RIN Endless Design - Glass Door Reach In
Refrigerators with 24" Wide Doors
• PRODUCT SPECIFICATIONS SHEETS
• Specification subject to change without notice
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity
Remote RIN2-24 RIN3-24 RIN4-24 RIN5-24
Length with ends 54-7/8" 78-7/8" 102-3/8" 126-1/8"
Height 78-1/2" 78-1/2" 78-1/2" 78-1/2"
Depth with ends 35-1/2" 35-1/2" 35-1/2" 35-1/2"
(Dimensions are +/-1/4")

RIN Endless Design - Glass Door Reach In
Refrigerators with 24" Wide Doors
Standard Specifications and Optional Features
OPTIONAL FEATURES
A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
UL Classified to ANSI/NSF 7
Heavy duty construction
CFC free foamed in place insulation
2, 3, 4, or 5 door models available
Inset door assembly
Endless for continuous line ups
Frame assembly and door - Anthony style 101
Exterior-designer white
Interior-designer white
CONSTRUCTION FINISHES
INTERIOR REFRIGERATION
EXTERIOR LIGHTING
ELECTRICAL REQUIREMENTS
White ends
Back is a combination of white and perforated
aluminum
Removable floor racks
5 heavy duty white epoxy shelves per door
Remote with R22 expansion valve
Coil and fans located below floor pans
White aluminum ends and fronts
Double pane glass doors 24"X63"
Black kick plate
60" fluorescent lamps
2 Dr = 3 lights
3 Dr = 4 lights
4 Dr = 5 lights
5 Dr = 6 lights
Fans and lighting - 115V/60Hz/1Ph
Unit must be hard wired
UL/CUL listed
Important Note: All refrigerated cases are
designed to operate in an environment of
75 degrees and 55% relative humidity.
Important Note: Product must be cooled
before being displayed within the case.
Stainless steel, laminate or paint
Digital thermometer
Door swing change
Insulated divider
Plexiglas divider
Door locks
Special door frames
Temperature control thermostat
Joint kit

A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
RIN Endless Design - Glass Door Reach In
Refrigerators with 24" Wide Doors
Technical Data
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity
• Specification subject to change without notice
SHIPPING INFORMATION
Model Remote RIN2-24 RIN3-24 RIN4-24 RIN5-24
54-7/8"
78-1/2"
35-1/2"
78-7/8"
78-1/2"
35-1/2"
102-3/8"
78-1/2"
35-1/2"
126-1/8"
78-1/2"
35-1/2"
Length
Height
Depth
(Dimensions are +/- 1/4")
36°F to 40°F
R22
2473
115V
4.4A
No
36°F to 40°F
R22
3471
115V
6.2A
No
36°F to 40°F
R22
4481
115V
8.0A
No
36°F to 40°F
R22
5522
115V
9.9A
No
Operating temperature
Refrigerant (expansion valve)
BTU’s at +20°F Evap. Temp.
Voltage
Amperage
Cord and plug
83"
61"
43"
568#
125ft3
83"
86"
43"
832#
177ft3
83"
107"
43"
1096#
221ft3
83"
134"
43"
1360#
276ft3
Height
Length
Depth
Gross weight
Cubic feet
White
White
White
White
Yes
10
24"X63"
White
White
White
White
Yes
15
24"X63"
White
White
White
White
Yes
20
24"X63"
White
White
White
White
Yes
25
24"X63"
Exterior color
Interior color
Inside end panels
Floor-removable deck pans
Drain required
Total shelves
Door size

RIF Endless Design - Glass Door Reach In
Freezers with 24" Wide Doors
• PRODUCT SPECIFICATIONS SHEETS
• Specification subject to change without notice
Remote RIF2-24 RIF3-24 RIF4-24 RIF5-24
Length with ends 54-7/8" 78-7/8" 102-3/8" 126-1/8"
Height 78-1/2" 78-1/2" 78-1/2" 78-1/2"
Depth with ends 35-1/2" 35-1/2" 35-1/2" 35-1/2"
(Dimensions are +/-1/4")
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity

