IEI Technology WAFER-C400EV User manual

WAFER-C400EV
User Manual
Version 1.0
Low Power Intel Mobile CPU
with SVGA, LAN, USB2.0, PC-104, SBC
March 10, 2004
©Copyright 2004 by ICP Electronics Inc. All Rights Reserved.

1
Copyright Notice
The information in this document is subjected to change without prior notice in
order to improve reliability, design and function and does not represent a
commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental,
or consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights
are reserved. No part of this manual may be reproduced by any mechanical,
electronic, or other means in any form without prior written permission of the
manufacturer.
Trademarks
WAFER-C400EV is a registered trademark of ICP Electronics Inc. IBM PC is a
registered trademark of International Business Machines Corporation. Intel is a
registered trademark of Intel Corporation. Other product names mentioned herein
are used for identification purposes only and may be trademarks and/or
registered trademarks of their respective companies.

2
Table of Contents
CHAPTER 1 INTRODUCTION.............................................................4
1.1 SPECIFICATIONS ...........................................................................5
1.2 PACKAGE CONTENTS.......................................................................6
CHAPTER 2 INSTALLATION ..............................................................7
2.1 BLOCK DIAGRAM & BOARD LAYOUT .....................................................7
2.2 UNPACKING PRECAUTIONS................................................................9
2.3 SYSTEM MEMORY DRAM .................................................................9
2.4 WATCH-DOG TIMER SETTING ............................................................9
2.5 CLEAR CMOS SETUP......................................................................9
2.6 LCD VCC VOLTAGE SELECTOR ........................................................10
2.7 SYSTEM PANEL CONNECTORS (CN9)..................................................10
CHAPTER 3 CONNECTION...............................................................11
3.1 FLOPPY DISK DRIVE CONNECTOR (FDD1) ...........................................11
3.2 PCI E-IDE DISK DRIVE CONNECTOR (IDE1).......................................12
3.3 COMPACT FLASH CONNECTOR(CN12) ................................................13
3.4 PARALLEL PORT (CN10)................................................................14
3.5 SERIAL POSTS (COM1,CN4)...........................................................15
3.6 KEYBOARD & PS/2 MOUSE CONNECTOR (CN11)...................................16
3.7 USB PORT CONNECTOR (USB1)......................................................16
3.8 IRDA INFRARED INTERFACE PORT (CN5)............................................16
3.9 VGA CONNECTOR (VGA1).............................................................17
3.10 LAN RJ45 CONNECTOR (P1,P2) .....................................................17
3.11 LCD INTERFACE CONNECTOR (CN8) .................................................18
3.12 EXTERNAL POWER CONNECTOR (CN7)................................................19
3.13 ATX POWER CONNECTOR (CN6) ......................................................19
3.14 PC/104 CONNECTION BUS (J5, J6) .................................................20
3.15 4-BIT GPIO CONNECTOR (CN1).....................................................21
3.16 FAN CONNECTOR (JFAN1) .............................................................21
3.17 AUDIO CONNECTOR (CN2).............................................................22
CHAPTER 4 AMI BIOS SETUP..........................................................23
4.1 INTRODUCTION...........................................................................23
4.2 STARTING SETUP.........................................................................23

3
4.3 USING SETUP.............................................................................24
4.4 GETTING HELP ...........................................................................24
4.5 MAIN MENU...............................................................................25
4.6 STANDARD CMOS SETUP ..............................................................27
4.7 ADVANCED CMOS SETUP ..............................................................28
4.8 ADVANCED CHIPSET SETUP.............................................................32
4.9 POWER MANAGEMENT SETUP...........................................................33
4.10 PCI / PLUG AND PLAY SETUP ..........................................................35
4.11 PERIPHERAL SETUP ......................................................................37
4.12 HARDWARE MONITOR SETUP ...........................................................38
4.13 CHANGE SUPERVISOR PASSWORD .....................................................39
APPENDIX A. WATCHDOG TIMER............................................................40
APPENDIX B. DIGITAL I/O.....................................................................42
APPENDIX C. I/O ADDRESS MAP............................................................43

