Primis Single Port Bridge™
Installation Guide
PART NUMBERS FR-50-40-1, FR-50-40-1L FR-50-24-1
PHYSICAL SPECIFICATIONS
Length 76 mm (3.00 in.)
Width 47 mm (1.85 in.)
Height 17 mm (0.67 in.)
Weight 26 g (1.20 oz.)
Max Readers 1
Max Input 2
Max Output 1
Electrical: UL294 and UL294B
Power over ethernet: IEEE 802af
EMI Radiation: FCC Part 15 Class B
SUMMARIZED LEVELS OF
ACCESS CONTROL COMPONENTS
Destructive Attack Level I
Line Security Level I
Endurance Level I
Standby Power Level I
Single Point Locking Level I
BASE PLATE MOUNTING
Dimension Millimeters Inches
A116.07 4.57
B78.74 3.10
C15.24 0.60
D85.59 3.37
E10.16 0.40
F58.42 2.30
E
D
A
C
BF
Primis Bridges should only be installed in dry, non-condensing
environments. The ambient temperature of the environment should
range between -40°C and 50°C.
Primis Encryption Bridges should only be mounted to non-conductive
surfaces. Incorrect mounting may short-circuit the electronics, which will
cause it to malfunction.
DC power, reader, input contact, and output device wires should
be between 16-28 AWG. They should also be stripped 5.5mm to
contact with each other.
INSTALLATION REQUIREMENTS
For each of the following steps, be sure to reference the wiring
diagram on page 2 for additional details:
1. Connect a Wiegand Reader to the Wiegand Reader Input on the
Primis Bridge.
A. If the reader has a shield wire, connect the shield wire
to the 0v terminal on the Wiegand Reader Input. If an
extension cable is used between the reader and the
Primis Bridge, connect the reader’s shield wire to the
cable’s shield, then connect the cable’s shield to the 0v
terminal on the Wiegand Reader Input.
B. Any unused wires on the reader must be evenly snipped
and have their tips insulated using electrical tape or
equivalent. The shield wire on the reader must also be
completely insulated.
2. If you have any supervised input contacts, wire them to the Digital
Contact Inputs using Method 1 or Method 2.
3. If you have any non-supervised input contacts, wire them to the
Digital Contact Inputs.
4. If you have a relay output contact, wire it to the Relay Output.
5. Supply power to the Primis Bridge using either or both of the
following methods:
A. A 2.25 – 5.25 W Power over Ethernet (PoE) port on an
Ethernet switch connected to the Primis Bridge using a
Cat5e or Cat6 cable.
B. 12 – 16 Vdc & 350 mA (300 mA external & 50 mA
internal) DC power connected directly to the TB1 terminal
on the Primis Bridge.
6. If you are not using PoE to power your Primis Bridge, connect
a Cat5e or Cat6 cable from any port on an Ethernet switch to the
RJ- 45 connector on the Primis Bridge. Note: Ethernet only
supports a maximum cable length of 100 m.
7.
INSTALLATION PROCEDURE
To configure and add the Freedom Bridge to a Primis
Server, refer to the Primis Solution Guide manual.

INSTALLATION GUIDE
TECHNICAL DATA IS SUBJECT TO CHANGE WITHOUT NOTICE.
REVISION DATE: 2020-07-25
services address the markets for physical and logical access control, video analytics and a wide range of RFID-enabled applications.
For more information, visit identiv.com or email [e-mail].
© Identiv, Inc. | All rights reserved. This document is Identiv public information.
Wiring Reference
OPTIONAL DC POWER IN
0v DC Power Ground
+12 DC Power Input
TB1
Requirements
• 12 – 16 Vdc
• 350 mA
(300 mA external & 50 mA internal)
1
DIGITAL CONTACT INPUTS
R1 - R2 Ground
In1 - In2 Non-supervised or supervised
inputs 1 - 2
4
RELAY OUTPUT
Nc Normally closed
CCommon
No Normally open
Relay Contact DC: 30 Vdc @ 1 Adc
AC: 60 Vac @ 0.5 Aac
5
3
Press andhold this button for 10 secondsto
RESET BUTTON
This product is sensitive to Electrostatic Discharges (ESD).
Take precautions while handling the product by using proper grounding straps at all times.
CAUTION
NOTE
As long as the total current of the reader plus a door strike DOES NOT EXCEED 300mA,
you may power the door strike using the power out and ground from the reader Input terminal block.
the Primis Bridge circuit board indicates
that the bridge is powered but not
connected to a server.
A solid green “Ready” LED light indicates
that the Primis Bridge has established a
connection to the server and is ready to use.
2
WIEGAND READER INPUT
+12 Power Output
0v Ground
D1 Data 1 Input
D0 Data 0 Input
Ld LED Output
Bz Buzzer Output
Power Output
Using PoE
• 12.0 - 16.5 Vdc
• 300 mA max current
Power Output
Using DC
• 8.5 - 16.0 Vdc
• 300 mA max current
