Hyundai i10 2019 Technical manual

INDEX - VICS(VEHICLE INSTRUCTION CARD)
HYUNDAI VEHICLES
Page Vehicle Details
1Index n/a
2Supplement (Electronic Parking Brake, etc) n/a
3i10 5 seats / 5 door hatchback
4i20 5 seats / 3 door hatchback
5ix20 5 seats / 5 door hatchback
6i30 5 seats / 3-5 door hatchback / estate
7i40 5 seats / 4 door saloon / 5 door estate
8Kona 5 Seats / 5 door SUV / 2x4 or 4x4
9Tucson 5 Seats / 5 door SUV / 2x4 or 4x4
10 Ioniq 5 seats / 5 door hatchback hybrid
11
12
13
14
15
16
17
18
19
20
INDEX PAGE 1

LOCATION
The diagrams above indicate example locations of the electronic parking brake (A) which is labelled with the universal icon symbol:
ACTIVATION
The EPB will normally auto activate. If will also activate if seat belts are not being worn, or when luggage placed on top of seats activates the system. To
enable the system to function correctly, fasten seatbelts, and remove luggage from the seats and store it securely in the boot. Pull the switch labelled A to
manually apply the parking brake. The warning lamps on both the switch and instrument panel will light up to confirm its activation.
DEACTIVATION
The EPB will normally auto release. Depress the brake or accelerator pedal to auto release it, or press the switch (A) to manually release it. The
associated warning lamps on both the switch and dashboard instrument panel will go out to confirm its deactivation. Note: seatbelts should be fastened,
and luggage should not be placed on seats.
WHEN DRIVING AWAY
The parking brake will deactivate automatically when driving away, and it also prevents the vehicle from rolling back unintentionally for a few seconds
when starting on a gradient. This works by driving off in a normal way, the parking brake will automatically release and the vehicle will start moving in the
desired direction.
On vehicles fitted with an automatic gear box, you can apply the parking brake when stopping briefly at traffic lights etc., to avoid the vehicle creeping
forward. When you drive off the parking brake will be automatically released.
INFORMATION
Vehicle specifications are subject to change. This vehicle does not include any manufacturer handbooks or manuals.
VEHICLE INSTRUCTION CARD SUPPLEMENT
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
HYUNDAI VEHICLES
Where fitted, the electronic parking brake replaces the mechanical handbrake and is designed to prevent the vehicle from accidently rolling away. This
system offers convenience and safety features in addition to those normally associated with a mechanical handbrake. Please refer to the primary Vehicle
Instruction Guide for information about other operational instructions.
06-05-2017
ELECTRONIC PARKING BRAKE (EPB)
Don’t panic! Despite seeing a new light pop-up on your instrument panel, unless it is red it is likely the car is still running fine, and while there may be a
problem to attend to, proceed with confidence and patience.
RED indicates a potentially serious problem or safety issue. Attend to it! Red may also indicate an important reminder.
YELLOW or orange means something needs to be serviced or repaired soon. If it is flashing, it is important that you contact your rental agent for advice.
GREEN or blue is only telling you that a system is on or operating normally.
WARNING LIGHTS AND WHAT THEY MEAN
Deadlock / safelock messages shown on the instrument display when the engine is turned off simply indicate that once you exit the vehicle and lock the
doors, they’re effectively deadlocked and anyone left in the car wouldn’t be able to get out in the event of an emergency. The warning is nothing to worry
about and is just a standard advisory message.
DEADLOCKS
A seatbelt warning light may illuminate when the engine is turned on. This may mean that the electronic parking brake (EPB) becomes auto activated to
prevent vehicle movement. To deactivate these warning lights, and turn off the auto activation of the EPB in this instance, ensure all passengers fasten
their seatbelts, and remove any luggage from on top of the seats. For safety secure all luggage inside the boot.
