hopf Elektronik GmbH 8030HEPTA/GPS User manual

_____________________________________________________________
Technical Manual
GPS - NTP Time Server with
2x 10/100/1000 MBit LAN Interface
Model 8030HEPTA/GPS
ENGLISH
Version: 04.00 - 12.04.2018
_____________________________________________________________
SET
IMAGE (8030)
FIRMWARE (8024)
Valid for
Version: 04.xx
Version: 04.xx
Version: 03.xx
Industriefunkuhren

8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 2 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]

INPORTANT NOTES
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 3 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
Version number (Firmware / Manual)
THE FIRST TWO DIGITS OF THE VERSION NUMBER OF THE TECHNICAL MANUAL AND
THE FIRST TWO DIGITS OF THE FIRMWARE VERSION MUST COMPLY WITH EACH OTHER.
THEY INDICATE THE FUNCTIONAL CORRELATION BETWEEN DEVICE AND TECHNICAL
MANUAL.
THE DIGITS AFTER THE POINT IN THE VERSION NUMBER INDICATE CORRECTIONS IN THE
FIRMWARE /MANUAL THAT ARE OF NO SIGNIFICANCE FOR THE FUNCTION.
Downloading Technical Manuals
All current manuals of our products are available free of charge via our homepage on the
Internet.
Homepage: http://www.hopf.com
E-mail: [email protected]om
Symbols and Characters
Operational Reliability
Disregard may cause damages to persons or material.
Functionality
Disregard may impact function of system/device.
Information
Notes and Information.

INPORTANT NOTES
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 4 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
Safety regulations
The safety regulations and observance of the technical data serve to
ensure trouble-free operation of the device and protection of persons and
material. It is therefore of utmost importance to observe and compliance
with these regulations.
If these are not complied with, then no claims may be made under the
terms of the warranty. No liability will be assumed for any ensuing
damage.
Safety of the device
This device has been manufactured in accordance with the latest
technological standards and approved safety regulations
The device should only be put into operation by trained and qualified staff.
Care must be taken that all cable connections are laid and fixed in position
correctly. The device should only be operated with the voltage supply
indicated on the identification label.
The device should only be operated by qualified staff or employees who
have received specific instruction.
If a device must be opened for repair, this should only be carried out by
employees with appropriate qualifications or by hopf Elektronik GmbH.
Before a device is opened or a fuse is changed all power supplies must
be disconnected.
If there are reasons to believe that the operational safety can no longer
be guaranteed the device must be taken out of service and labelled
accordingly.
The safety may be impaired when the device does not operate properly
or if it is obviously damaged.
CE-Conformity
This device fulfils the requirements of the EU directive 2014/30/EU
"Electromagnetic Compatibility" and 2014/35/EU "Low Voltage Equipment".
Therefore the device bears the CE identification marking
(CE = Communautés Européennes = European communities)
The CE indicates to the controlling bodies that the product complies with the requirements of
the EU directive - especially with regard to protection of health and safety for the operator and
the user - and may be released for sale within the common markets.

