Hughes HN7700S User manual

1037753-0001
Revision A
May 19, 2008
HN System
Terrestrial Broadband Router
Installation Guide
Model: HN7700S

Copyright © 2008 Hughes Network Systems, LLC
All rights reserved. This publication and its contents are proprietary to Hughes Network Systems,
LLC. No part of this publication may be reproduced in any form or by any means without the written
permission of Hughes Network Systems, LLC, 11717 Exploration Lane, Germantown, Maryland
20876.
Hughes Network Systems, LLC has made every effort to ensure the correctness and completeness
of the material in this document. Hughes Network Systems, LLC shall not be liable for errors
contained herein. The information in this document is subject to change without notice. Hughes
Network Systems, LLC makes no warranty of any kind with regard to this material, including, but not
limited to, the implied warranties of merchantability and fitness for a particular purpose.
Trademarks
Hughes, Hughes Network Systems, and HughesNet are trademarks of Hughes Network Systems,
LLC. All other trademarks are the property of their respective owners.
Revision record
Revision Date of issue Scope
A May 19, 2008 Initial release

• Important safety information
1037753-0001 Revision A iii
Important safety information
For your safety and protection, read this entire manual before you
attempt to install the HN router. In particular, read this safety
section carefully. Keep this safety information where you can
refer to it if necessary.
Types of warnings used
in this manual
This section introduces the various types of warnings used in this
manual to alert you to possible safety hazards
WARNING
Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury.
CAUTION
Indicates a situation or practice that might result in property
damage.
Note: A note provides additional information.

• Important safety information
iv 1037753-0001 Revision A

• Contents
1037753-0001 Revision A v
Contents
Important safety information . . . . . . . . . . . . . . . . . . . . . iii
Types of warnings used in this manual . . . . . . . . . . . . . . . . . . . iii
Chapter 1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Scope and audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
HN router overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Router specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Associated transport devices . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Installation and commissioning steps. . . . . . . . . . . . . . . . . . . . . .4
Contact information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Chapter 2
Preparing the HN router for installation. . . . . . . . . . . . .5
Items required for installation . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Items required for installation . . . . . . . . . . . . . . . . . . . . . . . . .6
Confirming installer PC and site requirements . . . . . . . . . . . . . .6
Customer site requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Chapter 3
Assembling and connecting the HN router hardware . .9
Using the pedestal base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Attaching the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Removing the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Selecting the router location. . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Connecting the power supply . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Connecting an AC/DC power supply . . . . . . . . . . . . . . . . . . .12
In-line units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Connecting a DC/DC power supply . . . . . . . . . . . . . . . . . . . .13
Chapter 4
Connecting the HN router to a transport device . . . . .15
Connecting the cables to a modem transport device . . . . . . . . .15
Connecting the cables to a T-1 transport device . . . . . . . . . . . .16
Powering up and observing the router LEDs . . . . . . . . . . . . . . .16
LEDs on power-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

• Contents
vi 1037753-0001 Revision A
Chapter 5
Commissioning the HN router . . . . . . . . . . . . . . . . . . . .19
Router connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Commissioning procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Changing from VSAT to router mode . . . . . . . . . . . . . . . . . . . .20
Terrestrial Broadband Setup page . . . . . . . . . . . . . . . . . . . . . . .22
Commissioning by auto selection. . . . . . . . . . . . . . . . . . . . . . . .24
Selecting and verifying the NAP . . . . . . . . . . . . . . . . . . . . . .24
Entering and verifying configuration parameters. . . . . . . . . .28
Completing the commissioning process. . . . . . . . . . . . . . . . . . .30
Connecting the HN router . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Commissioning by manual entry . . . . . . . . . . . . . . . . . . . . . . . .33
Selecting and verifying the NAP . . . . . . . . . . . . . . . . . . . . . .33
Entering and verifying the configuration parameters. . . . . . .34
Chapter 6
Verifying the installation and commissioning . . . . . . . .37
Verifying the terrestrial link . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Verifying the download status . . . . . . . . . . . . . . . . . . . . . . . . . .38
Completing the process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Chapter 7
System Control Center . . . . . . . . . . . . . . . . . . . . . . . . . .41
Internet browser settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Accessing the System Control Center . . . . . . . . . . . . . . . . . . . .43
The System Control Center home page . . . . . . . . . . . . . . . . . . .43
System Control Center buttons and indicators . . . . . . . . . . . . . .44
System Status button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Other System Control Center buttons. . . . . . . . . . . . . . . . . . .46
The System Status page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
LAN Info page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
WAN Info page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
System Info page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Additional Home Page links. . . . . . . . . . . . . . . . . . . . . . . . . . . .51
System Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Diagnostic Utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Connectivity Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Detailed Problem Statistics. . . . . . . . . . . . . . . . . . . . . . . . . . .52
Help page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Help page links. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Advanced Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Accessing the Advanced Pages . . . . . . . . . . . . . . . . . . . . . . .55
Expanding and collapsing menus . . . . . . . . . . . . . . . . . . . . . .56

