Honeywell H11MFB User manual

1.1 Cubic Feet Compact Freezer
User Manual
Read and save these instructions before use
H11MFB
H11MFS
H11MFW

CONTENTS
1Safety Warnings
1.1 Warning
1.2 Electricity related warnings
1.3 Related warnings for use
1.4 Warnings related to placing items
1.5 Warnings for energy
1.6 Warnings related to disposal
2Proper Use of Upright Freezer
2.1 Names of components
2.2 Temperature control
2.3 Placement
2.4 Start to use
2.5 Energy saving tips
2.6 Leveling feet
2.7 Reversing the door swing (optional)
3Maintenance of Upright Freezer
3.1 Cleaning
3.2 Defrost
3.3 Stop using
4Troubleshooting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
DEAR CUSTOMER:
Thank you for buying this upright freezer. To ensure that you get the best results from your new product,
please take the time to read through the instructions in this booklet. Please ensure that the packing material is
disposed of in accordance with the current environmental requirements. When disposing of any upright freezer
equipment, please contact your local waste disposal department for advice on safe disposal. This appliance
must be only used for its intended purpose.

1
1 SAFETY WARNINGS
This appliance is intended to be used in household, non-retail applications.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities unless they have been given permission by
a person responsible for their safety. Children should be supervised to ensure that
they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent, or similarly qualified persons in order to avoid a hazard.
The appliance has to be unplugged after use and before carrying out
user maintenance.
DO NOT store explosive substances such as aerosol cans in this appliance.
DO NOT use extension cords or ungrounded (two prong) adapters.
WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: Do not use electrical appliances inside the food storage compartments
of the appliance, unless they are the type recommended by the manufacturer.
WARNING: This freezer uses flammable blowing gas and refrigerant. Please
dispose of according to local regulators.
WARNING: When positioning the appliance, ensure the supply cord is not trapped
or damaged, and that it is positioned in accordance with the instructions.
WARNING: Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the appliance.
DANGER: Risk of child entrapment. Before disposing your old freezer:
• Take off the doors.
• Leave the shelves in place so that children may not easily climb inside.
The freezer must be disconnected from the source of electrical supply before
attempting the installation of accessory.
1.1 Warning
WARNING: risk of fire / flammable materials

2
Refrigerant and cyclopentane foaming material used for the appliance are
flammable. To prevent damage to the environment or any other harm, when the
appliance is scrapped, please keep away from any fire source.
For EN standard: This appliance can be used by children aged 8 years and above
and persons with reduced physical sensory or mental capabilities if they have been
given instruction concerning the use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision. Children aged 3 to 8
are allowed to load and unload refrigerating appliances.
To avoid contamination of food, please read the following:
• Opening the door for long periods can cause a significant increase of the
temperature in the compartments of the appliance.
• Regularly clean surfaces that can come in contact with food and accessible
drainage systems.
• Clean water tanks if they have not been used for 48 h; flush the water system
connected to a water supply if water has not been drawn for 5 days.
• Store raw meat and fish in suitable containers in the freezer to prevent it from
contacting or dripping onto other food.
• If the freezer is left empty for long periods, switch off, defrost, clean, dry, and leave
the door open to prevent mold from developing within the appliance.
This upright freezer is not intended to be used as a built-in appliance.

3
1.2 Electricity Related Warnings
• Do not pull the power cord when unplugging the upright freezer. Please
firmly grasp the plug and pull out it from the socket directly.
• Do not damage the power cord under any condition, do not use when the
power cord is damaged or the plug is worn.
• Replace worn or damaged power cord in manufacturer-authorized
maintenance stations.
• To prevent a fire, the power plug should be firmly contacted with the
socket. Please ensure that the grounding electrode of the power socket is
equipped with a reliable grounding line.
• In case of a gas leak, please turn off the valve of the leaking gas and then
open the doors and windows. Do not unplug the upright freezer and other
electrical appliances since that spark may cause a fire.
• To ensure safety, it is not recommended to place regulators, rice cookers,
microwave ovens and other appliances on the top of the upright freezer,
unless recommended by the manufacturer.
1.3 Related Warnings for Use
• Do not arbitrarily disassemble or reconstruct the upright freezer, nor
damage the refrigerant circuit. Maintenance of the appliance must be
conducted by a specialist.
• Damaged power cord must be replaced by the manufacturer, its
maintenance department, or related professionals in order to avoid danger.
• To prevent injury, do not to put your hand between the upright freezer doors
and body. Please be gentle when opening the door to avoid falling items.
• To avoid frostbite, do not handle food or containers, especially metal, with
wet hands in the freezing chamber when the upright freezer is running.
• Do not allow children to enter or climb the upright freezer to prevent
entrapment or injury.
• Do not spray, wash, or put the upright freezer in moist places or places
where it can be easily splashed with water to protect the electrical insulation
properties.
• Do not place heavy objects on the top of the appliance. Objects may fall
when opening the door, and may cause accidental injury.
• Please pull out the plug in case of power failure or cleaning. Do not connect
the upright freezer to power supply within five minutes to prevent damages
to the compressor due to successive starts.