TABLE OF CONTENTS
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 5 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
Contents Page
1GPS - NTP Time Server 8030HEPTA/GPS ...................................................................9
2System Structure........................................................................................................12
2.1 19 inch Rack 1U/84HP (Slim Line) ..........................................................................13
2.2 Functional Overview of the Front Panel Elements ...................................................13
2.2.1 LCD-Display with Pushbutton ............................................................................................ 13
2.2.2 Status-LEDs –System (& Extension)................................................................................ 14
2.2.3 Reset-(Default) Button ....................................................................................................... 15
2.2.4 Status LEDs (TS/Error/Operation) ..................................................................................... 15
2.2.5 USB-Port (Host) ................................................................................................................. 15
2.2.6 LAN Interface ETH0/ETH1................................................................................................. 16
2.2.6.1 MAC-Address for ETH0/ETH1.................................................................................................... 16
2.2.7 Sync Status Optical Coupler.............................................................................................. 17
2.2.8 Sync Status LEDs.............................................................................................................. 17
2.2.9 GPS Antenna Input............................................................................................................ 17
2.2.10 Extension Modules 1 –6 (Option)...................................................................................... 17
3Function Principle.......................................................................................................18
3.1 Block Diagram.........................................................................................................18
3.2 Function 8030HEPTA (WebGUI: Device)................................................................19
3.3 Function 8024GPS (WebGUI: Sync Source) ...........................................................19
3.4 LCD-Display with Pushbutton..................................................................................19
3.5 System EXTENSION 1 - 8 (Option).........................................................................20
4System Behaviour.......................................................................................................21
4.1 Boot Phase..............................................................................................................21
4.2 NTP Adjustment Process (NTP/Stratum/Accuracy) .................................................21
4.3 Reset-(Default) Button.............................................................................................21
4.4 Firmware Update.....................................................................................................22
4.4.1 Firmware Update 8030HEPTA (WebGUI: Device)............................................................ 22
4.4.2 Firmware Update 8024GPS (WebGUI: Sync Source)....................................................... 23
4.5 Activation of Functions (Activation Key)...................................................................24
5Installation...................................................................................................................25
5.1 System 8030HEPTA/GPS in 1U Slim Line Housing.................................................25
5.1.1 Installation of the 19 Inch Rack.......................................................................................... 25
5.1.2 Earthing.............................................................................................................................. 25
5.1.3 AC Power Supply............................................................................................................... 25
5.1.3.1 Safety and Warning Instructions................................................................................................. 26
5.1.3.2 Power Supply Unit Specifications ............................................................................................... 26
5.1.3.3 Fusing......................................................................................................................................... 26
5.1.4 DC Power Supply (Option)................................................................................................. 27
5.1.4.1 Power Supply Unit Specifications............................................................................................... 27
5.1.4.2 Fusing......................................................................................................................................... 27
5.1.4.3 Reverse Voltage Protection........................................................................................................ 27
5.2 Connection GPS Antenna System...........................................................................28

TABLE OF CONTENTS
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 6 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
5.3 Connection LAN Interface ETH0/ETH1....................................................................28
5.4 Connection Sync Status Optical Coupler.................................................................28
6Commissioning...........................................................................................................29
6.1 General Procedure..................................................................................................29
6.2 Switching the Operating Voltage on.........................................................................30
6.3 LCD-Display after Switch On / Reset (Boot Phase) .................................................30
6.4 Establish the Network Connection via Web Browser ...............................................31
6.5 Network Configuration for ETH0 via LAN through hmc software............................31
7LCD-Display with Pushbutton –Function.................................................................35
7.1 Pushbutton Function (Light / Scroll).........................................................................35
7.2 Standard Display Image..........................................................................................35
7.2.1 Standard Display Image without valid Time....................................................................... 35
7.2.2 Standard Display Image with valid Time............................................................................ 36
7.2.3 Standard Display with Additional Information .................................................................... 37
7.3 GENERAL ERROR .................................................................................................37
7.4 LAN Parameter........................................................................................................38
7.5 Local Time Parameter.............................................................................................39
7.6 GPS Satellite Display ..............................................................................................40
7.7 Position ...................................................................................................................40
7.8 Receiver Status.......................................................................................................40
7.9 Sync Source ERROR..............................................................................................41
7.10 Announcements (Summertime / Leap Second) .......................................................41
7.11 System-Info.............................................................................................................42
8HTTP/HTTPS WebGUI –Web Browser Configuration Interface...............................43
8.1 Quick Configuration.................................................................................................43
8.1.1 Requirements..................................................................................................................... 43
8.1.2 Configuration Steps............................................................................................................ 43
8.2 General –Introduction.............................................................................................44
8.2.1 LOGIN and LOGOUT as User ........................................................................................... 45
8.2.2 Navigation via the Web Interface....................................................................................... 46
8.2.3 Enter or Changing Data ..................................................................................................... 47
8.2.3.1 Changing of Data in 8030HEPTA (WebGUI: Device) ................................................................. 47
8.2.3.2 Changing of Data in 8024GPS (WebGUI: GPS Sync Source).................................................... 48
8.2.4 Plausibility Check during Input........................................................................................... 49
8.3 Description of the Tabs............................................................................................50
8.3.1 GENERAL Tab................................................................................................................... 50
8.3.2 NETWORK Tab.................................................................................................................. 52
8.3.2.1 Host/Name Service..................................................................................................................... 52
8.3.2.2 Network Interface ETH0/ETH1 ................................................................................................... 54
8.3.2.3 Network Interface Bonding/Teaming (Activation Key necessary) ............................................... 59
8.3.2.4 Network Interface PRP (Activation Key necessary).................................................................... 64
8.3.2.5 Routing (Activation Key necessary)............................................................................................ 67

