LOOKING FOR MORE INFORMATION
ThisQuickReferenceGuide does not replaceyour
System Owner’s Manual.
If you require additional information or are unsure
of a specific issue, please refer to the System
Owner’s Manual.
Functional introduction
System components . . . . . . . . . . . . 2
Controller functions . . . . . . . . . . . . . 2
Main function buttons. . . . . . . . . . . . 3
Function buttons on the steering wheel 3
Basic operations . . . . . . . . . . . . . . . 4
Audio settings . . . . . . . . . . . . . . . . . 4
FM and AM mode
HD Radio (TM) information . . . . . . . 6
Tuning to stations. . . . . . . . . . . . . . . 6
Storing stations . . . . . . . . . . . . . . . . 7
XM Satellite Radio mode
XM Satellite Radio information. . . . . 8
Tuning to channels. . . . . . . . . . . . . . 8
Storing channels . . . . . . . . . . . . . . 10
Settings . . . . . . . . . . . . . . . . . . . . . 10
Disc mode
Loading/ejecting a disc . . . . . . . . . 11
Audio disc playback. . . . . . . . . . . . 11
Video DVD playback . . . . . . . . . . . 13
AUX mode
Connecting a device . . . . . . . . . . . 15
AUX and iPod®menu . . . . . . . . . . 15
iPod®and USB functions. . . . . . . . 16
Phone
Pairing a mobile phone . . . . . . . . . . 18
Connecting a mobile phone. . . . . . . 18
Initiating/canceling a call . . . . . . . . . 19
Phonebook. . . . . . . . . . . . . . . . . . . . 19
Navigation
Navigation main menu. . . . . . . . . . . 20
Entering destinations. . . . . . . . . . . . 20
After entering the destination. . . . . . 22
During route guidance . . . . . . . . . . . 23
Audible driving recommendations . . 23
Destination memory. . . . . . . . . . . . . 24
Settings menu . . . . . . . . . . . . . . . . . 24
Map functions . . . . . . . . . . . . . . . . . 25
Voice control
General information. . . . . . . . . . . . . 26
Operating picklists . . . . . . . . . . . . . . 26
Example FM/AM . . . . . . . . . . . . . . . 26
Example Phone . . . . . . . . . . . . . . . . 26
Command overview. . . . . . . . . . . . . 27
Info
Info main menu . . . . . . . . . . . . . . . . 28
Rear camera
General operation . . . . . . . . . . . . . . 28
Table of contents
Functional introduction

2
Functional introduction
System components
Headunit
The headunit is located in the
vehicle dashboard.
Display
The display is located in the
vehicle dashboard. It does
not have any controls.
Central control panel
The central control panel is
located in the front in the
vehicle center console. It
comprises the controller and
the main function buttons.
Controller functions
You can push, turn and press
the controller ".
Pushing the controller
웇Push (): Switching
between the areas in a
main menu.
웇Push *+ : Scrolling
through a list page by
page, or selecting a menu
item
웇Push *+ () ,-:
Moving the map
Turning the controller
Turn to the left or right '&:
Selecting a menu item
Pressing the controller
Press ": Confirming the
selection
Press !:Switching off /on
Turn !:Setting the volume
Disc slot
Ejecting a disc
 Loading a disc
Front display
Main function buttons
Controller
Functional introduction

3
Functional introduction
Main function buttons


Switching to FM or AM
mode and switching radio
band


Short press:
Going back one menu level
Long press:
Opening the main menu for
the active main function


웇Calling up the map
displayandswitchingto
navigation mode
웇 Repeating an audible
driving recommendation
Function buttons on the
steering wheel
<
Activating/deactivating the
voice control system

/
웇Opening the Phone
main menu
웇Using redial
웇Accepting/rejecting an
incoming call
웇Ending a call
웇Swapping between two
calls



Opening the Navigation
main menu


웇Opening the Info main
menu
웇Opening the Phone
main menu


웇Switching to disc mode
웇During video playback,
press and hold 
until the Disc main
menu appears.
웇SwitchingtoAUXmode
(e.g. iPod, USB stick)
and opening the AUX
main menu
웇Press .