SEATBELT WARNING LIGHTS
Unless indicated otherwise by road traffic signs and/or local road regulations and/or dictated by weather conditions, the Highway Code states that
provided always it is safe to do so, a passenger vehicle may be driven at the following MAXIMUM speeds (MPH):
DRIVING RESTRICTIONS AND/OR CONDITIONS
Drivers are reminded that they are responsible for the consequences arising out of their failure
to comply at all times with the requirements of any applicable Road Traffic Regulations, the
Highway Code and/or to the road conditions prevailing at the time and in the locality through
which they are driving the vehicle.
Europcar accepts no responsibility or liability for any costs, claims, penalties, fines or any other
circumstances arising out of or in connection with the driver’s failure to comply with all and any
road restrictions and/or conditions.

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
HYUNDAI i10 5 SEATS
5 DOOR HATCHBACK
Key / remote control operated central high security dead locking. Depress the central locking switch to lock the doors from
the inside. Auto door locking on vehicle motion.
Remote anti-theft alarm. Passive arming of electronic engine immobiliser after removal of the key from the starter switch.
Centrally locked. Use the key or remote control to unlock / open. Pull the release handle to open.
Electric adjustment operated by the control pad on the driver’s door.
Electric front and rear operated via control buttons on the driver’s door.
If fitted: Electric tilt / slide sunroof operated by roof mounted switchgear.
Located on the edge of the rear doors, slide the door locking lever on the edge of the door to activate it. Or press the central
locking switch on the centre console. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral (or N or P if automatic) and handbrake is on. Place ignition key in starter switch. Use a
normal starting routine. Select desired gear. Release handbrake and brake pedal and gently press the accelerator to move
the vehicle. Some vehicles feature automatic engine stop/start - the engine will switch off when vehicle is stationary, gears
are in neutral and foot pedals are not depressed - engine instantly restarts when a foot pedal is depressed.
Located under a flap on the rear offside. Centrally locked. Lightly press the edge of the flap to open it, and twist off the fuel
cap anticlockwise.
Pull bonnet release lever located under the steering wheel column. Unhook catch under bonnet.
The rear seat is divided into 60:40 sections which can be folded separately. To release the seat press the seat unlocking
catch and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock.
Check it is locked before using the seat.
Vehicle is not normally supplied with a spare wheel or tyre repair kit. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999. Lift the carpet cover in the boot to access the storage housing the tools and jack,
lift out this tray to reveal the spare wheel Release the wheel by turning the retaining bolt anticlockwise. Move the vehicle to
firm / level ground. Turn the engine off, select first gear (manual) or P (automatic). Apply the handbrake. Loosen the wheel
nuts (do not remove them). Only use the specific reinforced jack points on the underside of the vehicle. Crank the jack to lift
the vehicle. Undo wheel nuts and change the wheel. Lower the vehicle. Tighten the wheel nuts.
Select N for neutral, P when leaving the vehicle, R for reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select D where the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration
point forcing the transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator
to return to normal accelerator use). Select the D+ or D- options to manually select gears. Whenever the vehicle is at a
standstill apply the handbrake.
VIC-HYU-01 / 14-04-2019
Locking the doors?
Anti-theft system?
Opening boot/tailgate?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an automatic?
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
40.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
175/65 R14
185/55 R15
Note: driving speeds and travel distances
are restricted when using spacesaver
spare tyres.
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
14 Hand brake
Tilt
Lumbar
Legroom
Height
10
3
1
11
7 / 8
2
or
4 / 5 / 6 / 12 / 13
9
1 3 5
2 4 R
P
R
N
D
14
+
-

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
HYUNDAI i20 5 SEATS
3-5 DOOR HATCHBACK
Key / remote control operated central high security dead locking. Depress the central locking switch on the driver’s door to
lock the doors from the inside. Auto door locking on vehicle motion.
Remote anti-theft alarm. Passive arming of electronic engine immobiliser after removal of the key from the starter switch.
Centrally locked. Use the key or remote control to unlock / open. Pull the release handle to open.
Electric adjustment operated by the control pad on the driver’s door.
Electric front operated via control buttons on the driver’s door.
If fitted: Electric tilt / slide panoramic sunroof operated by roof mounted switchgear.