TABLE OF CONTENTS
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 7 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
8.3.2.6 Routing File................................................................................................................................. 68
8.3.2.7 Management (Management-Protocols –HTTP, SNMP, SNMP-Traps, etc.)............................... 69
8.3.2.8 Time (Time Protocols –NTP, DAYTIME etc.)............................................................................. 72
8.3.3 NTP Tab............................................................................................................................. 74
8.3.3.1 System Info................................................................................................................................. 75
8.3.3.2 Kernel Info .................................................................................................................................. 75
8.3.3.3 Peers .......................................................................................................................................... 76
8.3.3.4 Server Configuration................................................................................................................... 77
8.3.3.5 Extended NTP Configuration...................................................................................................... 80
8.3.3.6 Restart NTP................................................................................................................................ 82
8.3.3.7 Configuring the NTP Access Restrictions................................................................................... 83
8.3.3.8 Symmetric Key............................................................................................................................ 87
8.3.3.9 Autokey....................................................................................................................................... 88
8.3.4 PTP Tab............................................................................................................................. 90
8.3.4.1 PTP Configuration ...................................................................................................................... 90
8.3.4.2 PTP IEEE C37.238 Power Profile Settings................................................................................. 91
8.3.4.3 PTP Advanced Settings.............................................................................................................. 92
8.3.4.4 PTP Leap Second File................................................................................................................ 93
8.3.5 ALARM Tab (Activation Key necessary)............................................................................ 95
8.3.5.1 Syslog Configuration................................................................................................................... 95
8.3.5.2 E-mail Configuration ................................................................................................................... 96
8.3.5.3 SNMP Configuration / TRAP Configuration ................................................................................ 97
8.3.5.4 Alarm Messages......................................................................................................................... 98
8.3.6 DEVICE Tab....................................................................................................................... 99
8.3.6.1 Device Information...................................................................................................................... 99
8.3.6.2 Hardware Information ................................................................................................................. 99
8.3.6.3 Restoring the Factory Defaults Settings ................................................................................... 100
8.3.6.4 Restarting the Module (Reboot Device / Hardware Reset)....................................................... 101
8.3.6.5 Image Update & H8 Firmware Update...................................................................................... 102
8.3.6.6 Upload SSL-Server-Certificate.................................................................................................. 104
8.3.6.7 Customized Security Banner .................................................................................................... 104
8.3.6.8 Product Activation..................................................................................................................... 105
8.3.6.9 Diagnostics Function ................................................................................................................ 106
8.3.6.10 Passwords (Master/Device)...................................................................................................... 106
8.3.6.11 Downloading Configuration Files / SNMP MIB.......................................................................... 107
8.3.7 GPS SYNC SOURCE Tab............................................................................................... 108
8.3.7.1 Time and Status........................................................................................................................ 109
8.3.7.2 Set Sync Source Time.............................................................................................................. 110
8.3.7.3 Time Zone Offset...................................................................................................................... 111
8.3.7.4 Daylight Saving Time (DST) ..................................................................................................... 112
8.3.7.5 Reception Quality ..................................................................................................................... 113
8.3.7.6 Reception Mode........................................................................................................................ 114
8.3.7.7 Receiver Position...................................................................................................................... 115
8.3.7.8 SyncON / SyncOFF Timer........................................................................................................ 116
8.3.7.9 Module Info............................................................................................................................... 117
8.3.7.10 Module Reset............................................................................................................................ 117
8.3.7.11 Factory Default ......................................................................................................................... 118
8.3.7.12 H8 Firmware Update (Sync Source)......................................................................................... 119
8.3.7.13 Sync Source Errors................................................................................................................... 121
8.3.7.14 Sync Status OC........................................................................................................................ 123
8.3.8OUTPUT Tab................................................................................................................... 124
8.3.8.1 PPS (Optional Hardware necessary)........................................................................................ 124
8.3.8.2 DCF77 (Optional Hardware necessary).................................................................................... 126
8.3.8.3 IRIG-B (Optional Hardware necessary) .................................................................................... 128
8.3.8.4 Cyclic Pulse (Optional Hardware necessary)............................................................................ 130
8.3.8.5 Serial Interface (Optional Hardware necessary) ....................................................................... 133
9SSH and Telnet Basic Configuration.......................................................................149
10 Fault Analysis / Troubleshooting.............................................................................150

