Ideal Air GSH200 700861 User manual

COMMERCIAL-GRADE
GSH200™ HUMIDIFIER
200 PINTS PER DAY
PRODUCT# 700861
Exclusively distributed by:
www.sunlightsupply.com
All design and specifications herein are subject to change without
notice for product improvement. Contact Ideal Air for
details, updates and other information.
Contact Ideal Air Support directly
at [e-mail] or call
1- 877-9-IDEAL-1
Product not working properly?
DO NOT return this product to the
store where you purchased it.
For answers to most common questions and a complete
technical support library please visit
www.ideal-air.com
c
ifications herein are sub
j
ect t
o
o
duct improvement.
C
ontact I
d
l
s, u
p
dates and other informati
o
m
ost common
q
uest
i
ons a
n
t
lib
rary p
l
ease v
i
s
i
t
w
ww.
i

COMMERCIAL-GRADE GSH200™ HUMIDIFIER
EXPLODED VIEW DIAGRAM
IDEAL-AIR™ IDEAL-AIR™
PRODUCT# 700861 PRODUCT# 700861
NOTES:
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
_________________________________________________
_________________________________________________
_________________________________________________
_____________________________________________ ___
________________________________________________
________________________________________________
________________________________________________
________________________________________________
_______________________________________________
11
19
15
30
32
33
17
20
21
22
24
25
26
27
28
34
35
36
37
29
23

—PART IDENTIFICATION LIST—
ID# Description ID# Description
11 Upper Fan Blade
15 Motor(110V/60HZ)
17 Capacitor(250V/60HZ)
19 Motor Cover
20 Motor Support
21 Cord
22 Atomizing Screen
23 Hub Assembly
24 Disk
25 Pump
26 Lower Fan Blade
—MAINTENANCE—
• Regularly clean the Reservoir Pan Assembly with soap and water
to remove dirt and sediment. Use liquid bleach after cleaning, to
sterilize any parts if algae was present.
• Periodically remove Strainer Screen and thoroughly flush. Also
check to make sure the tapered pump/fan blade assembly is free of
debris.
• Once every three months, check unit for calcium build-up. If build-
up deposits are present, disconnect the water and take the unit
outside. Pour calcium dissolving solvent (available in local hard-
ware stores) in pan and operate unit outside to soften and remove
the deposits.
• About once a year, remove the housing to check the SST Atom-
izing Screen to be sure the slots are clear of mineral build-up. To
clean, scrub with a calcium dissolving solvent.
• Unplug the appliance during filling and cleaning.
• Cleaning and user maintenance should not be made by children
without supervision.
—CAUTION—
• The appliance is not to be used by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge.
• Do not let children play with the appliance.
• If the power cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified person in order
to avoid a hazard.
• Unplug the appliance during filling and cleaning, Follow the
instructions included regarding filling, cleaning and descaling.
• Maximum permissible water pressure in pascals: 1, 2 MPa.
(Minimum permissible water pressure in pascals : 0,5 MPa)
IDEAL-AIR™
IDEAL-AIR™
PRODUCT# 700861
PRODUCT# 700861
27 Mid Pan
28 Lower Pan
29 Leg
30 Fogging Head
32 Screen
33 Handle
34 Housing
35 Float Valve (part #460885)
36 Float
37 Resevoir Pan

—WATER CONNECTION—
Place the unit on a level surface, such as a benchtop or floor. In an
environment with little to no ventilation, place the unit in a central
location. In a ventilated area, place unit near the intake end. When
the unit is in the desired location, connect a water supply to the
female 6 mm / 1/4 inch inlet.
See options as follows:
• Plumb directly to a water supply (6 mm / 1/4 inch plastic
tubing is preferred).
• Connect to a garden hose fitting.
• Plumb to a storage tank higher than the fogging unit (gravity feed).
—Power Connection—
Plug the unit directly into an electrical outlet for evaluation. Listen for
a smooth, quiet operation. Motor shaft should be centered and
vertical. Make any necessary adjustments. If the power cord is
damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
—Operation—
WARNING: Designed for atomizing water only! Don’t use flammable,
toxic or corrosive liquids.
• Operating the unit using the fogging head will provide directional
fogging output and a drier fog.
• For maximum fogging and circulation, operate unit without
fogging head. Fog will propel 4 ~ 5 feet above the unit.
—TROUBLESHOOTING—
No Fog:
Check for motor rotation. If motor is operating properly, there will be
an adequate amount of water in the pan (1/4” to 1-1/4”).
If the pan runs dry, the float valve may be sticking in the up posi-
tion. If so, the inlet water pressure needs to be reduced. If water
supply is adequate, check the tapered pump for internal calcium
build-up. Remove, inspect and clean as needed.
Overflowing Pan:
An overfilled pan can cause poor quality fog and wetness around
the unit.
A leaky float valve or a float that has filled with water may be the
problem. To check the float, raise it out of the water and visually
inspect it. No water should be inside and it should not sink.
If OK, then check for leaky valve. Turn water off and remove the
fogger from the pan.
Empty the pan and towel dry. Hold the float in the up position and
turn on the water.
If any water enters the pan while the float is in the up position, the
float valve needs to be replaced.
IDEAL-AIR™ IDEAL-AIR™ PRODUCT# 700861 PRODUCT# 700861

