Howdens HJA7043 Assembly Instructions

Built-in Microwave
Oven With Grill
HJA704
HJA704with Trim Kit HJA7041
Installation & User Instructions

Page 3www.howdens.com
CONTENTS
Environmental note 4
Safety information 5 – 7
Specications 8 - 10
Product dimensions 8
Aperture dimensions 8
Product specications 8
Description of the appliance 9
Control panel 10
The turntable 10
Using your microwave 11 - 22
Setting the clock 11
Before rst use 11
Cooking food (microwave mode) 11 - 12
Cooking food (grill/grill combi mode) 13
Automatic defrost programmes 14
Defrosting guidelines 15
Defrosting table 16
Automatic cooking programmes 17 - 18
Setting multiple cooking phases 19
Setting a delay start 19
Materials you can use in a microwave oven 20
Materials not to be placed in a microwave oven 21
Utensils table 22
Safety lock 22
Microwave cooking guidelines 22
Cleaning & maintenance 23
The appliance exterior 23
The appliance interior 23
Rotating plate and rotating base 23
General cleaning advice 23
Installation 24-27
Electrical connection 24
Aperture and ventilation requirements 25
Installing the microwave into the housing unit 26 - 27
Troubleshooting 28
Your Guarantee 29
Guarantee conditions 29
Reporting a fault 29
Contact details 32

Page 4www.howdens.com
ENVIRONMENTAL NOTE
This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health, which could otherwise by
inappropriate waste handling of this product.
The symbol on the product, or on the documents accompanying the product, indicates that this appli-
ance may not be treated as household waste. Instead it shall be handed over to the applicable collection
point for recycling of electrical and electronic equipment.
Disposal must be carried out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please contact
your local city oce, your household waste disposal service or the shop where you purchased the
product.
t The packaging materials that Lamona uses are environmentally friendly and can be recycled
t Please discard all packaging material with due regard for the environment.

Page 5www.howdens.com
SAFETY INFORMATION
Your safety is of the utmost importance to Lamona. Please make sure that
you read this instruction booklet before attempting to install or use the
appliance. If you are unsure of any of the information contained in this
booklet, please contact the Lamona Advice Line.
General Information
t This appliance is designed for domestic household use. It can NOT be used as a freestanding
microwave and must be built in to a standard kitchen cabinet or housing unit (see the section
entitled “Installation” below).
t You should only operate the appliance when the turntable and turntable support are in position.
t You should only use ovenware that is suitable for being used in a microwave.
t To prevent corrosion occurring due to moisture/condensation, the cavity and the door of the
microwave should be wiped dry after each use of the appliance.
t The appliance must not be left unattended if you are heating or cooking food in containers
that are made of paper, plastic or other ammable materials. If left unattended, they could pose a
re hazard.
t If you notice smoke coming from the appliance, you should keep the door of the microwave
closed and then disconnect it from your mains supply. DO NOT use your microwave oven, if
you think it is not operating correctly.
Installation
t IMPORTANT: Only the built in installation sanctioned by Lamona and outlined in this manual
should be followed.
t A separate building in kit will be supplied with the microwave, to allow you to complete a built in
installation.
t IMPORTANT: The adjacent furniture or housing and all materials used in the installation MUST be
able to withstand a minimum temperature of 85°C above the ambient temperature
of the room it is located in, whilst in use.
t Certain types of vinyl or laminate kitchen furniture are particularly prone to heat damage or
discolouration at temperatures below the guidelines given above.
t Any damage caused by the appliance being installed in contravention of this temperature
limit, or by placing adjacent cabinet materials closer than 4mm to the appliance, will be the
liability of the owner.
t For use in leisure accommodation vehicles, please refer to the appropriate information given in the
installation instructions for this appliance.
t The use of this appliance for any other purpose or in any other environment without the express
agreement of Lamona will invalidate any warranty or liability claim.
!