TABLE OF CONTENTS
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 8 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
10.1 Error Patterns........................................................................................................150
10.1.1 Complete Failure.............................................................................................................. 150
10.1.2 No GPS Reception / No Synchronization ........................................................................ 150
10.1.3 No Daylight Saving Time / Summer Time Switchover..................................................... 152
10.2 Support by Company hopf ...................................................................................152
11 Maintenance..............................................................................................................153
11.1 General Guidelines for Cleaning............................................................................153
11.2 Cleaning the Housing............................................................................................153
11.3 Cleaning the Display and Front Panel....................................................................153
12 Technical Data ..........................................................................................................154
12.1 General –8030HEPTA/GPS .................................................................................154
12.2 Module 8030HEPTA..............................................................................................156
12.3 Module 8024GPS..................................................................................................158
13 Factory Defaults of Time Server 8030HEPTA/GPS.................................................159
13.1 Factory Default Values of Module 8030HEPTA (Device).......................................159
13.1.1 Network............................................................................................................................ 159
13.1.2 NTP.................................................................................................................................. 160
13.1.3 PTP .................................................................................................................................. 161
13.1.4 ALARM............................................................................................................................. 161
13.1.5 DEVICE............................................................................................................................ 162
13.2 Factory Default Values of Module 8024GPS (Sync Source)..................................162
14 Glossary and Abbreviations ....................................................................................163
14.1 NTP-specific Terminology......................................................................................163
14.2 Tally Codes (NTP-specific)....................................................................................163
14.2.1 Time-Specific Expressions............................................................................................... 164
14.3 Abbreviations.........................................................................................................165
14.4 Definitions .............................................................................................................166
14.4.1 DHCP (Dynamic Host Configuration Protocol) ................................................................ 166
14.4.2 NTP (Network Time Protocol).......................................................................................... 166
14.4.3 SNMP (Simple Network Management Protocol).............................................................. 167
14.4.4 TCP/IP (Transmission Control Protocol / Internet Protocol) ............................................ 167
14.4.5 PTP (Precision Time Protocol)......................................................................................... 167
14.5 Accuracy & NTP Basic Principles..........................................................................168
15 List of RFCs...............................................................................................................170
16 List of Open Source Packages Used.......................................................................171

