ENTOURAGE Quick Reference Guide Commonly Asked Questions

INSTRUMENT PANEL
01 02 03
04
06
05
08 09
07
1110 13 1514
16
17 1812
01 Driver Position Memory System
02 Power Seat Adjustment
03 Power Mirror Control
04 Fuel Lid Release
05 Steering Wheel Audio Controls
06 Headlights
07 Adjustable Pedals
08 Parking Brake Release
09 Hood Release
10 Cruise Control
11 Wiper / Washer
12 Tire Pressure Monitoring System (TPMS)
13 Automatic Transmission
14 Clock Adjustment
15 Occupant Classification System
16 Audio
17 Climate Control
18 Heated Seats

02 POWER SEAT ADJUSTMENT (if equipped)
ALUMBAR CONTROL
To manually adjust the lumbar support, move the lever to the
desired position.
BSEATBACK ANGLE
To recline the seatback, move the control forward or
backward.
CSEAT HEIGHT AND FORWARD / BACKWARD
To raise or lower the seat, raise or lower the
control switch. Raising / lowering the front of
the control will raise / lower the front portion
of the cushion. Raising / lowering the back of
the control will raise / lower the rear portion
of the cushion. Move the control switch
forward or backward to move the seat forward
or backward.
03 POWER MIRROR CONTROL
ADJUSTING
1. Move the select switch to
the right or left to activate the
corresponding mirror.
2. Adjust the mirror angle by
depressing the appropriate
perimeter switch as illustrated.
3. Place the select switch in the
middle position to deactivate the
perimeter switch.
INSTRUMENT PANEL FEATURES
01 DRIVER POSITION MEMORY SYSTEM (if equipped)
The Driver Position Memory System controls
are located on the driver’s side door trim.
MEMORIZING DRIVER POSITION
1. Place the shift lever into “P” while the
ignition switch is “ON.”
2. Adjust the driver’s seat, outside rearview
mirrors and adjustable pedal positions to
the desired position.
3. Push the “M” button on the control panel until the signal beeps.
4. Within five seconds, push button “1” or “2” until the signal beeps twice. The beep
confirms that the positions are successfully memorized.
TO ACTIVATE THE MEMORIZED POSITION
1. Place the shift lever into “P” while the ignition switch is “ON.”
2. When you push button “1” or “2,” the driving position will be automatically adjusted
to the position recorded for that button.
EASY ACCESS FUNCTION
When the auto button is “ON” (the indicator light illuminates) with the shift lever in
the “P” position, the system will move the driver’s seat forward or backward automati-
cally so you can comfortably enter and exit the vehicle.
See the Owner’s Manual for conditions in which the Driver Position Memory System will
not operate.
2
1
M
AUTO
LR
04 FUEL LID RELEASE
To open the fuel filler lid, push
the release button located on
the driver’s lower door.
2
1
M
AUTO
05 STEERING WHEEL AUDIO
CONTROLS (if equipped)
AMODE switch
BMUTE switch
CVOL ( ) switches
MODE
VOL
VOL
M
U
T
E

RES
ACCEL
ON
OFF
CANCEL
COAST
SET
08 PARKING BRAKE RELEASE
To release the parking brake, pull
the parking brake release lever
while applying the service brake.
11 WIPER / WASHER
AWIPER SPEED
The windshield wiper switch has four
positions: intermittent or AUTO (if
equipped), low speed, high speed
and mist. For mist (single
wipe), move the lever up
one position.
BINTERMITTENT WIPERS
With the windshield wiper
switch in the “INT” position, the interval
between wipes can be varied by turning the
intermittent wiper switch.
CWIPE / WASH OPERATION
To use the windshield washer, pull the wiper / washer lever toward you. The washer
continues to operate until the lever is released. When the washer is operated, the wipers
automatically make two passes across the windshield.
F
S
INT
MIST
OFF
OFF
ON
REAR
INT
INT
LO
HI
TIME
OFF
INT
MIST
LO
HI
ARESUME / ACCEL switch
BCANCEL switch
CCOAST / SET switch
DON / OFF SWITCH
(Pull to activate the system)
10 CRUISE CONTROL
D
OFF
ON
AUTO
OFF
A
B
07 ADJUSTABLE PEDALS (if equipped)
Turn the ignition key to the “ON”
position with the selector lever
in the “P” position and push the
switch.
If you move the portion of the
switch, the pedals move rearward.
If you move the portion of the
switch, the pedals move forward.
To unlatch the hood, pull
the release lever. The hood
should pop open slightly.
09 HOOD RELEASE
06 HEADLIGHTS
AHEADLIGHT SWITCH
To operate the headlights, turn the
switch on the end of the lever:
OFF – Headlights off
– Parking lights on
– Headlights on
AUTO – Auto Light (if equipped)
NOTE: The ignition must be in the
“ON” position to turn on the headlights.
HIGH BEAM ACTIVATION
Push the lever forward.
Flash-To-Pass Feature: Pull the lever towards you and release.
BFOG LIGHT SWITCH (if equipped)
Turn the switch to the “ON” position.
NOTE: Fog lights will only function on low beam.