Page 6www.howdens.com
t Your new appliance is guaranteed against electrical or mechanical defects, subject to certain
exclusions that are noted in Lamona’s Conditions Of Guarantee. The foregoing does not
aect your statutory rights.
Service
t Your microwave complies with all relevant safety standards. In order for it to continue
to operate safely, only an engineer that is approved by the Lamona Customer Care
Department should work on the appliance.
t IMPORTANT: It is dangerous for a non qualied person to work on the appliance, in particular
if they remove the cover that provides protection against exposure to microwave energy.
t If you notice that the door seal, door surfaces, power cord and plug are damaged. You should stop
using the appliance, disconnect it from the mains supply and contact the Lamona Customer Care
Department.
t Only genuine Lamona spare parts should be tted to your appliance. These can be obtained
from the Lamona Spares Department.
Warning and safety instructions
t This appliance complies with all current European safety legislation. Lamona do wish to
emphasise that this compliance does not remove the fact that the appliance surfaces will
become hot during use and retain heat after operation.
t DO NOT place anything between the door and the door frame.
t DO NOT store anything that is ammable inside of the microwave. When it is switched on, the
items could catch re.
t DO NOT switch the appliance on if there is no food or liquid inside of the microwave. If you run the
microwave whilst it is empty, there is a chance that it will overload.
t The door seals and the door surfaces should ALWAYS be kept clean and free from debris.
Child Safety
t Lamona strongly recommend that babies and young children are prevented from being near to
the appliance and not allowed to touch the appliance at any time.
t If it is necessary for younger family members to be in the kitchen, please ensure that they are
kept under close supervision at all times.
t IMPORTANT: This appliance should only be operated by adults. You SHOULD NOT allow
young children to use the microwave without supervision. Older children should only operate
the appliance if they have been thoroughly instructed on how to use the microwave and the
consequences of improper usage.
General Safety
t DO NOT allow electrical ttings or cables to come into contact with areas on the appliance that get
hot.
t DO NOT use the appliance to heat the room it is located in.

Page 7www.howdens.com
t DO NOT use the appliance to dry paper, textiles or animals.
t DO NOT install the appliance next to curtains or soft furnishings.
t DO NOT use the appliance to heat unopened bottles or cans etc.
t DO NOT heat cooking oil or liquid containing alcohol, as there is the chance of spontaneous
combustion.
t DO NOT boil eggs or similar foods in their shells, otherwise they may burst. It is possible
to poach eggs in your microwave, providing you prick the yolks rst. Do not attempt to
lift or move cooking appliances by using the oven door, as this may cause damage to the
appliance or result in injury to the person lifting the appliance.
Cleaning
t Cleaning of the oven should be carried out on a regular basis.
t Great care should be taken whilst using this appliance and when following the cleaning
procedure.
t IMPORTANT: The appliance must be disconnected from the mains before following the
cleaning procedure.
Installation
This appliance must be correctly installed by a suitably qualied
person, strictly in accordance with the manufacturer’s instructions.
t Lamona declines any responsibility for injury or damage, to person or property, as a result of
improper use or installation of this appliance.
t Heat, steam and moisture will be created during use of the appliance, take care to avoid injury and
ensure that the room is adequately ventilated. If the appliance is going to be used for prolonged
periods of time, then additional ventilation may be required.
t Please consult with your qualied installer if you are in any doubt about the amount of ventilation
that you will require.
Declaration of conformity
t CE: Appliance conforming to the European directives 89/336/EEC, 93/68/EEC, 73/23/EEC and sub
sequent revisions and “RoHS”directive 2002/95/CE.*
t The manufacturer declares that the oven is built using certied materials and requires the
appliance to be installed in accordance with the standards currently in force. This appliance must
be used by a trained person for domestic purposes only.
t The RoHS directive stands for“the restriction of the use of certain hazardous substances in
electrical and electronic equipment”. This directive bans the placing on the EU market of
new electrical and electronic equipment containing more than the agreed levels of lead,
cadmium, mercury, hexavalent chromium, polybrominated biphenyl (PBB) and
polybrominated diphenyl ether (PBDE) ame retardants
!