GPS -NTP TIME SERVER 8030HEPTA/GPS
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 9 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
1 GPS - NTP Time Server 8030HEPTA/GPS
By GPS time synchronization and the worldwide used time protocol NTP (Network Time Pro-
tocol) the Time Server 8030HEPTA/GPS turns into a highly accurate NTP Stratum 1 Time
Server. It is used for the synchronization of computers and industrial networks.
The Time Server supports the following synchronization protocols:
•NTP (incl. SNTP)
•Daytime
•Time
•SINEC H1 time datagram (Activation Key necessary)
•IEEE 1588 Precision Time Protocol (PTP) (Activation Key necessary)
Front Side
Rear Side
The Time Server 8030HEPTA/GPS is integrated into a 1U/84HP 19" rack and characterized
by its easy and simple operation. Some of these practice-oriented functionalities are e.g.:
•Complete parameterisation via protected WebGUI access
All required settings for operation can be executed via a password protected WebGUI
also giving an overview of the status of the Time Server 8030HEPTA/GPS.
•LCD-Display and Status-LEDs in the front panel
The LCD-Display and the Status-LEDs make rapidly and easily substantial information
for commissioning, on the operating status and for support matters available if a prob-
lem occurs, even without WebGUI access.
•Monitoring of GPS antenna circuit
An error message is generated when there is a short circuit in the GPS antenna circuit
or an open antenna input.
•Automatic switch-over of summer/winter time (initial setting required)
After initial commissioning there is no user intervention for a correct summer/winter
time changeover for the following years required.
•Automatic handling of the leap second
Should a leap second be inserted in the UTC time, it is recognized by the Time Server
8030HEPTA/GPS via the GPS signal and the leap second is automatically inserted in
the time information.
•Customized extensions possible
The new designed housing concept allows customized system extensions for addi-
tional signal outputs (processed ex-works) easily and fast.

GPS -NTP TIME SERVER 8030HEPTA/GPS
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 10 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
A superior security is guaranteed via available coding procedures such as symmetric keys,
autokey and access restrictions and deactivation of non-used protocols.
Different Management and Monitoring Functions are available as options (e.g. SNMP,
SNMP-Traps, E-mail notification, Syslog-messages including MIB II and private Enterprise
MIB).
The Time Server 8030HEPTA/GPS currently has unlockable features that are described in
chapter 4.5 Activation of Functions (Activation Key):
•SINEC H1 time datagram
•Static Routing Table
•Alarming and management features
•Network Interface Bonding/Teaming
•IEC 62439-3 Parallel Redundancy Protocol (PRP)
•IEEE 802.1Q Tagged VLAN
•IEEE 1588 Precision Time Protocol (PTP)
A few other basic functions of the Time Server 8030HEPTA/GPS:
•The Time Server 8030HEPTA/GPS operates as NTP Server with Stratum 1
•Easy operation via WebGUI
•LCD-Display (2x40) and Status LEDs on the front panel
•Sync status output via optical coupler
•High freewheel accuracy provided by GPS-supported regulation of the internal
quartz basis
•Completely maintenance-free system
•SyncOFF Timer (reception failure bypassing) for operation free of fault messages
even based on difficult reception conditions
•Redundant multiple validation of the synchronization signal for an error-free and leap
free signal evaluation
•Maintenance-free, buffered backup clock for at least three days
Software supplied:
• hmc ( hopf Management Console) Software

GPS -NTP TIME SERVER 8030HEPTA/GPS
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 11 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
Overview of the functions of the network Time Server 8030HEPTA/GPS:
Two Ethernet Interfaces
•Auto negotiate
•10 Mbps half-/full duplex
•100 Mbps half-/full duplex
•1 Gbps full duplex
Time Protocols
•RFC-5905 NTPv4 Server
oNTP Broadcast Mode
oNTP Multicast Mode
oNTP Client for additional NTP Servers (redundancy)
oSNTP Server
oNTP Symmetric Key Encryption
oNTP Autokey Encryption
oNTP Access Restrictions
•SINEC H1 time datagram (Activation Key necessary)
•RFC-867 DAYTIME Server
•RFC-868 TIME Server
•Precision Time Protocol (PTP) according to IEEE Std 1588™-2008 (Activation Key
necessary)
oIEEE Standard Profile for Use of IEEE 1588™ Precision Time Protocol
in Power System Applications (Power Profile) according
to IEEE Std C37.238™-2011
Network Configuration (Activation Key necessary)
•Routing
•Bonding (NIC Teaming) Link aggregation according to IEEE 802.1ad
•VLAN support according to IEEE 802.1q
•PRP (Parallel Redundancy Protocol) according to IEC62439-3
System Management (Activation Key necessary)
•E-mail notification
•Syslog messages to external syslog server
•SNMPv2c/v3, SNMP Traps (MIB II, Private Enterprise MIB)
Configuration Channel
•HTTP/HTTPS WebGUI (browser-based)
•Telnet
•SSH
•External LAN configuration tool ( hmc –Network-Configuration-Assistant)
Additional Features
•Firmware Update via TCP/IP
•Fail-safe
•Watchdog circuit
•Customizable security banner
•NTP local time support

