IFM O2M20 Series User manual

Operating instructions
Robust camera system with
analogue video output
O2M20x
O2M21x
80292660 / 00 03 / 2020
UK

2
Content
1 Preliminary note������������������������������������������������������������������������������������� 3
1�1 Symbols used ���������������������������������������������������������������������������������� 3
1�2 Copyright and trademarks ��������������������������������������������������������������� 3
2 Safety instructions ��������������������������������������������������������������������������������� 4
3 Functions and features �������������������������������������������������������������������������� 5
3�1 Properties ����������������������������������������������������������������������������������������6
4 Items supplied����������������������������������������������������������������������������������������6
5 Accessories �������������������������������������������������������������������������������������������6
6 Installation����������������������������������������������������������������������������������������������7
6�1 Mounting dimensions����������������������������������������������������������������������� 7
6�2 Mounting and adjustment of the device������������������������������������������� 7
6�3 Installation location �������������������������������������������������������������������������� 9
7 Electrical connection���������������������������������������������������������������������������� 12
7�1 Device wiring ��������������������������������������������������������������������������������� 12
7�2 Device function at different voltages���������������������������������������������� 13
7�3 Connection with a dialogue module����������������������������������������������� 14
7�4 Connection with a monitor ������������������������������������������������������������� 16
7�4�1 Connection of 1 camera with a monitor �������������������������������� 16
7�4�2 Connection of 2 cameras with a monitor ������������������������������ 16
7�4�3 Connection of 3 cameras with a monitor ������������������������������ 17
7�4�4 Connection of 4 cameras with a monitor ������������������������������ 17
7�5 Interference due to external influences ����������������������������������������� 18
8 Maintenance, repair and disposal�������������������������������������������������������� 18
9 Approvals/standards���������������������������������������������������������������������������� 18

3
UK
1 Preliminary note
Technical data, approvals, accessories and further information at
www�ifm�com�
1.1 Symbols used
►Instruction
> Reaction, result
[…] Designation of keys, buttons or indications
→Cross-reference
Important note
Non-compliance may result in malfunction or interference�
Information
Supplementary note
1.2 Copyright and trademarks
© All rights reserved by ifm electronic gmbh� No part of these instructions
may be reproduced and used without the consent of ifm electronic gmbh�
All product names, pictures, companies or other brands used on our
pages are the property of the respective rights owners�
• CODESYS™ is the property of 3S – Smart Software Solutions GmbH,
Germany (→ www.codesys.com)

4
2 Safety instructions
• The device described is a subcomponent for integration into a system�
- The system architect is responsible for the safety of the system�
- The system architect undertakes to perform a risk assessment and
to create documentation in accordance with legal and normative
requirements to be provided to the operator and user of the system�
This documentation must contain all necessary information and
safety instructions for the operator, the user and, if applicable, for any
service personnel authorised by the architect of the system�
• Read this document before setting up the product and keep it during
the entire service life�
• The product must be suitable for the corresponding applications and
environmental conditions without any restrictions�
• Only use the product for its intended purpose (→ Functions and
features).
• If the operating instructions or the technical data are not adhered to,
personal injury and/or damage to property may occur�
• The manufacturer assumes no liability or warranty for any conse-
quences caused by tampering with the product or incorrect use by the
operator�
• Installation, electrical connection, set-up, operation and maintenance
of the product must be carried out by qualified personnel authorised by
the machine operator�
• Protect units and cables against damage�

5
UK
3 Functions and features
The camera (in the following referred to as "device") allows for the mo-
nitoring of areas of poor visibility in mobile machines and utility vehicles�
The connection and the visualisation of the images are made via dialogue
modules with graphics capabilities or monitors with analogue input�
The device works with a PAL25 fps 720H x 576V (active 720 x 480)
video signal and permanently provides images to the connected dialogue
modules (e.g. CR1083) or monitors (e.g. E2M231).
Applications are for example:
• Rear area or blind spot monitoring for municipal vehicles
• Machine monitoring in construction machinery
• Rear view camera on vehicles

6
3.1 Properties
The devices differ in their angle of aperture and mirror function�
Article no� Angle of aperture Angle of aperture
(integrated mirror function)
O2M200 80° -
O2M201 - 80° M
O2M202 118° -
O2M203 - 118° M
O2M210 170° -
O2M211 - 170° M
4 Items supplied
• O2M2xx
• E2M210 mounting set
• 2x M6 x 20 mm screws, 2x washers, 2x M6 nuts
• Operating instructions
5 Accessories
The device is supplied with the E2M210 mounting set�
Available accessories: www�ifm�com

7
UK
6 Installation
6.1 Mounting dimensions
The E2M210 mounting set has a borehole spacing of 25 mm� Installation
is effected via the 2 supplied M6 screws�
Scale drawings and technical data: www�ifm�com
6.2 Mounting and adjustment of the device
► Determine a suitable installation location (→ 6.3 Installation location).
►Bore the holes for the lower part of the E2M210 mounting set�
> Borehole spacing: 25 mm
►Fix the lower part of the mounting set with the M6 screws, washers
and self-locking nuts supplied with the unit�
> Max. tightening torque: 11 Nm (± 1 Nm)
►Place the anti-slide pad ② in the lower part�
►Place the device in the lower part of the mounting set� Fix the upper
part with the supplied M3 socket head screws�
►Align the device to the area to be monitored�
►Fix the mounting set with a max� tightening torque of 0�8���1 Nm�
►Drill a hole of d = 19 mm for the supply cable�

8
M6 x 20
∅6,5
25
55
2
1
1� Fig�: Mounting and adjustment of the device
►Lay the supply cable and seal the drill hole with the rubber grommet
①�
Observe the minimum bending radius of 50 mm of the supply
cable�

9
UK
6.3 Installation location
►Mount the device in front of or above the area to be monitored�
> The size of the area depends on the operating distance�
The values indicated in the figures are theoretical values and can
be different in the application�
Field of view size (2 m operating distance) O2M200 / O2M201
2
0
3
2� Fig.: Operating distance and field of view size (80° angle of aperture)
①Operating distance
[m]
②Width of field of view
[m]
③Height of field of
view [m]
1 1�7 1�1
2 3�4 2�3
5 8�4 5�7

10
Field of view size (2 m operating distance) O2M202 / O2M203
2
0
3
3� Fig.: Operating distance and field of view size (118° angle of aperture)
①Operating distance
[m]
②Width of field of view
[m]
③Height of field of
view [m]
1 3�3 2
2 6�7 3�9
5 16�6 9�8

11
UK
Field of view size (2 m operating distance) O2M210 / O2M211
2
0
3
4� Fig.: Operating distance and field of view size (170° angle of aperture)
①Operating distance
[m]
②Width of field of view
[m]
③Height of field of
view [m]
1 22�9 3�3
2 45�7 6�5
5 114�3 16�3
►Do not mount the device in heavily polluting areas�
> Splashing water, tyre abrasion etc� will have adverse effects on the
image detection�
►Avoid installation in niches�
►Observe the angle of aperture of the lens�
►Avoid strong back light�
►Do not position illumination elements directly facing the camera lens�
►Mount the device with the supply cable coming from below�
►Provide all cables with a strain relief�
►Observe the minimum bending radius of 50 mm of the supply cable�

12
7 Electrical connection
The unit must be connected by a qualified electrician�
Voltage supply according to EN 50178, SELV, PELV�
►Use a screened cable
►Use screened connector housings�
►Do not lay the cable in parallel to live cables�
►Lay supply and signal cables away from the device using the shortest
possible route�
7.1 Device wiring
3
4
2
1
Signal and supply voltage
M16 connector, 4 poles
3
4
2
1
1Coax cable core (video signal)
2Coax screen (video GND)
3 8���32 V DC
4 0 V

13
UK
7.2 Device function at different voltages
Voltage Video signal Lens heating
< 6 V DC - -
> 6 V DC Yes -
> 7 V DC Yes 20 % heating power
> 8 V DC Yes 40 % heating power
12��33 V DC Yes 100 % heating power
> 33 V DC
The overvoltage protection switches the device and the heating
element off�When 32 V DC are no longer reached, the overvol-
tage protection is deactivated�

14
7.3 Connection with a dialogue module
►Use adapter cables and, if necessary, connection cables�
The integration of the device into a CODESYS application is de-
scribed in separate instructions� These instructions are available
in the download area of the O2Mxx: www�ifm�com
Camera
4
5
Display
1 3
2 4
6 8
5 7
21
3
5
Display
5� Fig�: O2M2xx connected with a CR1083 dialogue module
①M16 connection cable
② Adapter cable M12 connector ↔ M16 coupling
③ 8���32 V *
)
④ 0 V *
)
⑤ GND (screen) *
)
*
)
Core colours of ifm adapter cables: 3 = RD (red); 4 = BK (black); GND = GY (grey)

15
UK
Cameras
Display
2
1
1
5
4
3
5
Display
1 3
2 4
6 8
5 7
6� Fig�: 2x O2M2xx connected with a CR1083 dialogue module
①M16 connection cable
② Adapter cable M12 connector ↔ M16 coupling
③ 8���32 V *
)
④ 0 V *
)
⑤ GND (screen) *
)
*
)
Core colours of ifm adapter cables: 3 = RD (red); 4 = BK (black); GND = GY (grey)

7.4 Connection with a monitor
7.4.1 Connection of 1 camera with a monitor
1 32
Connection of 1 O2M200 analogue camera with an E2M231 monitor
①E3M231 monitor
②E2M203 connection cable, 5 m
③ O2M200 analogue camera
7.4.2 Connection of 2 cameras with a monitor
1 2 43
Connection of 2 O2M200 analogue cameras with an E2M231 monitor
①E3M231 monitor
②E2M235 video switcher, 3 ports
③ E2M203 connection cable, 5 m
④ O2M200 analogue camera

17
UK
7.4.3 Connection of 3 cameras with a monitor
1 2 3 4
Connection of 3 O2M200 analogue cameras with an E2M231 monitor
①E3M231 monitor
②E2M235 video switcher, 3 ports
③ E2M203 connection cable, 5 m
④ O2M200 analogue camera
7.4.4 Connection of 4 cameras with a monitor
1 2 43
Connection of 4 O2M200 analogue cameras with an E2M232 monitor
①E3M232 monitor
②E2M235 video switcher, 3 ports
③ E2M203 connection cable, 5 m
④ O2M200 analogue camera

18
7.5 Interference due to external influences
Image transmission may be disturbed by
• faulty or insufficient radio interference suppressors in other
electrical equipment (inverters or generators),
• voltage fluctuations when switching on/off high electrical
loads�
8 Maintenance, repair and disposal
Keep the front lens of the device clean. Soiling may considerably
affect the image quality!
►To clean the lens window, do not use any detergents or solvents which
might damage the front glass�
►Do not open the housing of the device� The device does not contain any
components that need to be maintained by the user� The device must only
be repaired by the manufacturer�
►Dispose of the device in accordance with the national environmental
regulations�
9 Approvals/standards
The EU Declaration of Conformity is available at www�ifm�com�
This manual suits for next models
7
Table of contents
Other IFM Digital Camera manuals