Switching to XM®Satellite
Radio mode.
3and 4
웇Tuning to a station via
the presets or via a
search (FM or AM)
웇Tuning to a channel via
the channel list (XM®
Satellite Radio)
웇Selecting discs
웇Fast forwarding/
reversing: USB
memory stick, iPod®
웇Skipping chapters
forward/back: video
DVD
웇Skipping tracks
forward/back: Audio
disc, Video CD, iPod®,
USB

1and 2
Setting the volume

0
웇Switching mode
웇Switching private mode
on/off (phone)
웇Switching audio/video
playback on/off


4
Functional introduction
Basic operations
Selecting a menu item
왘Turn "'& or push "
*+ until the desired
menu item is highlighted.
왘To confirm a selection:
Press ".
Opening the Options menu
왘With the content area
active (blue frame
around), push "once ).
You can now select and
confirm further menu items.
Switching between the areas
왘Push "repeatedly ()
.
Scrolling through a list page
by page
왘Push "repeatedly +/ *.
Closing a menu
왘Push "once (, or
press .
Audio settings
Opening the Audio Settings
menu
왘In a main menu (here
Disc), select
Settings .
왘If an audio/video
selection menu is
displayed, select
Audio .
Setting the balance/fader
왘In the Audio Settings
menu, select
Balance/
Fader
.
왘To switch between
Balance and Fader,
press ".
The previously inactive
function is now active.
왘To set a value:
Turn "'& until the
desired setting is
reached.
The system saves the
setting automatically.
Main menu, content area and
Options menu
Main menu
Content area (blue frame =
menu is active)
Selected menu item in the
content area
I왘: Options menu is available
웇: currently selected station
Main menu
Top status line
Content area
Options menu
Highlighted menu item in the
Options menu
Bottom status line
Top status line
Currently active main function
Currently active entertainment
source
Preset of the currently selected
station in the presets
Frequency of the currently
selected station
Indicator for stereo reception
Scale for the fader setting
Fader indicator
Balance indicator
Scale for the balance setting
All menus must have "HD Seek &
Scan", "HD off" and "RDS off"

5
Functional introduction
Setting the treble/mid/bass
왘In the Audio Settings
menu, select
Treble/Mid/
Bass
.
The Treble/Mid/Bass
menu is displayed in the
content area.
왘Activating a scale:
Press "or push "
repeatedly *+ until the
desired scale is active.
왘To set a value:
Turn "'& until the
desired setting is
reached.
The indicator moves
accordingly on the scale,
showing you the setting.
Setting the equalizer
왘In the Audio Settings
menu, select
EQ Presets .
In the content area, the
Equalizer menu is
displayed.
왘To activate a preset:
Select the desired preset.
The Equalizer menu is
automatically closed after
a short time.
Switching surround on/off
왘In the Audio Settings
menu, select
Surround .
Depending on the
previous status, the
function will be switched
on or off.
= function switched off
= function switched on
Scale for the treble setting
Scale for the mid setting
Scale for the bass setting
Treble indicator
Mid indicator
Bass indicator
Highlighted menu item
: currently active preset
: currently inactive preset
Status display
Menu item Surround
FM and AM mode

6
FM and AM mode
HD Radio (TM) information
 The Driver Information
System is able to receive
standard analog FM/AM radio
broadcasting as well as digital
HD Radio
TM
FM/AM
broadcasting.
HD RadioTM is a technology
to carry digital broadcasting
as well as analog one using
existing FM and AM
broadcasting frequencies.
HD RadioTM is available in
the United States, including
Alaska and Hawaii.
Opening the FM or AM main
menu or switching bands
왘Press .
Tuning to stations
Tuning to a station via the
station list
왘Press .
왘Select Strong Stations .
The station list appears.
왘Totune toa station: Select
the desired station in the
station list.
Tuning to a station via the
Scan function
왘Press .
왘Select Presets .
The presets appear.
왘To open the Options
menu: Push "once ).
The Options menu
appears.
왘To start the Scan function:
Select
Scan .
왘To stop the Scan function
manually: Press ".
Currently active main function
Highlighted main menu item
Currentlyactiveentertainment
source
Preset of the currently tuned
station in the presets
If transmitted name of the
tuned station, else frequency
Indicator for HD RadioTM
reception
 Iftransmittedsongtitlecurrently
playing (only HD Radio
TM
)
Main menu (not with analog AM)
웇: currently tuned station
Options menu
Menu item Scan
FM and AM mode