Page 8www.howdens.com
SPECIFICATIONS
Product dimensions
Height: 265.2 mm
Width: 485.0 mm
Depth: 369.2 mm
Facia dimensions
Height: 458.5 mm
Width: 593.5 mm
Depth: 18.0 mm
Aperture dimensions
Height: 460 mm
Width: 514 mm
Depth: 550 mm
* Please refer to the installation instructions contained in this user manual, to see the ventilation gaps
you will need to leave around the appliance.
Product specications
t 5 power levels
t 13 programs
t 8 auto-programs
t Electronic control operation
t LED display
t Clock
t Safety lock
t Interior light
t Weight control auto-programs
t Quartz grill mode
t Stainless steel exterior and interior
t Viewing window
t Capacity: 23 litres
t MAX microwave power: 900 W
t MAX grill power: 1000W
For future reference please record the following information which can be found on the rating plate and
the date of purchase which can be found on your sales invoice. The rating plate for your oven can be
located by opening the microwave oven door and looking on the right hand side of the chassis and/or
on the rear of the appliance.
Model Number ……………………………….
Serial Number ……………………………….
Date of Purchase ……………………………….

Page 9www.howdens.com
Description of the appliance
a) Oven door
b) Door interlock
c) Oven cavity
d) Glass turntable
e) Rotating axis
f) Rotating ring
POWER
GRILLAUTO COOKING DEFROST
g) Oven foot
h) Grill rack
i) Microwave housing
j) Door open button
k) Control buttons
l) LED Display
a
b
cde f
gh
i
j
k l

Page 10www.howdens.com
Control panel
1) LCD display.
This display shows the clock time, cooking mode
and remaining operation time.
2) Auto cooking / plus button.
Press this button to select auto- cooking mode or to
increase the weight or cooking time when setting a
program.
3) Stop / clear button.
Press this button once to cancel any input programs
and resume the rst stage or to stop the oven operation.
Press this button twice to cancel a cooking program.
4) Instant / start button.
Press this button to begin a chosen program.
5) Time and weight / minus button.
Use this button to decrease the weight or cooking
time when setting a program.
6) Micro power button.
Use this button to set the power level for the
microwave cooking mode.
7) Grill, combi button.
Press this button to enter the grill and grill and
microwave combination cooking mode.
8) Defrost button.
Press this button to enter the defrost mode.
9) Preset, clock button.
Use this button to set a pre-set cooking time or to
set the time of day.
The turntable
t Never place the rotating plate upside down.
t The rotating plate and rotating base MUST always be
used during cooking.
t All food and food containers must ALWAYS be placed on
the rotating plate during cooking.
t If the rotating plate or rotating base cracks or breaks,
it must be replaced immediately. Genuine Lamona parts
can be obtained from the Lamona Spares Department.
1
25
48
96 7
3
M
LMLMM H
G D.2D.1 Auto
H
KG
D.3

Page 11 www.howdens.com
USING YOUR MICROWAVE
Setting the clock
t When your microwave is connected to the power supply, you
can set the clock to the correct time of day.
t Press the clock button (9) to enter the time setting mode.
t The hour digits will ash. Use the plus (2) and minus (5 buttons
to set the current hour.
t Press the clock button (9) again to conrm.
t The minute digits will ash. Use the plus (2) and minus (5)
buttons to set the current minutes.
t Press the clock button (9) again to conrm the time or wait 5
seconds and the time will be automatically set.
Before rst use
t To remove any residue from the oven that may have been left from the manufacturing process,
you should place a cup that is half lled with water in the microwave.
t Set the microwave on its highest power level for 2 minutes.
t The oven cavity and outside of the appliance should be cleaned with warm soapy water, using
either a sponge or soft cloth. No abrasive cleaners should be used. The appliance should be
thoroughly dried afterwards.
t We would recommend that an appropriate stainless steel cleaner and polish is regularly used on
the stainless steel surfaces of this appliance.
Microwave cooking
t Once the clock has been set, your microwave is then ready to use.
t Check that the rotating plate and rotating base are correctly assembled in the cavity. NEVER use
the grill rack during microwave cooking.
t Place whatever you are cooking in the centre of the microwave cavity and then close the
microwave door. IMPORTANT: You should make sure that the door of the microwave is shut
securely.