Ensure gear selector is in neutral and handbrake is on. Place ignition key in starter switch. Use a normal starting routine.
Select desired gear. Release handbrake and brake pedal and gently press the accelerator to move the vehicle.
Located under flap on rear nearside. Centrally locked. Release it using the internal remote release. Press the edge of the
flap to open it, and twist off the cap anticlockwise.
Pull bonnet release lever located under the steering wheel column. Unhook catch under bonnet.
The rear seat is divided into sections which can be folded separately. To release the seat press the seat unlocking catch and
fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock. Check it is
locked before using the seat.
The vehicle is not normally supplied with a spare wheel or tyre repair kit. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call
the Europcar Tyre Helpline 0800 0280 999. Lift the carpet cover in the boot to access the storage tray housing the tools
and jack, lift out this tray to reveal the spare wheel. Release the wheel by turning the retaining bolt anticlockwise. Move the
vehicle to firm / level ground. Turn the engine off, select first gear (manual) or P (automatic). Apply the handbrake or parking
brake. Loosen the wheel nuts (do not remove them). Only use the specific reinforced jack points on the underside of the
vehicle. Crank the jack to lift the vehicle. Undo wheel nuts and change the wheel. Lower the vehicle. Tighten the wheel nuts.
Select N for neutral, P when leaving the vehicle, R for reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select D where the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to
return to normal accelerator use). Whenever the vehicle is at a standstill apply the handbrake.
VIC-HYU-02 / 11-02-2018
Locking the doors?
Anti-theft system?
Opening boot/tailgate?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an automatic?
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
50.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
185/65 R15
195/55 R16
205/45 R17
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
Tilt
Lumbar
Legroom
Height
10
3
11
1
7 / 8
2
4 / 5 / 6 / 12 / 13
9
R 1 3 5
2 4 6
3 door: Tilt front seats to access
rear seats
P
R
N
Dor

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
HYUNDAI ix20 5 SEATS
5 DOOR HATCHBACK
Key / remote control operated central high security dead locking. Depress the central locking switch on the driver’s door to
lock the doors from the inside. Auto door locking on vehicle motion.
Remote anti-theft alarm. Passive arming of electronic engine immobiliser after removal of the key from the starter switch.
Centrally locked. Use the key or remote control to unlock / open. Pull the release handle to open.
Electric adjustment operated by the control pad on the driver’s door.
Electric front and rear operated via control buttons on the driver’s door.
If fitted: Electric tilt / slide panoramic sunroof operated by roof mounted switchgear.
Located on the edge of the rear doors, press the central locking switch to activate child proof locks. Check from inside that
the doors are securely locked.
Ensure gear selector is in neutral (or N or P if automatic) and handbrake is on. Place ignition key in starter switch. Use
a normal starting routine. Some vehicles also feature automatic engine start/stop technology - whereby the engine
automatically shuts off when vehicle is not moving, gears are in neutral and foot pedals are not depressed - engine instantly
restarts on depression of the clutch (or accelerator pedal for autos). Select desired gear. Release handbrake and brake
pedal and gently press the accelerator to move the vehicle.
Located under a flap on the rear nearside. Centrally locked. Lightly press the edge of the flap to open it, and twist off the fuel
cap anticlockwise.
Pull bonnet release lever located under the steering wheel column. Unhook catch under bonnet.
The rear seat is divided into 60:40 sections which can be folded separately. To release the seat press the seat unlocking
catch and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock.
Check it is locked before using the seat.
Vehicle is not normally supplied with a spare wheel or tyre repair kit. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999. Lift the carpet cover in the boot to access the tools and jack, and the spacesaver
spare wheel. Release the wheel by turning the retaining bolt anticlockwise. Move the vehicle to firm / level ground. Turn the
engine off, select first gear (manual) or P (automatic). Apply the handbrake. Loosen the wheel nuts (do not remove them).
Only use the specific reinforced jack points on the underside of the vehicle. Crank the jack to lift the vehicle. Undo wheel
nuts and change the wheel. Lower the vehicle. Tighten the wheel nuts.