• Contents
1037753-0001 Revision A vii
Chapter 8
Configuring the HN router for VADB backup . . . . . . .57
VADB overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Requirements for VADB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Installing VADB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Verifying that the VADB profile is loaded . . . . . . . . . . . . . .59
Testing the telephone line. . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Connecting the HN router to the telephone line . . . . . . . . . .61
Optional protection module . . . . . . . . . . . . . . . . . . . . . . . . . .62
Installing the protection module. . . . . . . . . . . . . . . . . . . . .63
Verifying VADB functionality. . . . . . . . . . . . . . . . . . . . . . . .64
LED appearance during VADB operation . . . . . . . . . . . . . . . . .65
VADB troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Appendix A
Configuring a computer to support DHCP . . . . . . . . . .69
Windows Vista . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Windows XP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Appendix B
Updating the router software . . . . . . . . . . . . . . . . . . . . .77
Saving the utility on the installer laptop. . . . . . . . . . . . . . . . . . .77
Configuring TCP/IP properties on the installer laptop. . . . . . . .78
Windows Vista . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Windows XP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81
Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
Updating the fallback.bin file. . . . . . . . . . . . . . . . . . . . . . . . . . .86
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Appendix C
Disabling a Web browser’s proxy connection. . . . . . . .89
Internet Explorer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Netscape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Appendix D
Conformance with standards and directives. . . . . . . . .93
Safety – operating conditions for Canada . . . . . . . . . . . . . . . . .94
Repairs in Canada. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
Electromagnetic compatibility (EMI) . . . . . . . . . . . . . . . . . . . .95
FCC Part 15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
Canada Class B warning. . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
R&TTE (EU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Telecommunications standards . . . . . . . . . . . . . . . . . . . . . . . . .96
IPoS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96

• Contents
viii 1037753-0001 Revision A
FCC Part 68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Ringer equivalence number (REN) . . . . . . . . . . . . . . . . . . . .97
Discontinuance of service. . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Telephone Company changes. . . . . . . . . . . . . . . . . . . . . . . . .97
Repairs in the United States . . . . . . . . . . . . . . . . . . . . . . . . . .98
Canada – equipment attachment limitations. . . . . . . . . . . . . .98
Appendix E
ADTRAN Total Access 600R . . . . . . . . . . . . . . . . . . . . .99
Minimum system requirements . . . . . . . . . . . . . . . . . . . . . . . . .99
ADTRAN shipping carton . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Installing the ADTRAN 600R . . . . . . . . . . . . . . . . . . . . . . . . .100
Wallmount installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
Supplying power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
ADTRAN front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Front panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Navigating the user interface . . . . . . . . . . . . . . . . . . . . . . . . . .103
Navigating using keystrokes . . . . . . . . . . . . . . . . . . . . . . . .105
Connecting the ADTRAN . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Logging in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
System Info menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
Configuring the ADTRAN. . . . . . . . . . . . . . . . . . . . . . . . . . . .107
DS0 mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Confirming connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115
Appendix F
Siemens 4100/4101 DSL Modem . . . . . . . . . . . . . . . . .117
Minimum system requirements . . . . . . . . . . . . . . . . . . . . . . . .117
Siemens 4100/4101 shipping carton. . . . . . . . . . . . . . . . . . .117
Items required for installation . . . . . . . . . . . . . . . . . . . . . . . . .117
Installation overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Installing line filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Connecting the cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Checking the modem LEDS. . . . . . . . . . . . . . . . . . . . . . . . .118
Installing the modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
The installation interface . . . . . . . . . . . . . . . . . . . . . . . . . . .119
The installation procedure . . . . . . . . . . . . . . . . . . . . . . . . .119
Acronyms and abbreviations . . . . . . . . . . . . . . . . . . . .123
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125