SYSTEM STRUCTURE
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 12 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
2 System Structure
The system 8030HEPTA/GPS consists of the following:
•1/1 19" module rack 1U/84HP (Slim Line)
•System front panel with LCD-Display (2x40), pushbutton and status LEDs
System front view:
•Wide-ranging power supply unit from 100-240V AC / 20VA (Standard)
or 40VA (47-63Hz). Other input voltages available
•Voltage feed with power switch with connections in accordance with
IEC/EN60320/C14 including EMI line filter
•Connection for protection earth (PE) cables up to 16mm²
•Module 8030HEPTA
•Module 8024GPS
•Space for up to 8 additional output modules depending on system structure
System rear side:
The new designed housing concept allows customized system extensions for additional signal
outputs (processed ex-works) easily and fast.

SYSTEM STRUCTURE
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 13 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
2.1 19 inch Rack 1U/84HP (Slim Line)
2.2 Functional Overview of the Front Panel Elements
This chapter describes the individual function elements of the front and rear panel.
2.2.1 LCD-Display with Pushbutton
The background illumination of the LCD-Display is activated or rather controlled by the
pushbutton Light/Scroll.
The 2x40 LCD-Display enables reading out the time and further essential information for the
commissioning, the operation status, and for support even without WebGUI access.
The operation and function of the pushbutton and the display are described in Chapter 7 LCD-
Display with Pushbutton –Function.

SYSTEM STRUCTURE
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 14 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
2.2.2 Status-LEDs –System (& Extension)
The Status LEDs on the front panel indicate the current synchronization and operation status
of the System 8030HEPTA/GPS. Meanings of the LEDs are the following:
During the boot process, all LEDs are flashing in a test sequence.
System - Sync
Status LEDs
Green
Red
Sync-Status
Status Code
ON
Off
Sync (radio-synchronous) with quartz regulation
SYNC
Flashes
Off
Sync (radio-synchronous) - SyncOFF timer running
SYOF
ON
Flashes
Sync (radio-synchronous) - simulation mode
SYSI
Flashes
Flashes
Quarz - SyncON timer running
QUON
ON
ON
Quarz - time was set via synchronization source
QUEX
Flashes
ON
Quarz - time set manually or after reset
QUSE
Off
ON
No valid time
INVA
Off
Off
No operating voltage / faulty
---
System - NTP
Status LEDs
NTP-Status
Green
Red
NTP Service
STRATUM
ACCURACY
Off
On
Not Active
---
Low
Flashes 1Hz 50%
On
Active
16
Low
Flashes 1Hz 10%
Flashes 1Hz 50%
Active
2-15
Low
Flashes 1Hz 50%
Flashes 1Hz 50%
Active
2-15
Medium
On
Flashes 1Hz 50%
Active
2-15
High
Flashes 1Hz 10%
Off
Active
1
Low
Flashes 1Hz 50%
Off
Active
1
Medium
On
Off
Active
1
High