Select N for neutral, P when leaving the vehicle, R for reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select D where the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration
point forcing the transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator
to return to normal accelerator use). Use the D+ and D- options to manually select gears. Whenever the vehicle is at a
standstill apply the handbrake.
VIC-HYU-03 / 14-04-2019
Locking the doors?
Anti-theft system?
Opening boot/tailgate?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an automatic?
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
50.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
205/55 R16
Note: driving speeds and travel distances
are restricted when using spacesaver
spare tyres.
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
14 Handbrake
Tilt
Lumbar
Legroom
Height
10
3
1
11
7 / 8
2
4 / 5 / 6 / 12 / 13
9
R 1 3 5
2 4 6
or
P
R
N
D
14
+
-

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
HYUNDAI i30 5 SEATS
5 DOOR HATCHBACK / ESTATE
Key / remote control operated central high security dead locking. Depress the central locking switch on the centre console
to lock the doors from the inside. Doors auto-lock on vehicle motion.
Remote anti-theft alarm. Passive arming of electronic engine immobiliser after removal of the key from the starter switch.
Centrally locked. Use the key or remote control to unlock / open. Pull the release handle to open.
Electric adjustment operated by the control pad on the driver’s door.
Electric front operated via control buttons on the driver’s door, with electric or manually operated rear windows.
If fitted: Electric tilt / slide panoramic sunroof operated by roof mounted switchgear.
Located on the edge of the rear doors, slide the door locking lever on the edge of the door to activate it. Check from inside
that the doors are securely locked. Or press the centre console central locking button.
Ensure gear selector is in neutral (or N or P if automatic) and parking brake is on. Place ignition key in starter switch.
Use a normal starting routine (or some vehicles feature an engine start/stop button, simply keep the key in your pocket or
handbag, and press the engine start/stop button to start or stop the engine). Select desired gear. Release parking brake (on
some models the parking brake will normally auto release) and brake pedal and gently press the accelerator to move the
vehicle. Vehicles feature automatic engine start/stop technology - whereby engine auto shuts off when stationary, gears are
in neutral and foot pedals are not depressed - engine instantly restarts on depression of the clutch or accelerator.
Located under flap on rear nearside. Centrally locked. Press the edge of the flap to open it, and twist off the cap
anticlockwise.
Pull bonnet release lever located under the steering wheel column. Unhook catch under bonnet.
The rear seat is divided into sections which can be folded separately. To release the seat press the seat unlocking catch and
fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock. Check it is
securely locked before using the seat.
Vehicle is not normally supplied with a spare wheel or tyre repair kit. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999. Lift the carpet cover to access the storage tray housing the tools and jack. Release
the wheel by turning the retaining bolt anticlockwise. Move the vehicle to firm / level ground. Turn the engine off, select first
gear (manual) or P (automatic). Apply the parking brake. Loosen the wheel nuts (do not remove them). Only use the specific
reinforced jack points on the underside of the vehicle. Crank the jack to lift the vehicle. Undo wheel nuts and change the
wheel. Lower the vehicle. Tighten the wheel nuts.
Select N for neutral, P when leaving the vehicle, R for reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select D where the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to
return to normal accelerator use). Use the D +/- selector to manually select gears (use low gears for best engine braking for
driving in hilly terrain or hazardous conditions). Whenever the vehicle is at a standstill apply the parking brake.
VIC-HYU-04 / 11-02-2018
Locking the doors?
Anti-theft system?
Opening boot/tailgate?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an automatic?
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
50.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
195/65 R15
205/55 R16
225/45 R17
Note: driving speeds and travel distances
are restricted when using spacesaver
spare tyres.
Fitted with auto tyre pressure monitoring
system.
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
14 Electronic Parking Brake
Tilt
Lumbar
Legroom
Height
10
3
11
1
7 / 8
2
P
R
N
Dor
4 / 5 / 6 / 12 / 13
9
R 1 3 5
2 4 6
14
+
-

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
When parked, the electronic parking brake
should be fully applied with the vehicle left in
first or reverse gear for vehicles equipped with
manual transmission or P (Park) for vehicles
with automatic transmission.