• Figures
1037753-0001 Revision A ix
Figures
Chapter 1
1. HN router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Chapter 2
2. HN router components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Chapter 3
3. Attaching the router to the pedestal base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4. AC/DC power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
5. DC/DC power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Chapter 4
6. Connecting the cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
7. Router LEDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Chapter 5
8. Advanced Commissioning Options link. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
9. Setup screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
10. Mode Change confirmation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
11. Terrestrial Broadband Setup page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
12. Configuration File Upload screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
13. Configuration file confirmation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
14. Terrestrial Broadband Setup screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
15. Auto selection - Service Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
16. Auto selection - Service Parameters selecting the NAP. . . . . . . . . . . . . . . . . . .26
17. Select Service Parameters for T-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
18. Auto selection - T-1 NAP verification screen . . . . . . . . . . . . . . . . . . . . . . . . . .28
19. DSL NAP verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
20. Auto selection - DSL Configuration Parameters . . . . . . . . . . . . . . . . . . . . . . . .29
21. T-1 Configuration Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
22. Sample Configurations Parameters verification screen. . . . . . . . . . . . . . . . . . .30
23. Auto selection - Confirmation screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
24. Router System Control Center home page . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
25. IP address assigned. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
26. Manual entry - Service Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
27. Manual entry - Verification of Service Parameters . . . . . . . . . . . . . . . . . . . . . .34
28. Manual entry - Manual Configuration screen. . . . . . . . . . . . . . . . . . . . . . . . . . .34

• Figures
x1037753-0001 Revision A
Chapter 6
29. Summary page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
30. SDL Monitor page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
31. System Status page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Chapter 7
32. Selecting settings option. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
33. Settings screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
34. System Control Center home page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
35. Web page top frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
36. Question link. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
37. Link explanation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
38. System Status indicator reporting
Web Acceleration feature down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
39. System Status indicator reporting a problem . . . . . . . . . . . . . . . . . . . . . . . . . . .46
40. System Status page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
41. LAN Info page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
42. WAN Info page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
43. System Info page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
44. Additional Home Page links. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
45. Detailed Problem Statistics selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
46. Help welcome page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
47. Help Introduction page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
48. Frequently Asked Questions page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
49. Advanced page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
50. Icon link to Advanced Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
51. Advanced page showing sub-menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Chapter 8
52. Verifying that the VADB profile is loaded . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
53. VADB cable connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
54. VADB connections with protection module . . . . . . . . . . . . . . . . . . . . . . . . . . .62
55. Connecting the protection module to the terminal . . . . . . . . . . . . . . . . . . . . . . .63
56. Connecting the protection module ground cable . . . . . . . . . . . . . . . . . . . . . . . .63
57. Verifying the VADB link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
58. HN router LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Appendix A
59. Network Connections - Windows Vista . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
61. Internet Protocol Properties - Windows Vista . . . . . . . . . . . . . . . . . . . . . . . . . .71
60. Local Area Connection Properties - Windows Vista . . . . . . . . . . . . . . . . . . . . .71
62. Network Connections - Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
63. Local Area Connection Properties - Windows XP. . . . . . . . . . . . . . . . . . . . . . .73

• Figures
1037753-0001 Revision A xi
64. Internet Protocol Properties - Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
65. Network and Dial-up Connections - Windows 2000 . . . . . . . . . . . . . . . . . . . . .75
66. Local Area Connection Properties - Windows 2000 . . . . . . . . . . . . . . . . . . . . .75
67. Internet Protocol Properties - Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . .76
Appendix B
68. Saving the Fallback Updater utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
69. Network Connections - Windows Vista . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
71. Internet Protocol Properties - Windows Vista . . . . . . . . . . . . . . . . . . . . . . . . . .80
70. Local Area Connection Properties - Windows Vista . . . . . . . . . . . . . . . . . . . . .80
72. Network Connections - Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
73. Local Area Connection Properties - Windows XP. . . . . . . . . . . . . . . . . . . . . . .83
74. Internet Protocol Properties - Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
75. Network and Dial-up Connections - Windows 2000 . . . . . . . . . . . . . . . . . . . . .84
76. Local Area Connection Properties - Windows 2000 . . . . . . . . . . . . . . . . . . . . .85
77. Internet Protocol Properties - Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . .85
78. Entering the router’s IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Appendix C
79. Selecting the Connections tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
80. Accessing LAN settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
81. Accessing proxy settings: Netscape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Appendix D
82. IPoS symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Appendix E
83. ADTRAN 600R front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
84. ADTRAN 600R back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
85. LED positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
86. Wallmount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
87. ADTRAN front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
88. Terminal menu window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
89. Login screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
90. System Info menu screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
91. Router menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
92. Config Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
93. Config/Interfaces screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
94. Interfaces/Setup screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
95. Sample setup screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
96. Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
97. Selecting the map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
98. Selecting the DS0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113

