IEI Technology AFL2-EM-RFID-KIT User manual

AFL2-EM-RFID-KIT01
Page i
User Manual
IRFD-210 RFID Reader
MODEL:
AFL2-EM-RFID-KIT
EM RFID reader, 125KHz, w/o LEDindicator, for
AFL2-W07A/08A/10A/W10A/12A/15A/W15B/17A/W19A Series ,
IEI As s embly Only, R10
Rev. 1.00 – 17 April, 2014

AFL2-EM-RFID-KIT01
Page ii
Revision
Date Version Changes
17 April, 2014 1.00 Initial release

AFL2-EM-RFID-KIT01
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

AFL2-EM-RFID-KIT01
Page iv
Table ofContents
1 INTRODUCTION.......................................................................................................... 1
1.1AFL2-EM-RFID-KIT01 OVERVIEW.......................................................................... 2
1.1.1 AFL2-EM-RFID-KIT01 Features ...................................................................... 2
1.2 TECHNICAL SPECIFICATIONS ...................................................................................... 3
2 CONNECTORS ............................................................................................................. 4
2.1AFL2-EM-RFID-KIT01 RFID READER.................................................................... 5
2.1.1 AFL2-EM-RFID-KIT01 Layout ......................................................................... 5
2.1.2 Peripheral Interface Connectors ....................................................................... 5
2.2 INTERNAL PERIPHERAL CONNECTORS........................................................................ 6
2.2.1 Antenna Connector ............................................................................................ 6
2.2.2 Buzzer Connector............................................................................................... 6
2.2.3 RS-232 and USB Connector............................................................................... 7
2.2.4 LED Indicators................................................................................................... 8
3 UNPACKING................................................................................................................. 9
3.1ANTI-STATIC PRECAUTIONS...................................................................................... 10
3.2 PACKING LIST........................................................................................................... 10
4 SOFTWARE APPLICATION..................................................................................... 12
4.1 CHAPTER OVERVIEW................................................................................................ 13
4.2 SYSTEM REQUIREMENT............................................................................................ 13
4.3 IEI IRFD-210 TOOL SUPPORT LIBRARY................................................................... 13
4.4 SOFTWARE INTERFACE............................................................................................. 13
4.4.1 Open IRFD-210 ............................................................................................... 14
4.5 EM4100................................................................................................................... 15
4.6 EM4450................................................................................................................... 16
4.6.1 Setup................................................................................................................. 16
4.6.2 Read Block....................................................................................................... 16
4.6.3 Write Block....................................................................................................... 16
4.6.4 Login................................................................................................................ 18

AFL2-EM-RFID-KIT01
Page v
4.6.5 Selective Read.................................................................................................. 18
4.6.6 Set Control Word.............................................................................................. 19
4.6.7 Read Control Word........................................................................................... 19
4.6.8 New Password.................................................................................................. 20
4.6.9 Reset Tag.......................................................................................................... 20
4.7 EM4305................................................................................................................... 21
4.7.1 Setup................................................................................................................. 21
4.7.2 Configuration................................................................................................... 21
4.7.3 Read Block....................................................................................................... 23
4.7.4 Write Block....................................................................................................... 23
4.7.5 Login................................................................................................................ 23
4.7.6 New Password.................................................................................................. 24
4.7.7 Protection......................................................................................................... 24
4.7.8 Disable............................................................................................................. 26
4.7.9 Read Tag Memory............................................................................................ 26
4.7.10 Initialize Tag Value......................................................................................... 27
A IRFD-210 TOOLLIBRARY ...................................................................................... 28
A.1 IRFD-210-API........................................................................................................ 29
B HAZARDOUS MATERIALS DISCLOSURE ......................................................... 30
B.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY....................................... 31