RIF Endless Design - Glass Door Reach In
Freezers with 24" Wide Doors
Standard Specifications and Optional Features
OPTIONAL FEATURES
A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
UL Classified to ANSI/NSF 7
Heavy duty construction
CFC free foamed in place insulation
2, 3, 4, or 5 door models available
Inset door assembly
Endless for continuous line ups
Frame assembly and door - Anthony style 101
Exterior-designer white
Interior-designer white
CONSTRUCTION FINISHES
INTERIOR REFRIGERATION
EXTERIOR LIGHTING
ELECTRICAL REQUIREMENTS
White ends
Back is a combination of white and
perforated aluminum
Removable floor racks
5 heavy duty white epoxy shelves per door
Remote with R404A expansion valve
Coil and fans located below floor pans
White aluminum ends and fronts
Triple pane glass doors 24"X63"
Black kick plate
60" fluorescent lamps
2 Dr = 3 lights
3 Dr = 4 lights
4 Dr = 5 lights
5 Dr = 6 lights
Electric defrost and defrost termination
Standard 230V/60Hz/3Ph
Fans and lighting
115V/60Hz/1ph
Unit must be hard wired
UL/CUL listed
Important Note: All refrigerated cases are
designed to operate in an environment of
75 degrees and 55% relative humidity.
Important Note: Product must be cooled
before being displayed within the case.
Stainless steel, laminate or paint
Digital thermometer
Door swing change
Insulated divider
Plexiglas divider
Door locks
Special door frames
Hot gas defrost
Temperature control thermostat
Joint kit

A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
RIF Endless Design - Glass Door Reach In
Freezers with 24" Wide Doors
Technical Data
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity
• Specification subject to change without notice
SHIPPING INFORMATION
Model Remote RIF2-24 RIF3-24 RIF4-24 RIF5-24
54-7/8"
78-1/2"
35-1/2"
78-7/8"
78-1/2"
35-1/2"
102-3/8"
78-1/2"
35-1/2"
126-1/8"
78-1/2"
35-1/2"
Length
Height
Depth
(Dimensions are +/- 1/4")
0°F to -10°F
R404A
1
3840
3980
115/230V
9.1/5.4A
No
0°F to -10°F
R404A
1
5577
5829
115/230V
10.8/8.2A
No
0°F to -10°F
R404A
1
7173
7500
115/230V
15.6/11.1A
No
0°F to -10°F
R404A
1
8829
9231
115/230V
18.0/13.9A
No
Operating temperature
Refrigerant (expansion valve)
Defrost per day (24 hours)
BTU’s at -25°F Evap. Temp.
BTU’s at -35°F Evap. Temp.
Voltage
Amperage
Cord and plug
1 Defrost
83"
61"
43"
729#
125ft3
83"
86"
43"
1031#
177ft3
83"
107"
43"
1333#
221ft3
83"
134"
43"
1635#
276ft3
Height
Length
Depth
Gross weight
Cubic feet
White
White
White
White
Yes
10
24"X63"
White
White
White
White
Yes
15
24"X63"
White
White
White
White
Yes
20
24"X63"
White
White
White
White
Yes
25
24"X63"
Exterior color
Interior color
Inside end panels
Floor-removable deck pans
Drain required
Total shelves
Door size

RIN Endless Design - Glass Door Reach In
Refrigerators with 30" Wide Doors
• PRODUCT SPECIFICATIONS SHEETS
• Specification subject to change without notice
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity
Remote RIN2-63 RIN3-63 RIN4-63 RIN5-63
Length with ends 68" 98-1/2" 128-1/2" 162"
Height 78-1/2" 78-1/2" 78-1/2" 78-1/2"
Depth with ends 35-1/2" 35-1/2" 35-1/2" 35-1/2"
(Dimensions are +/-1/4")

RIN Endless Design - Glass Door Reach In
Refrigerators with 30" Wide Doors
Standard Specifications and Optional Features
OPTIONAL FEATURES
A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
UL Classified to ANSI/NSF 7
Heavy duty construction
CFC free foamed in place insulation
2, 3, 4, or 5 door models available
Inset door assembly
Endless for continuous line ups
Frame assembly and door - Anthony style 101
Exterior-designer white
Interior-designer white
CONSTRUCTION FINISHES
INTERIOR REFRIGERATION
EXTERIOR LIGHTING
ELECTRICAL REQUIREMENTS
White ends
Back is a combination of white and
perforated aluminum
Removable floor racks
5 heavy duty white epoxy shelves per door
Remote with R22 expansion valve
Coil and fans located below floor pans
White aluminum ends and fronts
Double pane glass doors 30"X63"
Black kick plate
60" fluorescent lamps
2 Dr = 3 lights
3 Dr = 4 lights
4 Dr = 5 lights
5 Dr = 6 lights
Fans and lighting - 115V/60Hz/1Ph
Unit must be hard wired
UL/CUL listed
Important Note: All refrigerated cases are
designed to operate in an environment of
75 degrees and 55% relative humidity.
Important Note: Product must be cooled
before being displayed within the case.
Stainless steel, laminate or paint
Digital thermometer
Door swing change
Insulated divider
Plexiglas divider
Door locks
Special door frames
Temperature control thermostat
Joint kit