• Figures
xii 1037753-0001 Revision A
99. Setting the service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
100. Mapping a DS0 port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
101. Mapping multiple DS0s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
102. Log out screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115
103. Ping Far-End IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115
Appendix F
104. Installation icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
105. Searching for device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
106. Ready message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
107. Downloading Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
108. Rebooting Device message. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
109. Installation complete . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122

• Tables
1037753-0001 Revision A xiii
Tables
Chapter 1
1. Specifications for the HN router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Chapter 3
2. Available power supplies for the HN router. . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Chapter 8
3. HN router LED appearance during VADB operation . . . . . . . . . . . . . . . . . . . .66
Appendix D
4. HN7700S standards compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Appendix E
5. ADTRAN front panel LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103

• Tables
xiv 1037753-0001 Revision A

Chapter 1 • Introduction
1037753-0001 Revision A 1
Chapter 1
Introduction
This manual explains how to install, commission, and service the
Hughes HN7700S as a Terrestrial Broadband Router (HN router).
The manual also includes installation information for the DSL
and T-1 transport methods used with the HN router. This chapter
discusses the following topics:
•Scope and audience on page 1
•HN router overview on page 1
•Router specifications on page 2
•Commissioning on page 3
•Installation and commissioning steps on page 4
The HN7700S has dual functions. This manual covers the
HN7700S’ function as a router. It is also used as a VSAT
terminal.
Scope and audience This manual is intended for use by the following audiences:
•Professional installers
•Installer trainers, who prepare separate instructions for the
installers
•Call center operators, who respond to customers’ calls
•Call center trainers, who train call center operators
This manual is intended for use in the United States and Canada.
Certain information may vary depending on the customer’s
location. This manual identifies such differences where
applicable.
In this guide, the term HN router refers to the HN7700S acting as
a router. Transport devices refer to the Siemens 4100/4101
SpeedStream Modem or the ADTRAN Total Access 660R T-1 line.
HN router overview The HN router, as shown in Figure 1 on page 2, is a standalone
unit that provides an integrated broadband LAN solution to
platforms running IP over Ethernet. The HN router provides two
10/100 LAN ports with one being used for local LAN
connectivity and one being used for WAN connectivity. The
Ethernet LAN port can be connected via a straight-through or

Chapter 1 • Introduction
21037753-0001 Revision A
crossover Cat-5 cable to a single computer or to an Ethernet
hub/switch port. It is completely self-contained requiring no
external PC to host any functions or software. The software is
automatically updated from the Network Operations Center. It
also has an an internal modem (with telephone jack) to support
the Virtual Private Network Automatic Dial Backup (VADB)
feature.
Router specifications Table 1 lists the specifications for the HN router.
Figure 1: HN router
Table 1: Specifications for the HN router
Weight 2.4 lb (1.089 kg)
Width 1.7 inch (4.32 cm)
4.5 inch (11.43 cm) with pedestal base
Height 9.5 inch (24.13 cm)
9.75 inch (24.77 cm) with pedestal base
Depth 10.5 inch (26.67 cm)