—WATER CONNECTION—
Place the unit on a level surface, such as a benchtop or floor. In an
environment with little to no ventilation, place the unit in a central
location. In a ventilated area, place unit near the intake end. When
the unit is in the desired location, connect a water supply to the
female 6 mm / 1/4 inch inlet.
See options as follows:
• Plumb directly to a water supply (6 mm / 1/4 inch plastic
tubing is preferred).
• Connect to a garden hose fitting.
• Plumb to a storage tank higher than the fogging unit (gravity feed).
—Power Connection—
Plug the unit directly into an electrical outlet for evaluation. Listen for
a smooth, quiet operation. Motor shaft should be centered and
vertical. Make any necessary adjustments. If the power cord is
damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
—Operation—
WARNING: Designed for atomizing water only! Don’t use flammable,
toxic or corrosive liquids.
• Operating the unit using the fogging head will provide directional
fogging output and a drier fog.
• For maximum fogging and circulation, operate unit without
fogging head. Fog will propel 4 ~ 5 feet above the unit.
—TROUBLESHOOTING—
No Fog:
Check for motor rotation. If motor is operating properly, there will be
an adequate amount of water in the pan (1/4” to 1-1/4”).
If the pan runs dry, the float valve may be sticking in the up posi-
tion. If so, the inlet water pressure needs to be reduced. If water
supply is adequate, check the tapered pump for internal calcium
build-up. Remove, inspect and clean as needed.
Overflowing Pan:
An overfilled pan can cause poor quality fog and wetness around
the unit.
A leaky float valve or a float that has filled with water may be the
problem. To check the float, raise it out of the water and visually
inspect it. No water should be inside and it should not sink.
If OK, then check for leaky valve. Turn water off and remove the
fogger from the pan.
Empty the pan and towel dry. Hold the float in the up position and
turn on the water.
If any water enters the pan while the float is in the up position, the
float valve needs to be replaced.
IDEAL-AIR™
IDEAL-AIR™
PRODUCT# 700861
PRODUCT# 700861

—PART IDENTIFICATION LIST—
ID# Description ID# Description
11 Upper Fan Blade
15 Motor(110V/60HZ)
17 Capacitor(250V/60HZ)
19 Motor Cover
20 Motor Support
21 Cord
22 Atomizing Screen
23 Hub Assembly
24 Disk
25 Pump
26 Lower Fan Blade
—MAINTENANCE—
• Regularly clean the Reservoir Pan Assembly with soap and water
to remove dirt and sediment. Use liquid bleach after cleaning, to
sterilize any parts if algae was present.
• Periodically remove Strainer Screen and thoroughly flush. Also
check to make sure the tapered pump/fan blade assembly is free of
debris.
• Once every three months, check unit for calcium build-up. If build-
up deposits are present, disconnect the water and take the unit
outside. Pour calcium dissolving solvent (available in local hard-
ware stores) in pan and operate unit outside to soften and remove
the deposits.
• About once a year, remove the housing to check the SST Atom-
izing Screen to be sure the slots are clear of mineral build-up. To
clean, scrub with a calcium dissolving solvent.
• Unplug the appliance during filling and cleaning.
• Cleaning and user maintenance should not be made by children
without supervision.
—CAUTION—
• The appliance is not to be used by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge.
• Do not let children play with the appliance.
• If the power cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified person in order
to avoid a hazard.
• Unplug the appliance during filling and cleaning, Follow the
instructions included regarding filling, cleaning and descaling.
• Maximum permissible water pressure in pascals: 1, 2 MPa.
(Minimum permissible water pressure in pascals : 0,5 MPa)
IDEAL-AIR™ IDEAL-AIR™ PRODUCT# 700861 PRODUCT# 700861
27 Mid Pan
28 Lower Pan
29 Leg
30 Fogging Head
32 Screen
33 Handle
34 Housing
35 Float Valve (part #460885)
36 Float
37 Resevoir Pan

COMMERCIAL-GRADE GSH200™ HUMIDIFIER
EXPLODED VIEW DIAGRAM
IDEAL-AIR™ IDEAL-AIR™
PRODUCT# 700861 PRODUCT# 700861
NOTES:
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
_________________________________________________
_________________________________________________
_________________________________________________
_____________________________________________ ___
________________________________________________
________________________________________________
________________________________________________
________________________________________________
_______________________________________________
11
19
15
30
32
33
17
20
21
22
24
25
26
27
28
34
35
36
37
29
23

COMMERCIAL-GRADE
GSH200™ HUMIDIFIER
200 PINTS PER DAY
PRODUCT# 700861
Exclusively distributed by:
www.sunlightsupply.com
All design and specifications herein are subject to change without
notice for product improvement. Contact Ideal Air for
details, updates and other information.
Contact Ideal Air Support directly
at [e-mail] or call
1- 877-9-IDEAL-1
Product not working properly?
DO NOT return this product to the
store where you purchased it.
For answers to most common questions and a complete
technical support library please visit
www.ideal-air.com
c
ifications herein are sub
j
ect t
o
o
duct improvement.
C
ontact I
d
l
s, u
p
dates and other informati
o
m
ost common
q
uest
i
ons a
n
t
lib
rary p
l
ease v
i
s
i
t
w
ww.
i
