Hotpoint VISR309JT User manual

2
Important Safety Information
3
Operating Instructions
The Controls on Your Washer
Other Washer Features
Preparing to Wash
Care of Product
10
Helpful Information
Specialized Fabric Guide
11
If Something Goes Wrong
Washer
Owner’s Manual
Model: VISR309JT
175D1807P163
39-9350
7-96 CG
CPrinted in the United States
General Electric Company, Appliance Park, Louisville, KY 40225 USA

2
Water Heater Safety
Important Safety Information
Read all safety information before using
Under certain conditions
hydrogen gas may be produced
in a water heater that has not
been used for two weeks or more.
HYDROGEN GAS CAN BE
EXPLOSIVE UNDER THESE
CIRCUMSTANCES.
If the hot water has not been used
for two weeks or more, prevent
the possibility of damage or injury
by turning on all hot water taps
and allow them to run for several
minutes before using any electri-
cal appliance which is connected
to the hot water system. This will
allow any hydrogen gas to escape.
Since the gas is flammable, do
not smoke or use an open flame
or appliance during this process.
SAVE THESE INSTRUCTIONS

•Use this appliance only for its
intended purpose as described
in this Owner’s Manual.
— Properly ground to conform
with all governing codes and
ordinances. Follow details in
Installation Instructions.
— Install or store where it will not be
exposed to temperatures below
freezing or exposed to the weather.
•Do not repair or replace any
part of the appliance or attempt
any servicing unless specifically
recommended in this Owner’s
Manual or in published user-
repair instructions that you
understand and have the skills
to carry out.
•Do not tamper with the controls.
•Never reach into the washer
while it is moving.
•Close supervision is necessary
if this appliance is used by or
near children or infirm persons.
Do not allow children to play
inside, on or with this appliance
or any discarded appliance.
Dispose of discarded appliances
and shipping/packing materials
properly. Before discarding
a washer, or removing from
service, remove the washer lid.
•Do not wash or dry articles that
have been cleaned in, washed
in, soaked in, or spotted with
combustible or explosive
substances (such as wax, oil,
paint, gasoline, degreasers,
dry-cleaning solvents, kerosene,
etc.) which may ignite or
explode. Do not add these
substances to the wash water.
Do not use these substances
around your washer and/or
dryer during operation.
•To minimize the possibility
of electric shock, unplug this
appliance from the power supply
or disconnect the washer at the
household distribution panel by
removing the fuse or switching
off the circuit breaker before
attempting any maintenance
or cleaning.
•NOTE: Turning the Cycle
Selector knob to an off position
does NOT disconnect the
appliance from the power supply.
3
Warning
To reduce the risk of fire, electric shock, or injury to persons
when using your appliance, follow basic precautions, including
the following sections.
Safety Precautions

By selecting load size, you are setting the
water level. For the best results, select a size
appropriate for the load you are washing.
This refers to the speed of the agitator during
the wash and the basket during the spin.
With the Normal wash speed the agitator moves
faster. Use for cottons, denims and play clothes.
With the Gentle wash speed the agitator moves
slower. Use for delicate and knit items.
The Fast spin speed is for durable items.
The Slow spin speed is for delicate items like
sweaters and lingerie. Clothes will be less dry
than when using a fast spin speed.
Always follow Fabric Manufacturer’s Care
Label or instructions when laundering. Use
this chart as a general guide.
•Push in the Cycle knob to select the desired
cycle. See the above Cycle Descriptions.
•Add detergent.
•Add clothes and close lid.
•Pull out the Cycle knob to start washer.
5
Operating Instructions
The
controls
on your
washer
4
Cycle Descriptions
For information on fabric care for specialty
items see the Specialty Care Guide.