4
Chapter 1 Introduction
WAFER-C400EV is designed for network applications. It supports the full functions
of an AT/ATX-compatible industrial computer on a single board. The
WAFER-C400EV is equipped with a low-power consumption and high performance
Intel Mobile processor on board. It also contains an SDRAM SODIMM socket that
support up to 512MB memory.
The WAFER-C400EV provides two Ethernet interfaces, one FDD interface, one
EIDE interface, one audio interface, one Compact Flash Type II, one parallel port,
one RS-232 serial port, one RS-232 / RS-422 / RS-485 header, one 2x25-pin LCD
header, one PC-104, two USB 2.0 ports, one 5-pin IR header, and one 6-pin
header of PS/2 keyboard/mouse interface. The built-in SVGA/LCD display
controller supports both the CRT and LCD display simultaneously. It offers the
resolutions of LCD screen up to 1024 x 768 @ 60HZ, and CRT resolutions up to
1600 x 1280 @ 64K colors. The Flash ROM contains both the system BIOS and
the VGA BIOS. Reprogramming the Flash ROM could do the modification, in case
of necessary.

5
1.1 Specifications
 CPU：Embedded Intel® Ultra Low Voltage Celeron 400MHz
 System Memory: One 144-pin SODIMM socket support up to 512 MB SDRAM
 BIOS: AMI 256 KB Flash memory
 Display Controller: VIA 8601T
 Support 24-bit TFT LCD panel resolution up to 1024x768 @ 60Hz
 Support non-interlaced CRT monitors resolutions up to 1600x1280 @ 16bit
colors
 IDE Interface: Supports two ATA100 IDE hard drives
 Compact Flash Disk: Runs in true IDE mode that is compatible with an IDE disk
drive. It can be used with a passive adapter in a Type II socket.
 FDD Interface: Supports up to two floppy disk drives, 5.25”（360KB and 1.2MB）
and/or 3.5”（720KB, 1.44MB, and 2.88MB）
 Serial Ports: Two RS-232 ports which COM2 can support RS-422/485
 Parallel Port: One parallel port supports SPP/EPP/ECP mode
 Audio Connector: One 2x8-pin header supports Line-in, Line-out, Speaker-out,
Mic-in.
 Digital IO: Supports four digital-in, and four digital-out
 IrDA: Supports Serial Infrared (SIR) or Amplitude Shift Keyed IR (ASKIR) interface
 PS/2 Mouse/Keyboard Connector: A 6-pin header connector supports PS/2
keyboard and PS/2 mouse.
 USB Interface: Two USB ports, USB 2.0 compliant
 Watchdog Timer: Can be set by 1-255 seconds period. Reset or NMI will be
generated when CPU does not periodically trigger the timer
 10/100Mbps Ethernet Controller: Two IEEE802.3 10/100M BASE-T standard Dual
auto-sensing interface to 10MBps or 100MBps networks. On board RJ-45 connectors
are provided for easy connection.
 PC-104 Interface: Supports ISA functions
 E2Key: A non-volatile 1Kbit EEPROM is provided to retain application critical
read/write data
 Power Supply: +5V: 3A typical, +12V: 0.1A
 Operating Temperature: 0-60℃
 Dimension: 5.9”（L）x 4.2”（W）（145mmx102mm）

6
1.2 Package Contents
Before any installation, please check if the following materials are included in the
package:
 One WAFER-C400EV all-in-one single board computer
 One compact disk for utility and drivers
 One 2.5" IDE flat cable (44-pin 2.0mm pitch to 40-pin 2.54mm pitch)
 One floppy cable (for 3.5" FDD only)
 One serial port cable (RS-422/485/232)
 One standard D-25 connector for parallel cable
 One 6-pin header connector for keyboard and mouse
 One audio cable
If any of these items are missing or damaged, contact your distributor or sales
representative immediately.

