Hongcheng stagelighting ELP-12*18W-6in1-WDMX User manual

9*12w 6in1 battery wireless par
User manual
P le ase rea d t he ins t r u ction s ca refu ll y before use

2
TABLE OF CONTENTS
1. S af ety I nst r uctions ..................................................................................................... 2
2. Technical Specifications ...........................................................................................4
3. How To Control The Unit ......................................................................................... 5
4. Remind ..................................................................................................................... 10
statement
The product has well capability and intact packing when leave
factory. All of the user should comply with warning item and manual, any
misuse cause of the damages are not included in our guarantee, and
also can not be responsible for any malfunction & problem owing to
ignore the manual.
1. S af ety I nst r uctions
Please keep this User Guide for future consultation. If you sell the unit to another
user, be sure that they also receive this instruction booklet.
Unpack and check carefully there is no transportation damage before using
the unit.
Before operating, ensure that the voltage and frequency of power
supply match the power requirements of the unit.
It’s important to ground the yellow/green conductor to earth in order
to avoid electric shock.
The unit must be installed in a location with adequate ventilation, at

3
least 50cm from adjacent surfaces. Be sure that no ventilation slots are
blocked.
Disconnect main power before replacement or servicing.
Make sure there are no flammable materials close to the unit while operating as
it is fire hazard.
Use safety cable when fixes this unit. DO NOT handle the unit by taking its head
only, but always by taking its base.
Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the
temperature is higher than this Unit surface temperature may reach up to 85℃.
DO NOT touch the housing bare-hand during its operation. Turn off the power
and allow about 15 minutes for the unit to cool down before replacing or serving.
In the event of serious operating problem, stop using the unit
immediately.Never try to repair the unit by yourself. Repairs carried out by
unskilled people can lead to damage or malfunction. Please contact the
nearest authorized technical assistance center. Always use the same type
spare parts.
DO NOT touch any wire during operation as high voltage might be causing
electric shock.
Warning:
Please set one light only as master when used Master-slave model in the same
channel.
DO NOT set any light as master when used DMX hold model.
To prevent or reduce the risk of electrical shock or fire, do not expose the unit to
moisture.

4
DO NOT open the unit within five minutes after switching off.
The housing, the lenses, or the ultraviolet filter must be replaced
if they are visibly damaged.
Caution:
There are no user serviceable parts inside the unit. DO NOT open the housing
or attempt any repairs yourself. In the unlikely event your unit may require
service, please contact your nearest dealer.
Installation:
The unit should be mounted via its screw holes on the bracket. Always ensure that
the unit is firmly fixed to avoid vibration and slipping while operating.
And make sure that the structure to which you are attaching the unit is secure
and is able to support a weight of 10 times of the unit’s weight. Also always use a
safety cable that can hold 12 times of the weight of the unit when installing the
fixture.
The equipment must be fixed by professionals. And it must be fixed at a place
where is out of the touch of people.
2. Technical Specifications
Light Sources:9pcs 6in1 RGBWA+UV LED
Beam Angle: 15°/25°
Power Voltage: AC 100-240V, 50/60Hz
Net Weight: 5Kgs
Control
DMX Channel: 7/11 Channel
Control Modes: DMX and wireless,IR Remote controller

5
Construction
Display: OLED Display
Data In/Out socket: IP65 3-pin XLR sockets
Power Socket: IP65 Powercon in/out
Protection Rating: IP65
Features
* OLED display
* Powercon in/Out
* Option for change LED Power (Eco, Medium, High power)
* Battery Charging Information and Wireless Channel change in Display
* Emergency Mode (enable / disable)
* DMX hold （on/off）in display
3. How To Control The Unit
Th e D M X512 is w id ely used in intellig ent ligh ti ng co n tr ol,with a DMX 512
controller.connect several lights together,dmx in and dmx out,
3 p in XLR co nn ectors : Pin 1: G ND , Pin 2: Nega tive s ig n a l (-), Pin 3: P o s itive s i gna l
(+)
Display:
MENU To select the programming functions
DOWN To go backward in the selected functions
UP To go forward in the selected functions
ENTER To confirm the selected functions

6
Set DMX Address Code
1 Press "Menu" to "Set DMX Address",and press"ENTER" keys to enter
into
2 Show "Set DMX Address DMX Address:001",Press the "UP and DOWN"
keys to amended
3 Press "ENTER"keys to save and Exit,Press the"MENU"Keys does not
save and Exit.
Turn on operation:
When in charging or turn off, press "MENU" for more than 4s,then screen will
display clients' logo and model of products,
there are "MENU","UP"."DOWN" for your selection to choose the function,pres
s" ENTER" to confirmed and enter the next menu,press "MENU" could back
to the last menu.
When turn on , press" MENU" for more than 4s,the screen will display " Power
Off",and will close LED output by then.
If charger connect with electricity,the screen will display charging icon and
percentage of battery power. Or will be turn off directly,and the battery
powered will be totally cut off.
Charging :
Please be fully charged for first use,it will take 4 hours,but would be good
for Battery,when charging show 100%,and also please keep charging for
another 1 hour,so total 5 hours.

