HPM EFD01 Series User manual

Ceiling Exhaust Fan –Ducted
Cat. No: EFD01RDWE, EFD01RDMS,
EFD01SQWE, EFD01RDWEKIT
Instruction Manual
Specifications
Cat. No.EFD01RDWE/EFD01RDWEKIT EFD01RDMS EFD01SQWE
Colour White Matt Silver White
Supply Voltage 230-240 V a.c 50Hz
Power Rating 40W max.
Max Airflow Rate (Non-ducted) 330m3/hr
MaxAirflow Rate (Ducted –Ø150mmx 3m) 250m3/hr
IP Rating IPX4
DuctRequirement Ø150mm
Ceiling Cut-out Size (Ceiling fan) Ø298mm
External grille cut-out size 160mm (EFD01RDWEKIT only)
ProjectionintoCeiling 190mm
ProtrusionfromCeiling 26mm
Grille Size (Ceiling fan) Ø372mm 350 x 350 mm
Sound Pressure level at 3m 36 dBA (Tested in accordance with AS1217.5)
EFD01RDWE/EFD01RDMS/EFD01RDWEKIT EFD01SQWE
EFD01RDWEKIT includes : 1) External Grill
2) Ø150mmX 3m Duct
3) Cable ties
4) Duct tape
5) Mounting screws
Also available
External wall kit accessory: R621/6D
Please read carefully: Read through these instructions completely before commencing installation. Retain for future use. This product should
be installed by a licensed electrical contractoror similarly qualified person.
ClassIIconstruction

Please read carefully
Read through these instructions completely before commencing installation. Retain for futureuse.
1. This product shall be installed in accordance to AS/NZS 3000 WiringRules.
2. Regulations concerning the discharge of air must be fulfilled. Local building codes may require venting to the outside.
3. This product must be installed at least 2.2m above floorlevel.
4. Do not install within 120cm of a stove or inside a shower recess.
5. Cross Ventilation:
Ventilation products must have an adequate source of external air to ensure rated performance.
Steam and air will only be exhausted through the fan if there is sufficient flow of air through the room. Ensure adequate inlets exist through windows, vents or
under the door. Airflow path from the inlet to the fan should ideally pass over the source of steamor air to be removed from theroom.
Restrictions on replacement air entering the room to be ventilated, or pressure-differentials between the room and outside air will significantly reduce the exhaust
fan’sperformance.
6. Compliance with Section 6 Damp Situation of AS/NZS 3000 WiringRules:
No part of the unit may be located directly above any part of the bath or shower recess or enclosure. The unit must be installed within zones 2 and 3 only. For further
information, refer to AS/NZS3000.
7. Unit Orientation:
The unit must be installed to ensure the housing outlet and ducting is oriented in parallel to any roofing structures or supports. Refer to image below for correct
installation orientation. Orientation which forces the unit to be ducted into a 90°bend immediatelyafter the fan outletwill cause a significant performance reduction.
120
100
80
60
40
20
0
-20 050 100 150 200 250 300
Back Pressure(PA)
Air Flow(m3/H)
8. Duct Size and Length:
The unit must be installed with Ø150mmduct using the adaptor supplied to ensure optimum extraction and performance. The maximum recommended duct length
is 3m. The graph below shows the unit’s performance with 3m of duct. Longer ducts will reduce the unit’sperformance.
9. Duct Routing:
As the back pressure increases the unit’s performance is reduced. Airflow will be reduced with bends in duct or squashing of duct. Every 90°bend/ elbow results
in approx 20% reduction in the unit’sperformance.
Please refer to the graph below, an almost linear relationship between back pressure and fan performance proves just how critical correct installation of the exhaust
fan is in relation toperformance.
EFD01 series
(Ducted- Ø150mm x3m)