Page 12www.howdens.com
t After initially supplying power to the appliance, the colon on the LCD display will ash, Press the
stop / clear button (3) to enter manual mode.
t Press the micro power button (6) repeatedly to select the required cooking power from the
following options: 100P>80P>60P>40P>20P. Please see the table below for a power level guide.
t Use the plus (2) and minus (5) buttons to set the desired cooking time. The maximum time
available is 60 minutes.
t Press the instant / start button (4) to begin the cooking function. The LCD display will count down
the remaining time.
t It is possible to change the cooking time during operation, using the plus and minus buttons.
t It is recommended that food is turned half way through the cooking process to ensure proper
cooking results. Press the instant / start button (4) to continue the cooking process after turning
the food.
t If you intend to remove the food before the cooking time is reached, you MUST press the stop /
clear button (3) to avoid unintended operation during next usage.
LED Display Microwave power level Power level suitable for…
Full power (100%) Meat and vegetables
Medium/high power
(80%) Eggs, sh, rice, soup
Medium power (60%) Steaming food
Medium/low power (40%) Defrosting food
Low power (20%) Keeping food warm
t IMPORTANT: The inside of the microwave and the food that you have been cooking may be
extremely hot. So care should be taken when removing items from the microwave. We would
recommend that you use an oven glove.
t After the food has been removed from the microwave, you should make sure that the door is
closed

Page 13 www.howdens.com
Grill/grill combi mode
IMPORTANT: When using the grill and/or grill combi mode, the inside of the
oven, grill rack and cooking containers may become extremely hot. YOU
MUST use an oven glove when removing items from the cavity.
!
t Check that the rotating plate and rotating base are correctly assembled in the cavity.
t Place whatever you are grilling in the centre of the microwave cavity on the grill rack and then
close the microwave door. IMPORTANT: You should make sure that the door of the microwave is
shut securely.
t There is no need to preheat the cavity when using any of the grill modes.
t After initially supplying power to the appliance, the colon on the LCD display will ash. Press the
stop / clear button (3) once to enter manual mode.
t Press the grill, combi button (7) repeatedly to select the required grill function from the following
options: G > C1 > C2. Please see the table below for a grill cooking function guide.
t Use the plus (2) and minus (5) buttons to select the required cooking time.
t Press the instant / start (4) to begin the chosen cooking function. The LCD display will countdown
the remaining cooking time.
LED Display Description Suitable for...
Grill cooking only
Grilling and browning thin meats, pork, sausage
and chicken wings.
Grill and
microwave
cooking
The microwaves will penetrate thicker food,
alternating with the grill element, which will
brown and crisp o the food.
Grill and
microwave
cooking
As C1, but the grill element remains on for lon-
ger periods of time.

Page 14www.howdens.com
Automatic defrost
t Check that the rotating plate and rotating base are correctly assembled in the cavity.
t Place whatever you are grilling in the centre of the microwave cavity on the grill rack and then
close the microwave door. IMPORTANT: You should make sure that the door of the microwave is
shut securely.
t After initially supplying power to the appliance, the colon on the LCD display will ash. Press the
stop / clear button (3) once to enter manual mode.
t Press the grill, defrost button (8) repeatedly to select the required defrost level from the following
options: d1> d2 > d3. Please see the table below for a grill cooking function guide.
t Set the appropriate weight of the food you wish to defrost using the plus (2) and minus (5)
buttons..
t Press the instant / start (4) to begin the chosen cooking function. The LCD display will countdown
the remaining cooking time.
t Start the defrost function by pressing the instant / start button (4). The LCD display will show the
remaining defrost time which the appliance has calculated, based on the information you have
programmed.
t Half way through the defrosting time, 3 beeps will sound to prompt you to turn over the food
to ensure thorough defrosting. Press the instant / start button again to continue the defrosting
process once the food has been turned.
t If you do not turn the food over, the defrosting cycle will continue automatically.
LED Display Defrost level suitable for… Weight range (kg)
Defrosting meat 0.1 – 2.0
Defrosting poultry 0.2 – 3.0
Defrosting seafood 0.1 – 0.9
t Usually the defrosting process will take a longer time to complete than cooking the food. If the
food can be cut by a knife, this usually indicates the defrosting is complete.
t For optimum defrosting results, see the instructions in the table below for defrosting specic
foods.