CAUTION!
HYUNDAI i40 5 SEATS
4 DOOR SALOON / 5 DOOR ESTATE
Key / remote control operated central high security dead locking. Depress the central locking switch on the centre console
to lock the doors from the inside. Auto door locking on vehicle motion.
Remote anti-theft alarm. Passive arming of electronic engine immobiliser after removal of the key from the starter switch.
Centrally locked. Use the key or remote control to unlock / open. Pull the release handle to open. Saloon has a remote
release.
Electric adjustment operated by the control pad on the driver’s door.
Electric front operated via control buttons on the driver’s door, with electric or manually operated rear windows.
If fitted: Electric tilt / slide panoramic sunroof operated by roof mounted switchgear.
Located on the edge of the rear doors, slide the door locking lever on the edge of the door to activate it. Or use the central
locking switch on the centre console. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral (or N or P if automatic) and electronic parking brake is on. Place ignition key in starter
switch. Use a normal starting routine (or some vehicles feature an engine start/stop button, simply keep the key in your
pocket or handbag, and press the engine start/stop button to start or stop the engine). Select desired gear. Release
electronic parking brake and brake pedal and gently press the accelerator to move the vehicle. Some vehicles also feature
automatic engine start/stop technology where the engine shuts off when the vehicle is stationary, gears are in neutral and
pedals are not depressed - engine instantly restarts on depression of the clutch (or brake on auto).
Located under flap on rear nearside. Centrally locked. Release it using the internal remote release adjacent to the driver’s
seat. Lightly press the edge of the flap to open it, and twist off the fuel cap anticlockwise.
Pull bonnet release lever located under the steering wheel column. Unhook catch under bonnet.
The rear seat is divided into 60:40 sections which can be folded separately. To release the seat press the seat unlocking
catch and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock.
Check it is locked before using the seat.
Vehicle is not normally supplied with a spare wheel or tyre repair kit. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999.
Select N for neutral, P when leaving the vehicle, R for reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select D where the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to
return to normal accelerator use). Use the D+ or D- selector positions to manually select gears. Whenever the vehicle is at a
standstill apply the electronic parking brake.
VIC-HYU-05 / 14-04-2019
Locking the doors?
Anti-theft system?
Opening boot/tailgate?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an automatic?
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
70 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
215/50 R17
225/45 R18
Note: driving speeds and travel distances
are restricted when using spacesaver
spare tyres.
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
14 Electronic parking brake
Tilt
Lumbar
Legroom
Height
10
3
1
11
7 / 8
2
or
4 / 5 / 6
9
R 1 3 5
2 4 6
12 / 13
14
P
R
N
D+
-

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
HYUNDAI KONA 5 SEATS
5 DOOR SUV 2X4 OR 4X4
Key / remote control operated central high security dead locking. Depress the central locking switch to lock the doors from
the inside. Auto door locking on vehicle motion. Some models feature keyless entry.
Remote anti-theft alarm. Passive arming of electronic engine immobiliser after removal of the key from the starter switch.
Centrally locked. Use the key or remote control to unlock / open. Pull the release handle to open. Some models feature a
smart auto hands-free opening power tailgate.
Electric adjustment operated by the control pad on the driver’s door.
Electric front and rear operated via control buttons on the driver’s door.
If fitted: Electric panoramic electric / tilt slide sunroof operated by roof mounted switchgear.
Located on the edge of the rear doors. Press central locking button to lock all doors, or for each rear door, insert ignition key
into key slot on edge of rear door, and turn to activate child locks. Repeat process for each door. Check from inside that the
doors are securely locked.
Ensure gear selector is in neutral (or N or P if automatic) and handbrake is on. Place ignition key in starter switch and use
a normal starting routine or press the engine start/stop button to turn the engine on or off. Release handbrake and brake
pedal and gently press the accelerator to move the vehicle. Vehicles feature automatic engine start/stop technology - engine
auto shuts off when vehicle is stationary, gears are in neutral and foot pedals are not depressed, engine auto restarts on
depression of the clutch or accelerator.