7
FM and AM mode
Tuning to a station via manual
tuning or a search
왘Press .
왘Select Tune & Seek .
The indicator shows
either
HD, HD 1 , HD 2 , MHz or
kHz .
왘To tune manually:
Turn "'&.
The frequency increases
or decreases, depending
on the direction of
rotation.
왘To search: Push "*+.
The seek proceeds
upwards or downwards
and stops at the next
receivable station.
Storing stations
왘Tune to a desired channel
왘In the FM or AM main
menu, select
Presets .
The presets appear.
왘To select a preset:
Turn "'&
until the
desired preset number is
highlighted .
왘To store the currently
tuned station in the
selected preset: Press
and hold "until the
station is stored.
Screenshot needed, frequency
indicator must be highlighted,
System must be tuned to a HD Radio
with a sub channel (multicasting
station)
Frequency indicator (shows
the currently tuned frequency)
Indicator.
Tuning to a station via the
presets
왘Press .
왘Select Presets .
The presets appear.
왘Totune toastation: Select
the desired station in the
list.
Presetnumber ofthecurrently
tuned station
웇: currently tuned station
Presets
XM Satellite Radio mode

8
XM Satellite Radio mode
XM Satellite Radio
information
 XM
®
Satellite radio offers the
reception of a wide range of
programs, e.g. music, sports,
news - all in digital quality.
XM
®
Satellite Radio is
available in the United States
(including Alaska and Hawaii)
and Canada.
Opening the XM®Satellite
Radio main menu or
switching bands
왘Press .
Tuning to channels
왘Press .
왘Select
Presets .
왘To tune to a channel:
Select the desired
channel in the presets.
왘To show details of the
currently tuned channel:
Highlight the currently
tuned channel in the
presets.
왘Push "once ).
The Options menu
appears.
왘Select
Details .
You will see the details
screen.
Screenshot is needed, menu item
"Presets" must be highlighted.
Currently active main function
Highlighted main menu item
Currentlyactiveentertainment
source
Preset of the currently tuned
channel in the presets
Channel name or number of
the currently tuned channel
(depends on the "Setting")
Indicator for XM®Satellite
Radio reception
If transmitted song title
currently playing
Main menu
Screenshot is needed, the first
channel in the presets must be
highlighted and tuned.
Presetnumber ofthecurrently
tuned channel
웇: currently tuned channel
Screenshot is needed, menu item
"Details" must be highlighted.
Options menu
Menu item Details
XM Satellite Radio mode

9
XM Satellite Radio mode
Tuning to a channel via the
Scan function
왘Press .
왘Select Presets .
The presets appear.
왘To open the Options
menu: In the presets
push "once ).
The Options menu
appears.
왘To start the Scan function:
Select
Scan .
왘To stop the Scan function
manually: Press ".
Picture has the same content as the
one on page 12, middle column
Presets
Tuning to a channel via
channel number input
왘Press .
왘 Select Direct Tune .
The number of the
currently tuned channel is
displayed.
왘To enter the digits:
Turn "'& until the
desired digit is displayed.
왘After that, press ".
After entering three digits
in this way, the system
tunes to the
corresponding channel.
-Digits of the channel
number (first is highlighted)
Channel related information
Tuning to a channel via the
channel list
왘Press .
왘Select Channel List .
The channel list appears.
왘To tune to a channel:
Select the desired
channel in the channel
list.
왘To show details of the
currently tuned channel:
Highlight the currently
tuned channel in the
channel list.
왘Push "once ).
The Options menu
appears.
왘Press ".
You will see the details
screen.
Tuning to a channel via the
category list
왘Press .
왘Select Category List .
The category list appears.
First category in list be highlighted.
Category list
왘Select the desired
category.
A channel list appears.
왘
Select the desired channel.
왘To show details of the
currently tuned channel:
Highlight the currently
tuned channel in the
channel list.
왘Push "once ).
왘In the Options menu,
press ".