Chapter 1 • Introduction
1037753-0001 Revision A 3
Commissioning Commissioning is the process of registering an HN router for
service. During the commissioning process you may use auto
selection or manual entry of parameters.
•Auto Selection - Allows you to choose the Network Access
Provider (NAP) from a predetermined list of providers. Many
of the commissioning parameters are automatically
configured for the provider chosen.
•Manual Entry - This mode requires you to enter all
parameters manually.
Associated transport
devices
Installation and commissioning of the HN router requires
configuring/commissioning tasks for the transport device. This
version of the Installation Guide provides information on the
following:
•ADTRAN Total Access 600R as described in Appendix E –
ADTRAN Total Access 600R, on page 99.
•Siemens Model 4100/4101 as described in Appendix F –
Siemens 4100/4101 DSL Modem, on page 117.
Safe operating
temperature range
5 to 40°C (Above 5000 ft altitude, reduce maximum temperature by 1°C per
1000 ft)
Safe operating
humidity range
5% to 95% non-condensing
Safe altitude 10,000 ft
Cooling method Convection
Main processor 300 MHz
Main memory 64 Mbyte
Flash memory 16 Mbyte
Protocol support TCP/IP (Transmission Control Protocol/Internet Protocol) protocol suite
Interfaces/ports • Two Ethernet ports supporting 10BaseT or 100BaseT operation, RJ45-switched
• Telephone line port
• Serial port, DTE/DCE RS-232, which supports the following protocols:
– VISA (Veriphone 3200 and 3300) (the asynchronous protocol of Vanguard
International Service Association credit card)
– X.25 International Telecommunication Union-Telecommunication
Standardization Sector (ITU-T) protocol standard for WAN communications
– XPAD (X.25 Packet Assembler/Disassembler)
– SDLC (Synchronous Data Link Control)
– LLC (Logical Link Control)
Power supplies and
power requirements
See Table 2 on page 11.
Table 1: Specifications for the HN router

Chapter 1 • Introduction
41037753-0001 Revision A
Installation and
commissioning steps
The installation and commissioning of the HN router is a
multi-step process involving two pieces of equipment—the HN
router and the associated transport device. The workflow and
chapter reference numbers for the process steps follow.
1. Preparing, installing, and commissioning the transport device
a. ADTRAN Total Access 600R
–Installing the ADTRAN 600R on page 100
–Connecting the ADTRAN on page 106
–Configuring the ADTRAN on page 107
–Confirming connectivity on page 115
b. Siemens 4100/4101 DSL Modem
–Installation overview on page 118
–Installing the modem on page 119
2. Preparing the router for installation
Chapter 2 on page 5
3. Assembling the HN router
Chapter 3 on page 9
4. Connecting the router to the transport device
Chapter 4 on page 15
5. Commissioning the HN router
Chapter 5 on page 19
6. Verifying the installation, commissioning, and connections
Chapter 6 on page 37
Contact information If you experience installation problems with the HN Router, first
try the Diagnostic Utilities on page 51.
For warranty or repair support, the contact information varies
depending on the location. If the customer needs service,
warranty or repair support, they should contact their customer
service representative in accordance with their service agreement.

Chapter 2 • Preparing the HN router for installation
1037753-0001 Revision A 5
Chapter 2
Preparing the HN router for installation
This chapter discusses preparations you must make prior to
installing the HN router and information you should know before
beginning the installation.
This chapter discusses the following tasks:
•Items required for installation on page 5
•Confirming installer PC and site requirements on page 6
•Customer site requirements on page 7
Items required for
installation
The HN router and the transport device shipping cartons contain
the equipment necessary for installation. Before beginning the
installation make sure you have all of the items shown in Figure 2
on page 6 and any other materials you may need.
Note: Install your trasport device before installing the HN router.
The appendices listed below give the installation instructions for
the trasport devices.
•Appendix E – ADTRAN Total Access 600R, on page 99
•Appendix F – Siemens 4100/4101 DSL Modem, on page 117
Note: Customers who purchased their system from a Hughes
retail channel receive an order confirmation e-mail.
Note: If the site has a DC power source, it will require a DC/DC
power supply. See Table 2 on page 11. You must provide the
wire required to assemble the DC input power cable.

Chapter 2 • Preparing the HN router for installation
61037753-0001 Revision A
Items required for
installation
Ensure the HN router shipping carton contains the items shown in
Figure 2.
Confirming installer PC
and site requirements
You must confirm that your PC (the installer laptop) and the
customer’s computer meet specific requirements before you
install the HN router or the transport device. The installer laptop
PC must meet the following requirements:
•Ethernet enabled network interface card (NIC) and Ethernet
cable.
•Windows Vista, Windows XP, or Windows 2000 operating
system with DHCP configured to automatically obtain IP
addresses. See Appendix A – Configuring a computer to
support DHCP, on page 69.
Figure 2: HN router components
Items provided in the remote terminal shipping carton
Items provided by the installer
Cat-5 Ethernet cable
Power supply
Wall unit or in-line unit
or
Wall unit
In-line Warranty
Warranty
Pedestal base
Remote
terminal
Installation
specification
or work order
Installation specification
or work order
terr.cfg file (if you are
instructed to upload it)
G-29716 C 05/19/08