4
1.4 Warnings Related to Placing Items
• Do not put flammable, explosive, volatile, and highly corrosive items in the
upright freezer to prevent damages to the product or fires.
• Do not place flammable items near the upright freezer to avoid fires.
• This product is household upright freezer and is suitable for the storage
of foods. According to national standards, household upright freezers
shall not be used for other purposes, such as storage of blood, drugs or
biological products.
• Do not place items such as bottled or sealed container of fluid such as
bottled beers and beverages in the upright freezer.
• Upright freezer might not operate consistently when sited for an extended
period of time below the range of temperatures that it is designed to
withstand.
• Do not exceed the storage time recommended by the food manufacturers
for any kind of food and commercially quick-frozen food in upright freezer.
• A rise in temperature of the frozen food during maintenance or cleaning
could shorten the storage life.
1.5 Warnings for Energy

5
1.6 Warnings Related to Disposal
The upright freezer’s refrigerant and cyclopentane foam materials are
combustible materials. Discarded upright freezers should be isolated from fire
sources and can not be burned. Please transfer the upright freezer to qualified
professional recycling companies for processing to avoid damages to the
environment or other hazards.
Please remove the door of the upright freezer and shelves to prevent children
from entering and playing in the upright freezer.
Correct Disposal of this product:
This marking indicates that this product should not be disposed with other
household wastes. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer where
the product was purchased. Contact the retailer as many will take them back
for recycling.

6
2 PROPER USE OF UPRIGHT FREEZER
2.1 Names of Components
2.2 Temperature Control
(The picture above is only for reference. The actual configuration will depend on the
physical product or statement by the distributor.)
• The markings on control knob indicate the “MIN, NORMAL, MAX and OFF”
for the different temperature level.
“MIN.” is the warmest setting;
”MAX.” is the coldest setting;
For normal use, please set the control knob to “NORMAL” position.
Recommended gear: ”NORMAL”
• The low temperature of upright freezer may keep food fresh for a long time
and it is mainly used to store frozen foods and to make ice.
• The upright freezer is suitable for storage of meat, fish, shrimp, pastries
and other foods not to be consumed in short term.
• Chunks of meat are preferably to be divided into small pieces for easy
access. Please be noted food shall be consumed within the shelf time.
Shelf
Adjustable foot
Thermostat knob
N
O
R
M
A
L

7
2.3 Placement
2.4 Start to Use
2.5 Energy Saving Tips
• Before using the upright freezer, remove all packaging materials including
bottom cushions, foam pads and tape inside, tear off the protective film on
the door and the upright freezer body.
• The upright freezer should be placed in a well-ventilated indoor place on
ground that is flat and sturdy.
• Keep away from heat and avoid direct sunlight. Do not place the upright
freezer in moist or watery places to prevent rust or reduction of insulation.
• Please leave at least 30 cm of space above the upright freezer, and 10 cm
from both sides and backside to facilitate heat dissipation.
• The freezer must stand upright for half an hour before connecting power
when it is first started.
• Run the upright freezer for 2 to 3 hours, or 4+ hours in the summer, before
loading fresh or frozen food.
• The appliance should be located in the coolest area of the room, away from
heat producing appliances or heating ducts, and out of the direct sunlight.
• Let hot foods cool to room temperature before placing in the appliance.
Overloading the appliance forces the compressor to run longer. Food that
freeze too slowly may lose quality, or spoil.
• Be sure to wrap food properly, and wipe containers dry before placing them
in the appliance to cut down frost build-up inside the appliance.
• Do not line storage bin with aluminum foil, wax paper, or paper towels.
Liners interfere with cold air circulation, making the appliance less efficient.
• Organize and label food to reduce door openings and extended searches.
Remove as many items as needed at one time, and close the door as soon
as possible.

8
2.6 Leveling Feet
2.7 Reversing the Door Swing (optional)
Schematic diagram of the leveling feet
(The picture above is only for reference. The actual configuration will depend on the
physical product or statement by the distributor.)
Adjusting procedures:
a. Turn the feet clockwise to raise the upright freezer;
b. Turn the feet counterclockwise to lower the upright freezer;
c. Adjust the right and left feet based on the procedures above to a horizontal level.
01 Remove all food from door shelves. Fix the door with tape.
List of tools to be provided by the user
Phillips head screwdriver
Flat head screwdriver
Masking tape

9
04 Dismantle the lower hinge assembly and adjustable leg;
Lower hinge assembly
Adjustable leg
03 Remove the door;
02 Dismantle hole caps, the upper hinge cover, fitting screws of upper hinge, and remove
the upper hinge. Please keep the door vertical to prevent it from falling;
Hole cap
Upper hinge
Upper hinge cover

