Hongqi E-HS9 User manual

Foreword
Thank you for choosing Hongqi E-HS9!
Hongqi E-HS9 is equipped with a variety of luxurious equipment and designed with
advanced technologies. To enable you to make full use of these equipment and
technologies in future driving, it is recommended that you read this manual carefully so that
you can quickly and comprehensively get familiar with Hongqi E-HS9.
In addition to how to use the vehicle, this manual also details safe driving, vehicle service
and emergency measures. By knowing those contents, you will be able to use the vehicle
safely and comfortably, while keeping the value of the vehicle to the greatest extent.
This manual is developed based on the status of the product at the time of publication.
Subsequent changes to the product will be revised at the time of reprinting. Note that there
will not be any prior notification about the revised contents, please understand.
If you have other questions about the vehicle or think that the contents of the attached
documents are not exhaustive, please consult the authorized FAW Hongqi dealer. We will
serve you wholeheartedly!
The latest version of the User Manual can be viewed or downloaded through the official
website of FAW Hongqi. Before you start to use the vehicle, it is recommended that you
read the Manual carefully.
Official website: https://www.hongqi-auto.com/
Address of EU representative: China FAW Group Import & Export Co., Ltd. Deutschland
Eschersheimer Landstraße 14 60322 Frankfurt am Main
Wish you have a good drive and all the best! FAW

1
Picture index
Search by illustration
1
Safety
precautions
Be sure to read the safety instructions thoroughly
2
Instrument
cluster
Read instrument information, various alarm lamps and
indicators, etc.
3
Operating the
components
Open and close doors and windows, adjust before driving,
etc.
4
Driving
Necessary operations and suggestions when driving
5
Multimedia
System
Operate the multimedia system
6
In-car equipment
Use in-car equipment, etc.
7
Service and
maintenance
Vehicle service and maintenance steps
8
In case of failure
Countermeasures in case of failure or emergency
9
Vehicle
specifications
Details of vehicle specifications
Other information
List the abbreviations and other information contained in this
manual
Contents

Contents
Index
2
1
Safety precautions
1-1. Instructions for safety operation
Safe driving...........................................20
Seat belt................................................21
Airbag ...................................................27
Child safety information.........................38
Child restraint system............................39
Installing a child restraint system ..........42
High voltage safety ...............................45
1-2. Charging/discharging
Methods and steps of
charging/discharging.............................47
Display and settings of
charging/discharging.............................54
Troubleshooting in charging/
discharging ...........................................58
1-3. Immobilizer system
Shutdown system..................................60
Body immobilizer system ......................61
2
Instrument cluster
2. Instrument cluster
Instrument cluster .................................64
Alarm lamp............................................66
Indicator................................................68
Instrument cluster multi-function display
information............................................70
3
Operating the components
3-1. Key information
Key.......................................................80
3-2. Opening, closing and locking the
doors and trunk lid
Door......................................................83
Trunk lid................................................87
Passive entry and passive start (PEPS)
system..................................................91
3-3. Adjusting the seat
Front seat .............................................96
Rear seat..............................................99
Headrest.............................................102
Seat memory......................................104
3-4. Adjusting the steering wheel and
rearview mirrors
Steering wheel....................................106
Anti-glare rearview mirror....................108
Exterior rearview mirror.......................109
3-5. Opening and closing windows
Power window ....................................112
Panoramic sunroof..............................114

3
4
Driving
4-1. Before driving
Driving the vehicle...............................118
Cargo and luggage .............................124
4-2. Driving rules
Power (ignition) switch........................125
Shift control.........................................127
Driving mode.......................................131
Air suspension *..................................135
Turn signal lamp control handle..........139
Electric parking brake (EPB)...............140
AUTO HOLD.......................................142
4-3. Operating lights and wipers
Headlamp ON/OFF.............................143
Adaptive driving beam (ADB) *............145
Fog lamp switch..................................147
Front windshield wiper and washer.....148
Rear windshield wiper and washer......151
4-4. Charging port cover
Open charging port cover....................152
4-5. Operating other driving systems
Adaptive cruise control (ACC) * ..........154
Super adaptive cruise control
(SACC)*..............................................161
Front and rear parking sensor
(PSS) *................................................168
AVM system .......................................173
Tire pressure management system
(TPMS)...............................................178
LDW/LKA............................................180
Front collision warning (FCW) system 183
Autonomous emergency braking
(AEB)..................................................186
Blind spot detection (BSD) system......189
TSR system*.......................................194
Auto parking assist (APA)...................196
Driver assist system (DAS).................203
4-6. Driving information
Driving essentials in winter .................206
Refer to the Annex for trailer traction