7
Chapter 2 Installation
This chapter gives instructions about how to set up the WAFER-C400EV hardware,
including directions of setting jumpers and connecting peripherals, switches and
indicators. Before installation, please pay attention to the unpacking precautions
on the following page for safety.
2.1 Block Diagram & Board Layout

8
 BOARD LAYOUT
 BOARD DIMENSION – SIDE VIEW
 BOARD DIMENSION

9
2.2 Unpacking Precautions
Some components of WAFER-C400EV SBC are very sensitive to static electric
charges and can be damaged by a sudden rush of power. To protect it from
unintended damage, be sure to note these precautions:
1. Ground yourself to remove any static charge before touching the
WAFER-C400EV SBC. You can do it by using a grounded wrist strap at all
times or by frequently touching any conducting materials that is connected
to the ground.
2. Handle WAFER-C400EV SBC by its edges. Don’t touch IC chips, leads or
circuitry if not necessary.
3. Do not plug any connector or jumper while the power is on.
2.3 System Memory DRAM
There is one 144-pin SO-DIMM socket to accept 3.3V non-buffered SDRAM. The
max Memory size is 512MB.
2.4 Watch-Dog Timer Setting
Reading port 443H enables the Watchdog Timer. It should be triggered before the
time-out period ends, otherwise it will assume the program operation is abnormal
and will issue a reset signal to start again. Reading port 043/843H disables the
Watchdog Timer. Please refer to Appendix A for detailed information.
2.5 Clear CMOS Setup
If the user needs to clear the CMOS setup (for example, the user forgot the
password, then the setup should be cleared and the password should be re-set).
The user should short the JP1 about 3 seconds, and then open it again. Opening
JP1 can set the system back to normal operation mode.
 JP1: Clear CMOS Setup (Reserve Function)
JP1 DESCRIPTION
1-2 Normal Operation
2-3 Clear CMOS Setup

10
2.6 LCD VCC Voltage Selector
The LCD interface connector JP2 can provide 5V or 3.3V power supply by
selecting the JP2 to meet the different LCD requirement.
 JP2: LCD VCC Voltage Selector
JP2 DESCRIPTION
1-2 5V
2-3 3.3V
2.7 System Panel Connectors (CN9)
 Pin 1-3 System power LED connector
 Pin 5-7 ATX power on button
 Pin 9-11 IDE active LED connector
 Pin 2-8 External speaker connector
 Pin 10-12 System reset connector
PIN DESCRIPTION PIN DESCRIPTION
1 VCC 2 SPEAK
3 GND 4 NC
5 GND 6 NC
7 PS_ON 8 VCC
9 VCC 10 RESET
11 HD-LED 12 GND

11
Chapter 3 Connection
This chapter describes how to connect peripherals, switches and indicators to
the WAFER-C400EV board.
3.1 Floppy Disk Drive Connector (FDD1)
WAFER-C400EV board is equipped with a 34-pin daisy-chain driver connecting
cable.
 FDD1: FDC CONNECTOR
PIN DESCRIPTION PIN DESCRIPTION
1 GROUND 2 REDUCE WRITE
3 GROUND 4 N/C
5 GROUND 6 N/C
7 GROUND 8 INDEX#
9 GROUND 10 MOTOR ENABLE A#
11 GROUND 12 DRIVE SELECT B#
13 GROUND 14 DRIVE SELECT A#
15 GROUND 16 MOTOR ENABLE B#
17 GROUND 18 DIRECTION#
19 GROUND 20 STEP#
21 GROUND 22 WRITE DATA#
23 GROUND 24 WRITE GATE#
25 GROUND 26 TRACK 0#
27 GROUND 28 WRITE PROTECT#
29 GROUND 30 READ DATA#
31 GROUND 32 SIDE 1 SELECT#
33 GROUND 34 DISK CHANGE#

12
3.2 3.2 PCI E-IDE Disk Drive Connector (IDE1)
For IDE HDD connection, the WAFER-C400EV was designed with one 2.0mm
connector (IDE1), which could be converted to two 2.54mm standard IDE
connectors via proprietary cable. Using this cable the user can attach two IDE
hard disk drives to the WAFER-C400EV.
 IDE1: 44-pin Primary Mini-pitched IDE Interface Connector
 IDE1: Primary IDE Interface Connector
PIN DESCRIPTION PIN DESCRIPTION
1 RESET# 2 GROUND
3 DATA 7 4 DATA 8
5 DATA 6 6 DATA 9
7 DATA 5 8 DATA 10
9 DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GROUND 20 N/C
21 IDE DRQ 22 GROUND
23 IOW# 24 GROUND
25 IOR# 26 GROUND
27 IDE CHRDY 28 GROUND
29 IDE DACK 30 GROUND–DEFAULT
31 INTERRUPT 32 N/C
33 SA1 34 N/C
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GROUND
41 VCC 42 VCC
43 GROUND 44 N/C