There are three control
buttons for the digital
clock. Their functions are:
H: Push “H” to advance
the hours.
M: Push “M” to advance the minutes.
R: Push “R” to reset minutes to “:00.” Continue to press and hold the “R” button to
toggle between military time and standard time.
15 OCCUPANT CLASSIFICATION SYSTEM
PASSENGER AIR BAG OFF
INDICATOR
The indicator will illuminate
when you turn the ignition key
to “ON” or “START.” The light
will not illuminate when the
passenger’s airbag is enabled. Refer to the Owners’ Manual for a complete description
of this system. NOTE: The driver’s air bag and the driver’s side impact air bag are not
part of the occupant classification system.
14 CLOCK ADJUSTMENT
H
M
R
H
M
R
2:32
RADIO CONTROLS
01 POWER ON-OFF, VOLUME
Control
02 Band Select
03 AUDIO Select
04 TUNE Select/AUDIO Control
05 AUTO SEEK Select
06 SCAN
07 EQ or AUX
08 PRESET Station Select
CASSETTE CONTROLS
09 TAPE Program
10 Tape Eject
11 Auto Music Search (AMS)
12 FF/REW Button
13 Repeat (RPT)
14 Dolby
15 EQ or AUX
CD CONTROLS
16 LOAD
17 Playing CD
18 CD Eject
19 Track Up/Down
20 Scroll
21 FF/REW
22 EQ or AUX
23 CD SCAN
24 Bookmark (MARK)
25 Repeat (RPT)
26 Random (RDM)
27 Disc Up/Down
28 File Search
29 TUNE Select
30 Directory Search (DIR)
08
16 AUDIO (if equipped)
AM/FM radio with cassette and MP3 compatible 6 disc CD changer shown. See your
Owner’s Manual for information on available audio systems.
07 15
22
09
03
06
23
1424 30 2804 29 13
2625
12 211911
05
01
10
02
18
17
LOW TIRE PRESSURE INDICATOR: Illuminates if one or more of your tires is
significantly under-inflated.
LOW TIRE PRESSURE POSITION INDICATOR: Indicates which tire is significantly
under-inflated by illuminating the corresponding position light.
TPMS MALFUNCTION INDICATOR: Illuminates and stays illuminated when there
is a problem with the Tire Pressure Monitoring System.
12 TIRE PRESSURE MONITORING SYSTEM (TPMS)
13 AUTOMATIC TRANSMISSION
P
R
+
–
N
D
To select automatic mode, shift to “D.” To select “SPORTS” mode,
move the shift lever right to the manual shift gate. The instrument
cluster displays the selected forward gear. Refer to the Owner’s Manual
for detailed information. 20
1627