Located under flap on rear offside. Centrally locked. Release it using the internal remote release adjacent to the driver’s
seat. Lift the edge of the flap to open it, and twist off the cap anticlockwise.
Pull bonnet release lever located under the steering wheel column. Unhook catch under bonnet.
The rear seat is divided into sections which can be flat-folded. To release the seat press the seat unlocking catch and fold
the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock. Check it is locked
before using the seat.
Vehicles are not normally supplied with a spare wheel or emergency tyre repair inflation kit. For any assistance in the
event of having a punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair
kit, please call the Europcar Tyre Helpline 0800 0280 999.
Select N for neutral, P when leaving the vehicle, R for reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select D where the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to
return to normal accelerator use). Use the D+ or D- to manually select gears. Whenever the vehicle is at a standstill apply
the handbrake.
VIC-HYU-06 / 11-05-2018
Locking the doors?
Anti-theft system?
Opening boot/tailgate?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an automatic?
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
50 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
205/60 R16
215/55 R17
235/45 R18
Note: travel distance and driving speeds
are limited using spacesaver spare tyre or
tyres repaired by emergency tyre repair
kits.
1Heating & Ventilation
2Hazard Lights
3Engine Start / Stop
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
Tilt
Lumbar
Legroom
Height
10
11
1
7 / 8
3
P
R
N
D
or
4 / 5 / 6 / 12 / 13
9
R 1 3 5
2 4 6
2
+
-

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
HYUNDAI TUCSON 5 SEATS
5 DOOR SUV 2X4 OR 4X4
Key / remote control operated central high security dead locking. Depress the central locking switch on the driver’s door to
lock the doors from the inside. Auto door locking on vehicle motion. Some models feature keyless entry.
Remote anti-theft alarm. Passive arming of electronic engine immobiliser after removal of the key from the starter switch.
Centrally locked. Use the key or remote control to unlock / open. Pull the release handle to open. Some models feature a
smart auto hands-free opening power tailgate, operated by foot gesture activated sensors below the rear bumper.
Electric adjustment operated by the control pad on the driver’s door.
Electric front and rear operated via control buttons on the driver’s door.
If fitted: Electric panoramic electric / tilt slide sunroof operated by roof mounted switchgear.
Located on the edge of the rear doors, depress the central locking switch on the driver’s door to activate it. Check from
inside that the doors are securely locked.
Ensure gear selector is in neutral (or N or P if automatic) and handbrake is on. Place ignition key in starter switch and use
a normal starting routine. (Some models are fitted with an engine start/stop button to turn the engine on or off, for keyless
starting - just keep the key in your bag or pocket, and press the button to start or stop the engine). Release handbrake
and brake pedal and gently press the accelerator to move the vehicle. Some vehicles feature automatic engine start/stop
technology - engine auto shuts off when vehicle is stationary, gears are in neutral and foot pedals are not depressed, engine
auto restarts on depression of the clutch or accelerator.
Located under flap on rear offside. Centrally locked. Release it using the internal remote release adjacent to the driver’s
seat. Lightly press the edge of the flap to open it, and twist off the fuel cap anticlockwise.
Pull bonnet release lever located under the steering wheel column. Unhook catch under bonnet.
The rear seat is divided into 60:40 sections which can be flat-folded. To release the seat press the seat unlocking catch
and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock. Check it is
locked before using the seat.
Vehicle is not normally supplied with a spare wheel or tyre repair kit. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999. Lift the carpet cover to access the storage tray housing the tools and jack, lift out
this tray to reveal the full size spare wheel. Release the wheel by turning the retaining bolt anticlockwise. Move the vehicle to
firm / level ground. Turn the engine off, select first gear (manual) or P (automatic). Apply the handbrake. Loosen the wheel
nuts (do not remove them). Only use the specific reinforced jack points on the underside of the vehicle. Crank the jack to lift
the vehicle. Undo wheel nuts and change the wheel. Lower the vehicle. Tighten the wheel nuts.