Contents
Index
4
5
Multimedia System
5-1. Basic operation
Multimedia display ..............................210
USB data interface..............................214
5-2. Operating the multimedia system
Vehicle................................................216
Travel..................................................228
Entertainment......................................242
5-3. Operating the on-board Bluetooth
phone
Hands-free system..............................245
Bluetooth® phone...............................248
5-4. Operating the voice recognition
Voice recognition ................................252
5-5. Operating Mobile APP
Hongqi Zhilian APP.............................254
6
In-car equipment
6-1. Operating the air-conditioning (A/C)
system
Fully automatic A/C system.................258
Fully automatic A/C system —front
control system.....................................259
Fully automatic A/C system —second-
row control system..............................267
Third-row A/C control system..............273
Heat rear windshield...........................277
6-2. Operating the interior lights
List of interior lights.............................278
6-3. Operating storage box
List of storage boxes...........................281
Trunk device.......................................287
6-4. Other in-car equipment
On-board wireless charging system....288
Sun visor.............................................289
File folder............................................290
Make-up mirror ...................................291
Power socket......................................292
220V power outlet...............................294
Seat temperature controller *..............296
Seat massage function*......................298
Rear center armrest * .........................299
Ceiling handle.....................................300
Coat hook...........................................301
7
Service and maintenance
7-1. Service and maintenance
Cleaning and protecting vehicle
exteriors..............................................304
Cleaning and protecting vehicle
interiors...............................................306
7-2. Maintenance
Maintenance instructions.................... 308

5
7-3. Self-maintenance
Precautions for self-maintenance........310
Hood...................................................312
Engine compartment...........................313
Tire .....................................................321
Tire pressure.......................................324
Wheel..................................................326
A/C filter..............................................327
Replacing the key battery....................329
Checking and replacing the fuse.........331
Power battery......................................335
8
In case of failure
8-1. Important information
Hazard warning lamp..........................340
SOS alarm..........................................341
8-2. Measures to be taken in case of
emergency
If the vehicle needs to be towed..........342
If the vehicle is found to be abnormal..346
If the alarm lamp lights up or the alarm
speaker sounds...................................347
If a tire leaks .......................................352
In case of power system failure to
starter..................................................354
If the key is lost...................................355
In case of key failure to work normally 356
If the door can not be locked properly.358
In case of low 12 V battery..................360
If the vehicle is overheated.................363
In case of an electrical fire..................365
If a trap occurs....................................366
If driving on waterlogged roads...........367
In the event of a flat tire ......................368
In the event of an accident..................369
Emergency opening of trunk lid ..........370
9
Vehicle specifications
9-1. Specification
Service data........................................372
Other information
List of abbreviations .............................386

6
Picture index
Exterior
Hood
Towing eye cover
Low beam
Corner lamp
Windshield wiper
Sunroof
Exterior
rearview mirror
Side turn
signal lamp
Front turn
signal lamp
High beam
Daytime running
lamp
Position lamp
Towing eye cover

7
Rear position
lamp
High mounted
brake lamp
Charging port
cover
Door
Tire
⚫Rotation
⚫Tire pressure
Reversing lamp
Stop lamp
Rear fog lamp
Rear turn
signal lamp
License plate
lamp
Trunk lid
Trunk lid switch

8
Picture index
Interior
Glove box
Cup holder
Front passenger airbag
Front central storage box
Seat belt
Curtain airbag
Headrest
Driver airbag
Front seat
Rear seat

9
Central control door
lock switch
Interior door release
handle
Rear door child safety lock
switch
Power window
switch

10
Picture index
Interior
Sunroof switch
Interior lamp
button
Sunshade switch
Rear reading lamp switch
Ceiling handle
Bluetooth
microphone
SOS switch
Make-up
mirror
Sun visor
Front reading lamp
switch
Anti-glare rearview
mirror

11
Picture index
Instrument panel
Light control handle
Headlamp
Turn signal lamp
Fog lamp
Instrument cluster display
Wiper control handle
Multimedia display
Front A/C operation
panel
Steering wheel
electric adjustment
button
Cruise control handle
Adaptive cruise control
SACC

12
Picture index
Instrument panel
Electronic Parking
Brake switch
Shift lever handle
Shift unlock button
P button
Glove box opening
button

13
Instrument cluster display
operation buttons
Voice recognition button
Phone button
Volume adjustment/mute
button
Track/station switch button
Multi-function
button
Driving mode
selection button
Menu button

