RVM1625SJ – Hotpoint Counter Saver Plus™ Microwave Oven
Specification Created 1/04
440017
R
Listed by
Underwriters
Laboratories
Dimensions (in inches)
21-3/4"
Door open
16-13/32
66" MIN.
Mounting
height
from
floor
30"
MIN.
width
required
12"
MIN.
Exhaust outlet
connects to
3-1/4" X 10" duct
15-1/4
16
29-7/8
Important Information: When installing the Counter Saver Plus
microwave oven over a range, allow minimum of 2" from bottom of
Counter Saver Plus microwave oven to top of range backguard to allow for
removal of light covers.
Installation Information: This information is not intended to be used for
installing unit described. Before installing, consult installation instructions
packed with product/kit for current dimensional data.
When replacing a 36" range
hood, this kit fills in the
additional width to provide a
custom, built-in appearance. For
installation between cabinets only;
not for end-of-cabinet installation.
Each kit contains two, 3"-wide
filler panels.
JX81A–
Recirculating
Charcoal Filter Kit
To be used when the
Counter Saver Plus
microwave oven
cannot be vented to
the outside.
Optional Accessories (Available at additional cost)
JX48BL – Black Filler
Panel Kit
Ventilation Options: The Counter Saver Plus microwave oven is designed for adaptation for the
following three types of ventilation:
Outside Exhaust (Vertical)
Outside Exhaust (Horizontal)
Recirculating (Non-vented ductless–see Filter Kit Drawing)
Note: Before installing, consult installation instructions for current dimensional data on these
three types of ventilation.

®
Specification Created 1/04
440017
RVM1625SJ – Hotpoint Counter Saver Plus™ Microwave Oven
Features and Benefits
• 1.6 cu. ft. capacity – 1000 Watts (IEC-705 test procedure)
• Turntable – Continually rotates food to ensure even cooking
• Convenience cooking controls – Allows cooking and reheating at the touch of a button
• Auto/Time Defrost – Automatically defrosts for a specified amount of time
• Delay Start – Allows preprogramming of the oven start time, making it easy to
plan ahead
• 10 Power Levels – Offer maximum cooking flexibility, from warming and reheating,
to the full speed of microwave cooking at high power
• Timer on/off – Optional reminder signals when meals are done
• Model RVM1625SJ – Silver metallic
*IEC-705 Test Procedure
RVM1625SJ
Timer
On/Off
Defrost
Auto/Time
AM/PMClock
Time
Cook Popcorn Reheat
Reminder
display on/off
minute cook 1-6
guide behind door
scroll speed
Start
Delay
Start
Surface
Light
on-off
high-low-off
1 2 3
4 5 6
7 8 9
0
Clear
Off
Power
Level
Vent
Fan