01 AUTO (Automatic Control)
02 Driver’s Temperature Control
03 A/C Display
04 Passenger’s Temperature Control
05 Dual Temperature Control Selection
06 Front Fan Speed Control
07 Mode Selection
08 Front Windshield Defrost
09 Recirculated Air Position
10 Rear Temperature Control
11 Rear Fan Speed Control
12 OFF
13 Air Conditioning
14 Rear Window Defrost
15 Outside Air Position
18 HEATED SEATS (if equipped)
The front seats can be electrically heated individually when the ignition switch is ON. When
the switch is ON, a number ranging from 1 to 5 is displayed on the switch (5 = warmest
setting). To turn off the seat warmer, set the switch to 0.
17 CLIMATE CONTROL (if equipped)
R
L
ADDITIONAL FEATURES
REAR SEAT ENTERTAINMENT SYSTEM (RSE) (if equipped)
01 Stop/Eject
02 Speaker Volume
Control
03 Play/Pause
04 Display
05 Forward
06 Reverse
07 Next Chapter
08 Previous Chapter
09 Enter
10 Menu
11 Source
12 AUX Button
13 RCA Input Jacks
CONNECTING OTHER DEVICES TO THE RSE SYSTEM
Electronic devices such as video game systems and video cameras can be connected to the
RSE system using the available RCA input jacks.
MENU
NEXT
ENT
PREV
FWDREW
DISP SRC /VOL
SPEAKER
D V D P L AY E R
–+
/
AUX
VIDEO
H-VIDEO-L
12
13
11 3 2
1
410
8
6 5
7
9
01
12
06 07
13
08
14
09
15 10
04 05
11
02 03

REMOTE KEYLESS ENTRY
POWER TAILGATE
(if equipped)
There are three ways
to open and close the
tailgate automatically:
• Overhead console
• Tailgate button
• Keyfob
NOTE: When the
power ON/OFF button
(PWR), located in the
overhead console, is
OFF (not depressed), the
power sliding door and
power tailgate cannot be
controlled with the sub-
control buttons or door
handles. However, the
doors can be controlled
with the transmitter or
the main control buttons
on the overhead console
even through the power
ON/OFF button (PWR) is
OFF (not depressed).
STOWING THE 3RD ROW SEAT
01 Lower the headrest to the
lowest position.
02 Fold the seatback by pulling out
the folding strap.
03 Pull the seat downward by using the
stowing strap.
04 Stow the seat by pushing down firmly.
ADJUSTING AND FOLDING THE 2ND ROW SEAT
01 Lower the headrest to the lowest position.
02 Move the seat to rearmost position.
03 Flip up the armrests.
04 Double-fold the rear seat forward by pulling up the seatback recliner lever.
05 Pull the folding strap out of the pocket located under the seat cushion. Lift the entire
folded seat forward and tie the folded seat to the assist handle using the strap.
01
02
04
03 04 05
A
B
CD
E
F
ALOCK
Press to lock all doors and arm the alarm. Press again
to hear a confirmation chirp.
BUNLOCK
Press to disarm the alarm and unlock the driver’s door.
Press again within four seconds to unlock all doors.
CLEFT SLIDING DOOR (if equipped)
Press to open or close the sliding door.
DRIGHT SLIDING DOOR (if equipped)
Press to open or close the sliding door.
EPANIC
Press to activate the horn and flashing lights for 30
seconds. Press again to turn off panic mode.
FPOWER TAILGATE (if equipped)
Press to open or close the tailgate.
01
02
03
04
OVERHEAD CONSOLE
TAILGATE
KEYFOB

TRIP
MPH
MPG
8 8 8888
MODE
RESET
CHILD-PROTECTOR REAR DOOR LOCK
To engage the child-protector feature so
that the door cannot be opened from the
inside, move the child-protector lever to
the “LOCK” position and close the door.
Move the lever to the “UNLOCK” position
when normal door operation is desired.
To open the door from the outside, pull
the outside door handle.
REAR CLIMATE CONTROLS
01 Rear fan speed
control knob
02 Rear mode
selection buttons
03 Rear temperature
control button
Set the rear fan speed control knob in
the front climate control panel to the “R”
position to allow the rear climate controls to be operated independently of the front climate
control system.
HEIGHT ADJUSTABLE SEAT SHOULDER
BELT (Front seat and 2nd row)
To adjust, press the button and raise or
lower the height adjuster to an
appropriate position.
01 02
03
SAFETY INFORMATION
SUNROOF CONTROLS (if equipped)
01 Slide button
02 Tilt button
03 Close button
01
02
03
POWER SLIDING DOORS (if equipped)
There are three ways to open and close the sliding doors automatically:
• Overhead console • Center pillar • Keyfob
OVERHEAD CONSOLE CENTER PILLAR BUTTON KEYFOB
HOMELINK®
The Homelink® Wireless Control System
that is integrated into the rearview mirror
provides a convenient way to replace up
to three hand-held radio-frequency (RF)
transmitters used for garage doors(s),
estate gates, home lighting, etc. with a
single built-in device.
To set or operate your Homelink®, refer
to your Owner’s Manual for detailed
instructions. Additional Homelink®
information can be found at:
www.homelink.com or by calling
1-800-355-3515.
TRIP COMPUTER
Pushing the MODE button when the
ignition switch is in the “ON” position
changes the display as follows:
Distance to empty (RANGE)
Driving time (ET)
Average fuel consumption (AVG)
Outside temperature
OFF
NOTE: When the power ON/OFF button (PWR) is OFF (not depressed), the power sliding
doors and power tailgate cannot be controlled with the sub control buttons or door handles.
However, the doors can be controlled with the transmitter or the main control buttons on
the overhead console even through the power ON/OFF button (PWR) is OFF (not depressed).
Also, the doors can be opened and closed manually by pulling the inside or outside
door handles.

