ICEMASTER SDA1801 User manual

IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be followed. These instructions should be
saved for future reference:
Read and familiarise yourself with all operating instructions
before using this fridge.
Before plugging your unit into the mains, visually check that the
unit is intact and has not suffered any transit damage.
If this appliance is to replace an old refrigerator with a lock,
please remove the lock or door before disposal.
Your old appliance may contain insulation, gases and
refrigerant that need to be disposed of correctly. Please ensure
that the refrigerant circuit is not damaged before the appliance
is disposed of. If in any doubt contact your local authority for
advice.
This appliance may contain the refrigerant isobutene (R600a).
This is a natural gas with a high level of environmental
compatibility, however, caution is required as isobutene is a
flammable gas. It is essential that refrigerant tubes are not
damaged during transit or installation of the appliance. In the
event that the refrigerant circuit is damaged, avoid naked
flames and sources of ignition and ventilate the room in which
the appliance is situated.
Do not damage the refrigerant circuit
Following installation ensure the power cable is not trapped
beneath the appliance.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children unless they are
older than 8 and supervised
Do not use mechanical devices or other means to accelerate

the defrosting process, other than those recommended by the
manufacturer.
Do not use electrical appliances inside the food storage
compartment of the appliance, unless they are of a type
recommended by the manufacturer.
This appliance is for household use only.
Keep all ventilation openings clear of obstruction.
Do not store explosive substances such as aerosol cans with
flammable propellants in this appliance.
It is imperative to unplug the power cord after the appliance has
been used, before it is cleaned and whilst being repaired.
Repairs to electrical appliances should only be performed by a
qualified electrician. Improper repairs may place user at serious
risk
Do not operate this appliance with a damaged plug or cord,
after a malfunction or after being dropped or damaged in any
way.
Regular, periodic checks should be carried out on the mains
cable to ensure no damage is evident. Should there be any
signs of damage the appliance should not be used.
Do not allow the mains cable to hang over sharp edges or come
in contact with hot surfaces.
Do not run the mains cable under carpets, rugs, etc.
Installation
IMPORTANT! This appliance must be left to stand in an upright
position for a minimum of 4 hours prior to switching on for the first
time.
Please read these operating instructions thoroughly and keep them in a
safe place for future reference.
Remove all packing materials and discard responsibly.
Clean the interior of the appliance with lukewarm water containing a small
amount of bicarbonate of soda (5ml to 0.5 l of water)
Position the appliance out of direct sunshine.
Do not position next to a cooker or other sources of heat such as a
radiator.
If positioned next to another fridge or freezer, leave a minimum gap of 2cm

between the appliances to avoid condensation.
A clearance of 50mm should be left above the appliance, if this is not
possible 25mm of clearance should be left on each side of the appliance.
Ensure there is a clearance between the condenser and rear wall.
Do not place heavy items on top of the appliance.
Position the appliance on a solid flat surface.
This appliance must be level. Adjust the level by screwing the adjustable
feet up or down as required, using your fingers or a suitable spanner.
Ensure that the power supply is in accordance with the rating plate found
at the rear of the appliance.
Do not push objects into any openings as damage to the appliance and/or
electric shock may occur.
Do not use any accessories or attachments with this appliance other than
those supplied or recommended by supplier.
THIS APPLIANCE MUST BE EARTHED
Description
1. Ice box
2. Drip tray
3. Full width shelf
4. Half width shelf
5. Salad/vegetable crisper compartment
6. Thermostat control
7. Rack shelves
1
2
3
4
5
6
7

Switching on the appliance
Allow the appliance to stand for a minimum of 4 hours after installation.
Plug in the appliance and switch on the mains supply.
Set the thermostat to the required setting (The temperature selector is
situated to the right of the icebox, setting 0 = off, setting 3 or 4 are most
commonly used for normal operation, however this can be changed to
your own preferred temperature, with 5 being the coldest setting).
Leave the appliance for 4 hours to reach temperature before use.
NOTE: During periods of high ambient temperatures (ie hot sunny days)
it may be necessary to set the temperature to a higher setting than is
normally used.
Operation
You may hear faint gurgling or bubbling sounds as the refrigerant is
pumped around the cooling circuit, this, along with the slight hum of the
compressor is normal and will stop and start as the thermostat operates.
In the event of a power failure
If there is a power failure keep the door closed if possible to maintain the
internal temperature. After power is restored it may take some time to
return to the set temperature level.
Energy saving advice
Do not install the appliance close to sources of heat such as
cookers or radiators.
Locate the appliance in a well ventilated area.
Ensure the door seal is clean and there are no tears or rips.
Do not overload the fridge.
Never put hot or warm foods into the fridge, allow to cool to room
temperature first.

Cleaning and maintenance
WARNING: Before any maintenance or cleaning is carried out
disconnect the appliance from the mains supply.
Internal cleaning
Clean the interior and accessories with warm water and bicarbonate of
soda (5ml to 0.5l of water). Rinse and dry thoroughly. Do not use
detergents, abrasives, highly perfumed cleaning products, wax polishes
or cleaning products containing bleach or alcohol.
External cleaning
Wash the outer cabinet with warm soapy water. Do NOT use abrasive
cleaners. There may be some sharp edges on the underside of the
appliance so care should be taken when cleaning. Once or twice a year
clean the rear of the appliance and the compressor using a soft brush or
vacuum cleaner as an accumulation of dust will affect the performance
of the appliance and cause increased energy consumption.
Defrosting
If the buildup of ice in the freezer box exceeds 3-5mm, empty the
compartment and switch off the appliance, leave the door open and
allow the ice to melt. Do not use sharp objects to remove the ice.
Clean and dry the interior, close the door and turn on the power, the
appliance will start to operate but will take some time to reach the preset
temperature.
If the appliance is not in use for some time, disconnect from the mains
supply and leave the door slightly ajar until next use.
Changing the light bulb
Switch off the power supply
Remove the screw from the light cover and remove the cover.
Unscrew the bulb from the light fitting.
Replace the bulb with a suitable replacement (SES E14 10W).
Refit the cover and switch the appliance back on.

Reversing the door
The door can be reversed from right hand hinged to left hand hinged if
required and vice versa.
Warning: When reversing the door the appliance must be disconnected
from the mains supply.
Remove the retaining screws and lift off the top cover.
Remove the screws and upper hinge assembly then lift off the door
from the lower hinge assembly.
Remove the screws, lower hinge and foot assembly. Remove the
hinge pin from the lower hinge, turn the hinge over and refit the pin
into the same hole.
Remove the left foot and refit on the right hand side.
Fit the door onto the lower hinge and refit the upper hinge , fixing
to the predrilled holes on the left hand side of the cabinet. Tighten
the screws.
Ensure the door is correctly aligned and the seal fits correctly
Replace and secure the top cover.
Technical Data
Voltage : 220-240V ~ 50Hz
Rated power : 60W
Model Number : SDA1801
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with your
Local Authority or retailer for recycling advice.