SYSTEM STRUCTURE
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 15 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
2.2.3 Reset-(Default) Button
The Reset-(Default) Button is accessible with a thin object
through the small drilling in the front panel next to the "Reset" in-
scription" (see Chapter 4.3 Reset-(Default) Button).
2.2.4 Status LEDs (TS/Error/Operation)
TS-LED
(Green)
Time service of the Time Server
8030HEPTA/GPS
On
Standard, running
Off
Not or partially not running
ERROR-LED
(Red)
Description
Off
Standard case,
system 8030HEPTA/GPS is working.
3Hz flashing
Fail-safe basic parameterization is not
available (emergency operation mode)
On
Primary CPU of system 8030HEPTA/GPS
does not show any activity.
Operation-LED
(Green)
Description
On
Standard case,
system 8030HEPTA/GPS is working
1Hz flashing
System 8030HEPTA/GPS is booting the
operating system.
3Hz flashing
A firmware update (image) of system
8030HEPTA/GPS is being executed.
Off
System 8030HEPTA/GPS is not ready for
operation.
2.2.5 USB-Port (Host)
On specific problems the USB connection can be used for a sys-
tem recovery after consulting the hopf Support.

SYSTEM STRUCTURE
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 16 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
2.2.6 LAN Interface ETH0/ETH1
LNK LED (Green)
Description
Off
10 MBit Ethernet detected
On
100 MBit / 1 GBit Ethernet detected
SPD LED (Yellow)
Description
Off
No LAN connection to a network
On
LAN connection available
Flashes
Network activity at ETH0 (transmission
/ reception)
Pin No.
Assignment
1
TX_DA+
2
TX_DA-
3
RX_DB+
4
BI_DC+
5
BI_DC-
6
RX_DB-
7
BI_DD+
8
BI_DD-
2.2.6.1 MAC-Address for ETH0/ETH1
Each LAN interface is clearly identifiable on the Ethernet via a unique MAC Address (hardware
address).
The MAC addresses given for the LAN interfaces can be read in WebGUI of the appropriate
board or be evaluated via the hmc Network Configuration Assistant.
The MAC address for ETH1 is incremented hexadecimal by 1 to the MAC address of ETH0.
Example:
•MAC address ETH0 = 00:03:C7:12:34:59
•MAC address ETH1 = 00:03:C7:12:34:5A
The MAC address is uniquely assigned for each LAN interface by the company hopf El-
ektronik GmbH.
hopf Elektronik GmbH MAC addresses begin with 00:03:C7:xx:xx:xx.

SYSTEM STRUCTURE
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 17 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
2.2.7 Sync Status Optical Coupler
Sync Status Optical Coupler
3-pole pluggable Connector
Pin
Signal
1
Collector
2
n.c.
3
Emitter
2.2.8 Sync Status LEDs
Sync Status LEDs
LED
Meaning
RD
Status LED red
GN
Status LED green
The Status LEDs on the front panel signal the current (synchronization) status of the Sync
Source (here Module 8024GPS). The meanings of the LEDs are as follows:
LED RD
Red
LED GN
Green
Status
STATUS
Code
Off
ON
Sync (radio-synchronous) with quartz regulation
SYNC
Off
Flashes
Sync (radio-synchronous) - SyncOFF timer running
SYOF
Flashes
ON
Sync (radio-synchronous) - simulation mode
SYSI
Flashes
Flashes
Quarz - SyncON timer running
QUON
ON
ON
Quarz - time was set via synchronization source
QUEX
ON
Flashes
Quarz - time set manually or after reset
QUSE
ON
Off
No valid time
INVA
Off
Off
No operating voltage / faulty
---
3Hz
Off
General Module Error (PCID)
INVA
3Hz
Invert
3Hz
User settings missing
(Difference time / ST-WT Changeover)
INVA
2.2.9 GPS Antenna Input
GPS Antenna
BNC connector
GPS
Antenna input
The antenna input provides an internal monitoring for "short-circuit" and
"open input".
2.2.10 Extension Modules 1 –6 (Option)
All installed system extensions deviating from the standard system 8030HEPTA/GPS includ-
ing the pertinent Status LEDs are documented and described in a device-specific supplemen-
tary instruction.