10
XM Satellite Radio mode
Storing channels
왘Tune to a desired channel
왘In the XM®Satellite Radio
main menu, select Presets .
The presets appear.
왘To select a preset:
Turn "'& until the
desired preset number is
highlighted.
왘To store the currently
tuned station in the
selected preset: Press
and hold "until the
station is stored.
Settings
The XM®Radio settings
include the following
functions:
웇Setting the display in the
upper status line
웇Setting the category filter
for the channel list
웇Showing the Radio ID
number
Opening the XM®Radio
settings menu
왘Press .
왘Select Settings.
The Settings menu
appears.
왘Select XM Radio.
The XM®Radio settings
menu appears.
Tuned channel must not be stored in
the presets. All channel memories
must be occupied. The sixth station
must be highlighted, see example
picturebelowfromtheFM/AMchapter.
Currently tuned channel
웇: currently tuned channel
It must match with screenshot above
Options menu
Menu item "XM Radio" must be
highlighted
Settings menu
Menu item "Display by CH number"
must be highlighted.
XM®Radio settings menu
Disc mode

11
Disc mode
Loading/ejecting a disc
 The Driver Information
Systemfeaturesa built-in disc
changer magazine with six
compartments.
Loading a disc
왘Briefly press .
The system will prompt
you to insert a disc with
the message
Please insert
Disc
.
왘Insert a disc into the slot.
Ejecting the last disc played
왘
Briefly press  .
The system will eject the
disc last played.
왘
Remove the disc from the
slot
.
Audio disc playback
Opening the Disc main menu
 At least one disc must be
loaded.
왘Press once or twice
until the Disc main menu
appears.
Selecting and playing discs
왘Selectanaudiodiscinthe
list of discs in the Disc
main menu.
Pausing or resuming
playback
왘In the Disc main menu,
highlight the track
currently playing and
press ".
The system will pause or
resume playback,
depending on the
previous status.
= pause
= play
Press !:Switching off /on
Turn !:Setting the volume
Disc slot
Ejecting a disc
 Loading a disc
Occupied magazine
compartments
Disc main menu
 Empty magazine compartments
Mode display
 Disc main menu with list of discs
Disc icon
Track currently playing
Track list of the disc currently
playing (MP3: or folder list)
Name of the disc currently
playing
  : track currently playing
(MP3: or current folder)
Disc currently playing
Icon for the disc
: disc currently playing
Disc mode

12
Disc mode
Fast forwarding/reversing
왘In the Disc main menu,
highlight any track and
push "once ).
왘To start forwarding/
reversing: Select
FF or
REW . Then press and
hold ".
왘To terminate forwarding/
reversing: Release ".
Repeating tracks or folders
왘Highlight the desired
track or folder.
Push "once ).
왘Select
Repeat Track or
Repeat Folder .
= function switched off
= function switched on
Random play
Switchingrandomplayof
all tracks on/off
왘Highlight the track
currently playing.
왘Push "once ).
왘Select
Random Disc .
= function switched off
= function switched on
Scan function
왘Highlight the track from
which you want the
function to start.
왘Push "once ).
왘Select
Scan .
Options menu
Folder
Highlighted track
Track
Highlighted track currently
playing.
Status display
Options menu