14
Reference information
Instructions for User Manual
The user must have a driving license to drive the vehicle on the road. This User Manual is
specially written for such users.
In this manual, "*" means that the configurations and functions may vary from model to
model, and are only provided in certain models. Please refer to the actual vehicle for
specific equipment information.
The pictures in this manual are only for illustration, which can help you understand the
vehicle more intuitively. They may be slightly different from the pictures of your vehicle.
Please refer to the actual vehicle during driving.
All specifications provided in this Manual are up-to-date until it is delivered for printing.
However, in view of continuous modification and improvement of vehicles made by FAW,
the equipment and performance of subsequent models will be changed. Therefore, the
contents of this Manual will be updated at any time without further notice. Please do not
compare the contents of other versions of the User Manual with the equipment and
performance of the vehicle you purchased, and put forward the requirements for
supplementary equipment based on the differences between the two. If you have any
questions about the purchased vehicle and the User Manual, please consult the authorized
FAW Hongqi dealer.
Accessories, spare parts and modification of vehicles
The authorized FAW Hongqi dealer has the advanced tools, equipment and pure spare
parts required to provide maintenance and service for your vehicle. We strongly recommend
that you use FAW genuine spare parts and accessories that meet the requirements of this
vehicle.
For any non FAW genuine spare parts and accessories, whether used for replacement or
installation, FAW does not assume any responsibility or provide any guarantee. In addition,
vehicle damage and performance problems caused by the use of non FAW genuine spare
parts or accessories are not included in the scope of warranty.
It is not allowed to use products not authorized by FAW to refit the vehicle, otherwise the
controllability, safety and durability of the vehicle will be affected, and even the local
government regulations may be violated. Additionally, any problems caused by modification
are not included in the scope of warranty.
Reading vehicle identification number (VIN)
Use the scan tool to connect the vehicle OBD port, and read the VIN when reading HCU
information. The reading tools can be purchased from the market, and they shall conform to
the standards of ISO14229, ISO15765, ISO15031 and ISO11898.

15
Installation of RF transmitter system
The installation of RF transmitter system on the vehicle may affect the electronic systems,
such as:
⚫Anti-lock Braking System (ABS)
⚫Cruise Control System (CCS)
⚫Supplemental Restraint System (SRS)
⚫Seat belt pretensioner system
Before installing the RF transmitter system, please consult the authorized FAW Hongqi
dealer.
Scrapping of vehicles
The airbags and seat belt pretensioners in vehicles contain explosive chemicals. If the
vehicle is scrapped without removing the airbags and seat belt pretensioners, it may cause
personal injury, fire and other accidents. Before scrapping a vehicle, please contact a
qualified enterprise or organization to remove and dispose of the airbags and seat belt
pretensioners. The authorized FAW Hongqi dealer has an intimate knowledge of the
relevant laws and regulations and can provide consulting services for you.
Event data recorder
The vehicle is equipped with event data recorder (EDR). The main function of EDR is to
record data in the case of some collision or near collision (such as airbag deployment or
road obstacles impact), so as to help understand the operation of vehicle system. EDR is
specifically used to record data related to vehicle dynamic control and safety systems in a
short period of time. However, the data may not be recorded depending on the severity and
type of collision.
Data recorded by EDR of the vehicle, such as:
⚫Safety belt status of driver and vehicle occupant
⚫The extent to which the driver steps on the brake and accelerator pedals
⚫Working status of vehicle related systems
⚫Vehicle speed
These data can help to better understand the situation in case of collision and personal
injury.
Note: EDR data will only be recorded when a certain degree of collision occurs; During
normal driving, EDR does not record data and does not record personal data (such as
name, gender, age and crash location). In order to read the data recorded by EDR, it is
necessary to use the special equipment of vehicle manufacturer and access the vehicle
EDR. In addition to vehicle manufacturers, third parties with special equipment (such as law
enforcement departments) can also read information if they have access to vehicles or
EDR.

16
Based on the statutory obligation of product monitoring, the company can use the data for
environmental monitoring, research purposes and quality improvement of vehicle safety
system. For the purpose of research needs, the company may provide anonymous data to
relevant parties, that is, the data does not involve personal vehicle, owner or lessee
information.
Model code
This Manual describes models E-HS9E01, E-HS9E02 and E-HS9E03.
WARINING
◼Driving precautions
Drivers must drive soberly, carefully and attentively.
⚫Sober driving: Do not drive after drinking or taking medicine. Alcohol or some drugs will
delay reaction time, affect judgment and coordination ability, which may lead to serious
injury or even death.
⚫Careful driving: Be careful when driving. Pay attention to the movement of other vehicles
and pedestrians at any time, so as to make timely judgment and prevent accidents.
⚫Attentive driving: Be sure to concentrate on driving. Anything that distracts the driver,
such as adjusting the control buttons, making a call or reading, may lead to a collision
accident and cause serious injury or even death.
◼Precautions for children's safety
⚫Do not leave children alone in the vehicle.
⚫Do not allow children to carry or use the key. Children may start the vehicle or operate the
shift lever, which may cause safety hazards.
⚫Do not allow children to play with the doors, windows or other vehicle equipment, as this
may injure them.
⚫Make sure that the temperature in the car is appropriate. If the temperature is too high or
too low, it may cause fatal injury to children.

17
Reading this Manual
WARINING
Introduce the warnings. Failure to comply may result in serious injury or even death.
Notice
Introduce the precautions. Failure to comply may result in damage or failure of the vehicle.
Represents the operating or operation steps, which are carried out in numerical
order.
Indicates the action (push, turn, press,
etc.) used to operate switches and
other devices.
Indicates the result of the operation
(e.g. lid open).
Means "Do not," "Do not do this" or
"Don't let that happen.".

18