AFL2-EM-RFID-KIT01
Page vi
List of Figures
Figure 1-1: AFL2-EM-RFID-KIT01..................................................................................................2
Figure 2-1: Connector and Jumper Locations.............................................................................5
Figure 2-2: LED Locations (Solder Side)......................................................................................5
Figure 2-3: Buzzer Connector Location .......................................................................................6
Figure 2-4: RS-232 and USB Connector Locations.....................................................................7
Figure 4-1: Software Interface.....................................................................................................14
Figure 4-2: Open IRFD-210 ..........................................................................................................14
Figure 4-3: EM4100.......................................................................................................................15
Figure 4-4: EM4450.......................................................................................................................16
Figure 4-5: Write Block Value......................................................................................................17
Figure 4-6: Login – Enter Password...........................................................................................18
Figure 4-7: Set Control Word.......................................................................................................19
Figure 4-8: Set Password.............................................................................................................20
Figure 4-9: EM4305.......................................................................................................................21
Figure 4-10: EM4305 Configuration............................................................................................22
Figure 4-11: Login – Enter Password.........................................................................................24
Figure 4-12: Set Protection Bits..................................................................................................25
Figure 4-13: Read Tag Feature....................................................................................................26
Figure 4-14:InitializeTag Value....................................................................................................27

AFL2-EM-RFID-KIT01
Page vii
List of Tables
Table 1-1: Technical Specifications..............................................................................................3
Table 2-1: Peripheral Interface Connectors and Indicators .......................................................6
Table 2-2: Buzzer Connector Pinouts...........................................................................................7
Table 2-3: RS-232 and USB Connector Pinouts ..........................................................................7
Table 3-1: Package List Contents...............................................................................................11

AFL2-EM-RFID-KIT01
Page 1
Chapter
1
1Introduction

AFL2-EM-RFID-KIT01
Page 2
1.1 AFL2-EM-RFID-KIT01 Overview
Figure 1-1: AFL2-EM-RFID-KIT01
The AFL2-EM-RFID-KIT01 is an RFID reader for Low Frequency (LF) RFID systems and
is compliant with ISO 11784 and ISO 11785 industrial standards. The
AFL2-EM-RFID-KIT01 also comes with a utility and a software development kit (SDK) for
configuring reader module and writing/reading tags.
1.1.1 AFL2-EM-RFID-KIT01 Features
The AFL2-EM-RFID-KIT01 has the following features
125 KHz radio frequency industrial RFID reading module
Supports standard protocol ISO 11784 and ISO 11785
Supports the following EM transponders:
oEM4100
oEM4450
oEM4305
Single power supply and low power consumption
Keyboard data entry
Various interfaces to main system
o115.2 Kbps maximum serial communication speeds
oUSB

AFL2-EM-RFID-KIT01
Page 3
1.2 TechnicalSpecifications
The specifications for the Intel based embedded systems are listed below.
AFL2-EM-RFID-KIT01
Support Protocol ISO 11784, ISO 11785 (EM4305/EM4450 R/W)
RF Frequency 125 KHz
Interface RS-232 serial port or USB
UART RS-232
USB USB 2.0 full speed with 3.3 V or 5 V logic levels
RFID ASIC EM4095
Processor AT90USB162 and ATMEGA64
Power Consumption 5V @ 150 mA
Storage Temperature -10ºC ~ 70ºC
Operating Temperature 0ºC ~ 50ºC
Operating Humidity 10% ~ 85% RH
Driver Support Windows XP
Windows XPE
Table 1-1: Technical Specifications

AFL2-EM-RFID-KIT01
Page 4
2Connectors
Chapter
2

AFL2-EM-RFID-KIT01
Page 5
2.1 AFL2-EM-RFID-KIT01 RFID Reader
The following sections describe the relevant components and jumpers on the RFID reader
module.
2.1.1 AFL2-EM-RFID-KIT01 Layout
Figure 2-1 shows the on-board peripheral connectors and rear panel LEDs.
Figure 2-1: Connector and Jumper Locations
Figure 2-2: LED Locations (Solder Side)
2.1.2 PeripheralInterface Connectors
Table 2-1 shows a list of the peripheral interface connectors on the AFL2-EM-RFID-KIT01.
Detailed descriptions of these connectors can be found below.
Connector Type Label
Antenna connector 2-pin J3
Buzzer connector 2-pin J2
RS-232 and USB connector 6-pin header J4