1 2 3 4
wash
temperature
hot
warm*
warm*
cold
warm*
rinse
temperature
cold
cold
cold
cold
warm*
21
Load Size Wash/Spin Speed
43
Wash/Rinse Temp Selecting Cycle/Starting Washer
COTTONS WHITE
COTTONS COLORS
PERMANENT PRESS
DELICATES
WASHABLES WOOLENS
See next page for other washer features
*Warm water is approximately 32°C. to 43°C. (90°F. to 110°F.) (hand comfortable).
REGULAR
For heavily to lightly
soiled cottons, linens,
work and play clothes.
PERM PRESS
For synthetics and
blends with normal soil.
KNITS
Specially designed for
normally soiled knits.
DELICATES
For lingerie and special-
care fabrics with light to
normal soil.
Wash/Rinse Temperature Guide
AUTO SOAK
For heavily soiled
clothes. Begins with a
brief agitation, soaks for
a specified period of
time, then moves
through the rest of the
cycle automatically.

6
Operating Instructions
Other washer features your model may have
This dispenser dilutes liquid
chlorine bleach before it reaches
into your wash load. To use, follow
these steps:
1 Check clothing care labels for
special instructions.
2 Measure liquid bleach carefully,
following instructions on bottle.
3 Before starting the washer, pour
measured amount of bleach
directly into bleach dispenser.
Avoid
splashing or over-filling
dispenser.
NOTE:
• Never pour undiluted liquid chlorine
bleach directly onto clothes or into
the wash basket.
• Do not pour powdered bleach
into bleach dispenser. If you prefer
to use powdered bleach, pour it
into the wash basket with your
detergent.
Liquid Bleach
Dispenser
Pour liquid bleach into bleach
dispenser
This cap fits into the top of the agita-
tor. If it accidentally comes off, sim-
ply put it back on.
Agitator Cap
Do not pour anything into the
agitator if the top is removed
When you use extra detergent
or bleach to clean heavily soiled
clothes, you may want to use the
Extra Rinse option. This option
provides a second deep cold rinse
in the Cottons Regular cycle. Turn
the Extra Rinse knob to SET.
The washer will pause for a few
minutes before the Extra Rinse
option begins.
Extra Rinse
OFF SET

This dispenser automatically releas-
es liquid fabric softener at the prop-
er time during the cycle. To use,
follow these steps:
1 Make sure dispenser is securely
attached to agitator.
2 Pour liquid fabric softener
into dispenser, using amount
recommended on package.
3 Add water to dispenser until it
reaches the maximum fill line.
NOTE:
• Do not stop the washer during
the first spin. This will cause
the dispenser to empty too soon.
• Do not use the Fabric Softener
Dispenser with the Auto Soak.
• Never pour fabric softener directly
on clothes. It will leave spots on
clothes.
• Only use dispenser for liquid fabric
softeners. If dispenser gets clogged,
see Cleaning section below.
Do not pour anything into the
agitator if the top is removed
Fabric Softener
Dispenser
1 Remove the dispenser from the
top of the agitator.
2 Separate the dispenser cup from
the cover by grasping the top and
pushing down on the inside of the
cup with your fingers. Dispenser
cup will pop free from the cover.
3 To clean dispenser, soak both the
dispenser cup and the dispenser
cover in a solution of warm water
and liquid detergent.
4 If necessary, loosen build-up with
a clean, soft cloth after soaking.
Do not use a stiff brush; you may
roughen the surface of the dis-
penser.
5 Rinse and reassemble dispenser.
Place dispenser back on the
agitator.
Cleaning Fabric
Softener Dispenser
Pour liquid fabric softener
and water into fabric softener
dispenser
Separate for cleaning
The lint filter is located under the
agitator. It is self-cleaning and
requires no maintenance.
Lint Filter
7

8
Operating Instructions
Preparing to Wash
Always follow Fabric Manufacturer’s
Care Label when laundering.
Sort by color
(Separate colorfast from
non-colorfast fabrics*)
•Whites
•Lights
•Darks
Separate by fabric type
•Cottons and linens
•
Permanent press cottons and
blends
•Synthetic and poly knits
•Delicates
Separate lint producers from
lint collectors
•Lint producers: terry cloth and
chenille
•Lint collectors: velveteen and
corduroy
Sort by soil
•Light
•Medium
•Heavy
* Non-colorfast fabrics may bleed or fade. Sort by
individual color.
Sort
Always add detergent before
adding clothes so that the deter-
gent can work effectively.
Using the correct amount of
detergent is one of the most
important things you can do to
make sure your wash comes out
clean. Always follow the detergent
package directions.
Using too little detergent is
a common cause of laundry
problems. Use more detergent if
you have hard water, large loads,
greasy or oily soils or lower water
temperature.
Detergent