Page 15 www.howdens.com
Defrosting guidelines
t Only use microwave-safe dishes for defrosting (porcelain, glass, suitable plastic).
t The defrosting time depends on the quantity and weight of the food that you are defrosting. When
freezing, you should split the food into quantities that are suitable for defrosting in the microwave.
t Distribute the food as evenly as possible within the microwave cavity. The thickest parts of sh or
chicken legs should be placed on top.
t The thicker parts of the food should be turned around several times during the defrosting process.
t Foods that are rich in fats, such as butter, cottage cheese and cream should not be entirely
defrosted. If they are at room temperature, they will be ready to serve within a few minutes. If
cream are deep frozen and little bits of ice remain on the top of it, the cream should be whipped
before eating.
t Bread should be wrapped in a napkin so that it does not get too dry when being defrosted.
t Remove frozen food from its packaging and do not forget to remove any metal clips. If the
containers are suitable for placing in a freezer and a microwave, then you can simply remove the
lid.
t The liquid that is created during the defrost process, particularly in the case of poultry should be
discarded. Under no circumstances should it come into contact with other foods.
t A resting period is required when defrosting food, to ensure that the food is totally defrosted. This
normally takes between 15 – 20 minutes.

Page 16www.howdens.com
Food Defrosting guidance
Steak / chops
t Shield the thin end of the chops or steak with foil.
t Position the food with thinner parts in the centre in a single
layer on a shallow dish. If pieces are stuck together, try to
separate as soon as possible.
t When the oven beeps, you should turn the food over. Rearrange
and shield the defrosted portions.
t After the defrost time, stand the food covered with aluminium
foil for 5-15 minutes.
Minced beef
t Place the frozen minced beef on a shallow dish and shield the
edges.
t When the oven beeps you should turn the food over. Remove
the defrosted portions and shield the edges with foil strips.
t After the defrost time, stand the food covered with aluminium
foil for 5-15 minutes.
Roast meat (beef / pork /
lamb)
t Shield the edges with foil strips.
t Place the joint with the lean side facing upwards if possible on
a shallow dish.
t When the oven beeps you should turn the food over and shield
the defrosted portions.
t After the defrost time stand the food covered with aluminium
foil for 10-30 minutes.
Poultry
t Remove from the original wrapper. Shield the wing and leg tips
with foil.
t Place the breast side down on a shallow dish.
t When the oven beeps you should turn the food over and shield
the defrosted portions.
t After the defrost time, stand the food covered with aluminium
foil for 15-30 minutes.
t After standing, run under cold water to remove giblets if
necessary.
Chicken pieces (chicken
wings and drumsticks)
t Shield the exposed bone with foil. Place the chicken pieces on a
shallow dish.
t When the oven beeps you should turn the food over, rearrange
and shield the defrosted portions.
t After the defrost time, stand the food covered with aluminium
foil for 5-30 minutes.
Automatic cooking
Defrosting Table

Page 17 www.howdens.com
The oven has a default cooking menu for simple operation. Choose the appropriate menu according to
the food type and weight and strictly observe the directions of the table below, otherwise the cooking
eect may be largely inuenced.
t The automatic cooking times are suitable for food that is stored at room temperature.
t The temperature, weight and shape of the food will all inuence the nal cooking results. It is
possible to adjust the cooking times to suit personal preference using the plus and minus buttons
while cooking is in progress.
t Check that the rotating plate and rotating base are correctly assembled in the cavity.
t Place whatever you are cooking in the centre of the microwave cavity and then close the
microwave door. IMPORTANT: You should make sure that the door of the microwave is shut
securely.
t After initially supplying power to the appliance, the colon on the LCD display will ash. Press the
stop / clear button (3) once to enter manual mode.
t Choose the desired menu by pressing the auto cooking button (2) and then the minus (5) and plus
(2) buttons from A1 to A8.
t Start the cooking function by pressing the instant / start button (4) and the LCD display will count
down the remaining cooking time.

