IFM M03933 User manual

Operating instructions
2D/3D camera head
M03933
M03969
M03976
O3R222
O3R225
O3R252
11400774 / 0005 / 2021
GB

M03933 M03969 M03976 O3R222 O3R225 O3R252 2D/3D camera head
2
Contents
1 Preliminary note ............................................................. 3
1.1 Symbols used.......................................................... 3
1.2 Warnings used ......................................................... 3
1.3 Safety symbols on the unit ................................................ 3
1.4 Legal and copyright information ............................................ 3
1.5 Open source information.................................................. 4
2 Safety instructions............................................................ 5
2.1 Invisible laser light....................................................... 5
2.2 Cyber security.......................................................... 5
3 Intended use................................................................ 6
3.1 Application area ........................................................ 6
4 Installation.................................................................. 7
4.1 Preparing the set-up..................................................... 7
5 Electrical connection.......................................................... 9
5.1 Wiring................................................................ 10
6 Scale drawings.............................................................. 11
6.1 O3R222 / O3R252 / M03933 / M03976 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.2 O3R225 / M03969....................................................... 12
7 Maintenance, repair and disposal................................................ 13
8 Approvals/standards.......................................................... 14

2D/3D camera head M03933 M03969 M03976 O3R222 O3R225 O3R252
3
1 Preliminary note
You will find instructions, technical data, approvals and further information using the QR code on the
unit / packaging or at www.ifm.com.
1.1 Symbols used
Requirement
Instructions
Reaction, result
[...] Designation of keys, buttons or indications
Cross-reference
Important note
Non-compliance may result in malfunction or interference.
Information
Supplementary note
1.2 Warnings used
ATTENTION
Warning of damage to property
CAUTION
Warning of personal injury
wSlight reversible injuries may result.
1.3 Safety symbols on the unit
Electric supply must correspond to IEC61010-1, chapter 9.4 - Limited-energy circuit.
Device of protection class III. Only for operation in PELV circuits. (Ò Electrical connection/9)
Laser class 1 device. (Ò Invisible laser light/5)
1.4 Legal and copyright information
© All rights reserved by ifm electronic gmbh. No part of these instructions may be reproduced and
used without the consent of ifm electronic gmbh.
All product names, pictures, companies or other brands used on our pages are the property of the
respective rights owners.

M03933 M03969 M03976 O3R222 O3R225 O3R252 2D/3D camera head
4
1.5 Open source information
This product can contain Free Software or Open Source Software from various software developers
which is subject to the following licenses: General Public License version 1, version 2 and version 3
(General Public License version 3 in conjunction with the GNU Compiler Collection Runtime Library
Exception version 3.1), Lesser General Public License version 2.1, Lesser General Public License
version 3, Berkeley Software Distribution (BSD-2-Clause, BSD-3-Clause, BSD-4-Clause), MIT-License
(MIT), Python Software Foundation License 2.0, Pearl Artistic License and Artistic License 2.0,
Microsoft Public License, Apache Software License Version 1.0, 1.1 und 2.0, ISC License, libpng
License, zlib Licence, the Academic Free License version 2.1. For the components subject to the
General Public License in their respective versions the following applies:
This program is free software: you can redistribute it and/or modify it under the terms of the GNU
General Public License as published by the Free Software Foundation. If version 1 applies to the
software: either version 1 of the License or (at your option) any later version; if version 2 (or 2.1)
applies to the software: either version 2 (or 2.1) of the License or (at your option) any later version; if
version 3 applies to the software: either version 3 of the License or (at your option) any later version.
The following disclaimer of the software developers applies to the software components that are
subject to the General Public License or the implied warranty of MERCHANTABILITY or FITNESS
FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General
Public License for more details.
The responsibility of ifm electronic gmbh for ifm products, in the case of product-specific software,
remains unaffected by the above disclaimer. Please note that the firmware for the ifm products is in
some cases provided free of charge.
The price of the ifm products has then to be paid for the respective device itself (hardware) and not for
the firmware. For the latest information on the license agreement for your product please visit
www.ifm.com
For binaries that are licensed under any version of the GNU General Public License (GPL) or the GNU
LGPL you may obtain the complete corresponding source code of the GPL software from us by
sending a written request to: [email protected] or to ifm electronic gmbh, Friedrichstraße 1, 45128
Essen, Germany.
We charge €30 for each request. Please write “source for product Y” in the memo line of your
payment. Your request should include (i) the name of the covered binary, (ii) the name and the version
number of the ifm product, (iii) your name and (iv) your return address.
This offer is valid to anyone in receipt of this information. This offer is valid for at least three years
(from the date you received the GPL/LGPL covered code).