Select N for neutral, P when leaving the vehicle, R for reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select D where the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to
return to normal accelerator use). Use the D+ or D- to manually select gears. Whenever the vehicle is at a standstill apply
the handbrake.
VIC-HYU-07 / 14-04-2019
Locking the doors?
Anti-theft system?
Opening boot/tailgate?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an automatic?
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
62.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
215/70 R16
225/60 R17
225/55 R18
245/45 R19
Note: vehicle is supplied with a full-size
spare wheel.
1Heating & Ventilation
2Hazard Lights
3Engine Start/Stop
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
14 Handbrake
Tilt
Lumbar
Legroom
Height
10
11
1
7 / 8
2
P
R
N
D
or
4 / 5 / 6 / 12 / 13
9
R 1 3 5
2 4 6
3
+
-
14

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
HYUNDAI ioniq HYBRID 5 SEATS
HYBRID - 5 DOOR HATCHBACK
Key / remote control operated central high security dead locking. Depress the central locking switch on the driver’s door to
lock the doors from the inside. Auto door locking on vehicle motion.
Remote anti-theft alarm. Passive arming of electronic engine immobiliser after removal of the key from the starter switch.
Centrally locked. Use the key or remote control to unlock / open. Pull the release handle to open.
Electric adjustment operated by the control pad on the driver’s door.
Electric front and rear operated via control buttons on the driver’s door.
If fitted: Electric tilt / slide sunroof operated by roof mounted switchgear.
Located on the edge of the rear doors, press the central locking switch on the dashboard to activate child proof locks.
Check from inside that the doors are securely locked.
Ensure gear selector is in neutral (or N or P if automatic) and handbrake is on. Insert key into key slot and turn on. Press
the engine start/stop button to left of steering wheel to manually start/stop the engine. Select desired gear. Release parking
brake and brake pedal and gently press the accelerator to move the vehicle. Vehicles also feature automatic engine start/
stop technology - whereby the engine and electric motor automatically shuts off when vehicle is not moving, gears are in
neutral and foot pedals are not depressed - engine and electric motor instantly restart on depression of the clutch.
NOTE: the hybrid electric engine works automatically together with the petrol engine - with ECO (economy) and SPORT
(more responsive) driving mode options. Electric engine is used at low speed and during acceleration, it is auto recharged
during deceleration and downhill driving. During mid speeds only the petrol engine is used.
Located under flap on rear nearside. Centrally locked. Lift the edge of the flap to open it, and twist off the cap anticlockwise.
Pull bonnet release lever located under the steering wheel column. Unhook catch under bonnet.
The rear seat is divided into sections which can be folded separately. To release the seat press the seat unlocking catch and
fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock. Check it is
locked before using the seat.
Lift the carpet cover in the boot to access the tools and jack, and the spacesaver spare wheel. Release the wheel by turning
the retaining bolt anticlockwise. Move the vehicle to firm / level ground. Turn the engine off, select first gear (manual) or P
(automatic). Apply the handbrake or parking brake. Loosen the wheel nuts (do not remove them). Only use the specific
reinforced jack points on the underside of the vehicle. Crank the jack to lift the vehicle. Undo wheel nuts and change the
wheel. Lower the vehicle. Tighten the wheel nuts. For any assistance in the event of having a punctured tyre, or should
the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the Europcar Tyre Helpline
0800 0280 999.
VIC-HYU-08 / 30-09-2017
Locking the doors?
Anti-theft system?
Opening boot/tailgate?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
45.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
Check the tyre pressure table found on the
inside of driver’s door B-pillar (or fuel filler
cap). Electronic tyre pressure monitor.
195/65 R15
Note: driving speeds and travel distances
are restricted when using spacesaver
spare tyres.
1Heating & Ventilation
2Hazard Lights
3Igntion key slot
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
14 Engine start/stop
Tilt
Lumbar
Legroom
Height
10
3
11
1
7 / 8
2
4 / 5 / 6 / 12 / 13
9
R 1 3 5
2 4 6
14