Load dry items loosely, spacing
evenly around agitator, and close
the lid.
A typical wash load: two twin sheets,
two tablecloths, four collared
shirts, three pillow cases, three
small bath
towels, three t-shirts,
and three pairs of shorts
.
Place large items in bottom, small
items in the middle and medium
items on top.
When loading wet items make
sure you set the load/water level
high enough to allow the items to
move freely.
Wash bulky items like blankets
separately.
To add items after washer has
started, push in Cycle knob and
submerge additional items next to
the agitator. Close the lid and pull
Cycle knob out to restart.
To reduce wrinkling, give
permanent press items, synthetics
and poly knits room to move freely
in the washer.
NOTE:
• Do not wrap large items like sheets
around the agitator.
• Do not wash fabrics containing
flammable materials (waxes, clean-
ing fluids, etc.) in your washer.
Load
Leave the lid open after washing
to allow moisture to evaporate. The
wash basket is practically care free.
If you want to clean the washer use
a clean soft cloth dampened with
liquid detergent, then rinse. (Do
not use harsh or gritty cleaners.)
Fill Hoses— Hoses connecting
washer to faucet should be replaced
every five years.
Moving and Storage— Ask the service
technician to remove water from
drain pump and hoses. Contact
your local distributor for informa-
tion on how to keep the tub station-
ary when moving the washer.
Long Vacations— Be sure water
supply is shut off at taps. Drain all
water from hoses if weather will be
below freezing.
The Washer
Care & Cleaning
9

Down-Filled Garments Always wash down-filled garments separately from other types
of garments. Wet down gives off an odor that will disappear when
the down is dried. Wash down items frequently to fluff up the
down and to retain down’s warmth. When washing make sure
the load is balanced. Add towels if necessary. Always tumble-dry
down garments.
Pillows Pillows are made from a variety of materials. Wash only if
recommended on the Pillow Manufacturer’s Care Label. Before
washing check pillows for weak seams or holes, and mend. Let
the washer fill with water and add detergent. Let the washer
agitate for several minutes and then add pillows in pairs. This
will keep the load balanced. Use the largest load/water level
available.
Blankets Let the washer fill with water, add detergent, allow detergent to
dissolve, then add blanket. Wash only one blanket at a time.
Permanent Press Clothes Select a larger load/water level than normal. This will provide
that are Line Dried more water to help reduce wrinkling and to allow clothes enough
room to move around. Remove clothes as soon as the wash cycle is
complete and hang them up immediately.
10
Helpful Information
Specialty Care Guide
Item Suggested Care
Always follow Fabric Manufacturer’s Care Label or instructions when laundering.
Otherwise use the information below as a general guide.

11
If Something Goes Wrong
Problem Possible Causes What to Do
Washer is unplugged •Make sure cord is plugged securely into a
working outlet.
Water supply is turned off •Turn both hot and cold taps fully on.
Controls are not set properly •Check controls and make sure Cycle knob
is pulled out to ON position.
Lid is open •Close lid and pull Cycle knob out to ON
position.
Circuit breaker/fuse is •Check house circuit breakers/fuses. Replace
tripped/blown fuses or reset breaker. Washer should have
separate outlet.
Washer Won’t Operate
Drain hose is kinked or •Straighten drain hose and make sure
improperly connected washer is not sitting on it.
•Top of drain outlet should be less than
1m (3 ft.) above floor.
Water Won’t Drain
Control is not set properly •Check water temperature control and adjust.
Water supply is turned off •Turn both hot and cold taps fully on and
or improperly connected make sure hoses are connected to correct
taps.
Water valve screens are •Turn off the water source and remove the
stopped up
water connection hoses from the upper back
of the washer. Use a brush or toothpick to
clean the screens in the machine. Reconnect
the hoses and turn the water source back on.
House water heater is not set •Make sure house water heater is delivering
properly water at 48°C.–65°C. (120°F.–150°F.).
Water Temperature
is Incorrect