2D/3D camera head M03933 M03969 M03976 O3R222 O3R225 O3R252
5
2 Safety instructions
• The unit described is a subcomponent for integration into a system.
– The system architect is responsible for the safety of the system.
– The system architect undertakes to perform a risk assessment and to create documentation in
accordance with legal and normative requirements to be provided to the operator and user of
the system. This documentation must contain all necessary information and safety instructions
for the operator, the user and, if applicable, for any service personnel authorised by the
architect of the system.
• Read this document before setting up the product and keep it during the entire service life.
• The product must be suitable for the corresponding applications and environmental conditions
without any restrictions.
• Only use the product for its intended purpose (Ò Intended use).
• If the operating instructions or the technical data are not adhered to, personal injury and/or damage
to property may occur.
• The manufacturer assumes no liability or warranty for any consequences caused by tampering with
the product or incorrect use by the operator.
• Installation, electrical connection, set-up, operation and maintenance of the product must be
carried out by qualified personnel authorised by the machine operator.
• Protect units and cables against damage.
2.1 Invisible laser light
CAUTION
Invisible laser light; LASER CLASS 1.
EN/IEC 60825-1:2007 and EN/IEC 60825-1:2014
comply with 21 CFR Part 1040 except for deviations pursuant to Laser Notice No. 50, dated
June 2007.
2.2 Cyber security
ATTENTION
Unprotected network environment:
The unit does not include IT security measures according to IEC 62443.
wUnauthorised read or write access to data is possible.
wUnauthorised manipulation of the device function is possible.
uCheck and restrict access options to the device.

M03933 M03969 M03976 O3R222 O3R225 O3R252 2D/3D camera head
6
3 Intended use
The unit features a TOF (Time Of Flight) camera and, additionally, an RGB camera.
The TOF camera measures the distance between the camera and the object for each pixel by means
of the time-of-flight principle. For this purpose, the objects are illuminated with the internal infrared light
source.
The RGB camera uses ambient light to capture a colour image of the objects. The infrared light of the
TOF camera is not visible to the RGB camera.
The image processing system OVPxxx is additionally required to use the unit.
3.1 Application area
The device safety is rated for use under the following operating conditions according to EN IEC
61010-2-201:
• indoor use
• altitudes up to 4000 m
• relative air humidity up to max. 90%, non condensing
• pollution degree 2
Electromagnetic compatibility (EMC):
The unit is designed for use in industrial environments.
This product may cause radio interference in domestic areas.
uIf required, take appropriate EMC screening measures.
The IP rating has not been evaluated by UL® Underwriters Laboratories®.

2D/3D camera head M03933 M03969 M03976 O3R222 O3R225 O3R252
7
4 Installation
1
23 3
Fig.1: Installation of the device
1 Unit 2 Field of view of the device
3 Area adjacent to the field of view
Mounting the unit:
uDo not place any objects in area (3).
wThis avoids disturbing contours and possible measurement errors.
uAvoid transparent panes in the viewing area of the unit (2).
wEven a very clean glass plate reflects some of the light. This means that measurement errors
are possible.
uUse strain reliefs for all cables connected to the device.
uConnect the housing of the device and the OVP8xx image processing system to the same earth.
wIf no connection to the same earth is possible: mount both units isolated from the earth.
uAvoid installation in heavily polluted environments.
uConsider the installation tolerances when selecting an installation location.
Measurement errors when using the unit
uFollow the instructions.
wIf the instructions are ignored, measurement errors are possible when using the unit.
4.1 Preparing the set-up
ATTENTION
The device can heat up depending on the operating mode, the set parameters and the heat
dissipation to the environment.
The difference between the device's surface temperature and the ambient temperature
must not exceed 25 degrees (according to IEC61010-2-201).
uReduce the surface temperature.
uAdapt operating mode and parameters.
uUse a contact protection for the device.