NP150P7000 NP150 - P7000 02/06
MAINTENANCE
*All Units Displayed In Miles For Additional Maintenance Schedule Information See Your Owner’s Manual
Looking For More Detailed Information? This Quick Reference Guide does not replace your vehicle’s Owner’s
Manual. If you require additional information or are unsure of a specific issue, you should always refer to
the vehicle’s Owner’s Manual or contact your dealer.
Engine Oil & Filter Replace 7.5K Replace 3K
Fuel Lines, Fuel Hoses & Connections Inspect 7.5K
Vacuum Hose Inspect 7.5K
Vapor Hose & Fuel Filler Cap Inspect 7.5K
Suspension Mounting Bolts Inspect 7.5K
Steering Gear Box, Linkage & Boots/ Inspect 7.5K Inspect More Frequently
Lower Arm Ball Joint, Upper Arm Ball Joint
Climate Control Air Filter (For Evaporator & Replace every 12 Inspect More Frequently
Blower Unit) mos.
Or 10K”
Electronic Throttle Control Inspect 15K
Brake Hoses & Lines Inspect 15K
Brake Pads, Calipers & Rotors Inspect 15K Inspect More Frequently
Exhaust Pipe & Muffler Inspect 15K
Power Steering Pump, Belt & Hoses Inspect 15K
Drive Shaft & Boots Inspect 15K Inspect 7.5K
Air Conditioning Refrigerant Inspect 15K
Inspect 15K Inspect More Frequently
Air Cleaner Filter (Engine) Replace 30K
Inspect 15K
Fuel Tank Air Filter Replace 30K
Inspect 15K Replace 30K
Automatic Transaxle Fluid Replace 105K
Brake Fluid Inspect 30K
Drive Belt (Autotensioner, Alt, P/Str’g, Inspect 30K
A/con, W/Pump)
Rear Disc Brake/Linings, Parking Brake Inspect 30K Inspect More Frequently
Crankcase Ventilation Hose Inspect 30K
Fuel Filter Replace 37.5K
Coolant Replace 60K
Valve Clearance Inspect 60K
Spark Plugs (Iridium Coated) Replace 97.5K Replace More Frequently
Scheduled Maintenance Normal Usage Severe Usage
SALES COPY
Hyundai Owner Dealership Name Sales Consultant
Date Model Year Color VIN
QUICK REFERENCE GUIDE REVIEW
INSTRUMENT PANEL FEATURES
qDriver Position Memory System
qPower Seat Adjustment
qPower Mirror Control
qFuel Lid Release
qSteering Wheel Audio Controls
qHeadlights
qAdjustable Pedals
qParking Brake Release
qHood Release
qCruise Control
qWiper/Washer
qTPMS
qAutomatic Transmission
qClock Adjustment
qOccupant Classification System
qAudio
qClimate Control
qHeated Seats
ADDITIONAL FEATURES
qRear Seat Entertainment System
qAdjusting, Removing and Folding the 2nd Row Seat
qStowing the 3rd Row Seat
qRemote Keyless Entry
qPower Tailgate
qPower Sliding Doors
qRear Climate Controls
qSunroof Controls
qChild-Protector Rear Door Lock
qHeight Adjustable Shoulder Belt
qHomelink®
qTrip Computer
qMaintenance
MISCELLANEOUS ITEMS REVIEW
qCompass Calibration
qWarranty Chart
Sales Consultant Date Sales Manager Date
Customer Date
