Idea Display OG34RWA-165HZ User manual

G34W-Gaming Monitor
Please read this manual thoroughiy before use,and keep it handy for future reference

GENERAL INFORMATION
Dear Customer,
Thank you for having purchased this product. This document describes how to install and use the
LCD colour monitor. Read this manual which contains information for correct, safe use carefully.
Keep this manual at hand so that you can refer to it when needed.
PRODUCT DESCRIPTION AND TYPE OF USE
The LCD color monitor presents a very rugged structure. It is designed for continuous operation and
can be used in closed circuit TV systems without risks of excessive fatigue. The Flat Panel Display has
an active matrix, thin-film transistor (TFT), liquid crystal display (LCD).
GENERAL FEATURES
 Display area
 Wall mounting with not included bracket
 One composite two DP,one HDMI
 Wide inclination to allow viewing either from a seated position or standing up and when moving
from one position to the other
Multilingual OSD menu for easy setting and optimization of the display
OPENING THE BOX
Check that the packing and the contents are not visibly damaged. Contact the retailer immediately if
parts are either missing or damaged. Do not attempt to use the device in this case. Send the product
back in its original packing if it is damaged.
CONTENTS OF THE BOX
 LCD monitor
 Power Adaptor
 Power cable
 DP cable
 Audio cable(Optional)
 User's manual
Important Note: Accessories may be changed without prior notice.
1

2
WARNINGS
POWER
 Only use the power unit provided to power the device. Check mains rating before plugging the
power unit in.
 Do not pull the cable to unplug the device.
SAFETY PRECAUTIONS
 Keep the device away from rain and humidity to prevent risk of fire and electrocution. Do not
introduce material (solid or liquid) inside. If this should accidentally occur, disconnect the device
from the mains and have it inspected by qualified personnel.
 Never open the device. In all cases, contact the qualified personnel or authorized service center
for repairs.
 Keep the device away from children, to prevent accidental damage.
 Do not touch the device with wet hands to prevent electrical shock or mechanical damage.
 Do not use the device if it should fall or the external casing is damaged. Risk of electrocution if
the device is used in such conditions. Contact the retailer or authorized installer.
 It is advisable to disconnect the power wire if the monitor is not used for a certain time.
INSTALLATION PRECAUTIONS
 To prevent overheating the device, arrange it in a position allowing the flow of air through the
slots in the casing. Ensure at least 5 cm of free space when installing inside a rack. For the same
reason, do not install sources of heat, such as radiators or hot air ducts. Keep away from direct
sunlight. Do not install in areas subject to excessive dust, mechanical vibrations or shocks.
 Do not arrange this device on an unstable surface, such as a tottering or slanted table. The
device could fall causing injury or mechanical failures.
 Do not install the device in a place where it could be exposed to humidity or water. Do not direct
a jet of water onto the device: risk of fire, electrocution or mechanical failure.
 Stop using the device if water or other material should penetrate inside: risk of fire and
electrocution. Contact the retailer or authorized installer.
 Slots and openings in the cabinet are provided for ventilation. These openings must not be
blocked or covered.
 Do not place heavy or heat generating objects on top of the device: this could damage the casing
and/or increase internal temperature causing faults.
 Do not cover the device with a cloth while it is running to prevent deforming the external casing
and overheating the internal parts: risk of fire, electrocution and mechanical failure.
 Keep magnets and magnetized objects away from the device to prevent faults.
 Do not use the device in presence of smoke, vapor, humidity, dust or intense vibrations.
 Wait for a while before operating a device immediately after transporting it from a cold place to
a warm place and vice versa. Wait on average for three hours: this will allow the device to adapt
to the new ambient (temperature, humidity, etc.).
 The monitor is provided with a plastic base and rubber feet. It can be positioned on a horizontal
surface, such as a desk or a table. Make sure that the device is fastened firmly and that it is not
resting on unstable supports or surfaces. Dropping could cause severe injury and damage the
device.
 Remember to adjust the brightness and contrast to obtain a perfect image.

1.3.4 CLEANING THE DEVICE
 Rub delicately with a dry cloth to remove dust and dirt.
 Dip the cloth in neutral detergent if dirt cannot be eliminated with a dry cloth alone.
 Do not use volatile liquids (such a petrol, alcohol, solvents, etc.) or chemically treated clothes to
clean the device to prevent deformation, deterioration or scratches to the paint finish.
1.3.5 PRIVACY AND COPYRIGHT
 The LED monitor is a device for Gaming. Recording of images is subject to the laws in
force in your country. Recording of images protected by copyright is forbidden.
Product users shall be responsible for checking and respecting all local rules and regulations
concerning monitoring and recording video signals. The manufacturing SHALL NOT BE LIABLE for use
of this product not in compliance with the laws in force.
Base removal and installation
3
1 2
3 4

Technical Drawing
Monitor Inputs
USB
Power
4
1
HDMI
2
DP2
3
DP1
4
AUDIO OUT
5
6
6

Accessories
34inch MonitorDP Cable
5
GETTING STARTED
MONITOR CONTROLS
Select signal source or Exit OSD
Go Up on the Main OSD Menu increase the value of a selected item
Go Down on the Main OSD Menu and decrease the value of a selected item
Open the Main OSD Menu Select submeu
Turn the monitor on or off
1
2
3
4
5

