IFM Electronic efector 250 O2M20 Series User manual

UK
Operating instructions
Robust camera system with
analogue video output
O2M20x
706360 / 00 02 / 2014

2
Contents
1 Preliminary note�������������������������������������������������������������������������������������3
1�1 Symbols used ����������������������������������������������������������������������������������3
1�2 Warning signs used ������������������������������������������������������������������������� 3
2 Safety instructions ��������������������������������������������������������������������������������� 4
2�1 General��������������������������������������������������������������������������������������������4
2�2 Target group ������������������������������������������������������������������������������������4
2�3 Electrical connection������������������������������������������������������������������������ 4
2�4 Tampering with the device ��������������������������������������������������������������� 5
3 Functions and features �������������������������������������������������������������������������� 6
3�1 Features at a glance������������������������������������������������������������������������ 6
4 Installation����������������������������������������������������������������������������������������������8
4�1 Mounting accessory������������������������������������������������������������������������� 8
4�2 Mounting dimensions����������������������������������������������������������������������� 8
4�3 Installation and adjustment of the camera��������������������������������������� 9
4�4 Installation location ������������������������������������������������������������������������ 10
5 Electrical connection���������������������������������������������������������������������������� 12
5�1 Camera������������������������������������������������������������������������������������������12
5�2 Voltage supply and operational availability������������������������������������ 13
5�3 Connection and laying of cables���������������������������������������������������� 13
5�3�1 Connection to the dialogue module �������������������������������������� 14
5�4 Interference due to external influences ����������������������������������������� 16
6 Maintenance, repair and disposal�������������������������������������������������������� 17
7 Approvals/standards���������������������������������������������������������������������������� 17

3
UK
1 Preliminary note
1.1 Symbols used
►Instruction
> Reaction, result
[…] Designation of keys, buttons or indications
→Cross-reference
Important note
Non-compliance can result in malfunction or interference�
Information
Supplementary note
1.2 Warning signs used
WARNING
Warning of serious personal injury�
Death or serious irreversible injuries may result�
CAUTION
Warning of personal injury�
Slight reversible injuries may result�
NOTE
Warning of damage to property�

4
2 Safety instructions
2.1 General
These instructions are part of the device� They contain texts and figures
concerning the correct handling of the device and must be read before
installation or use�
Observe the operating instructions� Non-observance of the instructions,
operation which is not in accordance with use as prescribed below,
wrong installation or incorrect handling can seriously affect the safety of
operators and machinery�
2.2 Target group
These instructions are intended for authorised persons according to
the EMC and low-voltage directives� The device must only be installed,
connected and put into operation by a qualified electrician�
2.3 Electrical connection
Disconnect the unit externally before handling it� If necessary, also
disconnect any independently supplied output load circuits�
If the device is not supplied by the mobile on-board system (12/24
V battery operation), it must be ensured that the external voltage is
generated and supplied according to the criteria for safety extra-low
voltage (SELV) as this voltage is supplied without further measures to the
connected controller, the sensors and the actuators�
The wiring of all signals in connection with the SELV circuit of the device
must also comply with the SELV criteria (safety extra-low voltage, safe
electrical isolation from other electric circuits)�
If the supplied SELV voltage is externally grounded (SELV becomes
PELV), the responsibility lies with the user and the respective national

5
UK
installation regulations must be complied with� All statements in this
document refer to the device the SELV voltage of which is not grounded�
The connection terminals may only be supplied with the signals indicated
in the technical data and/or on the device label and only the approved
accessories of ifm electronic may be connected�
2.4 Tampering with the device
In case of malfunctions or uncertainties please contact the manufacturer�
Any tampering with the device can seriously affect the safety of operators
and machinery� This is not permitted and leads to the exclusion of any
liability and warranty claims�

6
3 Functions and features
The camera serves for monitoring of areas outside of the field of view in
mobile machines and utility vehicles� The connection and the visualisation
of the images are made via dialogue modules with graphics capabilities�
The camera works with a nested PAL25 fps 720H x 576V (active
720 x 480) video signal and permanently provides images to the
connected dialogue module�
Applications are for example:
• Rear area or blind spot monitoring for municipal vehicles
• Machine monitoring in construction machinery
• Rear view camera on vehicles
3.1 Features at a glance
Article no� Angle of aperture Angle of aperture
(integrated mirror function)
O2M200 78° -
O2M201 - 78° M
O2M202 115° -
O2M203 - 115° M
• Use and operation with process and dialogue module, e�g� CR1083
• ¼‘‘ 4:3 VGA CMOS image sensor, resolution 640H x 480V
• Lens with fixed focal length
• Light sensitivity < 0�25 lux
• Automatic exposure, automatic white adjustment
• Dynamic range > 70 dB
• Temperature-controlled lens heating

7
UK
• Resistance to materials in use for transport vehicles such as:
Medium Concentration
Ammonia 5 %
Isopropanol 5���10 %
Soap water min� 50 per cent by volume of soap
Alkaline defatting
compounds
Concentrations as found for use in high-pressure
cleaning devices
• Protection rating IP68 to IEC 60529 (10 m water depth / 30 min)
• Protection rating IP69K to DIN 40050-9
• IEC 60068-2-52 (cyclic salt spray test)
• Anodised, weather-proof aluminium housing
• Integrated protective circuitry against overvoltage or undervoltage
supply, peak voltages, ripple and load dump of the voltage supply
• Nitrogen-filled housing (1 bar pressure)

8
4 Installation
4.1 Mounting accessory
►The unit is supplied with an E2M210 universal mounting clamp�
Other mounting accessories are available as alternative
�
You can find more information about the available accessories at:
www.ifm.com→Newsearch→O2M200→Accessories
or directly
www.ifm.com→Newsearch→e.g.E2M210
4.2 Mounting dimensions
The supplied universal mounting clamp has a borehole spacing of
25 mm� Installation is effected via 2 M6 screws�
2 M6 x 20 mm screws, washers and M6 self-locking nuts are supplied
with the unit�
Dimensions of the camera, e�g� O2M200:
www.ifm.com→Newsearch→O2M200
Dimensions of the universal mounting clamp:
www.ifm.com→Newsearch→E2M210

9
UK
4.3 Installation and adjustment of the camera
Installation (example)
1� Determine a suitable installati-
onlocation(→4.4Installation
location)�
6,5
2� Bore the holes for the lower part
of the universal mounting clamp�
Borehole spacing = 25 cm�
3� Fix the lower part of the mounting
clamp with the M6 screws,
washers and self-locking nuts
supplied with the unit�
Max� tightening torque 11 Nm
(± 1 Nm)�
4� Insert the camera in the lower part
of the clamp� Fix the upper part
with the supplied M3 socket head
screws�
5� Align the camera to the area to be monitored� Fix the mounting clamp with a
max� tightening torque of 0�8���1 Nm�
6� Provide for a borehole of d = 19 mm for the cable entry in the cabin / termi-
nal chamber� Insert the camera cable and seal the cable entry with the freely
positionable rubber grommet (1)�
The minimum bending radius of the camera cable of 50 mm must be
observed�

10
4.4 Installation location
►Mount the camera in front of or above the area to be monitored�
The size of the area to be monitored depends on the operating distance:
Field of view size (2 m operating distance) O2M200 / O2M201
2
0
3,0
2,2 3
Figure 1: Operating distance and field of view size (78° angle of aperture)
1� Operating distance
[m]
2� Width of field of view
[m]
3� Height of field of view
[m]
1�0 1�5 1�1
2�0 3 2�2
5�0 7�5 5�5
The values indicated in figure 1 are theoretical values and can be diffe-
rent in the application�

11
UK
Field of view size (2 m operating distance) O2M202 / O2M203
2
0
6,0
4,4
3
Figure 2: Operating distance and field of view size (115° angle of aperture)
1� Operating distance
[m]
2� Width of field of view
[m]
3� Height of field of view
[m]
1 3 2�2
2 6�0 4�4
5 15 11
The values indicated in figure 2 are theoretical values and can be diffe-
rent in the application�
►To avoid adverse effects on the image detection, avoid installation
in heavily polluting areas of the machine (e�g� splashing water, tyre
abrasion, etc�)�

12
►Avoid installation in niches, observe the angle of aperture of the lens�
►Avoid back light�
►Do not position lighting elements directly facing the camera lens�
►Mount the device in such a way that the cables / connectors are
connected from below�
►The connected cables must be provided with a strain relief�
►Observe the minimum bending radius of 50 mm of the camera cable�
5 Electrical connection
5.1 Camera
3
4
2
1
Signal and supply voltage
M16 connector, 4 poles
3
4
2
1
1 Coax cable core
(video signal)
2 Coax screen (video GND)
3 8���32 V DC
4 0 V
Information about connection cables at:
www.ifm.com→Newsearch→e.g.O2M200→Accessories

13
UK
5.2 Voltage supply and operational availability
Power
supply Video signal Lens heating
< 6 V DC - -
> 6 V DC Yes -
> 7 V DC Yes 20 % heating power
> 8 V DC Yes 40 % heating power
12���33 V DC Yes 100 % heating power
> 33 V DC
The overvoltage protection switches the camera and the
heating element off�
When 32 V DC are no longer reached, the overvoltage protec-
tion is deactivated�
5.3 Connection and laying of cables
►Use a screened cable
www.ifm.com→Newsearch→e.g.O2M200→Accessories.
►Use screened connector housings�
►Do not lay the cable in parallel to live cables�
►Lay supply and signal cables away from the camera using the shortest
possible route�

14
5.3.1 Connection to the dialogue module
►Use adapter cables and, if necessary, connection cables�
Connection principle: O2M20x camera at the dialogue module, e�g� CR1083
Camera
4
5
Display
1 3
2 4
6 8
5 7
21
3
5
Display
1� M16 connection cable
2� M12↔M16adaptercable
3� 8���32 V *
)
4� 0 V *
)
5� GND (screen) *
)
*
)
Core colours of ifm adapter cables: 3 = RD (red); 4 = BK (black); GND = GY (grey)
You find more information about adapter or connection cables at:
www.ifm.com→Newsearch→e.g.O2M200→Accessories
Information about the integration of the camera in a CODESYS
application:www.ifm.com→Newsearch→e.g.O2M200→Operating
instructions→ShortinstructionsanaloguecameraattheCR108x
dialogue module

15
UK
Connection principle: Two O2M20x cameras at the dialogue module, e�g�
CR1083
Cameras
Display
2
1
1
5
4
3
5
Display
1 3
2 4
6 8
5 7
1� M16 connection cable
2� M12↔2xM16Yadaptercable
3� 8���32 V *
)
4� 0 V *
)
5� GND (screen) *
)
*
)
Core colours of ifm adapter cables: 3 = RD (red); 4 = BK (black); GND = GY (grey)
You find more information about adapter or connection cables at:
www.ifm.com→Newsearch→e.g.O2M200→Accessories

5.4 Interference due to external influences
Faulty or insufficient radio interference suppressors in electrical
equipment, such as inverters or generators, as well as voltage
fluctuations when switching on/off electric loads may lead to
problems with the image transmission�

17
UK
6 Maintenance, repair and disposal
Keep the lens window of the camera free from soiling�
Soiling may considerably affect the image quality!
►To clean the lens window, do not use any detergents or solvents which
might damage the front glass�
►Do not open the housing as the device does not contain any
components which can be repaired by the user� The device must only
be repaired by the manufacturer�
►Dispose of the device in accordance with the national environmental
regulations�
7 Approvals/standards
The CE declarations of conformity and approvals can be found at:
www.ifm.com→Newsearch→e.g.O2M200→Moreinformation→
Certificates

ifm weltweit • ifm worldwide • ifm à l’échelle internationale
Service hotline: 0800 16 16 16 4
(only Germany, Mon-Fri from 7�00-18�00 h)
TechnischeÄnderungenbehaltenwirunsohnevorherigeAnkündigungvor.•Wereservetherighttomaketechnical
alterationswithoutpriornotice.•Nousnousréservonsledroitdemodifierlesdonnéestechniquessanspréavis.
This manual suits for next models
4
Table of contents
Other IFM Electronic Digital Camera manuals
