises
Dishwasher won’t fill
Detergent cup opening/Drain
pump sound
A hard object has entered the wash
module. When the object is ground
up, the sound should stop
Water valve is turned off
Door latch may not be properly
sealed
This is normal
If the noise persists after a
complete cycle, call for service
Check if the water valve is
turned on
Make sure the door is closed
6.1 Error Codes
When some malfunctions come on, the appliance will display error codes to warn you:
MeaningsCodes Possible Causes
E1
E4
E9
E8
Longer inlet time
Overflow
Keep touching a button more than
30 seconds
Improper orientation of
distributary valve
Faucets are not opened, or water
intake is restricted, or water
pressure is too low
Some element of dishwasher leaks
Water or something on the button
Open circuit or break of
distributary valve
If overflow occurs, turn off the main water supply before calling service.
If there is water in the base pan because of an overfill or small leak, the water
should be removed before restarting the dishwasher.

16
Capacity
Dimension
Power Supply
Rated Power Usage
Water Feed Pressure
8 place settings
17.6” x 21.7” x 32.4” (W x D x H)
120 volts, 60Hz
Wash Motor 100W, Heater 700W
5.8 ~ 145 psi (0.04 ~ 1MPa)
7 TECHNICAL INFORMATION

If you want to return or replace the product, please contact the store where it was purchased (remember to
bring the purchase invoice). If your product needs repair, please contact us via email or phone.
©2022 BHRS Group, LLC. All Rights Reserved.
The Honeywell Trademark is used under license from
Honeywell International Inc. Honeywell International
Inc. makes no representations or warranties with respect
to this product. This product is manufactured by BHRS
Group, LLC.
MADE IN CHINA
BHRS Group, LLC
585 Prospect St.
Lakewood, NJ 08701
Customer Service Tel: [phone]
Customer Service Email: [email protected]
Website: honeywellcoolingappliances.com