M03933 M03969 M03976 O3R222 O3R225 O3R252 2D/3D camera head
8
Reducing the surface temperature
To reduce the surface temperature of the device:
uMount the device on heat-conductive metal parts.
wA large-surface contact of the device with metal parts increases heat dissipation (e.g. conventional
aluminium heat sinks or profiles).
uReduce obstructions around the device. Reduce the density of objects mounted near the device.
wObstructions around the device and a high installation density may have a negative impact on
convection (air movement).

2D/3D camera head M03933 M03969 M03976 O3R222 O3R225 O3R252
9
5 Electrical connection
ATTENTION
The unit must be connected by a qualified electrician.
Protection class III (PC III) unit (IEC 61010-2-201 chap. 6.5.2.101.4).
The electrical supply must
- be provided only by PELV circuits (IEC 61010-2-201 chap. 3.111),
- not exceed 35 V DC during operation,
- not exceed 60 V DC in the event of a single fault and
- not exceed the permitted operating voltage of the unit (see data sheet).
Use energy-limited circuits for the electrical supply (IEC 61010-1 chap. 9.4). The energy of
the circuit can be limited at an operating voltage of 24 V by an overcurrent protection
device. The overcurrent protection device must switch off a current of 8.3A in maximum
120s. Observe the specific tripping characteristic. Possible overcurrent protection devices:
- fuse or
- non-adjustable and non-self-reclosing electromechanical device.
Separate the circuit from other, non-energy-limited circuits by at least basic insulation. The
separation of external circuits must comply with IEC61010-2-201, Figure 102.
uDisconnect power before connecting the unit.
uUse a maximum cable length of 20 m for the coaxial lines to the sensor ports.
wLonger coaxial cables will dampen the signal too much.
ATTENTION
Units damaged due to overload
wA camera head has 2 connections. If both connections are connected to different image
processing systems at the same time, an overload will occur. This will damage the units.
uConnect a camera head to only one vision system.
When the camera head is connected to an image processing system:
uObserve the operating instructions of the vision system.
Observe when connecting the unit:
uUse strain reliefs for cables connected to the unit.

M03933 M03969 M03976 O3R222 O3R225 O3R252 2D/3D camera head
10
5.1 Wiring
1 2
Fig.2: Wiring
1 TOF camera (coaxial connection) 2 RGB camera (coaxial connection)

2D/3D camera head M03933 M03969 M03976 O3R222 O3R225 O3R252
11
6 Scale drawings
6.1 O3R222 / O3R252 / M03933 / M03976
45
90
29
123
18,7 7,715
15,4
31
1
2
8
°
6
0
°
6
0
°
26
4
5
°
4
5
°
8
0
°
41,741,7
12,2
M3
Fig.3: Scale drawing
1 RGB camera 2 TOF camera
3 Illumination unit

M03933 M03969 M03976 O3R222 O3R225 O3R252 2D/3D camera head
12
6.2 O3R225 / M03969
45
90
29
123
18,7 7,715
15,4
31
1
1
0
°
1
2
8
°
1
0
5
°
26
9
0
°
7
8
°
8
0
°
41,741,7
12,2
M3
Fig.4: Scale drawing
1 RGB camera 2 TOF camera
3 Illumination unit

2D/3D camera head M03933 M03969 M03976 O3R222 O3R225 O3R252
13
7 Maintenance, repair and disposal
Maintenance
If used correctly, the unit is maintenance-free.
Soiling reduces the contrast and the recognition performance.
uKeep the front lens free from soiling.
uUse glass cleaner for cleaning.
Cleaning agents containing solvents and silicone may damage the unit.
uOnly use cleaning agents without solvents and silicone.
Repair
Only the manufacturer is allowed to repair the unit.
Disposal
uAfter use dispose of the unit in an environmentally friendly way in accordance with the applicable
national regulations.

M03933 M03969 M03976 O3R222 O3R225 O3R252 2D/3D camera head
14
8 Approvals/standards
For approvals and standards, the following information is available:
• Test standards and regulations: documentation.ifm.com
• EU declaration of conformity and approvals: documentation.ifm.com
• Notes relevant for approval: package inserts of the device
This manual suits for next models
5
Table of contents
Other IFM Digital Camera manuals