Page 18www.howdens.com
Display Category Directions
Popcorn
Suitable for popping a bag of corn which is
available on the market weighing 85g. During
the cooking process, if the popping speed has
decreased to 1 time per 1-2 seconds you should
press the stop / clear button to end the process.
Popcorn Same as A.1 except with a weight of 100g.
Pizza To warm a piece of chilled pizza of 0.15kg.
Beverage
Heating a cup of 250ml liquid. The liquid tem-
perature should be 5-10°C. Use a big mouthed
cup and do not seal.
Beverage
Heating a cup of 500ml liquid. The liquid tem-
perature should be 5-10°C. Use a big mouthed
cup and do no seal.
Potato
To cook potato strips, cut into 5mm width and
height lengths with a total weight of 0.45kg.
Place the strips on a large dish and cover with
thin lm to prevent water loss.
Potato Same as A.6 except the weight of the potato
strips is about 0.65kg.
Fish
Suitable for steaming a sh of 0.45kg. After
the sh is washed and the scales are removed,
make slits in the skin. Put the sh on a shallow
dish of 22-27cm diameter and cover with a thin
lm to prevent water loss. After cooking leave
to stand for 2 minutes.

Page 19 www.howdens.com
Setting multiple cooking phases
It is possible to set the microwave to cook at dierent power levels within a single cooking time. A
maximum of 4 cooking phases can be programmed for one cycle.
t Press the micro power button (6) or the grill, combi button (7) to select the rst cooking phase
function required.
t Use the plus (2) and minus (5) buttons to set the desired cooking time.
t Press the micro power button (6) or the grill, combi button (7) to select the second cooking phase
function required.
t Use the plus (2) and minus (5) buttons to set the desired cooking time.
t Repeat these steps a maximum of 4 times to create your desired cooking program.
t Start the cooking process by pressing the instant / start button (4).
t After the food has been removed from the microwave, you should make sure that the door is
closed.
Setting a delay start
This function will allow you to set a time in the future that the microwave will switch on at.
t IMPORTANT: You must make sure that the clock is set to the correct time before using this feature.
t IMPORTANT: It is not possible to set a delay start when using automatic cooking, automatic
defrost or quick start.
t Press the micro power button (6) or the grill, combi button (7) to select the required cooking mode.
t Use the plus (2) and minus (5) buttons to set the length of cooking time needed.
t Press and hold the clock button (9) for 3 seconds until a beep sounds.
t Use the plus (2) and minus (5) buttons to select the hour you wish the cooking program to start.
Press the clock button (9) again and set the minutes past the hour at which you wish
the cooking program to begin.
t Press the clock button (9) to conrm the set time and the delayed cooking function will be
activated. You can view the starting time by pressing the clock button.
IMPORTANT: If the microwave door is not shut when the time of day that you have programmed is
reached, then cooking will not commence
IMPORTANT: Although your microwave has a delay start feature, we do not
recommend that the microwave is EVER programmed to switch on when it is
unattended.
!

Page 20www.howdens.com
Materials you can use in a microwave oven
Material Remarks
Aluminium foil
To be used for shielding only. Small smooth pieces can be used to cover thin parts
of meat or poultry to prevent overcooking. Arcing can occur if foil is too close to the
cavity walls. The foil should be at least 2.5 cm away from the cavity walls.
Browning dish
Follow the manufacturer’s instructions. The bottom of the browning dish must be
at least 5 mm thick above the turntable. Incorrect usage may cause the turntable to
break.
Dinnerware
Microwave-safe only. Follow the manufacturer’s instructions. Do not use cracked or
chipped dishes.
Glass jars
Always remove the lid. Use only to heat food until just warm. Most glass jars are not
heat resistant and may break.
Glassware
Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use
cracked or chipped dishes.
Oven cooking
bags
Follow the manufacturer’s instructions. Do not close with a metal tie. Make slits in
the bag to allow steam to escape.
Paper plates
and cups
Use for short-term cooking/warming only. Do not leave the oven unattended whilst
cooking.
Paper towels
Use to cover food for reheating and absorbing fat. Use under supervision and for
short-term cooking only.
Parchment
paper
Use as a cover to prevent splattering or as a wrap for steaming
Plastic
Microwave-safe only. Follow the manufacturer’s instructions. It should be labelled as
“microwave safe”. Some plastic containers soften as the food inside gets hot. “Boiling
bags”and tightly closed plastic bags should be slit, pierced or vented, as described
by the package.
Plastic wrap
Microwave-safe only. Use to cover food during cooking to retain moisture. Do not
allow the plastic wrap to touch the food.
Thermometers Microwave-safe only. Meat and candy thermometers.
Wax paper Use as a cover to prevent splattering and to retain moisture.
