Host HOST0731HD User manual

Heated Display
Merchandiser
Instruction manual
Model:
HOST0731HD
Read this instruction
manual carefully
before use
HOST0731HD_EN_A5_v1_20220817.indb 1HOST0731HD_EN_A5_v1_20220817.indb 1 2022/8/17 18:25:002022/8/17 18:25:00

2
Safety Instructions
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- BS EN Codes of practice
- Fire Precautions
- Wiring Regulations
- Building Regulations
• Warning! Hot surface! Always wear safety
gloves when placing or removing food.
• This product is only designed to store food temporarily. Do not
use for laboratory or industrial purposes.
• DO NOT use jet/pressure washers to clean the appliance.
• DO NOT use the appliance outside.
• DO NOT allow oil or fat to come into contact with the plastic
components or door seal. Clean immediately if contact occurs.
• DO NOT store products on top of the appliance.
• Always carry, store and handle the appliance in a vertical
position and move by holding the base of the appliance.
• Always switch off and disconnect the power supply to the
appliance when not in use.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
• If the power cord is damaged, it must be replaced by a
recommended qualified technician in order to avoid a hazard.
HOST0731HD_EN_A5_v1_20220817.indb 2HOST0731HD_EN_A5_v1_20220817.indb 2 2022/8/17 18:25:002022/8/17 18:25:00

3
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• HOST recommend that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection, Polarity
Test, Earth Continuity, Insulation Continuity and Functional
Testing.
• HOST recommend that this product is connected to a circuit
protected by an appropriate RCD (Residual Current Device).
Installation
• Remove all packaging and dispose of it safely.
• Wipe all surfaces with a clean, damp cloth before use.
• Position the Merchandiser on a level and stable surface, insert the shelves on to the shelf supports,
add water to the Water Tray if humidification is required, taking care not to overfill.
• There should be at least 100mm clearance on all sides, Do not place objects on top of the
Merchandiser at any time.
Operation
• Add water to the Water Tray if humidification is required, then place the Tray in position inside the
Merchandiser.
• Connect the Merchandiser to electricity by inserting the plug into a socket, turn on supply at socket.
• Turn switch at the rear of the Merchandiser to the on position, this will start the heating element.
• Rotate the knob at the rear of the Merchandiser to set the temperature.
• The Merchandiser is now ready for food to be displayed and kept warm.
Cleaning, Care & Maintenance
Always turn off and disconnect the appliance from the power supply before cleaning.
Always allow the appliance to cool before emptying or cleaning.
• Remove any food debris that is present in the Merchandiser after use.
• Clean the internal surfaces with a cloth that is damp with soapy water, or with a food safe cleaning
agent.
• Dry thoroughly after cleaning making sure that no moisture is left in the Merchandiser.
HOST0731HD_EN_A5_v1_20220817.indb 3HOST0731HD_EN_A5_v1_20220817.indb 3 2022/8/17 18:25:002022/8/17 18:25:00

4
Removable crumb tray
• Periodically empty the crumb tray (located at
the rear of the appliance).
• Slide the tray out to empty.
• Slot back in securely when replacing the tray.
Crumb tray
Troubleshooting
A qualified technician must carry out repairs if required.
Fault Probable Cause Solution
The appliance is
not working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug or lead is damaged Replace plug or lead
Fuse in the plug has blown Replace the fuse
Mains power supply fault Check mains power supply
Thermostat has failed Consult a qualified technician
Indicator Light
comes on but unit
does not heat up
Heating element has failed Consult a qualified technician
Thermostat has failed Consult a qualified technician
Service
Should your appliance have a fault, please visit the Service section of the HOST website.
Technical Specifications
Model Voltage Power Current Temperature
range
Dimensions
(H x W x D) (mm)
Weight
(kg)
HOST0731HD 220-240V~
50Hz 800W 3.5A 30°C-90°C 376 x 554 x 376 14.4
Due to our continuing program of research and development, the specifications herein are subject to
change without notice.
HOST0731HD_EN_A5_v1_20220817.indb 4HOST0731HD_EN_A5_v1_20220817.indb 4 2022/8/17 18:25:002022/8/17 18:25:00

5
Electrical Wiring
This appliance is supplied with a 3 pin BS1363 plug and lead.
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The WEEE logo on this product or its documentation indicates that the product must not
be disposed of as household waste. To help prevent possible harm to human health and/
or the environment, the product must be disposed of in an approved and environmentally
safe recycling process. For further information on how to dispose of this product correctly,
contact the product supplier, or the local authority responsible for waste disposal in your
area.
HOST parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic, mechanical,
photocopying, recording or otherwise, without the prior written permission of HOST.
Every effort is made to ensure all details are correct at the time of going to press, however, HOST reserve the right to change specifications
without notice.
HOST0731HD_EN_A5_v1_20220817.indb 5HOST0731HD_EN_A5_v1_20220817.indb 5 2022/8/17 18:25:002022/8/17 18:25:00

We {Host} of {Host House, Chepstow, NP16 6UP} hereby declare that the equipment is in conformity with the requirements of the
following Regulations:
Electrical Equipment (Safety) Regulations 2016
Electromagnetic Compatibility Regulations 2016
The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012
We hereby declare that:
Equipment Model number HOST0731HD - 45Ltr Countertop Heated Food Display
is in conformity with the applicable requirements of the following documents
Ref. No.
Edition/date
BS EN 60335-1
2012 + A11:2014 + A13:2017 + A1:2019 + A14:2019 + A2:2019 + A15:2021
BS EN 60335-2-49
2003 + A1:2008 + A11:2012 + A2:2019
BS EN 62233
2008
EN IEC 61000-6-3
2021
EN IEC 61000-6-1
2019
I hereby declare that the equipment named above has been designed to comply with the relevant sections of the above referenced
specifications and is in accordance with the requirements of the Regulations:
Signed by:
Full Name Jess Attree
Title: General Manager
Location: Chepstow, Great Britain
Date: 16th June 2022
UKCA Declaration of Conformity
DocuSign Envelope ID: DA4256D2-A1DE-4750-BC23-AF75CB542431