13
3.3 Compact Flash Connector(CN12)
You can attach one Compact Flash Disk to CN12 that occupies the secondary
IDE channel. The CN12 supports both the TYPE II and TYPE I module.
 CN12: Compact Flash Connector (Secondary IDE)
PIN DESCRIPTION PIN DESCRIPTION
1 GROUND 26 VCC-IN CHECK1
2 DATA 3 27 DATA 11
3 DATA 4 28 DATA 12
4 DATA 5 29 DATA 13
5 DATA 6 30 DATA 14
6 DATA 7 31 DATA 15
7 HDC_CS0# 32 HDC_CS1
8 N/C 33 N/C
9 GROUND 34 IOR#
10 N/C 35 IOW#
11 N/C 36 N/C
12 N/C 37 INTERRUPT
13 VCC_COM 38 VCC_COM
14 N/C 39 CSEL
15 N/C 40 N/C
16 N/C 41 HDD_RESET
17 N/C 42 IORDY
18 SA2 43 N/C
19 SA1 44 VCC_COM
20 SA0 45 HDD_ACTIVE#
21 DATA 0 46 N/C
22 DATA 1 47 DATA 8
23 DATA 2 48 DATA 9
24 N/C 49 DATA 10
25 VCC-IN CHECK2 50 GROUND

14
3.4 Parallel Port (CN10)
This port is usually connected to a printer. The WAFER-C400EV includes an
on-board parallel port (CN10), accessed through a 26-pin flat-cable connector.
 CN10: Parallel Port Connector
PIN DESCRIPTION PIN DESCRIPTION
1 STROBE# 2 DATA 0
3 DATA 1 4 DATA 2
5 DATA 3 6 DATA 4
7 DATA 5 8 DATA 6
9 DATA 7 10 ACKNOWLEDGE
11 BUSY 12 PAPER EMPTY
13 PRINTER SELECT 14 AUTO FORM FEED #
15 ERROR# 16 INITIALIZE
17 PRINTER SELECT LN# 18 GROUND
19 GROUND 20 GROUND
21 GROUND 22 GROUND
23 GROUND 24 N/C
25 GROUND 26

15
3.5 Serial Posts (Com1,CN4)
The WAFER-C400EV offers two high speed NS-16C-550 compatible UARTS with
Read/Receive 16 byte FIFO serial ports, and supports RS-422/485 mode from
CN4 Pin11~14 by setting J4 connector. These ports let you connect to serial
devices or a communication network. The J3 header also provides a 1A-fuesd
+5V or +12V power out from CN4 pin 8. One 9-pin D-SUB connector and one
14-pin header are also provided. The detailed pin assignment of the connectors
is specified as following tables:
 COM1: Serial Port1 Connector (9-pin D-SUB)
PIN DESCRIPTION PIN DESCRIPTION
1 DCD 2 RX
3 TX 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI
 CN4: Serial Port2 Connector (14-pin 2.0mm Header)
PIN DESCRIPTION PIN DESCRIPTION
1 DCD 2 DSR
3 RX 4 RTS
5 TX 6 CTS
7 DTR 8 RI
9 GND 10 N/C
11 TX+ 12 TX-
13 RX+ 14 RX-
 J3: Com1 Pin 9 selector (2X3-pin 2.0mm Header)
PIN DESCRIPTION PIN DESCRIPTION
1 VCC 2 RI (To I/O Buffer)
3 Connect to J3 Pin6 4 RI (To Com1)
5 +12V 6 Connect to J3 Pin9
Applications:
 For normal operation, connect Pin2-4
 For VCC supply from CN4 Pin8, connect Pin1-3 and Pin4-6
 For +12V supply from CN4 Pin8, connect Pin3-5 and Pin4-6
 J4: RS-232/RS-422/485 Selector (3-pin 2.0mm Header)
 Pin 1-2 RS-232
 Pin 2-3 RS-422/RS-485