A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
RIN Endless Design - Glass Door Reach In
Refrigerators with 30" Wide Doors
Technical Data
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity
• Specification subject to change without notice
SHIPPING INFORMATION
Model Remote RIN2-63 RIN3-63 RIN4-63 RIN5-63
68"
78-1/2"
35-1/2"
98-1/2"
78-1/2"
35-1/2"
128-1/2"
78-1/2"
35-1/2"
162"
78-1/2"
35-1/2"
Length
Height
Depth
(Dimensions are +/-1/4")
36°F to 40°F
R22
2840
115V
3.9A
No
36°F to 40°F
R22
4064
115V
5.6A
No
36°F to 40°F
R22
5206
115V
7.0A
No
36°F to 40°F
R22
6439
115V
8.7A
No
Operating temperature
Refrigerant (expansion valve)
BTU’s at +20°F Evap. Temp.
Voltage
Amperage
Cord and plug
83"
74"
43"
680#
153ft3
83"
107"
43"
1000#
221ft3
83"
134"
43"
1360#
277ft3
83"
171"
43"
1700#
353ft3
Height
Length
Depth
Gross weight
Cubic feet
White
White
White
White
Yes
10
30"X63"
White
White
White
White
Yes
15
30"X63"
White
White
White
White
Yes
20
30"X63"
White
White
White
White
Yes
25
30"X63"
Exterior color
Interior color
Inside end panels
Floor
Drain required
Total shelves
Door size

RIF Endless Design - Glass Door Reach In
Freezers with 30" Wide Doors
• PRODUCT SPECIFICATIONS SHEETS
• Specification subject to change without notice
Remote RIF2-63 RIF3-63 RIF4-63 RIF5-63
Length with ends 68" 98-1/2" 128-1/2" 162"
Height 78-1/2" 78-1/2" 78-1/2" 78-1/2"
Depth with ends 35-1/2" 35-1/2" 35-1/2" 35-1/2"
(Dimensions are +/-1/4")
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity

RIF Endless Design - Glass Door Reach In
Freezers with 30" Wide Doors
Standard Specifications and Optional Features
OPTIONAL FEATURES
A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
UL Classified to ANSI/NSF 7
Heavy duty construction
CFC free foamed in place insulation
2, 3, 4, or 5 door models available
Inset door assembly
Endless for continuous line ups
Frame assembly and door - Anthony style 101
Exterior-designer white
Interior-designer white
CONSTRUCTION FINISHES
INTERIOR REFRIGERATION
EXTERIOR LIGHTING
ELECTRICAL REQUIREMENTS
White ends
Back is a combination of white and
perforated aluminum
Removable floor racks
5 heavy duty white epoxy shelves per door
Remote with R404A expansion valve
Coil and fans located below floor pans
White aluminum ends and fronts
Triple pane glass doors 30"X63"
Black kick plate
60" fluorescent lamps
2 Dr = 3 lights
3 Dr = 4 lights
4 Dr = 5 lights
5 Dr = 6 lights
Electric defrost and defrost termination
Standard 230V/60Hz/3Ph
Fans and lighting
115V/60Hz/1Ph
Unit must be hard wired
UL/CUL listed
Important Note: All refrigerated cases are
designed to operate in an environment of
75 degrees and 55% relative humidity.
Important Note: Product must be cooled
before being displayed within the case.
Stainless steel, laminate or paint
Digital thermometer
Door swing change
Insulated divider
Plexiglas divider
Door locks
Special door frames
Hot gas defrost
Temperature control thermostat
Joint kit

A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
RIF Endless Design - Glass Door Reach In
Freezers with 30" Wide Doors
Technical Data
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity
• Specification subject to change without notice
SHIPPING INFORMATION
Model Remote RIF2-63 RIF3-63 RIF4-63 RIF5-63
68"
78-1/2"
35-1/2"
98-1/2"
78-1/2"
35-1/2"
128-1/2"
78-1/2"
35-1/2"
162"
78-1/2"
35-1/2"
Length
Height
Depth
(Dimensions are +/-1/4")
0°F to -10°F
R404A
1
4653
4873
115/230V
6.5/6.9
No
0°F to -10°F
R404A
1
6550
6866
115/230V
9.1/10.1
No
0°F to -10°F
R404A
1
8484
8897
115/230V
11.2/13.1
No
0°F to -10°F
R404A
1
10450
10961
115/230V
14.2/17.0
No
Operating temperature
Refrigerant (expansion valve)
Defrost per day (24 hours)
BTU’s -25°-EvapTemp.
BTU’s -35°-EvapTemp.
Voltage
Amperage
Cord and plug
1 DEFROST
83"
74"
43"
818#
153ft3
83"
107"
43"
1160#
221ft3
83"
134"
43"
1635#
277ft3
83"
171"
43"
1980#
353ft3
Height
Length
Depth
Gross weight
Cubic feet
White
White
White
White
Yes
10
30"X63"
White
White
White
White
Yes
15
30"X63"
White
White
White
White
Yes
20
30"X63"
White
White
White
White
Yes
25
30"X63"
Exterior color
Interior color
Inside end panels
Floor
Drain required
Total shelves
Door size