13
Disc mode
Video DVD playback
Switching to disc mode and
starting video DVD playback
 At least one DVD must be
loaded.
왘Press once or twice
until the Disc main menu
appears.
왘To play a disc: Select a
video DVD in the Disc
main menu.
Opening Disc main menu
during video playback
왘Press and hold 
until
the Disc main menu
appears
.
왘To return to the video full-
screen display:
Press .
Opening the native DVD menu
왘During video playback,
press .
The native DVD menu
appears, see page 14.
Audio and Video Settings
왘In the Disc main menu,
select Settings .
An audio/video selection
menu appears with the
following menu items:
웇
Audio
Please see page 4.
웇
Video
In the Video Settings
menu, you can select
Aspect Ratio , Brightness ,
Color , Contrast or Reset
Video Settings.
웇 Menu Language .
왘Call the desired function
and turn "'& until the
desired setting is
reached.
The system saves this
setting automatically.
왘To close a menu:
Press ",
or press  .
Mode display
Disc main menu with list of
discs
Disc icon
Chapter currently playing
Content area with native DVD
menu
Name of the disc currently
playing
Open the Settings menu
Disc currently playing
Icon for a video DVD
: disc currently playing
Selection menu
Video settings menu

14
Disc mode
Native DVD menu
The native DVD menu
includes the following
functions:
웇Returning to video full-
screen display
웇
DVD top menu/DVD menu
which is part of the DVD
itself.
웇Chapter list
웇Selecting titles
웇On-screen menu
웇Switching audio track
웇Switching viewing angle
Example: Selecting titles
왘
In the native DVD menu,
select Title List .
The title list appears.
왘Select the desired title or
movie.
On-screen menu
왘During video playback,
press ".
The on-screen menu will
be shown over the video
currently playing.
Pausing or resuming playback
왘Select .
The system will pause or
resume playback,
depending on the
previous status.
Skippping chapters forward/back
왘Select or .
The chapter list will be
shown over the video
currently playing.
Fast forwarding/reversing
왘Select or , then
press and hold ".
왘To terminate fast
forwarding/reversing,
release ".
Native DVD menu
Icon 웇for chapter currently
playing
Icon 웇for title currently playing
 Depending on the content of the
DVD currently playing, certain
menu items may have no
function even though they are
displayed.
Pause/resume playback
Skip chapter back
Skip chapter forward
Open the native DVD menu
Close the on-screen menu
Call up the chapter list
Fast reverse
Fast forward
Showstheselectedmenuitem
- 
AUX mode

15
AUX mode
Connecting a device
Connecting an iPod®
왘Connect an iPod®.
Playback will start with the
first track in the "Songs"
category.
Connecting an USB
왘
Connect an USB memory
stick containing audio files.
Open the AUX main menu
and, if necessary, select the
USB stick as the signal
source.
Starting playback:
see
page 16.
Connecting an AUX source
왘Connect an AUX (audio/
video) signal source.
왘If necessary, select the
desired signal source in
the AUX main menu.
왘Start playback on the
AUX signal source.
AUX and iPod®menu
Opening the AUX main menu
왘Press once or twice
until the AUX main menu
appears.
Opening/closing the AUX
main menu during playback
왘To show the AUX main
menu : Press .
왘 ToshowtheAUXfull-screen
display : Press .
Opening the iPod®menu
왘Push "()until the
content area is active
(blue frame).
왘Press repeatedly
until the iPod®menu
appears.
3,5 mm (0.14") jack socket
USB socket
Mode display
AUX main menu with list of
signal sources
AUX icon
Track currently playing
Content area with track list
(Blue frame = area active)
Name of the album currently
playing
Play icon for the track
currently playing
AUX mode

16
AUX mode
iPod®and USB functions
Navigating within the iPod®
menu and selecting a track
왘Forward: Select a menu
item in the iPod®menu.
왘Backwards: Press .
왘Select the desired track.
Navigating within the USB
menu and selecting a track
왘Select the desired folder.
You will see the tracks
stored in this folder.
왘To play a track: Select the
desired track.
왘To switch to the next
folder level up: Select .
Pausing or resuming
playback
왘Highlight the track
currently playing and
press ".
The play icon or the
pause icon shows the
corresponding status.
Fast forwarding/reversing
왘Highlight any track and
push "once ).
왘To start forwarding/
reversing: Select
FF or
REW . Then press and
hold ".
왘To terminate forwarding/
reversing: Release ".
iPod®menu
Menu item for the folder
change function
Folder
 Icon  for track currently playing
Track
Highlighted track
Mode display
AUX main menu with list of
signal sources
Aux icon
Track currently playing
AUX content area with track/
folder list
Name of the currently active
folder
Play icon for the track
currently playing
Options menu