6
Shortcut Key Guide
Activate the
Activate the
Activate the
Signal Input Selection menu.Use◄ ◄ and to navigate and M to select the source.
ine of Sight feature. Further press to cycle between the colors or turn off.
ECO Mode feature.Further press to cycle through the presets.
INITIAL SETUP
Connect the monitor to a power outlet.
1. Press the POWER button on the monitor or to turn it on (The indicator will be blue).
2. Connect the relevant cable to the corresponding input on the monitor. The source will be
automatically detected.
3. To change between inputs, press the “Source” button to enter the source menu. Use the
“”and“” buttons to choose the input source between Auto Select,DP1,DP2 and HDMI.
MENU OPTIONS
The menu for the monitor can be accessed by pressing the menu button on the control panel. This menu is
separated into the following sub menus: Picture Settings, Image Settings, Colour Temperature, OSD Settings,
Reset, and M iscellaneous options, details of each menu can be found in the following section.
DP2
DP1
HDMI

7
OSD MENU
B . Brightness/Contrast
Switch the signal input to DP1,DP2,HDMI,or have the monitor Auto Select the source.
A. Input Source
Brightness: Change the display brightness value from 0 to 100.
Contrast: Adjust the display contrast value from 0 to 100.
DCR: Turn the Dynamic Contrast Ratio feature On or Off.
Resolution: 3440x1440@165Hz
3440x1440@165Hz
DP1
DP1
DP1
DP2
HDMI
Resolution: 3440x1440@165HzDP1
3440x1440@165Hz
DP1

8
C . Color Settings
D . Picture Quality Settings
Sharpness: Change the display Sharpness value from 0 to 100.
Response Time: Turn the Response Time feature On or Off.
Noise Reduction: Select the Noise Reduction Value from,Low,Middle,High or turn it Off.
Super Resolution: Turn the Dynamic Luminance Control feature On or Off.
Dynamic Luminance Control: Turn the Dynamic Luminance Control feature On or Off.
Gamma: Change the display Gamma value to:2.0,2.2,2.4.
picture Mode: Change the pre-set mode to: Standard, Text, Game 1-3,Movie, or ECO.
Color Temperature: Change the color temperature to:Normal,Warm,Cool,User.
Hue: Change the display Hue value from o to 100.
Saturation: Change the display Saturation value from 0 to 100.
Low Blue Light: Change the display Saturation value from 0 to 100.
Picture Mode
Low Blue Light
2.2
Standard
Warm
50
50
0
Resolution: 3440x1440@165HzDP1
3440x1440@165Hz
DP1
Sharpness
Off
50
Off
Off
Noise Reduction
Resolution: 3440x1440@165HzDP1
3440x1440@165Hz
DP1

9
E . Display
F . Audio
Aspect Ratio: Change the image aspect ratio to Full Screen,Auto,4:3,5:4, or 1:1.
Mute:Turm On or Off to mute the audio source.
Volume: Change the audio source volume from 0 to 100.
Audio Source: Audio source interface switching HDMI DP1 DP2
Wide Screen
Resolution: 3440x1440@165HzDP1
3440x1440@165Hz
DP1
Mute
Audio Source HDMI
Off
50
Resolution: 3440x1440@165HzDP1
3440x1440@165Hz
DP1

10
H . OSD
G . Multi-window
Language: Change the OSD Menu display language.
OSD H Position: Change the horizontal position of the OSD Menu.
OSD V Position: Change the vertical position of the OSD Menu.
OSD Transparency: Change the transparency value of the OSD Menu from 0 to 100.
OSD Timer Out: Change how long the OSD Menu is on before it automatically exits.
OSD Rotation: Rotate the OSD Menu.
Multi-window: Adjust the muitl-window to off / PIP / PBP.
OffMultl-Window
DP2
Mediun
TopRight
Resolution: 3440x1440@165HzDP1
3440x1440@165Hz
DP1
OSD H-Position
OSD Transparency
OSD V-Position
OSD Time Out
OSD Rotation
50
50
20
20
Normal
Resolution: 3440x1440@165HzDP1
3440x1440@165Hz
DP1

11
I . Other
FreeSync Mode: Turn FreeSync On or Off.
HDR: Turn HDR On (requires HDMI 2.0 input).
MPRT: On or Off.
Cross: On or Off.
Firmware Update: On or Off.
Reset: Press this function to restore the original settings.
FreeSync (Adaptive Sync)
Firmware Update
MPRT
Reset
Off
Off
Off
Resolution: 3440x1440@165HzDP1
3440x1440@165Hz
DP1

Technical Specificaions
OG34RWA-165HZ
3440x1440
165Hz
400cd/m²
MPRT 1ms
21:9
178°(H)/178°(V)
16.7M color
x1
x1
x1
DC 12V 5A
0~50℃
No
Eng/Fr/Spanish/Ger/Korean/Japan/Chinese
Supported
Supported
Supported
Supported
Supported
Supported
x2
Panel
In/Out
ETC
Main
Features
Resolution
Model
Refresh
Brightness (MAX)
Response Time (Typical)
Aspect Ratio
Viewing Angle
Display Color
HDMI
USB
DP
Audio
Power Consumption
Typical 45W
Power Source
Operating Temperature
Remote Control
OSD
HDR
FreeSync/G-Sync
Low blue light
Flicker free
Over drive
PIP/PBP
12

Hi,
Thank you for chosing idea display from so many brands.
Please do not hesitate to contact us，if you have any questions and comments:
E-mail:[e-mail]
We will provide you with a satisfactory solution to the latest 48 hours.
Sincere Regards
REGISTER YOUR PRODUCT
idea display may require that you furnish proof of purchase details and / or
comply with registration requirements before receiving warranty service.
Please register your product online: https://www.perfectdisplay.com
idea display encourages you to register your products within thirty (30) days of
the original purchases in order to receive prompt service and support coverage
should you need it.Limited warranty period: 1 year.
THANK YOU FOR CHOOSING idea display
www.facebook.com/pd.display
www.twitter.com/DisplayPerfect
www.perfectdisplay.com
Register your product by serial number
Open the cover to check serial number and connectors
