HSI 4939FBOX User manual

Garden Pixie
Fountain
Assembly
Instructions:
•Set shell on base in firm level
position.
•Attach tubing to pump
discharge.
•Place pump (with intake
facedown or sideways) into
shell housing.
•Pass pump power cord out
groove at back of shell.
•Loop tubing (to prevent kinks)
and attach to bottom of figure.
•Set figure on shell.
•Apply three dabs of silicone
sealant to bottom of figure to
firmly attach it to the shell.
•Fill shell with water.
•Plug pump into 110V (A.C.
only) GFCI protected
receptacle.
Fountain Care:
Extreme and rapid changes in temperature and humidity affect all concrete adversely. Concrete has an inher-
ent tendency to expand and contract with climactic conditions (a phenomenon taken into account by experi-
enced masons who employ expansion joints - like those "lines" in the sidewalk).
Your HSI cast stone products has been manufactured with weather in mind. The concrete mix contains
additives which enhance the elastic qualities of the concrete. Occasionally, normal, unharmful surface shrink-
age cracks may sometimes appear - but your HSI cast stone products will not crack due to weather if these
simple rules are followed:
1. Do not allow water to collect and freeze in fountain bowls or shells!
2. Do not allow water to collect and freeze in planters, saucers or birdbaths!
3. Do not allow statuary or pedestals to sit in a pool of ice!
Cast stone products left exposed to icing conditions may shale or crack due to the mechanical force of
water solidifying and expanding along the concrete surface.
Important: If your HSI fountain, birdbath, planter or statuary cannot be stored indoors during the winter sea-
son, you must at least protect it from ice collection or exposure.
"How-To" protect your HSI cast stone products during the winter season: For fountains, first
remove the statue and pump, storing them inside if possible. Next, fill the bowl(s) or shell (s) with an
absorbent material such as LU85 Underlay, burlap bags, blankets, etc. Then, cover the entire fountain with a
FC22S Fountain Cover. Should condensation droplets form on the inside of the cover, they will be absorbed
by the material.
For birdbaths, planters or statuary set the pieces on high ground where a pool of ice will not form, and
then cover with a FC22S Fountain Cover.
By following these simple and sensible precautions during the winter season, you will protect your HSI
cast stone products for years of beauty and enjoyment!
General Maintenance:
Little or nothing needs to be done to protect the finish of natural concrete fountains and statuary. Many peo-
ple find the inevitable aging and weathering of natural stone to be appealing. But this natural weathering may
be impeded, if you wish, by the application of a clear concrete sealer, available from any hardware store.
HSI finished fountains and statuary have been painted with penetrating-sealer type paints, designed to
resist the elements for many years. The fountains clear luster may, however, be revived seasonally with a
light coat of CS22 Sealer Spray.
Should you choose to refinish your fountain after a number of years - whether in the original or a new
color - your HSI dealer can provide you with an RK10 Refinishing Kit, complete with all materials and
instructions.
To camouflage minor dings, nicks, and scratches, use just a dab of almost any sort of paint. For finishes
that employ a black antique effect, use black paint; for lighter antiques, use white. Simply dab the paint onto
the scratch, and wipe off the excess. The textured finishes of HSI concrete products "accept" paint easily, and
your touchup will blend in invisibly.
Finally, depending upon temperature and evaporation, you may notice a buildup of white residue on the
surface of the bowl or shell. Such a buildup is normal and unavoidable in areas with a high mineral content -
especially lime - in the local water supply. More frequent rinsing of the fountain and changing of the water
will help to minimize the problem.
When the lime buildup finally becomes unsightly, it may be safely and easily removed by using LR22
Fountain Cleaner And Lime Remover, available from you local HSI dealer. This product is not a water addi-
tive, but a surface cleaner specifically designed to foam away lime residue without affecting the fountain sur-
face. Be sure to follow all directions for cleaning specified on the bottle.
To keep fountain water clear from unsightly sludge, algae and cloudiness simply use CL22 Water
Clarifier. CL22 Water Clarifier can also be used to help prevent fountain water from becoming dirty, and it
will also improve filter efficiency in your HSI submersible pump.
#4939A Pixie
#6735
Basin
#7735 Base
#4939B Shell
Pump
Tubing
Slide adjuster on side
of pump to control
water flow.

Fountain
Congratulations on the purchase
of your HSI fountain.
This quality, cast stone decorative
fountain can be used outdoors or
indoors to brighten your backyard,
patio, garden, deck, balcony,
sunroom — or any place where
the sparkling sight and sound
of running water will enhance
your environment. It’s even
a beautiful way to help
humidify dry indoor air.
The small submersible
pump simply recirculates
the water — no plumbing
is needed. Just follow the
easy directions in this booklet
to assemble and maintain your
HSI fountain for years of beauty
and enjoyment.
1 YEAR LIMITED WARRANTY
This consumer warranty extends to the original purchase of any HSI Product (thereafter referred to
as the “Product”).
WARRANTY DURATION: This product is warranted to the original consumer purchase for a
period of 1 year from the original purchase.
WARRANTY COVERAGE: HSI Sculpture warrants to the original Consumer Purchaser that
any Product of it’s manufacture is as represented in the catalogue and is free from defects in
material and workmanship. THIS WARRANTY IS VOID IF THE PRODUCT HAS BEEN
DAMAGED BY ACCIDENT, UNREASONABLE USE, NEGLIGENCE, IMPROPER
SERVICE, FAILURE TO FOLLOW INSTRUCTIONS PROVIDED WITH THE PRODUCT OR
OTHER CAUSES NOT ARISING OUT OF DEFECTS IN MATERIAL OR WORKMANSHIP.
HSI Sculpture is not responsible for Products cracked or damaged due to exposure to freezing
temperatures.
This warranty shall not apply in any manner to parts or accessories not manufactured by HSI
Sculpture.
WARRANTY PERFORMANCE: During the above 1 year warranty period, HSI Sculpture shall
repair or replace with a comparable model, any Product, or component thereof, which may thus
prove defective under such normal use and proper care, and which our examination shall disclose to
our satisfaction to be thus defective, when the Product is returned, shipping to and from prepaid to:
HSI Sculpture • 1250 Henri Drive • Wauconda, IL 60084
Other than the shipping requirements no charge will be made for such repair or replacement of in-
warranty Products. HSI Sculpture strongly recommends that you insure the Product for value prior
to mailing.
WARRANTY DISCLAIMERS: ANY IMPLIED WARRANTIES ARISING OUT OF THIS
SALE, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN
DURATION TO THE ABOVE 1 YEAR PERIOD. HSI SCULPTURE SHALL NOT BE LIABLE
FOR LOSS OF THE PRODUCT OR OTHER CONSEQUENTIAL OR INCIDENTAL COSTS,
EXPENSES OR DAMAGES INCURRED BY THE CONSUMER OF ANY OTHER USE.
Some states do not allow the exclusion or limitation of implied warranties or consequential or
incidental damages, so the above limitations or exclusions may not apply to you.
LEGAL REMEDIES: This warranty gives you specific legal rights, and you may also have other
rights which might vary from state to state. 4939FBOX
Garden Pixie Fountain
IS/4939FBOX 4-00
©2000 HSI®Wauconda, Illinois