17
AUX mode
Skipping tracks forward/back
왘On the steering wheel,
briefly press 3or 4.
Repeating tracks or folders
 Repeating folders is only
available for USB.
왘In the USB or iPod®
menu, highlight the
desired track or folder
and push "once ).
왘To switch the function on/
off: In the Options menu,
select
Repeat Track or
Repeat Folder .
= function switched off
= function switched on
Scan function (only USB)
왘Highlight the track from
which you want the
function to start.
왘To open the Options
menu: Push "once ).
왘To switch the function on/
off: In the Options menu,
select
Scan .
Random play (only USB)
왘Random play of all tracks:
Highlight the track
currently playing.
왘Random play within a
specific folder: Highlight
the desired folder.
왘Push "once ).
왘In the Options menu,
select
Random Disc or
Random Folder .
= function switched off
= function switched on
Folder
Highlighted track
Track
Status display
Options menu
Play icon for track currently
playing
Highlighted folder
Phone

18
Phone
Pairing a mobile phone
 A precondition for pairing and
connectingisthat
Bluetooth
®
is activated on the mobile
phone.
왘 Press  until the Phone
main menu appears.
왘Select Connect Phone .
The device list appears.
왘Select
Pair Phone .
The Bluetooth®name of
the Driver Information
System is
GENESIS , it is
displayed under this
name on the mobile
phone.
왘Start pairing on the
mobile phone. When
prompted, enter the
passkey "1234".
The system will start the
process of connecting
with the mobile phone.
= No connection
= A mobile phone is
connected
Connecting a mobile
phone
After the system is switched
on, it automatically attempts
to reconnect with the last
mobile phone connected.
The following conditions
must be met for this:
웇The mobile phone is
switched on and is within
the reception range of the
system.
웇The mobile phone is still
paired with the system.
웇Bluetooth®is activated on
the mobile phone.
웇In the Settings menu,
Bluetooth Autoconnect is
activated = 
Opening the Phone main menu
왘Press once or twice
until the Phone main
menu appears.
Icon = Mobile phone is
paired with the system and
currently connected
Icon = Mobile phone is
pairedwith thesystem, butnot
currently connected
Phone name
Device list
Icon for the connection status
Bluetooth®name of the
Driver Information System
Passkey
Remainingtimeforentryofthe
passkey
Phone main menu
Phone

19
Phone
Initiating/canceling a call
Entering a phone number
왘Open the Phone main
menu.
왘Select
Dial Number .
The input menu appears.
This has two user-control
areas: The area with the
predictive speller and
the area with , and
.
왘To move from one area to
another: Push "*+.
왘To enter a number: In the
predictive speller,
highlight a digit by
turning "'& and
press ".
The digit is entered and
appears in input field .
왘To initiate a call:
From the predictive
speller, push "+and
select
CALL .
왘To cancel a call: Press ".
Phonebook
Calling up the phonebook
왘In the Phone main menu,
select
Phone Book .
The phonebook appears.
The following functions are
now available:
웇Creating a new entry
웇Editing an entry
웇Searching for an entry
웇
Displaying details on an
entry
웇Initiating a call to an entry
웇Deleting an entry
Search for an entry
Maximum number of entries
Existing entries
Create a new entry
Input field
Predictive speller
Enlarged display of the
currentlyhighlightedcharacter
in the predictive speller 
Initiate a call
Store number in the
phonebook
Delete individual digits
Delete a complete entry
Currently highlighted
character
Menu item END
Display during a call
Using call lists
왘In the Phone main menu,
select one of Missed Calls ,
Received Calls or Dialed
Numbers
.
The appropriate call list
appears.
왘To initiate a call: Select
the desired entry in the
call list.
Accepting/rejecting an
incoming call
The call menu is displayed
when there is a call
incoming.
왘Select
Accept or Reject .
When you accept the call
you conduct it over the
hands-free unit.
Ending a call
In the call menu, select
END .
Navigation