10
05 Install the lower hinge and adjustable leg on lower left side of cabinet and lower right
side respectively;
06 Put the door on lower hinge vertically, then install the upper hinge by fitting screws
and the hinge cover. Cover the hole caps on upper right side.
Lower hinge
Adjustable leg

11
3 MAINTENANCE OF UPRIGHT FREEZER
3.1 Cleaning
3.2 Defrost
3.3 Stop Using
• Clean dust behind the upright freezer and on the ground to improve the cooling effect
and energy saving.
• Check the door gasket regularly to make sure there is no debris. Clean the door gasket
with a soft cloth dampened with soapy water or diluted detergent.
• Clean the interior of the upright freezer regularly to avoid odor.
• Please turn off the power before cleaning interior, remove all food, shelves, drawers, etc.
• Use a soft cloth or sponge to clean the inside of the upright freezer, with two tablespoons
of baking soda and a quart of warm water. Then rinse with water and wipe clean. After
cleaning, open the door and let it dry naturally before turning on the power.
• For areas that are difficult to clean (such as narrow gaps or corners), it is recommended
to wipe them regularly with a soft rag, soft brush, etc. to ensure no contaminants or
bacteria accumulate in these areas.
• Do not use soap, detergent, scrub powder, spray cleaner, etc., as these may cause odors in
the interior of the upright freezer or contaminate food.
• Clean the bottle frame, shelves and drawers with a soft cloth dampened with soapy water
or diluted detergent. Dry with a soft cloth or dry naturally.
• Wipe the outer surface of the upright freezer with a soft cloth dampened with soapy
water, detergent, etc., and then wipe dry.
• Do not use hard brushes, clean steel balls, wire brushes, abrasives (such as toothpastes),
organic solvents (such as alcohol, acetone, banana oil, etc.), boiling water, acid or alkaline
items, which may damage the cooler surface and interior. Boiling water and organic
solvents such as benzene may deform or damage plastic parts.
• Do not rinse directly with water or other liquids during cleaning to avoid short circuits or
damage to the electrical insulation.
• Manually defrost the upright freezer. Disconnect the plug from the wall socket, open the
door and remove all the food to a cool place. It is recommended to remove the frost by a
plastic scraper, or let the temperature rise naturally until the frost melts. Then wipe away
the remaining ice and water, and plug in the freezer.
Power failure: Food can usually be preserved for a couple of hours in case of power failure. It
is recommended to reduce the frequency of opening the door and to not put fresh food into
the upright freezer.
Long-time nonuse: Please unplug unused upright freezer for cleaning. Keep the door open to
avoid odor.
Moving: Do not turn upside or shake the upright freezer, the carrying angle can not be
greater than 45°.
Do not hold the door and hinge when moving this unit.
Please unplug the upright freezer for defrost and cleaning.
Do not use other mechanical devices or other means to accelerate the
defrosting process except those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Continuous operation is recommended when the upright freezer is
started. To prevent affecting the upright freezer’s service life, please do
not stop the upright freezer under normal circumstances.

12
4 TROUBLESHOOTING
Inoperation
Odor
Long-term operation
of compressor
The upright freezer
door can not be
properly closed
Loud noises
Transient difficulty
in door opening
Upright freezer
enclosure heat
condensation
Airflow sound
Buzz
Clatter
Ensure the upright freezer is plugged in and connected
to power
Check that the voltage is not low
The temperature control knob is not set to “OFF”
Thoroughly clean the interior of the upright freezer.
Do not overload the upright freezer
Do not put hot contents in the freezer
Note that it is normal that the upright freezer
operates for a longer time in summer when the
ambient temperature is higher
Check for any items blocking the upright freezer
door or unbalanced placement of items.
Ensure that the freezer is sitting on a flat and
stable surface
Ensure that the upright freezer accessories are
properly placed
Pressure differences between the inside and
outside of the upright freezer may result in
transient difficulty in door opening.
The upright freezer enclosure may emit heat during
operation, especially in summer, caused by the
radiation of the condenser; this is normal.
Condensation may be detected on the exterior surface
and door seals of the upright freezer when humidity is
high; this is normal.
The compresser may cause a buzzing sound when
starting up or shutting down.
The solenoid valve or electric switch valve may create
a clattering sound which is normal and does not
affect the operation.

13

If you want to return or replace the product, please contact the store where it was purchased (remember to
bring the purchase invoice). If your product needs repair, please contact us via email or phone.
©2021 BHRS Group, LLC. All Rights Reserved.
The Honeywell Trademark is used under license from
Honeywell International Inc. Honeywell International
Inc. makes no representations or warranties with respect
to this product. This product is manufactured by BHRS
Group, LLC.
MADE IN CHINA
BHRS Group, LLC
585 Prospect St.
Lakewood, NJ 08701
Customer Service Tel: [phone]
Customer Service Email: [e-mail]
Website: honeywellcoolingappliances.com
