HuMANDATA LTD.
USB Isolator Board
USB-043
User’s Manual
Ver. 1.0

USB-043 (Ver.1.0)
Table of Contents
Precautions ..................................................................................................... 1
Revision History.............................................................................................. 1
Introduction .................................................................................................... 1
1. Overview............................................................................................................ 2
2. Power Supply ..................................................................................................... 2
3. SG/FG Separation Jumper (JP1, JP2) ................................................................ 3
4. Specifications ..................................................................................................... 4
4.1. Product Specification ...........................................................................................4
4.2. Optional Accessories ............................................................................................5
5. Additional Documentation and User Support ..................................................... 6
6. Warranty and Compensation.............................................................................. 6

USB-043 (Ver.1.0)
Precautions
1
This product uses ordinary off-the-shelf electronic components, and
is therefore inappropriate for use in applications that require special
quality or reliability and are expected to protect human lives or
prevent accidents, such as safety mechanisms in fields including
space, aeronautics, medicine, and nuclear power.
2
Do not be used underwater or in high-humidity environments.
3
Do not be used in the presence of corrosive gases, combustible gases,
or other flammable gases.
4
Do not turn on power when circuit board surface is in contact with
other metal.
5
Do not apply voltage higher than rated voltage.
6
This manual may be revised in the future without notice owing to
improvements.
7
All efforts have been made to produce the best manual possible, but
if users notice an error or other problem, we ask that they notify us.
8
Item 7 notwithstanding, HuMANDATA cannot be held liable for the
consequences arising from use of this product.
9
HuMANDATA cannot be held liable for consequences arising from
using this product in a way different from the uses described herein,
or from uses not shown herein.
10
This manual, circuit diagrams, sample circuits, and other content
may not be copied, reproduced, or distributed without permission.
11
If the product emits smoke, catches fire, or becomes unusually hot,
cut the power immediately.
12
Do not install the control cables or communication cables together
with the main circuit lines or power cables. In such an environment,
it may result in malfunction due to noise.
13
Be careful of static electricity.
Do Not
Attention

1
USB-043 (Ver.1.0)
Revision History
Date
Revision
Description
April 2, 2020 v1.0 Initial release
Introduction
Thank you very much for purchasing our product.
USB-043 is a USB 2.0 Full Speed(12Mbps) and Low Speed(1.5Mbps) compliant
isolator which isolates between a USB host and a USB peripheral device with
2500VDC. USB-043 can be used to built-in to the device for the board type. With
USB-043, it can be expected to eliminate ground loops that can cause measurement
errors and equipment from surges, common-mode voltage, static discharge,
magnetic fields, and radio frequency interference. There is no need to install any
drivers. It works with every operating system such as Windows, Linux, Mac OS X.

2
USB-043 (Ver.1.0)
1. Overview
2. Power Supply
USB-043 is powered through a USB port (Bus-powered).
USB Connector
(Host Side)
USB Connector (Target Side)
JP2
(Target Side)
JP1 (Host Side)
LED
(Bus-Power)

3
USB-043 (Ver.1.0)
3. SG/FG Separation Jumper (JP1, JP2)
You can change connection of SG (signal ground) and FG (frame ground).
JP1 Jumper (Host Side) SG-FG JP2 Jumper (Target Side) SG-FG
1-2 pin
Short
(Factory
Setting)
1-2 pin
Short
(Factory
Setting)
3-4 pin
Open
3-4 pin
Open

4
USB-043 (Ver.1.0)
4. Specifications
4.1. Product Specification
Item
Description
Remarks
Model
USB-043
Input Power
5VDC, Supplied through a USB
port (Bus-powered)
No external power supply
required
Current Consumption
Less than 100 mA + current of
the target device
Target device: 400mA max.
(Lower than the supply
capacity of the host side)
Host interface
USB 2.0 Compliant
(Supports Full and Low Speed)
USB 1.1 compatible
Hi Speed is not supported.
ESD protection
Isolation Method
Bus isolation
Isolation Protection
2500VDC Designed value
Support OS
OS-Independent
No drivers required
LED
PW: Power LED
USB Connector (Host)
Standard Type B Female High-retention connector
USB Connector (Target)
Standard Type A Female High-retention connector
Operating Ambient
Temperature
-20 to 60 °C
No condensation permitted
Operating Ambient
Humidity
30 to 85 %RH
Storage Ambient
Temperature
-20 to 60 °C
Storage Ambient
Humidity
30 to 85 %RH
Noise Tolerance
Not defined
Transmission and other
Standards
Not defined
Dimensions
63 x 40 [mm]
(2.480" x 1.575") Without projections
Weight
Approx. 20 [g] Only main body
* There may be cases that these parts and specifications are changed.

5
USB-043 (Ver.1.0)
4.2. Optional Accessories
Model
Description
ACC-024
Attachment A for panel mount
JAN：4937920801072
P112-M
USB Extension Cable for panel mount, type M
JAN：4937920800419
P112-S
USB Extension Cable for panel mount, type S
JAN：4937920800402
Sample image using ACC-024 (Attachment A for panel mount)

6
USB-043 (Ver.1.0)
5. Additional Documentation and User Support
The following documents and other supports are available at
https://www.hdl.co.jp/en/faspc/USB/usb-043
User’s Manual
… and more.
6. Warranty and Compensation
Please refer to the following URL for the warranty.
https://www.fa.hdl.co.jp/en/fa-warranty.html