16
3.6 Keyboard & PS/2 Mouse Connector (CN11)
A 6-pin header connector (CN11) is located on the mounting bracket for easy
connection to a keyboard and PS/2 mouse. The card comes with a Y split PS/2
cable for keyboard and mouse connection.
 CN11: 2.0mm header Keyboard & Mouse Connector
PIN DESCRIPTION
1 +5V
2 MOUSE DATA
3 MOUSE CLOCK
4 KEYBOARD DATA
5 KEYBOARD CLOCK
6 GROUND
3.7 USB Port Connector (USB1)
The WAFER-C400EV provides two USB 2.0 interfaces, which give the completed
plug and play, for up to 127 external devices.
 USB1: Internal USB Connector
PIN DESCRIPTION PIN DESCRIPTION
1 USBVCC1 1 USBVCC2
2 D1F+ 2 D2F+
3 D1F- 3 D2F-
4 USBGND1 4 USBGND2
3.8 IrDA Infrared Interface Port (CN5)
The WAFER-C400EV has a built-in IrDA port which supports Serial Infrared (SIR)
or Amplitude Shift Keyed IR (ASKIR) interface. To use the IrDA port, the system
has to be set to SIR or ASKIR model in the BIOS’s Peripheral.
 CN5: 1X5 2.0mm IrDA connector
PIN DESCRIPTION
1 VCC
2 NC
3 IRRX
4 GROUND
5 IR-TX

17
3.9 VGA Connector (VGA1)
The WAFER-C400EV has a built-in 15-pin VGA connector accepting the CRT
monitor.
 VGA1: 15-pin D-Sub Connector
PIN DESCRIPTION PIN DESCRIPTION
1 RED 9 NC
2 GREEN 10 GROUND
3 BLUE 11 NC
4 NC 12 DDCDAT
5 GROUND 13 HSYNC
6 GROUND 14 VSYNC
7 GROUND 15 DDCCLK
8 GROUND
3.10 LAN RJ45 Connector (P1,P2)
The WAFER-C400EV has two built-in RJ-45 LAN connectors for 10/100Mbps
Ethernet connection.
 P1,P2: LAN RJ-45 Connector
PIN DESCRIPTION PIN DESCRIPTION
1 TX+ 6 N/C
2 TX- 7 RX-
3 RX+ 8 N/C
4 N/C 9 N/C
 J1 : Lan1 link indicator (2-pin 2.54mm Header)
PIN DESCRIPTION
1 3VSB
2 Active
 J2 : Lan2 link indicator (2-pin 2.54mm Header)
PIN DESCRIPTION
1 3VSB
2 Active

18
3.11 LCD Interface Connector (CN8)
The WAFER-C400EV provides a 2x25-pin connector for the LCD flat panel
interface.
The TTL signal connecting interfaces locate on CN8.The display options need to be
setup manually from BIOS. The BIOS “Integrated Peripheral” Setup will allow
you to choose display resolution either 640x480 or 800x600 or 1024x768.
 CN8: LCD Interface Connector – support up to 24 bit LCD. For better
display quality, the length of LCD cable should be shorter than 35
cm.
PIN DESCRIPTION PIN DESCRIPTION
1 NC 2 NC
3 NC 4 NC
5 NC 6 NC
7 NC 8 NC
9 NC 10 NC
11 NC 12 NC
13 NC 14 RED5
15 RED7 16 RED6
17 RED0 18 RED4
19 RED1 20 RED2
21 RED3 22 GREEN6
23 GREEN5 24 GREEN4
25 GREEN7 26 GREEN3
27 BLUE7 28 GREEN2
29 LCD POWER 30 LCD POWER
31 GREEN1 32 GREEN0
33 BLUE4 34 BLUE6
35 BLUE3 36 BLUE5
37 BLUE2 38 BLUE1
39 DE 40 BLUE0
41 SFCLK 42 ENPBLT
43 ENPVDD 44 FLM
45 ENPVEE 46 LP
47 GND 48 GND
49 +12V 50 +12V

19
3.12 External Power Connector (CN7)
The WAFER-C400EV has an on-board external power connector CN7. You can
connect power directly to the CPU board.
 CN7: External Power Connector
PIN DESCRIPTION
1 +5V
2 GROUND
3 GROUND
4 +12V
3.13 ATX Power connector (CN6)
 CN6: ATX Power connector
PIN DESCRIPTION
1 5VSB
2 PSON
3 GND