7
MENU
Choose Pattern
Static Color
Macro Color
Show Mode
User Colors
User Run
RGBWAP (0-255) Strobe( 0-20)
001-016
AUTO / FADE / SNAP / STRO(RGBA)
RGBWAP ( 000-255) Bank : 1/16
1. Static Color
2. Auto Mode
User setting
Channel
DMX512 Address
Slave Mode
7CH / 11CH
001-512
System setting
White balance
Show Battery
Display sleep
Dimmer option
Auto power
IRC setting
RF 2.4 setting
RF 2.4 FREQ
Power Setting
Emergency Lamp
DMX Hold
RGBWAP ( 0-255)
Yes / No?
Open / 5Sec / 10Sec / 15Sec
Normal - lowest
Off / On
Yes/No
Yes/No
1CH-7CH
High / Medium / Low
Yes / No
Yes / No
Information
Led Temp:
Work Hours:
Software Version
Hardware version
Logo
30℃-70℃
000H-999H
V.1.06

8
Some tips for the lights:
1. About “user colors”
16 banks of colors for your setting ( single color or mixed colors),ENTER
button to choose the color,UP and DOWN button for save.then you can find
you setting at “ user run ”
2. Master-Slave model
When using Master-Slave model,apart from the first one as Master without
setting,the others need to set as Slave.
3. DMX512 control model
When using DMX512 controller,all the lights need to set as DMX model.
4. How to turn on the light?
A - when set "Auto power no", press "menu button" 3-5 seconds,will turn on
the display.
B - when set "Auto power yes", it will turn on automatically when power
cable plugged, disconnect the power cable will turn off.
5. How to check power information, please set "battery show " to yes, then

9
two ways.
A - when light on, you can see the info on the upper right corner of the
display.
B - when light off, press the menu button lightly,will show it in display
6.IRC Setting
Yes and No for option,when choose yes,the light can work with IR Remote
controller.
7. RF2.4 Setting
Yes and No for option,when choose yes,that’s wireless DMX function on.
8. RF 2.4 FREQ
7 wireless channels for option.
9. How to set wireless DMX
There is status lamp on transmitter,it have 7 colors,corresponding to 7
wireless dmx channels in the par light.
CH1 >> RED,
CH2 >> GREEN,
CH3 >> RED+GREEN,

10
CH4 >> BLUE,
CH5 >> RED+BLUE
CH6 >> BLUE+GREEN
CH7 >> RED+BLUE+GREEN
10. About " Emergency Lamp " function,
when set Emergency Lamp on,also light works with power cable connection.
If power cable is interrupted,leds will turn on white light. This feature suit to
special scenes
11. DMX Hold function
Yes and No for option,when choose yes,will keep the last status.

11
DMX channel´s functions and values (7/11 DMX channels):
7CH
No.
DMX512 Value
Function
1
0~255
Red dimmer
2
0~255
Green dimmer
3
0~255
Blue dimmer
4
0~255
White dimmer
5
0~255
Amber dimmer
6
0~255
UV dimmer
7
0~19
Normal model
20~39
Dimmer curve （slow )
40~59
Dimmer curve （slower )
60~255
Dimmer curve （slowest )
11CH
No.
DMX512 Value
Function
1
0~255
Total dimmer for CH11 (0~11)
2
0~9
Strobe off
10~255
Strobe：10 lowest，255 fastest
3
0~255
Red，the max depend on total dimmer
4
0~255
Green，the max depend on total dimmer
5
0~255
Blue，the max depend on total dimmer
6
0~255
White，the max depend on total dimmer
7
0~255
Amber, the max depend on total dimmer
8
0~255
UV, the max depend on total dimmer
9
0~9
Dimmer model

12
10~29
Color choose ：CH10
30~49
Jump variable effect ：CH10 control the speed
50~69
gradual variable effect ：CH10 control the speed
70~89
mutation effect：CH10 control the speed
90~109
Red + strobe:CH10 control the speed
110~129
Green + strobe:CH10 control the speed
130~149
Blue + strobe:CH10 control the speed
150~169
Total strobe: CH10 control the speed
170~209
Sounds control the jump variable effect
210~229
Sounds control the jump variable effect + gradual
variable effect
230~255
Sounds control the strobe
10
0~255
This channel’s function are depending on the value
of CH9：
When CH9 is 10~29 ，then the function is colors
choose.
When CH9 is 30~189 ，then the function is speed
control: 0 is the lowest,255 is the fastest.
11
0~19
Normal model
20~39
Dimmer curve （slow )
40~59
Dimmer curve （slower )
60~255
Dimmer curve （slowest )
4.Remind
It need to charge a times for each two months,and 50% battery power at
least, if for a long time without using.
