hopf 4985LAN User manual

_____________________________________________________________
Technical Manual
Large Matrix Display 4985
with integrated LAN Interface
Model 4985LAN
ENGLISH
Version: 08.00 - 15.10.2018
_____________________________________________________________
Valid for Devices 4985LAN with FIRMWARE
Version: 08.xx
and REMOTE-SOFTWARE (HMC)
Version: 01.13
Industriefunkuhren

4985LAN Large Matrix Display 4985 - V08.00 2 / 84
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]

INPORTANT NOTES
4985LAN Large Matrix Display 4985 - V08.00 3 / 84
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
Version number (Firmware / Manual)
THE FIRST TWO DIGITS OF THE VERSION NUMBER OF THE TECHNICAL MANUAL AND
THE FIRST TWO DIGITS OF THE FIRMWARE VERSION MUST COMPLY WITH EACH OTHER.
THEY INDICATE THE FUNCTIONAL CORRELATION BETWEEN DEVICE AND TECHNICAL
MANUAL.
THE DIGITS AFTER THE POINT IN THE VERSION NUMBER INDICATE CORRECTIONS IN THE
FIRMWARE /MANUAL THAT ARE OF NO SIGNIFICANCE FOR THE FUNCTION.
Downloading Technical Manuals
All current manuals of our products are available free of charge via our homepage on the
Internet.
Homepage: http://www.hopf.com
E-mail: [email protected]om
Symbols and Characters
Operational Reliability
Disregard may cause damages to persons or material.
Functionality
Disregard may impact function of system/device.
Information
Notes and Information.

INPORTANT NOTES
4985LAN Large Matrix Display 4985 - V08.00 4 / 84
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: in[email protected]
Safety regulations
The safety regulations and observance of the technical data serve to
ensure trouble-free operation of the device and protection of persons and
material. It is therefore of utmost importance to observe and compliance
with these regulations.
If these are not complied with, then no claims may be made under the
terms of the warranty. No liability will be assumed for any ensuing
damage.
Safety of the device
This device has been manufactured in accordance with the latest
technological standards and approved safety regulations
The device should only be put into operation by trained and qualified staff.
Care must be taken that all cable connections are laid and fixed in position
correctly. The device should only be operated with the voltage supply
indicated on the identification label.
The device should only be operated by qualified staff or employees who
have received specific instruction.
If a device must be opened for repair, this should only be carried out by
employees with appropriate qualifications or by hopf Elektronik GmbH.
Before a device is opened or a fuse is changed all power supplies must
be disconnected.
If there are reasons to believe that the operational safety can no longer
be guaranteed the device must be taken out of service and labelled
accordingly.
The safety may be impaired when the device does not operate properly
or if it is obviously damaged.
CE-Conformity
This device fulfils the requirements of the EU directive 2014/30/EU
"Electromagnetic Compatibility" and 2014/35/EU "Low Voltage Equipment".
Therefore the device bears the CE identification marking
(CE = Communautés Européennes = European communities)
The CE indicates to the controlling bodies that the product complies with the requirements of
the EU directive - especially with regard to protection of health and safety for the operator and
the user - and may be released for sale within the common markets.
