User's Manual
HCS-W1002
HCS-W1002
User's Manual
Desk
Anti-slip pad
6320000424 REV.0

32
01 Precautions on use
It contains some issues that can result in a serious injury
or even death. Please read and be fully aware of the
contents for the correct use of the device.
■Before use, remove all protective caps and plastic device.
■Any attempts of disassembly, repair and remodeling are prohibited.
■Do not use water or chemicals, such as alcohol to wipe the outside
of the device. Use only a piece of dry cloth.
■Do not install the device in a place where is hot or humid and do
not expose the product to direct sunlight.
■Do not have the device exposed to a physical impact, smoke,
oil or water.
■If there is any abnormal noise, smell or smoke coming out of the
device, stop using it immediately and call the Service Center.
■Do not place the device around any magnet stuff like TV or Speaker.
■This device is not operated in case of power shutdown or failure.
■ The device should be connected with wireless router via Wi protocol.
■Do not allow water to come in contact with the device.
■ Do not use a stylus, ngernail or sharp object as it may damage the
device.
02 External Structure and Description
Front view
Upper view
Remote IR Receiver
Indicator LED
IR LED 8 EA
For 360° Remote
Control
Side : 6 EA
Top : 2 EA
R

54
03 How to connect Power and IR cables
Press the mode button
for about 5 seconds to
enter Soft AP mode.
Press the RESET button for
about 5 seconds to reset
registered ZigBee devices.
*Factory Reset : Press RESET
& MODE button together at
the same time for about 10
seconds (you can hear the
beep sound 2 times)
IR 2
Power(Micro USB)
IR 1
*IR cable is an optional and IR cable length
can be extended by a link cable.
*Link Cable Plug Spec : Ø3.5mm, 2Pole
3.5mm
5mm
14mm 25mm
04 How to install
①Install the screws(Ø3x L12 3ea) on proper location where it sets.
②Assemble the "Deco Cover" on the device.
③Connect the power and IR cable(Optional) in each port on the bottom
of the main unit through bracket.
④Assemble the main unit and the bracket.
Ceiling mounting
Bracket
Screw Ø3 x L12
Deco Cover
Power Cable /IR Cable
(Optional)
Rubber Foots
Point Bracket Body
Body

76
Anti-slip pad
Desk
①Connect the power and IR cable (Optional) in each port on the
bottom of the main unit.
②Put the main unit on proper location. (Rubber foots are attached
on the bottom side)
*Recommend you not to install the device on the oor considering
that the wireless signal coverage may be unstable.
Place on the desk
Main Unit X 1 Bracket X 1 Screw(Ø3XL12) X 3
Power Cable(1.2M) X 1 IR Cable(2M) X 2Deco Cover X 1
05 Components
(Optional)
App Manual X 1User's Manual X 1Power Adaptor X 1
User's Manual
HCS-W1002
HCS-W1002
User's Manual
Desk
Anti-slip pad
User's Manual
HCS-W1002
HCS-W1002
Application
Anti-slip pad
Desk

98
HCS-W1002
Item Detail
Rated Voltage External DC Adaptor(DC 5V/1A)
Power Consumption
Max. 2.5W
Size 109.15(Ø)mm X 38.5(T)mm
Weight 150g
Environment
Temperature 0℃~ 40℃(Indoor)
Humidity Below 80%
Protocol
2.4GHz WLAN(802.11b/g/n), Zigbee,
IR Remote Control
Manufacturer HYUNDAI HT Co., Ltd. / Made in Korea
06 Product Specication
Warranty Conditions
HYUNDAI HT Products are supplied with return to base
warranty from the date of purchase, We will repair or replace the
defective item with a new or factory rebuilt replacement.
Condition
1. This warranty applies to the original purchaser only.
2. All warranty will be invalid if unauthorized repair or modication are
made to the unit or in any case of accident, misuse and damage
cause by improper installation and altered serial numbers.
3. The liability of HYUNDAI HT is limited to the cost of repair/replacement
of the unit under warranty.
4. If you need a warranty service, you should send the product to our
customer service Dept. or dealer ofce. The product in all cases
must be accompanied by the following items : Your name, address,
telephone number, the serial number and copy of your sales receipt
showing the purchase date.
The Model Number is on the box and front of the manual, The Serial
Number is on the bottom of the unit, Record the Model and Serial
Numbers in the spaces provided below, Refer to these numbers for
warranty service.
Model No. Serial No.

www.hyundaiht.co.kr
107, Yeouidaebang-ro,
Yeongdeungpo-gu, Seoul, 07433, Korea
(HYUNDAI HT Building, Shingil-dong)
Tel [phone] 6320000424 Rev 00