FUNCTION PRINCIPLE
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 18 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
3 Function Principle
This chapter describes the function principle of the Time Server 8030HEPTA/GPS and the
internal relations between the different functional groups.
3.1 Block Diagram

FUNCTION PRINCIPLE
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 19 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
•Firmware Update
A H8 firmware update of the Sync Source (here Module 8024GPS) is completely con-
trolled by Module 8030HEPTA.
The update file for Module 8024GPS is loaded into Module 8030HEPTA via LAN
through the WebGUI. Then Module 8030HEPTA performs the update of the Sync
Source (here Module 8024GPS) independently.
•Management
The entire control of the Sync Source (here Module 8024GPS) is done by Module
8030HEPTA. All data of the Sync Source, indicated via WebGUI, are demanded cy-
clically by Module 8030HEPTA from the Sync Source or if necessary. These data are
then prepared for the display in WebGUI. After activation settings for the Sync Source
are transferred to the Sync Source immediately.
•High Precision Time
The Sync Source provides a high-precision time information and the according syn-
chronization status to Module 8030HEPTA. This time and status information is used
for synchronization of the time sync services and if applicable other signal generations
running on 8030HEPTA.
3.2 Function 8030HEPTA (WebGUI: Device)
The Module 8030HEPTA is the "heart" of the Time Server 8030HEPTA/GPS. A complete
LINUX operating system is running on this Module providing all functions such as NTP,
WebGUI etc. The Module also controls the connected Sync Source (here Module 8024GPS).
Using the high-precise time information of Module 8024GPS the NTP service and all further
time sync services running on Module 8030HEPTA is also adjusted with high-precision. Thus
the Module 8030HEPTA is a very precise NTP STRATUM 1 - Time Server.
3.3 Function 8024GPS (WebGUI: Sync Source)
The Module 8024GPS is in principle an independent Module with GPS receiver and its own
µProcessor. In synchronous status it provides a high-precise time information to the Module
8030HEPTA. The control of Module 8024GPS in this system is completely done via Module
8030HEPTA. Parameters required by Module 8024GPS or provided are entered into WebGUI
of Module 8030HEPTA or rather be output.
The Module 8024GPS has an own failsafe memory in which all required data for operation
after generation via WebGUI are stored.
As the data of the Sync Source for the WebGUI indication need to be received by the Module
8030HEPTA at first, it is no real-time indication in WebGUI.
3.4 LCD-Display with Pushbutton
System settings cannot be changed via the pushbutton nor the display. The display allows the
readout of important system and operation parameters directly at the device, even without
WebGUI access.
Update of the data in both the display and the WebGUI is subject to specific refreshing cycles.
The display indicates if the refreshing cycle is not completed yet.

FUNCTION PRINCIPLE
8030HEPTA/GPS GPS - NTP Time Server with 2x 10/100/1000 MBit LAN Interface - V04.00 20 / 178
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
3.5 System EXTENSION 1 - 8 (Option)
System 8030HEPTA/GPS can be expanded with additional modules ex works. Therefore four
extension slots are available.
Each extension slot can either be equipped with one NTP time server module 8030NTS/M
(each with two GigaBit LAN interfaces) or max. two output modules.
Additionally implemented NTP time server modules 8030NTS/M are mutually independent and
are going to be parameterized via their WebGUI. The operating status of each module
8030NTS/M will be displayed via 2 status LEDs on the front panel which are assigned to the
particular module 8030NTS/M via the related EXTENSION number. If the application is exclu-
sively equipped with modules 8030NTS/M, max. 4 mutually independent modules 8030NTS/M
can be implemented.
Output modules issue signals of the internal signal generators of module 8030HEPTA via var-
ious electrical levels or via fiber optic. Parameterization of the particular signal generator can
be done via WebGUI of module 8030HEPTA. Status of the output modules will not be moni-
tored via status LEDs on the front panel. If the clock system is exclusively equipped with output
modules, max. 8 output modules can be implemented.
System front view:
System rear side / plug-in side:
All installed system extensions deviating from the standard system 8030HEPTA/GPS includ-
ing the pertinent Status LEDs are documented and described in a device-specific supplemen-
tary instruction.