10. The unit can be installed as shown below in fig. A, fig. B and fig. C. When fitted, the duct outlet can be at the same height or lower/higher than the exhaust fan.
11. Vertical ducting with roof vents will result in reduced fan performance, increased noise and condensation/dripping.
Installation (CEILING FAN)
1. Determineposition in ceilingwhere the exhaust fan is required to be installed (figure1).
2. Usethe template provided to drawacircle. To do this, inserta thumb tack atone end and insertapencilat theother end and scribeacircle (figure2).
3. Cutoutaround thisline (figure3).
4. Remove grille from the exhaust fan.
5. Attachduct adaptor to ductwith duct tape (figure4).
6. Ensurethatapoweroutlet is installed in the ceiling near the intended position of the exhaust fan. Ensure that power to the outlet is off. Plug the exhaust fan intothis
outlet (figure5).
7. Attachduct adaptor to theexhaust fan outlet (figure6).
8. Insert the unit into thecavity (figure 7).
9. Withtheunit in place, turn the toggles(4x)clockwise and tighten the screws until theclampssecurelygrip theceiling (figure 8).
10. Pushgrille onto unit and click into position (figure9).
figure 1 figure 2 figure 3 figure 4
figure6 figure7figure5
fig.A fig.B fig.C

AFTERBEFORE
figure8 figure9
Installation for External Grille (EFD01RDWEKIT ONLY)
A suitable position must be found that will suit:
1. The position of thevent on the outside wall.
2. The location of studs, pipes, wires inside the cavity. Make a circular hole
in the outside wall.
From theoutside:
1. From the outside, pull the ducting throughthe outside hole.
2. Remove the inner louvred grille section by gently prying open with a screw
driver.
3. Attach the vent frame to the duct with the cable tie firmly.
4. Push the vent frame back into the hole and attach with the appropriate
screwsfor the wall material.
5. Snap in the louvred grille from the outside with thelouvres pointing
downwards.
Note: It is desirable to have the ducting as taut as possible as any slackness
may restrict the air-flow through the ducting.
External Grille
Louvered Grille
189mm
18mm
Ø150mm
(R621/6D- Grille only)

Disclaimers
1. Thisproductmustbe installed and used as per these instructions.
2. Thisproductshould be cleaned periodically only with adampcloth. Cleaning agentsand solvents should not be used.
3. This product is not intended for use bypersons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance bya person responsible for their safety.Children should be supervisedto ensure thatthey do not
play withtheappliance.
4. Thisproductis intended for household use andsimilar purposes.It is not suitable for use in and environment heavily laden with dust. Under these conditions the life of the
fan motor canbe significantly reduced.
5. This product should not be enclosed in thermal insulation as it maycause the unit to overheat.
6. Thisproducthas been designed to operatein ambienttemperatures-10Cto 40C.
7. Thisproductcontains no serviceable parts and no attempt should be madeto repair it. Iftheproductis faultyit should be discarded.
8. Airflows listed in this productindicate the product performance. Refer to the BCA(Building Codeof Australia), or similar, for the appropriate airflow required for a
particular installation.
9. Ventilationproducts musthavean adequate sourceof external air to ensure correct performance.
10. Considerationmustbe taken in the installation of ductsto ensure that condensation thatwill form in theduct will not run backinto thefan housing.
11. Precautionsmust be taken to avoidtheback-flow of gasesinto the room from the open flue of gasor other fuel-burningappliances.
12. Thisproducthas been designed for domestic or similar usesand is not suitable for acommercial installation.
13. Thisproductis not suitable for installation in hazardous and/or corrosive areas.
14. Thematerialin thisproductmayvaryin colour from batch to batch. Colour matchingfrom one batch to anothercannotbe guaranteed.
15. Extended exposure to UV rays (such as exposure to direct sunlight) may cause discolouration of this product.
16. This productutilises intellectual property in the form of registered designs,trademarks, and/or patents. Such intellectual property remainsthe property of Legrand in
all cases.
17. Legrand reserves the right to modify the specification of thisproductatany time.
LE09237AAC
06_2020
Warranty
Legrand warrants this product for a period of3 years from the date of purchase. These
goods come with guarantees that cannot be excluded under the Australian and New
Zealand Consumer Laws. You are entitled to a replacement or a refund for a major
failure and for compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired ifthe goods fail to be acceptable quality and
the failure does notamount to a major failure.
Seethe Warranty card enclosed with this product forfurther details.
Customer Service
For all Customer Service and Technical Support please
call Monday to Friday during businesshours.
LegrandAustralia
1300 369777
www.hpm.com.au
Legrand NewZealand
0800 476009
www.hpm.co.nz
ABN: 31 000 102661