AFL2-EM-RFID-KIT01
Page 6
Connector Type Label
Function active LED (solder side) LED D1
Power LED (solder side) LED D2
Table 2-1: Peripheral Interface Connectors and Indicators
2.2 Internal Peripheral Connectors
This section has complete descriptions of all the internal peripheral connectors on the
AFL2-EM-RFID-KIT01.
2.2.1 Antenna Connector
CN Label: J3
CN Type: 2-pin
CNLocation: See Figure 2-1
The Antenna Connector connects to the 125 KHz antenna.
2.2.2 Buzzer Connector
CN Label: J2
CN Type: 2-pin
CNLocation: See Figure 2-3
CNPinouts: See Table 2-2
The 2-pin buzzer connector is connected to a buzzer.
Figure 2-3: Buzzer Connector Location

AFL2-EM-RFID-KIT01
Page 7
Pin No. Description
1 GND
2 MIC+
Table 2-2: Buzzer Connector Pinouts
2.2.3 RS-232 and USB Connector
CN Label: J4
CN Type: 6-pin header
CNLocation: See Figure 2-4
CNPinouts: See Table 2-3
The 6-pin RS-232 and USB connector is connected to a RS-232 and USB Y cable.
Figure 2-4: RS-232 and USB Connector Locations
Pin No. Description
1 GND
2 USBDM
3 USBDP
4 +5V
5 RXD
6 TXD
Table 2-3: RS-232 and USB Connector Pinouts

AFL2-EM-RFID-KIT01
Page 8
2.2.4 LEDIndicators
CN Label: D1 and D2 (Solder Side)
CN Type: On-board LED
There are two LED indicators located on the solder side of the AFL2-EM-RFID-KIT01
module to indicate the power status and activation status.

AFL2-EM-RFID-KIT01
Page 9
3Unpacking
Chapter
3

AFL2-EM-RFID-KIT01
Page 10
3.1 Anti-static Precautions
WARNING!
Static electricity can destroy certain electronics. Make sure to follow the
ESD precautions to prevent damage to the product, and injury to the
user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the AFL2-EM-RFID-KIT01-R10. Dry climates are especially susceptible to ESD.
It is therefore critical that whenever the AFL2-EM-RFID-KIT01-R10 or any other electrical
component is handled, the following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: Touch any grounded conducting material before handling
the board. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the AFL2-EM-RFID-KIT01-R10,
place it on an antic-static pad. This reduces the possibility of ESD damaging
the AFL2-EM-RFID-KIT01-R10.
3.2 Packing Lis t
NOTE:
If any of the components listed in the checklist below are missing, do not
proceed with the installation. Contact the IEI reseller or vendor the
AFL2-EM-RFID-KIT01-R10 was purchased from or contact an IEI sales
representative directly by sending an email to [e-mail].
The AFL2-EM-RFID-KIT01-R10 is shipped with the following components:

AFL2-EM-RFID-KIT01
Page 11
Quantity Item Ima g e
1 AFL2-EM-RFID-KIT01-R10
1 Utility CD
Table 3-1: Package List Contents

AFL2-EM-RFID-KIT01
Page 12
4Software Application
Chapter
4

AFL2-EM-RFID-KIT01
Page 13
4.1 Chapter Overview
This chapter describes the use of the IRFR-210 module control program. The IRFD-210
Tools is a program providing end user interface to help the user to communicate with 125
kHz operating frequency transponders using IRFD-210.
The IRFD-210 Tools provides almost complete command set to control the IRFD-210
reader and communicate with the following EM transponders:
EM4100
EM4450
EM4305
4.2 System Requirement
IEI IRFD-210 Tools can be installed in the following OS:
Windows 2000
Windows XP
4.3 IEI IRFD-210 Tool Support Library
VC ++
Visual Base .Net
4.4 Software Interface
The IRFD-210 Tools window is shown following. There are two main functions on the tool
bar, each contains several function commands:
File
oOpen Device: open IRFD-210
oExit: exit IRFD-210 Tools
Tag Selection
oEM4100
oEM4450
oEM4305
