Fire Brigade Indicator Panel (FAT)
Operating Instructions
Displays and Operating Controls of the FAT
First
message
Last
message
Further messages
Power
Buzzer OFF
Test
Indication level
Common displays
Fire-Alarm
Fault
Disabled
Fire Brigade Indicator Panel
23/03 Fire
MCP First floor
127/08 Fire
Det. Attic left
Message down
Message up
Indication level
Alarm / Fault /
Disabled
Buzzer OFF / Test
The LED of the indicated level
lights up continuously.
ON : ready for operation
Flashing: internal fault
Power LED :
Keys : Common LED displays :
LCD plain-text indication :
Message level LEDs
Alarm / Fault / Disabled :
ON: Message(s) of level
shown on LCD
Flashing: Message(s) present,
to be called up with keys
Line 1-2: first / further message
Line 3-4: last message
Alarms are immediately indicated on the LCD. Faults and disabled devices are signalled by a flashing common
message LED and have to be called up with keys. The level shown on the LCD is specified by the relevant common
LED display which lights up continuously.
Common LED displays (operating status)
LED Colour Function
Power green ON: Ready for operation
Flashing: Operating voltage ON, no communication
OFF : No operating voltage, FAT in programming mode
Alarm red ON : Fire alarm(s) present and shown on LCD
Flashing: Fire alarm(s) present but not shown on LCD
OFF : No fire alarm, FAT in programming mode
Fault yellow ON : Fault message present and shown on LCD
Flashing: Fault message present but not shown on LCD
OFF : No fault message, FAT in programming mode
Disabled yellow ON : Disabled device message present and shown on LCD
Flashing: Disabled device message present but not shown on LCD
OFF : No disabled device message, FAT in programming mode
Ingenieurbüro für Applikation von Mikrocomputern GmbH , Dalbergsweg 1 , D-99084 Erfurt
IFAM
(+49-361 / 6 59 11-0 Fax. +49-361 / 6 46 21 39 ifam@ifam-erfurt.de www.ifam-erfurt.de
2/ 2FAT-Operating-Instruction_GB.doc Rev 1.5 Ja 20.01.2006
Alphanumeric display
A message on the alphanumeric display always comprises 2 lines and starts in the first line with zone and detector
numbers, which are separated by a slash.
If several messages of one level are present (alarm, fault; disabled), the upper part shows, in order of time, the first
message, and the lower part, the last message. When scrolling with the “further messages” keys, the next message
in the upper part is indicated. After 30 seconds without any actuation, the display is automatically reset to the first
and last messages.
Only messages of the alarm level are immediately shown on the LCD without any operator intervention. Messages of
the fault and disabled device levels are signalled by flashing common message LEDs and have to be called up with
the “indication level” key. The relevant LED lights up continuously to specify the selected level. If messages of the
fault or disabled device level are indicated, the display is automatically reset after 30 seconds, without any further
actuation of the FAT, to the alarm level (fire alarms present ) or to normal indication (no current fire alarms).
Indication of normal operation : (no alarm message) Indication of messages :
First
message
Last
message
FAT 2002
Company
21.02.02 12:23:56
First
message
Last
message
23/12 Fire
MCP First floor
127/8 Fire
Det. Attic left
The LCD lighting is activated every time a key is pressed or by any new event. It goes out after approximately 30
seconds. The display remains illuminated if fire alarms are present.
Acoustic signaller
The acoustic signaller (Piezo buzzer) indicates alarms. It is switched off by pressing the “Buzzer OFF / Test” key
(double function). Any new alarm message re-activates the buzzer.
Operating controls
The FAT has four keys for operation:
•Two “Further Messages“ cursor keys to scroll the messages of one indication level
•One “Level” key to change the indication level (LCD)
•One “Buzzer OFF / Test” key (hold down key for 5 seconds ðto trigger indication test)
Flashing LEDs in the keys signal that further information in the respective direction selected can be called up with this
key (e.g. scrolling the messages of one level).
The “level” key is used to change the indication level (alarm, fault, disabled). The change-over function is only active if
messages are present at the fault and / or disabled device levels.
The “Buzzer OFF /Test” key is used to acknowledge acoustic signals and to perform the indication test.
Indication test
Press the “Buzzer OFF /Test” key for more than 5seconds to perform an indication test, which lasts at least 5
seconds or as long as the key is held down. During this test, all dots of the LCD matrix are controlled, all LEDs and
the LCD lighting are switched on and the buzzer is activated.
To set the time / date
Date and time are automatically transferred from the central fire detection device (BMZ) and can be overwritten if
relevant messages are sent via the interface. Manual setting is also possible.
To enter the edit mode, press both cursor keys simultaneously with the panel in normal operation (no messages
indicated). The digit which flashes can be edited and changed with the cursor keys. Press the “indication level“ key to
select the next digit. The edited data will be overwritten if the time / date is transferred via the serial interface!
To leave the edit mode, press both cursor keys or the "indication level" key when reaching the end of the line.
